ZJ03高速高精度鎖定電壓比較器的設計
THE DESIGN OF THE HIGH SPEED AND HIGH PRECISION LATCHING VOLTAGE COMPARATOR ZJ 03
-
摘要: 本文介紹一種新型的取樣鎖定電壓比較器ZJ03的設計。一般的電壓比較器由多級直接耦合放大器組戒,其精度(靈敏度)主要取決于總電壓增益,響應速度取決于總帶寬,精度與響應速度是矛盾的,難以實現高速和高精度。ZJ03在體制上有重要的改進,它含有一級受控的正反饋放大器,使精度主要取決于輸入失調電壓,與總帶寬幾乎沒有關系,可實現高速和高精度。在ZJ03的設計中,采用了容差擴展、中心設計和電平自適應技術,提高了產品性能的一致性和成品率。
-
關鍵詞:
- 電壓比較器; 取樣鎖定電壓比較器; 容差擴展; 電平自適應
Abstract: The design of a new type of sampling latching voltage comparator ZJ03 is described. The common voltage comparators consist of multistage DC amplifier. It is difficult to realize high speed and high precision. The voltage comparator ZJ03 contains a controlled positive feedback amplifier. Therefore, it is capable of realizing high speed and high precision. For improving the performance and yield, the tolerance extension, design centering and potential adapting are used for the design of the valtage comparator ZJ03. -
R. I. Widlar, Electronic Design, 13(1965)5, 20-27.[2]毛培法,電子科學技術,1981年,第1期,第17-18頁.[3]K.J. Antreich, R.K. Koblitz A New Approach to Design Centeriny Based on a Multiparameter Yield Prediction Formula, Proc. IEEE, IOCAS, (1980), pp.886-889.[4]于曉勇,朱輝,電子科學學刊,8(1986)3,169-179. -
