高速集成傳輸線不連續性的全波分析
FULL-WAVE ANALYSIS OF THE HIGH-SPEED INTEGRATED TRANSMISSION LINE DISCONTINUITIES
-
摘要: 本文通過多項式近似導出了一種可變網格的時域有限差分算法,其空間網格的大小能沿任意軸向變化,而且具有高階離散精度,從而節省了機時,提高了計算精度。并首次應用于高速集成傳輸線變角度拐角的全波分析。本方法簡化了以往方法的分析過程,其結果與有關文獻相一致,從而驗證了算法的可靠性和有效性。
-
關鍵詞:
- 傳輸線; 高速集成傳輸線; 全波分析; 時域有限差分法
Abstract: A new time domain finite difference method with variable grids of high accuracy is derived by the polynomial approximation, and applied to analyze the variable-angle transmission line discontinuities. The method has the advantages of comparatively less memory space and CPU time, and is much simpler than other techniques. Test results are in good agreement with published data, thereby the accuracy of the new method is verified. -
Palusinki D A, et al. IEEE Trans. on CHMT, 1990, CHMT-13(2): 160-166.[2]Gao D S, et al. IEEE Trans. on CAS, 1990, CAS-37(1):1-9.[3]Schutt-Aine J E, Mittra R. IEEE Trans. on MTT, 1988, MTT-36(3): 529-536.[4]Jun-Fa Mao, Zheng-Fan Li. IEEE Trans. an MTT, 1992, MTT-40(5):948-955.[5]李征帆.電子學報,1992,20(5): 67-72.[6]Mur G. IEEE Trans. on EMC, 1981, EMC-23(11): 377-382.[7]Moore J. Hao Ling, IEEE Trans. on MTT, 1990, MTT-38(4): 405-409.[8]Yee K S. IEEE Trans. on AP, 1966,AP-14(5): 302-307.[9]王秉中.電子科學學刊,1993,15(4): 337-341. -
