基于串聯陣列型磁電天線的甚低頻磁感應通信系統設計

張鋒; 李佳燃; 田玉曉; 徐梓洋; 宮兆前; 莊鑫

doi:10.11999/JEIT250065

基于串聯陣列型磁電天線的甚低頻磁感應通信系統設計

doi: 10.11999/JEIT250065 cstr: 32379.14.JEIT250065

張鋒^1, ,,
李佳燃^{1, 2},
田玉曉^{1, 2},
徐梓洋^{1, 2},
宮兆前^{1, 3},
莊鑫¹

1.
中國科學院空天信息創新研究院電磁輻射與探測技術重點實驗室北京 100190
2.
中國科學院大學電子電氣與通信工程學院北京 100049
3.
西北工業大學電子信息學院西安 710072

基金項目: 國家自然科學基金(62271470)，國家重點研發計劃(2021YFA0716500)

詳細信息

作者簡介:
張鋒：男，副研究員，研究方向?yàn)槌瑢拵Ю走_(dá)技術，超寬帶天線技術，磁感應通信技術等

李佳燃：男，碩士生，研究方向?yàn)榇鸥袘?yīng)通信技術， FPGA通信算法開發等

田玉曉：女，碩士生，研究方向?yàn)槌瑢拵炀€技術，小型化天線等

徐梓洋：男，碩士生，研究方向?yàn)槁曋C振器件、基于壓電磁致伸縮的磁電傳感器件開發等

宮兆前：男，助理研究員，研究方向?yàn)閿?shù)字信號處理、信息與通信算法研究等

莊鑫：男，副研究員，研究方向?yàn)楦哽`敏度磁場傳感器，磁電復合材料/器件，新型電磁輻射與探測技術等

通訊作者:
張鋒　zhangfeng002723@aircas.ac.cn

中圖分類號: TN914; TN92
計量
- 文章訪問數: 91
- HTML全文瀏覽量: 46
- PDF下載量: 15
- 被引次數: 0
出版歷程
- 收稿日期: 2025-02-12
- 修回日期: 2025-05-29
- 網絡出版日期: 2025-06-10

Design of a Very Low Frequency Magnetic Induction Communication System Based on a Series-Array Magnetoelectric Antenna

ZHANG Feng^{1
, ,},
LI Jiaran^{1, 2},
TIAN Yuxiao^{1, 2},
XU Ziyang^{1, 2},
GONG Zhaoqian^{1, 3},
ZHUANG Xin¹

1.
The Key Laboratory of Electromagnetic Radiation and Sensing Technology, Aerospace Information Research Institute, Chinese Academy of Sciences, Beijing 100190, China
2.
The School of Electronic, Electrical, and Communication Engineering, University of Chinese Academy of Sciences, Beijing 100049, China
3.
School of Electronics and Information, Northwestern Polytechnical University, Xi’an 710072, China

Funds: The National Natural Science Foundation of China (62271470), The National Key R&D Program of China (2021YFA0716500)

摘要

摘要: 磁電(ME)天線具有高能量轉換效率、小尺寸和輕量化的優勢，在便攜式跨介質通信系統中具有良好的應用前景。目前，ME天線存在輻射強度較低的問題，限制了系統的通信距離。為解決這一問題，該文設計了一種基于ME天線陣列的甚低頻(VLF)通信系統。該系統的發射天線是由7個ME天線單元串聯組成的發射陣列，有效提升了輻射強度。ME天線單元采用經過表面改性的Fe₈₀Si₉B₁₁層壓材料作為磁致伸縮單元，并結合Pb(Zr,Ti)O₃(PZT)壓電陶瓷構成三明治結構，增強了磁電耦合效率。對天線陣列施加高驅動電壓，可在1 m距離處產生165 nT的磁場強度?；谠撎炀€陣列的便攜式磁通信系統采用二進制振幅鍵控(BASK)調制技術，在高背景噪聲的實驗室環境中成功實現了11.4 m的無線通信，碼速率為50 bit/s。理論分析表明，該系統的最大誤碼率為0.12%，證明了其良好的抗噪能力。研究結果表明，基于串聯陣列型磁電(ME)天線的通信系統在提升通信距離具有顯著優勢，為低頻通信技術的發展提供了新的思路。
- 低頻通信系統 /
- 新型磁電天線 /
- 數字調制
Abstract: Objective MagnetoElectric (ME) antennas, recognized for their high energy conversion efficiency and compact structure, have gained attention in portable cross-medium communication systems. In the Very Low Frequency (VLF) range, conventional antennas are typically large and difficult to deploy, whereas mechanical antennas—though smaller—exhibit limited radiation intensity, constraining communication range. To address these limitations, this study proposes a portable VLF magnetic induction communication system based on a series-array ME antenna. By connecting seven ME antenna units in series, the radiated field strength is substantially increased. Through the combination of strong ME coupling and an optimized system design, this work offers a practical solution for compact low-frequency communication. Methods The radiated magnetic flux density of the antenna is evaluated using a small air-core coil (diameter: 50 mm; length: 120 mm) with a gain-500 preamplifier as the receiving antenna. The conversion coefficient T_r of the receiving antenna is calibrated using a standard Helmholtz coil, enabling conversion of the measured voltage to magnetic flux density. The ME antenna is driven by a signal generator and power amplifier, and the magnetic field strength is measured at a distance of 1.2 m under different drive voltages. To balance hardware simplicity and efficient bandwidth usage, Binary Amplitude Shift Keying (BASK) modulation is employed. On the transmitter side, a computer transmits the bitstream to a field-programmable gate array (FPGA), which generates the baseband signal and multiplies it by a 27.2 kHz carrier to produce the modulated signal. Following power amplification, the signal directly drives the ME antenna. On the receiver side, the air-core coil receives the transmitted signal, which is subsequently amplified by the preamplifier. A National Instruments (NI) data acquisition module digitizes the signal. Demodulation, including filtering, coherent detection, and symbol decision, is performed on a computer. For laboratory safety and signal stability, the Root Mean Square (RMS) drive voltage is set to 14.8 V, and the symbol rate is fixed at 50 bps. Communication experiments are conducted over distances from 1.2 m to 11.4 m. Results and Discussions (1) Antenna radiation intensity. When the RMS drive voltage of the series-array ME antenna is 180.5 V (25.8 V per unit), the measured magnetic field strength reaches 93.6 nT at 1.2 m and 165 nT at 1.0 m. These values indicate strong performance among acoustically driven ME antennas. The results demonstrate that the combination of ME materials with a seven-element series configuration substantially enhances both ME coupling and radiated field strength. (2) System communication performance. The BASK system operates at 50 bps, matching the measured 111 Hz bandwidth of the ME antenna. The receiving antenna exhibits a bandwidth of 851 Hz at 27.6 kHz, which fully covers the transmitted signal. Due to laboratory space constraints, 128-bit random data are transmitted over distances ranging from 1.2 m to 11.4 m. Even at 11.4 m—where the received signal amplitude falls below 0.004 V—the proposed demodulation scheme successfully recovers the transmitted data. To verify these results, a theoretical model of magnetic field attenuation with distance is fitted to the experimental data, showing strong agreement except for minor deviations attributed to environmental noise. Noise spectrum analysis within a 100 Hz bandwidth centered at 27.2 kHz indicates a maximum environmental noise level of approximately 4.41 pT, resulting in a Signal-to-Noise Ratio (SNR) of 12.65 dB at 11.4 m. Based on the theoretical relationship between SNR and Bit Error Rate (BER) for coherent ASK, the maximum BER under these conditions is approximately 0.12%, consistent with the measured performance. Conclusions This study presents a VLF magnetic induction communication system based on a series-array ME antenna, with the ME antenna serving as the transmitter and an air-core coil as the receiver. A standard Helmholtz coil circuit is used to calibrate the conversion coefficient between received voltage and magnetic flux density. The radiated magnetic field strength is characterized by varying the ME antenna’s drive voltage. Notably, at an RMS drive voltage of 180.5 V, the ME antenna generates a magnetic induction of 165 nT at a distance of 1 m. Laboratory communication experiments confirm that, with a drive voltage of 14.8 V, ASK transmission achieves a range of 11.4 m at a symbol rate of 50 bps. In a high-noise environment with an in-band noise level of 4.41 pT, the system achieves a BER of 0.12%, consistent with theoretical predictions and confirming the reliability of the demodulation process. These results demonstrate the feasibility and efficiency of ME antennas for compact, low-frequency magnetic communication. Further performance improvements may be achieved by (1) operating in low-noise environments and (2) increasing the drive voltage to enhance radiation strength by up to a factor of 6.4.
- Low-frequency communication systems /
- Novel MagnetoElectric (ME) antennas /
- Digital modulation

HTML全文

圖 1 不同退火溫度和時間的Fe₈₀Si₉B₁₁帶材參數

下載: 全尺寸圖片幻燈片

圖 2 磁電復合材料的三明治結構

下載: 全尺寸圖片幻燈片

圖 3 磁電天線陣列內部結構圖(部分)

下載: 全尺寸圖片幻燈片

圖 4 接收線圈天線的轉換系數測量實驗

下載: 全尺寸圖片幻燈片

圖 5 ME天線陣列輻射磁感應強度測量實驗

下載: 全尺寸圖片幻燈片

圖 6 基于串聯型ME天線陣列的磁通信系統框圖與設備

下載: 全尺寸圖片幻燈片

圖 7 磁通信系統的ASK調制解調方案

下載: 全尺寸圖片幻燈片

圖 8 不同距離下磁通信系統的發射與接收信號

下載: 全尺寸圖片幻燈片

圖 9 VLF磁通信系統的通信實驗結果和實驗環境

下載: 全尺寸圖片幻燈片

圖 10 環境噪聲譜密度與相干解調 ASK 通信系統的誤碼率/信噪比分析

下載: 全尺寸圖片幻燈片

表 1 基于不同機械天線的低頻通信系統性能

天線類型	f_carrier (Hz)	V_rad (cm³)	ΔB¹⁾	比特率 (bit/s)	通信距離	調制方式	參考文獻
旋轉永磁體	320	–	在3 m處7 nT	12.5	5 m	FSK	[10]
旋轉永磁體	440	0.64	在1 m處0.1 μT	214	–	ASK	[16]
壓電諧振型	33 230	～50.24	在6 m處40 fT	60	–	ASK/FSK	[17]
磁電諧振型	27 750	0.04	在6.5 m處43 pT	18 000	6.5 m(接收線圈直徑49 mm)	PSK	[18]
磁電諧振型	18 100	–	在0.5 m處3.8 nT	2 000	0.1m	ASK	[12]
磁電諧振型	21 200	3.38	在1 m處112 nT	300	18 m (接收線圈直徑200 mm)	ASK/PSK	[19]
磁電諧振型	27 200	7.07	在1 m處 B_MAX =165 nT	50	11.4 m(接收線圈直徑50 mm，長度120 mm)	ASK	本文
¹⁾B_max 表示發射天線輻射的最大磁感應強度。

下載: 導出CSV

參考文獻(22)

[1]	WHEELER H. Fundamental limitaions of a small VLF antenna for submarines[J]. IRE Transactions on Antennas and Propagation, 1958, 6(1): 123–125. doi: 10.1109/TAP.1958.1144550.
[2]	CELLA U M, JOHNSTONE R, and SHULEY N. Electromagnetic wave wireless communication in shallow water coastal environment: Theoretical analysis and experimental results[C]. The 4th International Workshop on Underwater Networks, Berkeley, USA, 2009: 9. doi: 10.1145/1654130.1654139.
[3]	SUN Zhi and AKYILDIZ I F. Magnetic induction communications for wireless underground sensor networks[J]. IEEE Transactions on Antennas and Propagation, 2010, 58(7): 2426–2435. doi: 10.1109/TAP.2010.2048858.
[4]	HAYAKAWA M. VLF/LF radio sounding of ionospheric perturbations associated with earthquakes[J]. Sensors, 2007, 7(7): 1141–1158. doi: 10.3390/s7071141.
[5]	GRIFFITHS D J and INGLEFIELD C. Introduction to electrodynamics[J]. American Journal of Physics, 2005, 73(6): 574–574. doi: 10.1119/1.4766311.
[6]	KING R W P. Lateral electromagnetic waves from a horizontal antenna for remote sensing in the ocean[J]. IEEE Transactions on Antennas and Propagation, 1989, 37(10): 1250–1255. doi: 10.1109/8.43533.
[7]	BICKFORD J A, MCNABB R S, WARD P A, et al. Low frequency mechanical antennas: Electrically short transmitters from mechanically-actuated dielectrics[C]. 2017 IEEE International Symposium on Antennas and Propagation & USNC/URSI National Radio Science Meeting, San Diego, USA, 2017: 1475–1476. doi: 10.1109/APUSNCURSINRSM.2017.8072780.
[8]	BARANI N and SARABANDI K. Mechanical antennas: Emerging solution for Very-Low Frequency (VLF) communication[C]. 2018 IEEE International Symposium on Antennas and Propagation & USNC/URSI National Radio Science Meeting, Boston, USA, 2018: 95–96. doi: 10.1109/APUSNCURSINRSM.2018.8608412.
[9]	WHEELER H. Small antennas[J]. IEEE Transactions on Antennas and Propagation, 1975, 23(4): 462–469. doi: 10.1109/TAP.1975.1141115.
[10]	SUN Faxiao, ZHANG Feng, MA Xiaoya, et al. Research on ultra-low-frequency communication based on the rotating shutter antenna[J]. Electronics, 2022, 11(4): 596. doi: 10.3390/ELECTRONICS11040596.
[11]	DU Yongjun, XU Yiwei, WU Jingen, et al. Very-low-frequency magnetoelectric antennas for portable underwater communication: Theory and ecperiment[J]. IEEE Transactions on Antennas and Propagation, 2023, 71(3): 2167–2181. doi: 10.1109/TAP.2022.3233665.
[12]	CHENG Jiawei, JIAO Jie, FU Shifeng, et al. Ultra-high baud rate VLF magnetoelectric antenna based on Rosen-type composite[J]. Applied Physics Letters, 2023, 123(7): 072903. doi: 10.1063/5.0167170.
[13]	ZHUANG Xin, XU Xin, ZHANG Xu, et al. Tailoring the magnetomechanical power efficiency of metallic glasses for magneto-electric devices[J]. Journal of Applied Physics, 2022, 132(10): 104502. doi: 10.1063/5.0098282.
[14]	KACZKOWSKI Z. Magnetomechanical coupling in transducers[J]. Archives of Acoustics, 1981, 6(4): 385–400.
[15]	COAKLEY K J, SPLETT J D, JANEZIC M D, et al. Estimation of Q-factors and resonant frequencies[J]. IEEE Transactions on Microwave Theory and Techniques, 2003, 51(3): 862–868. doi: 10.1109/TMTT.2003.808578.
[16]	REZAEI H, KHILKEVICH V, YONG Shaohui, et al. Mechanical magnetic field generator for communication in the ULF range[J]. IEEE Transactions on Antennas and Propagation, 2020, 68(3): 2332–2339. doi: 10.1109/TAP.2019.2955069.
[17]	HASSANIEN A E, BREEN M, LI M H, et al. Acoustically driven electromagnetic radiating elements[J]. Scientific Reports, 2020, 10(1): 17006. doi: 10.1038/s41598-020-73973-6.
[18]	XU Yiwei, WU Jingen, DU Yongjun, et al. A portable VLF magnetoelectric transmitter with high-rate phase modulation[J]. IEEE Transactions on Antennas and Propagation, 2024, 72(4): 3134–3149. doi: 10.1109/TAP.2024.3363466.
[19]	CHU Zhaoqiang, MAO Zhineng, SONG Kaixin, et al. A multilayered magnetoelectric transmitter with suppressed nonlinearity for portable VLF communication[J]. Research, 2023, 6: 0208. doi: 10.34133/research.0208.
[20]	BURCH H C, GARRAUD A, MITCHELL M F, et al. Experimental generation of ELF radio signals using a rotating magnet[J]. IEEE Transactions on Antennas and Propagation, 2018, 66(11): 6265–6272. doi: 10.1109/TAP.2018.2869205.
[21]	BALANIS C A. Advanced Engineering Electromagnetics[M]. 2nd ed. Hoboken, New Jersey, USA: John Wiley & Sons, 2012.
[22]	樊昌信, 曹麗娜. 通信原理[M]. 7版. 北京: 國防工業出版社, 2012: 200–210. FAN Changxin and CAO Lina. Principles of Communication[M]. 7th ed. Beijing: National Defense Industry Press, 2012: 200–210.
