基于并聯開關的低電壓低功耗電流型CMOS電路設計
Design of Low Voltage Low Power Current-Mode CMOS Circuits Based on Parallel Switches
-
摘要: 該文提出了一種電流型CMOS電路的并聯開關結構，使得電流型CMOS電路能在較低的電源電壓下工作，因而可以實現電路的低功耗設計，同時在相同的電源電壓下，采用并聯開關結構的電路比相應的串聯開關電路具有更快的速度，PSPICE模擬證明了采用并聯開關結構設計的電路能在較低的電源電壓下工作，并具有較小的電路延時。
-
關鍵詞:
- 電流型CMOS電路; 閾運算; 并聯開關; 多值邏輯
Abstract: A novel current-mode CMOS parallel structure is proposed. This parallel switch structure allows current-mode CMOS circuits to perform under lower source voltage which makes low power consuming possible. Beside, the current-mode circuits based on the pro-posed parallel structure have smaller propagation delay time than its counterpart which use cascade switches under the same source voltage. PSPICE simulation proves that circuits designed with the proposed structure can perform under low source voltage while holding short propagation delay time. -
Rabaey J M,Pedram M.Low Power Design Methodologies.Boston:Klumer Academic Press,1996:1-16.[2]Chandrakasan A P,Sheng S,Brodersen R W.Low power CMOS digital design[J].IEEE J.of Solid-State Circuits.1992,27(4):473-484[3]Small C.Shrinking devices put the squeeze on system packaging.EDN,1994,39(4):41-46.[4]Mead C,Conway L.Introduction to VLSI System.New York:Addison-Wesley Publishing Company,1980:1-8.[5]Masayuki Mizuno,Masakazu Yamashina,Koichiro Furuta.A GHz MOS adaptive pipeline technique using MOS current-mode logic[J].IEEE J.of Solid-State Circuits.1996,31(6):784-791[6]Wayne Current K.Current-mode CMOS multiple-valued logic circuits[J].IEEE J.of Solid-State Circuits.1994,29(2):95-107[7]吳訓威,應時彥.基于開關信號理論的三值電流型CMOS電路設計.電子科學學刊,1993,15(2):113-120.[8]吳訓威,Prosser F.數字電路的開關級設計理論.中國科學(E輯),1996,26(3):257-265.[9]Yeo K S,Lee H K.Novel 1V full-swing high-speed BiCMOS circuit using positive feedback baseboost technique.IEE Proc.-Circuits Devices Syst.,1999,146(3):129-134. -
