非均勻介質填充波導本征值問題的有限元分析
THE FINITE-ELEMENT ANALYSIS OF EIGENVALUEPROBLEM OF WAVEGUIDES FILLED WITHINHOMOGENEOUS DIELECTRICS
-
摘要: 本文討論了用有限元法求解非均勻介質填充波導本征值問題的具體過程。給出了有關的計算公式和程序。作為例子,對條形介質填充矩形波導主模場結構的分析和色散特性的計算,獲得了與解析解十分一致的結果,從而證實了所述程序的可靠性。
-
關鍵詞:
Abstract: The concrete procedure using finite-element method to solve the eigenvalue problem of waveguides filled with inhomogeneous dielectrics is discussed. The relative formula and programs are given. For an example, the field structure analysis and calculation of the dispersion feature for dominant mode of the dielectric slab loaded rectangular waveguide have been completed. The rather consistent results with analytical solution are obtained and the reliability of the programs is verified. -
