降低電纜內導線間串?dāng)_電壓的優化方法
THE OPTIMIZATION METHOD FOR REDUCING CROSSTALK IN MULTI-CONDUCTOR CABLE
-
摘要: 本文根據分布參數傳輸線理論導出了電纜內平行多導線間串?dāng)_電壓的傳遞函數矩陣表達式;構造了導線同串?dāng)_電壓最小的優化目標函數;利用可變多面體算法進行了優化設計;根據計算結果提出了降低申擾電壓的新方法。計算結果與已有的實驗結果吻合。
-
關鍵詞:
- 電纜; 電磁干擾; 傳輸線理論; 優化
Abstract: Based on transmission line theory, the voltage transfer ratio function matrixes are derived for the multi-conductor cable system. Then an optimising object function for reducing crosstalk in the multi-conductor cable is established. The nonlinear programming is applied to optimize the terminal impedance load. According to the optimization results, a new method for reducing crosstalk is presented. Theoretical results are in good agreement with experimental ones. -
Paul C R. IEEE Trans. on EMC, 1978, EMC-20(1): 216-222.[2]Paul C R. IEEE Trans. on EMC, 1982, EMC-24(3): 335-343.[3]Paul C R. IEEE Trans. on EMC, 1992, EMC-34(3): 315-319.[4]Olsen R G. IEEE Trans. on EMC, 1984, EMC-26(2):79-83.[5]Kami Y, Sato R. IEEE Trans. on EMC, 1986, EMC-28(4):204-209.[6]Paul C R. Sensitivity of Crosstalk to Variations in Wire Position in Cable Bundles. IEEE International Electromagnetic Compatibility Symposium Record. Atlanta, Georgia, USA: 1987.459-463. -
