有耗介質覆蓋平面導體表面波傳播特性的計算
PROPAGATION PROPERTY OF THE SURFACE WAVE ON CONDUCTOR-BACKED LOSSY DIELECTRIC PLANE
-
摘要: 本文推導了圓柱坐標系下有耗介質涂覆平面導體表面波的場函數和本征方程、每波長徑向衰減常數;分析了介質特性參數、介質層厚度與的關系;指出磁損耗介質比電損耗介質有更好的抑制表面波的效果。
-
關鍵詞:
- 有耗介質; 表面波; 徑向衰減常數
Abstract: The eignvalue equation, the attenuation constant a and the field distribution function of the surface wave(SW) in a conductor-backed lossy dielectric layer are derived. The relationship between the a and the parameters of the dielectric material is described. It was found that the magnetic-loss material showed better performance than the electric-loss material in attenuating the SW. -
Barlow M, Cullen A L. Proc. IEE, part Ⅲ, 1953, 100: 321.[2]饒克謹,等.吸收表面波的薄涂層材料的性質.吸收劑評價方法專題研討會,北京,1991.[3]Collin R E著,侯元慶澤.導波場論.上?？茖W(xué)技術出版社,1966年,446-450.[4]時振棟,等.有耗介質涂覆導體平面上的表而波分析.1991年全國微波會議論文集,西安,1991,244-248.[5]克拉特 F,等著,阮穎錚,等譯.雷達散射截面.北京:電子工業出版社,1988,263. -
