6H－SiC MOS結構電特性及其輻照效應的研究
Study of the electric characteristics and radiation response of 6h-sic mos structure
-
摘要: 對SiC MOS結構輻照引起的電參數退化及其電特性進行了研究。結果說明:在氧化層電場較高時Fowler-Nordheim隧穿電流決定著SiC MOS結構的漏電流,當幅照柵偏壓為高的正電壓時,電離幅照對SiC MOS電容的影響會更明顯,SiC MOS器件比Si器件具有好的抗輻照的能力,在58kGy(Si)的輻照劑量下,其平帶電壓漂移不超過2V。
-
關鍵詞:
- SiC MOS結構; 輻照; 平帶電壓; 退火
Abstract: The radiation response and electric characteristics of 6H-SiC MOS structure are studied with experiment. It is found that the main electronic conduction mechanism in the high field regions of the I-V characteristics is identified to be Fowler-Nordheim tunneling. The fact that ionization radiation effect becomes more notable at high oxide electric field indicates that the generation of radiation induced charge-centers near SiC/SiO2 interface and in gate oxide under high electric field is higher than that under low electric field. SiC MOS structure has a more significant tolerance to y rays than Si MOS structure. Flatband voltage shift of SiC MOS capacitor is less than 2V under radiation of 58kGy(Si). -
P. Friedrichs, E. P.Burte, Dielectric strength of thermal oxides on 6H-SiC and 4H-SiC, Appl.Phys. Lett., 1994, 65(13), 1665-1667.[2]M. Yoshikawa, Y. Morita, Gamma-ray irradiation effects on cubic silicon carbide metal-oxidesemiconductor structure, Springer Proceedings in Physics, Vol.71, Amorphous and Crystaline Silicon Carbide Ⅳ, 1992, 393-398.[3]M. Yoshikawa, K. Saitoh, T. Ohshima, Generation mechanisms of trapped charges in oxide layers of 6H-SiC MOS structures irradiated with gamma-rays, Int. Conf. on Silicon Carbide, III-Nitrides and Related Materials, Switzerland, 1998, 1017-1020.[4]J.B. Casady, J. D. Cressler, Direct current characterization of depletion-mode 6H-SiC MOSFETs form 294 to 723K, Solid State Electronics, 1996, 39(6), 777-784.[5]D. Alok, P. K. Mclarty, Electrical properties of thermal oxide grown on n-type 6H-silicon carbide,Appl. Phys. Lett., 1994, 64(21), 2845-2848.[6]郭維廉,硅～二氧化硅界面物理,北京,國防工業出版社,1989,第3章.[7]宋欽岐,MOS電容的電離輻照效應及其加固技術研究,抗核加固,1986,3(1),33-42.[8]賴祖武,抗輻射電子學-輻射效應及加固原理,北京,國防工業出版社,1998,46-83. -
