用VOLTERRA 級數精確分析 MESFET 功率放大器的副諧波負載牽引特性
ANALYSIS OF THE SUBHARMONIC LOAD PULL CHARACTERISTIC OF THE MESFET POWER AMPLIFIER PRECISELY WITH THE VOLTERRA SERIES METHOD
-
摘要: 為了分析CDMA類寬帶信號激勵下MESFET功放的副諧波負載牽引特性,推導了一組基于MESFET非線性模型的功放電路Volterra轉移函數解析式,利用此解析式,建立了三階交調分量與副諧波負載的解析關系,分析了不同副諧波負載情況下副諧波牽引特性;并推導出了最優副諧波負載的表達式。該文還從兩個三階交調幅度的差異著手,證明了電抗性副諧波負載是造成這一差異的主要因素,上述推導得到的結果與采用ADS軟件諧波平衡法仿真得到的結果吻合得很好。Abstract: In order to analyze the subharmonic load pull characteristic of MESFET power amplifier driven by CDMA type wide band signal, a set of Volterra transfer funcion expressions are deducted with the MESFET nonlinear model. With these expressions, the relation between the IM3 (third order intermodulation) and the subharmonic impedance is established, and the characteristic of the subharmonic load pull is analyzed. the expression of the optimal subharmonic load is also given with the analysis. It is proved in the paper that the reactance part of the subharmonic impedance is the main factor that leads to the difference of the two IM3. The result of the analysis agrees well with the simulation result got from ADS with harmonic balance method.
-
Xinwei. Wang. et al., A low quiescent current, 40% efficiency three-stage PHEMT power amplifier MMIC for PCS CDMA application, RFIC99, Anaheim, CA, USA, .]une 13 15. 1999. 121-121.[2]J.Staudinger. The importance of sub-harmonic frequency termination in modeling spectral regrowth from CW Am-Am Am-Pm derived nonlinearities, Annual Wireless Communication Conference. Boulder, CA, USA, Aug. 11-13, 1997, 121-125.[3]J. S. Kenney, et al., Power amplifier spectral regrowth for digital cellular and PCS applicatiions.Microwave Journal, 1995, 38(10), 74-92.[4]J.F. Sevic, K. L. Burger, M. B. Steer, A novel envelope-termination load pull method for ACPR optimization of RF/Microwave power amplifiers, 1998 IEEE MTT-S Digest, .June 7-12, 1998.Balimore, BD, USA, 723-726.[5]Wang Xinwei, et al., ACPR, IM3 and their correlation for a PCS CDMA power amplifier, .50th ARFTG Conference Digest, Benson Hotel, Portland, OR, 1997, 91-96.[6]洪興楠,張向東,用Volterra級數展開表示法分析砷化鎵場效應管交調失真,全國微波會議,西安,1985,132-152[7]S.A. Mass. Nonlinear Microwave Circuits, chapter 5, Norword, MA, Artech House 1988. -
