基于頻域稀疏壓縮感知的星載SAR稀疏重航過3維成像

田鶴; 于海鋒; 朱宇; 劉磊; 張潤寧; 袁莉; 李道京; 周凱

doi:10.11999/JEJT190638

基于頻域稀疏壓縮感知的星載SAR稀疏重航過3維成像

doi: 10.11999/JEJT190638 cstr: 32379.14.JEJT190638

1.
電磁散射重點實驗室北京 100854
2.
中國空間技術研究院總體設計部北京 100094
3.
中國科學院電子學研究所微波成像技術重點實驗室北京 100190

基金項目: 第五屆高分辨率對地觀測學術年會青年創新基金

詳細信息

作者簡介:
田鶴：女，1991年生，工程師，研究方向?yàn)槔走_(dá)信號處理、雷達成像識別和目標特性研究

于海鋒：男，1978年生，研究員，研究方向?yàn)槲⒉ㄟb感

朱宇：男，1978年生，研究員，研究方向?yàn)槲⒉ㄟb感

劉磊：男，1985年生，高級工程師，研究方向?yàn)槲⒉ㄟb感

張潤寧：男，1966年生，研究員，研究方向?yàn)槲⒉ㄟb感

袁莉：女，1977年生，研究員，研究方向?yàn)槔走_(dá)目標識別

李道京：男，1964年生，研究員，博士生導師，研究方向?yàn)槔走_(dá)系統，微波成像，信號處理方面

周凱：男，1995年生，博士生，研究方向?yàn)槔走_(dá)信號處理

通訊作者:
李道京　lidj@mail.ie.ac.cn

中圖分類號: TN959.74
計量
- 文章訪問數: 2312
- HTML全文瀏覽量: 572
- PDF下載量: 101
- 被引次數: 0
出版歷程
- 收稿日期: 2019-08-26
- 修回日期: 2020-05-05
- 網絡出版日期: 2020-05-16
- 刊出日期: 2020-08-18

Sparse Flight 3-D Imaging of Spaceborne SAR Based on Frequency Domain Sparse Compressed Sensing

1.
Science and Technology on Electromagnetic Scattering Laboratory, Beijing 100854, China
2.
General Design Department, China Academy of Space Technology, Beijing 100094, China
3.
Key Laboratory of Science and Technology on Microwave Imaging, Institute of Electronics, Chinese Academy of Sciences, Beijing 100190, China

Funds: Youth Innovation Fund of 5th China High Resolution Earth Observation Conference

摘要

摘要:
星載合成孔徑雷達(SAR)稀疏重航過3維成像技術通過交軌向的多次飛行觀測，獲得觀測場景的第3維分辨。該文給出了單顆衛星SAR稀疏重航過軌道分布，為有效縮短重訪時間，同時給出了編隊雙星SAR軌道分布，對應的交軌向等效孔徑長度為20 km。提出了一種基于干涉處理和頻域壓縮感知(CS)的稀疏3維成像方法，利用稀疏重航過中的部分回波形成參考3維復圖像，對待重建SAR 3維圖像信號進行干涉處理，使信號在頻域具備稀疏性。在大軌道分布范圍下，建立頻域距離向-交軌向線性測量矩陣，利用CS理論聯合求解稀疏表征下的圖像頻譜，避免交軌向和距離向的回波信號耦合。將求解所得頻譜逆變換至空間域，可得到觀測場景的3維圖像重建結果。仿真結果表明，該文方法在稀疏采樣率74.4%條件下，仍可獲得與滿采樣成像性能相當?shù)慕Y(jié)果，驗證了干涉處理頻域稀疏方法在星載SAR 3維成像中的有效性。
- 星載SAR /
- 稀疏重航過 /
- 編隊衛星 /
- 壓縮感知 /
- 干涉處理
Abstract:
The space-borne Synthetic Aperture Radar (SAR) sparse flight three-dimensional (3-D) imaging technology through the multiple observations in cross-track direction obtains the 3-D spatial distribution of the observed scene. In this paper, the orbit distribution of single satellite SAR sparse flight is given. In order to shorten effectively the satellite revisit time, the formation of double star SAR orbit distribution is given. The corresponding cross-track equivalent aperture length is 20 km. A sparse 3-D imaging method based on interferometry and compressed sensing is proposed. The referential complex image is formed by using part of the echoes of the sparse flight, and the SAR 3-D image signals which are to be reconstruct are processed by interferometry. This method makes the signal sparse in the frequency domain. Under the large orbit distribution range, the frequency domain range direction and cross-track linear measurement matrix is established, which is beneficial to the Compressed Sensing(CS) theory to solve jointly the image frequency spectrum under sparse representation, and avoid the echoes coupling between the range and cross-track direction. Inversely transforming the resulting spectrum into the spatial domain, the reconstruction result can be obtained. Simulation results show that under the condition of sparse sampling rate of 74.4%, the imaging performance of the proposed method is still comparable to that of full sampling.
- Space-borne SAR /
- Sparse flight /
- Satellite formation flying /
- Compressed Sensing (CS) /
- Interferometry

HTML全文

圖 1 星載SAR稀疏重航過3維成像幾何示意圖

下載: 全尺寸圖片幻燈片

圖 2 單顆衛星稀疏重航過軌道分布情況和10 m天線方向圖分析

下載: 全尺寸圖片幻燈片

圖 3 編隊雙星稀疏重航過軌道分布情況和10 m天線方向圖分析

下載: 全尺寸圖片幻燈片

圖 4 180次航過對應的滿采樣3維BP成像結果

下載: 全尺寸圖片幻燈片

圖 5 單顆衛星23次稀疏重航過對應的3維BP成像結果

下載: 全尺寸圖片幻燈片

圖 6 單顆衛星23次稀疏重航過對應的頻域CS成像結果

下載: 全尺寸圖片幻燈片

圖 7 編隊雙星23次稀疏重航過對應的3維BP成像結果

下載: 全尺寸圖片幻燈片

圖 8 編隊衛星23次稀疏重航過對應的頻域CS成像結果

下載: 全尺寸圖片幻燈片

表 1 衛星軌道漂移情況

時間	0.285479	6.285773	12.28588	18.2858	24.28553	30.28536	36.28558	42.28562
經度漂移	0	0.123000	0.180000	0.168000	0.087000	0.043000	0.141000	0.173000
距離漂移	0	13.692300	20.037520	18.701680	9.684800	4.786740	15.696060	19.258280
時間	48.285470	54.285150	60.285210	66.285380	72.285390	78.285250	84.284980	90.284810
經度漂移	0.138000	0.039000	0.079000	0.159000	0.183000	0.152000	0.071000	0.029000
距離漂移	15.362100	4.341462	8.794244	17.699810	20.371480	16.920570	7.903688	3.228267
時間	96.285010	102.285100	108.285000	114.284900	120.284600	126.284500	132.284700
經度漂移	0.119000	0.164000	0.167000	0.128000	0.049000	0.017000	0.117000
距離漂移	13.247030	18.256410	18.590360	14.248900	5.454658	1.892432	13.02439

下載: 導出CSV

表 2 星載重航過SAR側視3維成像仿真參數

參數	數值	參數	數值
工作波長$\lambda $	0.03 m	單星軌道最小間隔	111.3 m
發射信號帶寬${B_s}$	300 MHz	編隊雙星間隔	222.6 m
參考平臺高度$H$	550 km	交軌采樣最小間隔	111.3 m
入射角	45°	交軌等效孔徑長度	20 km
方位分辨率	1 m	重復軌道次數	23
機載平臺速度	7 km/s

下載: 導出CSV

表 3 圖像重建結果誤差分析

觀測方式	算法	評價指標
觀測方式	算法	圖像熵	相關系數	均方根誤差
180次滿采樣重航過	3維BP成像	0.4532
單顆衛星23次稀疏重航過	3維BP成像	0.7214	0.6566	0.0604
編隊雙星23次稀疏重航過	3維BP成像	0.6980	0.7903	0.0453
單顆衛星23次稀疏重航過	空間域CS成像	0.0095	0.5902	0.0432
編隊雙星23次稀疏重航過	空間域CS成像	0.0093	0.6094	0.0414
單顆衛星23次稀疏重航過	頻域CS成像	0.0503	0.7843	0.0405
編隊衛星23次稀疏重航過	頻域CS成像	0.0453	0.8280	0.0296

下載: 導出CSV

參考文獻(19)

GIRET R, JEULAND H, and ENERT P. A study of a 3D-SAR concept for a millimeter wave imaging radar onboard an UAV[C]. The 1st European Radar Conference, Amsterdam, The Netherland, 2004: 201–204.

REIGBER A, MOREIRA A, and PAPATHANASSIOU K P. First demonstration of airborne SAR tomography using multibaseline L-band data[C]. IEEE 1999 International Geoscience and Remote Sensing Symposium, Hamburg, Germany, 1999: 44–46. doi: 10.1109/IGARSS.1999.773395.

CANDES E J, WAKIN M B. An introduction to compressive sampling[J]. IEEE Signal Processing Magazine, 2008, 25(2): 21–30. doi: 10.1109/MSP.2007.914731

CANDèS E J. Compressive sampling[C]. The International Congress of Mathematicians, Madrid, Spain, 2006: 1–20.

DONOHO D L. Compressed sensing[J]. IEEE Transactions on Information Theory, 2006, 52(4): 1289–1306. doi: 10.1109/TIT.2006.871582

徐華平, 周蔭清, 李春升. 分布式星載干涉SAR中空間基線的分析和設計[J]. 電子與信息學報, 2003, 25(9): 1194–1199.

XU Huaping, ZHOU Yinqing, and LI Chunsheng. Baseline analysis and design for distributed spaceborne inteferometric SAR[J]. Journal of Electronics &Information Technology, 2003, 25(9): 1194–1199.

ZHU Xiaoxiang and BAMLER R. Very high resolution spaceborne SAR tomography in urban environment[J]. IEEE Transactions on Geoscience and Remote Sensing, 2010, 48(12): 4296–4308. doi: 10.1109/TGRS.2010.2050487

ZHU Xiaoxiang and BAMLER R. Sparse tomographic SAR reconstruction from mixed TerraSAR-X/TanDEM-X data stacks[C]. 2012 IEEE International Geoscience and Remote Sensing Symposium, Munich, Germany, 2012: 7468–7471. doi: 10.1109/IGARSS.2012.6351905.

ZHU Xiaoxiang and BAMLER R. Let’s do the time warp: Multicomponent nonlinear motion estimation in differential SAR tomography[J]. IEEE Geoscience and Remote Sensing Letters, 2011, 8(4): 735–739. doi: 10.1109/LGRS.2010.2103298

GE Nan and ZHU Xiaoxiang. Bistatic-like differential SAR tomography[J]. IEEE Transactions on Geoscience and Remote Sensing, 2019, 57(8): 5883–5893. doi: 10.1109/TGRS.2019.2902814

張清娟, 李道京, 李烈辰. 連續場景的稀疏陣列SAR側視三維成像研究[J]. 電子與信息學報, 2013, 35(5): 1097–1102. doi: 10.3724/SP.J.1146.2012.01136

ZHANG Qingjuan, LI Daojing, and LI Liechen. Research on continuous scene side-looking 3D imaging based on sparse array[J]. Journal of Electronics &Information Technology, 2013, 35(5): 1097–1102. doi: 10.3724/SP.J.1146.2012.01136

李烈辰, 李道京. 基于壓縮感知的連續場景稀疏陣列SAR三維成像[J]. 電子與信息學報, 2014, 36(9): 2166–2172. doi: 10.3724/SP.J.1146.2013.01645

LI Liechen and LI Daojing. Sparse array SAR 3D imaging for continuous scene based on compressed sensing[J]. Journal of Electronics &Information Technology, 2014, 36(9): 2166–2172. doi: 10.3724/SP.J.1146.2013.01645

TIAN He and LI Daojing. Sparse flight array SAR downward-looking 3-D imaging based on compressed sensing[J]. IEEE Geoscience and Remote Sensing Letters, 2016, 13(10): 1395–1399. doi: 10.1109/LGRS.2016.2560238

田鶴, 李道京. 稀疏重航過陣列SAR運動誤差補償和三維成像方法[J]. 雷達學報, 2018, 7(6): 717–729. doi: 10.12000/JR18101

TIAN He and LI Daojing. Motion compensation and 3-D imaging algorithm in sparse flight based airborne array SAR[J]. Journal of Radars, 2018, 7(6): 717–729. doi: 10.12000/JR18101

尹建鳳, 張慶君, 劉杰, 等. 國外編隊飛行干涉SAR衛星系統發展綜述[J]. 航天器工程, 2018, 27(1): 116–122. doi: 10.3969/j.issn.1673-8748.2018.01.016

YIN Jianfeng, ZHANG Qingjun, LIU Jie, et al. A review on development of formation flying interferometric SAR satellite system[J]. Spacecraft Engineering, 2018, 27(1): 116–122. doi: 10.3969/j.issn.1673-8748.2018.01.016

PETERSON E H, FOTOPOULOS G, and ZEE R E. A feasibility assessment for low-Cost InSAR formation-flying microsatellites[J]. IEEE Transactions on Geoscience and Remote Sensing, 2009, 47(8): 2847–2858. doi: 10.1109/TGRS.2009.2017521

ZINK M, BARTUSCH M, and MILLER D. TanDEM-X mission status[C]. 2011 IEEE International Geoscience and Remote Sensing Symposium, Vancouver, Canada, 2011: 2290–2293. doi: 10.1109/IGARSS.2011.6049666.

TRIDON D B, BACHMANN M, B?ER J, et al. TanDEM-X going for the DEM: Acquisition, performance, and further activities[C]. The 5th IEEE Asia-Pacific Conference on Synthetic Aperture Radar (APSAR), Singapore, 2015: 163–168. doi: 10.1109/APSAR.2015.7306180.

WANG Puzhong and SHI Changsheng. Antenna Principle[M]. Beijing: Tsinghua University Press, 1993.
