具有兩節濾波器的速調管寬帶輸出段的設計方法
DESIGN CONSIDERATIONS OF THE TWO-STAGE-FILTER TYPE OUTPUT CIRCUIT OF BROADBAND KLYSTRONS
-
摘要: 本文從等效電路和微波網絡理論出發,提出了具有兩節濾波器的速調管寬帶輸出段的設計方法,根據該方法,在給定的阻抗實部R*下,可求得頻寬最寬的一組設計參數。實驗證明該方法是可行的。
-
關鍵詞:
Abstract: In this paper, from the microwave network equivalent circuit point of view, we propose a design method of output circuit of broadband klystron which is made of two stage filters. According to this method, we can get a group of design parameters corresponding to the broadest bandwidth with given real part of interaction impedance. It is proved experimentally that this method is feasible. -
電子管設計手冊編委會編,大功率速調管設計手冊,國防工業出版社,1979年9月. -
