金屬截錐柱側天線輻射場的研究
STUDY ON RADIATION FIELD OF ANTENNAS ON THE TRUNCATED CONE-CYLINDER
-
摘要: 根據實測的單元天線方向圖,利用幾何繞射理論,給出了金屬截錐柱側天線三維輻射場的一種有效的數值分析方法。這些公式同樣適用于金屬截柱或截錐。應用上述公式計算了截錐側微帶天線及其排陣的任意平面方向圖,并與實測結果進行了比較,兩者吻合良好。Abstract: On the basis of the experimental element pattern and GTD, an efficient numerical method for analyzing 3-D radiation field of antennas on the truncated cone-cylinder is presented. These formulas are also applicable to the truncated cylinder and cone. Examples are given on the calculation of 3-D radiation fields of microstrip antennas on the truncated cone. The results of calculations agree well with the experimental ones.
-
劉其中,宮德明,馬澄波.電子學報,1990,18(5). 40-46.[2]劉其中,張野,王輝寧.電子學報,1992,20(9):93-95.[3]Pathak P H, Wang N. IEEE Trans. on AP, 1981, AP-29(4):609-622.[4]汪茂光.幾何繞射理論.西安:西北電訊工程學院出版社,1985,60-93.[5][5][6]劉其中,馬澄波,宮德明.西安電子科技大學學報,1991,18(3):45-53. -
