七級偏轉象差中的Trilemma效應
THE TRILEMMA EFFECT IN SEVENTH-ORDER DEFLECTION ABERRATION
-
摘要: Trilemma效應是偏轉系統實現自會聚的一個重要判據,對高級偏轉象差的校正,需要考慮高階Trilemma效應的影響,本文從多極場偏轉象差校正理論出發,應用區域分割的方法,對直至七階的Trilemma效應進行了分析,給出了各階Trilemma常數的表達式,其中七階Trilemma常數可以作為大偏轉角偏轉象差校正的判據。Abstract: Trilemma effect is an important criteria for the self-convergence deflection system. The influence of the higher order Trilemma effects should be taken into account for the correction of the higher-order deflection aberrations. In this paper, up to the seventh-order Trilemma effects are analyzed with region-cutting by means of the correction theory of the multipole field deflection aberration. The expressions of the various order of Trilemma constant are given, in which the seventh-order Trilemma constant can be used as a criteria of the deflection aberration correction at large deflection angle
-
Ando K, Hirota R, Akatsu M, Maruyama K. New selfconvergence yoke and picture tube system with 110 in-line feature. IEEE Trans. on CE. 1977, CE-23(3): 375-382.[2]Dasgupta B B. Is the Dilemma rule useful for designing deflection yoke used in color picture tubes?. Proc. SID, 1984, 25(2): 99-104.[3]丁守謙.磁偏轉線圈設計理論基礎.北京:國防工業出版社,1994,137-140.[4]Seyno Sluyterman A A. Fifth-order Trilemma in deflection yoke design. Proc. SID. 1987, 28(1):[5]9-13.[6]張曉兵,等.偏轉象差中束夾角的高次方項研究.真空科學與技術學報,1996, 16(4): 257-262.[7]Heijnemans W A L. The deflection coils of the 30AX colour-picture system. Philps Tech. Rev, 1979, 39(6/7): 154-171.[8]張曉兵,等.大偏轉角偏轉象差的分析與校正.東南大學學報,1996,26(3):19-23.[9]張曉兵,等.七級偏轉象差的多極場分析與校正.真空科學與技術學報,1996,16(2):73-80.[10]張曉兵.大偏轉角偏轉象差校正理論研究與多磁極自會聚偏轉系統計算機輔助設計:[博士論文].南京:東南大學電子所,1996, 75-102. -
