介質片上的金屬條帶交指型電容的三維分析
ANALYSIS OF CONDUCTING STRIP INTERDIGITAL CAPACITANCE ON A DIELECTRIC SUBSTRATE WITH MOMENT METHOD
-
摘要: 本文運用矩量法計算介質片上的金屬條帶交指型電容的電容量,給出了理論公式。這一分析可以很好地考慮指線末端的邊緣效應和介質片厚度的影響。實際計算表明,本文的方法是正確和有效的。
-
關鍵詞:
- 交指型電容器; 三維分析; 矩量法
Abstract: The conducting strip interdigital capacitance on a dielectric substrate is analyzed with the moment method. The theoretical formulas are given. A number of illustrative examples are numerically calculated, which shew the correctness and the effectiveness of the method presented here. -
L. Yong et al., Advance in Microwave, Vol.8, Academic Press. New York, (1974), pp, 165-172.[2]G. D. Alley, IEEE Trans. on MTT, MTT-18 (1970) 12, 1028-1033.[3]秦廷楷,通信學報,7(1986)1,60-67.[4]R. F. 哈林登著,孟侃譯,正弦電磁場,上海科學技術出版社,1964年1月第一版,第156-167頁. -
