可重構智能表面輔助的聯合空間和碼索引調制通信系統

陳平平; 張?jiān)栖?/>
	<meta name=

doi:10.11999/JEIT240987

可重構智能表面輔助的聯合空間和碼索引調制通信系統

doi: 10.11999/JEIT240987 cstr: 32379.14.JEIT240987

陳平平¹,
張?jiān)栖?/a>¹,

杜偉慶^2, ,

1.
福州大學先進制造學院泉州 362251
2.
福州大學物理與信息工程學院福州 350108

基金項目: 國家自然科學基金(62171135)

詳細信息

作者簡介:
陳平平：男，教授，研究方向?yàn)闊o(wú)線通信、極化碼信道編譯碼、網絡編碼、多用戶接入

張?jiān)栖埃号T士生，研究方向?yàn)闊o(wú)線通信

杜偉慶：男，助理研究員，研究方向?yàn)闊o(wú)線通信、流媒體傳輸協議、視頻編解碼

通訊作者:
杜偉慶　dwq_qz@fzu.edu.cn

中圖分類號: TN914.4
計量
- 文章訪問數: 268
- HTML全文瀏覽量: 96
- PDF下載量: 30
- 被引次數: 0
出版歷程
- 收稿日期: 2024-11-05
- 修回日期: 2025-02-11
- 網絡出版日期: 2025-02-25
- 刊出日期: 2025-02-28

Reconfigurable Intelligent Surface-Aided Joint Spatial and Code Index Modulation Communication System

1.
School of Advanced Manufacturing, Fuzhou University, Quanzhou 362251, China
2.
College of Physics and Information Engineering, Fuzhou University, Fuzhou 350108, China

Funds: The National Natural Science Foundation of China (62171135)

摘要

摘要: 傳統的可重構智能表面輔助的空間調制(RIS-SM)通信系統利用接收天線的索引來傳輸額外的信息比特，因此該系統數據傳輸速率的提升是以增加接收機天線數為代價。為了提高RIS-SM系統的數據傳輸速率和能量效率，該文提出可重構智能表面輔助的聯合空間和碼索引調制(RIS-JSCIM)通信系統。該系統利用多元正交幅度調制(M-QAM)符號、空域的接收天線索引和碼索引傳輸信息比特。天線索引和碼索引傳輸?shù)男畔⒈忍夭恍枰哪芰?，因此RIS-JSCIM系統能夠獲得良好的能量效率。該文對比了RIS-JSCIM系統和其他系統的能量效率、系統復雜度和誤碼率性能。對比結果表明，所提RIS-JSCIM系統以增加一定復雜度為代價，能夠獲得相比于其他系統更優異的能量效率和誤碼率性能。
- 可重構智能表面 /
- 碼索引調制 /
- 空間調制 /
- 擴頻 /
- 多元正交振幅調制
Abstract: Objective The rapid growth of wireless communication traffic is pushing existing networks toward greener, more energy-efficient solutions. Therefore, research into wireless communication systems that balance low complexity with high energy efficiency is of significant importance. Index Modulation (IM) technology, which offers advantages in low complexity and high energy efficiency, has emerged as a promising candidate for future systems. Reconfigurable Intelligent Surfaces (RIS) provide benefits such as reconfigurability, simple hardware, and low energy consumption, presenting new opportunities for wireless communication development. However, traditional RIS- aided Spatial Modulation (RIS-SM) and RIS-aided Code Index Modulation (RIS-CIM) systems use the index of the receiver antenna or code to transmit additional information bits. Therefore, the data transmission rates of RIS-SM systems improve at the cost of increasing the number of receiver antennas. To enhance the data transmission rates and energy efficiency of RIS-SM systems, this paper proposes a RIS-Aided Joint Spatial and Code Index Modulation (RIS-JSCIM) communication system. Methods The proposed system utilizes M-ary Quadrature Amplitude Modulation (M-QAM) symbols, spatial antenna index, and code index to transmit information bits. The information bits transmitted through the antenna and code indices of RIS-JSCIM do not consume energy, enabling RIS-JSCIM to achieve high energy efficiency. At the receiver, both Maximum Likelihood Detection (MLD) and low-complexity Greedy Detection (GD) algorithms are employed. The MLD algorithm, although high in complexity, provides excellent Bit Error Rate (BER) performance, while the GD algorithm offers a better trade-off between complexity and BER performance. Furthermore, this paper analyzes the energy efficiency and complexity of the proposed RIS-JSCIM system and uses Monte Carlo simulations to evaluate its BER performance. The performance metrics of the RIS-JSCIM system are also compared with those of other systems. The results show that, despite a slight increase in system complexity, the RIS-JSCIM system outperforms others in terms of energy efficiency and BER performance. Results and Discussions This paper compares the energy efficiency, system complexity, and BER performance of the RIS-JSCIM system with other systems. The comparison shows that, when the number of receiving antennas N_R=4 and the number of Walsh codes L=8, the energy efficiency of the RIS-JSCIM system improves by 60% and 6.67% compared to the RIS-SM and RIS-CIM systems, respectively (Table 2). The complexity of the RIS-JSCIM system with the GD algorithm is comparable to that of the GCIM-SM system and slightly higher than that of the RIS-CIM system (Table 3). Simulation results indicate that, at BER=10^–5, the RIS-JSCIM system achieves a performance gain of over 6 dB compared to the RIS-CIM system (Fig. 5). As the number of RIS units N increases, both the RIS-JSCIM and RIS-CIM systems show significant improvements in BER performance, with the RIS-JSCIM system outperforming the RIS-CIM system at high Signal-to-Noise Ratios (SNR). For example, at BER=10^–5 and N=128, the RIS-JSCIM system offers a 5 dB SNR gain over the RIS-CIM system (Fig. 6). Similarly, at high SNR, the BER performance of the RIS-JSCIM system consistently outperforms that of the RIS-SM system (Fig. 7). Conclusions The RIS-JSCIM system utilizes M-QAM symbols to transmit information bits and employs the receiver antenna and code indices to convey additional information. Both the MLD and GD algorithms are introduced for recovering the transmitted bits. The MLD algorithm explores all possible combinations of receiver antenna indices, code indices, and M-QAM symbols, offering improved BER performance at the cost of increased complexity. In contrast, the GD algorithm performs separate detection of antenna indices, code indices, and M-QAM symbols, providing a favorable trade-off between complexity and BER performance. The RIS-JSCIM system transmits receiver antenna index and code index bits without consuming energy, resulting in high energy efficiency. When the number of receiving antennas N_R=4 and the number of Walsh codes L=8, the energy efficiency of the RIS-JSCIM system improves by 60% and 6.67% compared to the RIS-SM and RIS-CIM systems, respectively. Moreover, when the BER=10^–5 and N=128, the RIS-JSCIM system offers a 5 dB SNR gain over the RIS-CIM system.
- Reconfigurable Intelligent Surface (RIS) /
- Code Index Modulation (CIM) /
- Spatial modulation (SM) /
- Spread spectrum /
- M-ary Quadrature Amplitude Modulation (M-QAM)

HTML全文

圖 1 RIS-JSCIM系統的發射機結構

下載: 全尺寸圖片幻燈片

圖 2 RIS-JSCIM系統的接收機結構

下載: 全尺寸圖片幻燈片

圖 3 本文所提RIS-JSCIM系統在不同碼索引比特?cái)?shù)和M-QAM調制比特?cái)?shù)下的誤碼率性能

下載: 全尺寸圖片幻燈片

圖 4 本文所提RIS-JSCIM系統MLD算法和GD算法的誤碼率性能對比

下載: 全尺寸圖片幻燈片

圖 5 所提RIS-JSCIM系統和其他系統的誤碼率性能對比

下載: 全尺寸圖片幻燈片

圖 6 本文所提RIS-JSCIM系統和RIS-CIM系統在不同RIS單元數下的誤碼率性能

下載: 全尺寸圖片幻燈片

圖 7 本文所提RIS-JSCIM系統和RIS-SM系統在不同RIS單元數下的誤碼率性能

下載: 全尺寸圖片幻燈片

表 1 本文所提RIS-JSCIM與其他方案的主要差異對比

系統	天線索引	碼索引	RIS
RIS-JSCIM	√	√	√
GCIM-SM ^[10]	√	×	×
RIS-AP^[14]	×	×	√
RIS-SM ^[15]	√	×	√
RIS-CIM ^[20]	×	√	√

下載: 導出CSV

表 2 本文所提RIS-JSCIM與RIS-SM, RIS-CIM方案的能量效率對比(%)

系統	${N_{\text{R}}} = 4,_{}^{}L = 4$	${N_{\text{R}}} = 8,_{}^{}L = 4$	${N_{\text{R}}} = 16,_{}^{}L = 4$	${N_{\text{R}}} = 4,_{}^{}L = 8$	${N_{\text{R}}} = 4,_{}^{}L = 16$
RIS-JSCIM	75	78	80	80	83
RIS-SM ^[15]	50	60	67	50	50
RIS-CIM ^[20]	67	67	67	75	80

下載: 導出CSV

表 3 本文所提RIS-JSCIM的兩種檢測方案與GCIM-SM, RIS-CIM方案的復雜度對比

系統	${N_{\text{R}}} = 2,L = 4,M = 4$	${N_{\text{R}}} = 2,L = 8,M = 8$	${N_{\text{R}}} = 2,L = 16,M = 4$
RIS-JSCIM (GD)	512	896	1280
RIS-JSCIM (MLD)	8256	65600	131136
GCIM-SM ^[10]	512	896	1280
RIS-CIM ^[20]	448	862	1216

下載: 導出CSV

參考文獻(21)

[1]	工業和信息化部, 國家發展改革委, 財政部, 等. 信息通信行業綠色低碳發展行動計劃(2022–2025年)[R]. 工信部聯通信〔2022〕103號, 2022. Ministry of Industry and Information Technology, National Development and Reform Commission, Ministry of Finance of the People’s Republic of China, et al. Green and low-carbon development action plan for the information and communications industry (2022–2025)[R]. 2022.
[2]	MAO Tianqi, WANG Qi, WANG Zhaocheng, et al. Novel index modulation techniques: A survey[J]. IEEE Communications Surveys & Tutorials, 2019, 21(1): 315–348. doi: 10.1109/COMST.2018.2858567.
[3]	BASAR E, WEN Miaowen, MESLEH R, et al. Index modulation techniques for next-generation wireless networks[J]. IEEE Access, 2017, 5: 16693–16746. doi: 10.1109/ACCESS.2017.2737528.
[4]	MESLEH R, HAAS H, SINANOVIC S, et al. Spatial modulation[J]. IEEE Transactions on Vehicular Technology, 2008, 57(4): 2228–2241. doi: 10.1109/TVT.2007.912136.
[5]	WEI R Y, CHANG C W, and CHENG Yuanfu. Temporal permutations in distinct accumulated blocks of space-time block-coded spatial modulation[J]. IEEE Transactions on Vehicular Technology, 2024, 73(12): 19240–19251. doi: 10.1109/TVT.2024.3446318.
[6]	ZHU Feifei, HAI Han, PENG Yuyang, et al. Extended variable active antenna generalized spatial modulation[J]. IEEE Wireless Communications Letters, 2024, 13(2): 265–269. doi: 10.1109/LWC.2023.3322005.
[7]	KADDOUM G, AHMED M F A, and NIJSURE Y. Code index modulation: A high data rate and energy efficient communication system[J]. IEEE Communications Letters, 2015, 19(2): 175–178. doi: 10.1109/LCOMM.2014.2385054.
[8]	KADDOUM G, NIJSURE Y, and TRAN H. Generalized code index modulation technique for high-data-rate communication systems[J]. IEEE Transactions on Vehicular Technology, 2016, 65(9): 7000–7009. doi: 10.1109/TVT.2015.2498040.
[9]	AYDIN E, COGEN F, and BASAR E. Code index modulation aided quadrature spatial modulation for high-rate MIMO systems[J]. IEEE Transactions on Vehicular Technology, 2019, 68(10): 10257–10261. doi: 10.1109/TVT.2019.2928378.
[10]	COGEN F, AYDIN E, KABAOGLU N, et al. Generalized code index modulation and spatial modulation for high rate and energy-efficient mimo systems on rayleigh block-fading channel[J]. IEEE Systems Journal, 2021, 15(1): 538–545. doi: 10.1109/JSYST.2020.2993704.
[11]	李斌, 劉文帥, 謝萬城, 等. 智能超表面賦能移動邊緣計算部分任務卸載策略[J]. 電子與信息學報, 2022, 44(7): 2309–2316. doi: 10.11999/JEIT211595. LI Bin, LIU Wenshuai, XIE Wancheng, et al. Partial computation offloading for double-RIS assisted multi-user mobile edge computing networks[J]. Journal of Electronics & Information Technology, 2022, 44(7): 2309–2316. doi: 10.11999/JEIT211595.
[12]	BASAR E, ALEXANDROPOULOS G C, LIU Yuanwei, et al. Reconfigurable intelligent surfaces for 6G: Emerging hardware architectures, applications, and open challenges[J]. IEEE Vehicular Technology Magazine, 2024, 19(3): 27–47. doi: 10.1109/MVT.2024.3415570.
[13]	WANG Chengxiang, YOU Xiaohu, GAO Xiqi, et al. On the road to 6G: Visions, requirements, key technologies, and testbeds[J]. IEEE Communications Surveys & Tutorials, 2023, 25(2): 905–974. doi: 10.1109/COMST.2023.3249835.
[14]	BASAR E. Transmission through large intelligent surfaces: A new frontier in wireless communications[C]. 2019 European Conference on Networks and Communications, Valencia, Spain, 2019: 112–117. doi: 10.1109/EuCNC.2019.8801961.
[15]	BASAR E. Reconfigurable intelligent surface-based index modulation: A new beyond MIMO paradigm for 6G[J]. IEEE Transactions on Communications, 2020, 68(5): 3187–3196. doi: 10.1109/TCOMM.2020.2971486.
[16]	ASMORO K and SHIN S Y. RIS grouping based index modulation for 6G telecommunications[J]. IEEE Wireless Communications Letters, 2022, 11(11): 2410–2414. doi: 10.1109/LWC.2022.3205038.
[17]	LI Qiang, WEN Miaowen, LI Jun, et al. Interplay between reconfigurable intelligent surfaces and spatial modulation: New application paradigms[J]. IEEE Wireless Communications, 2023, 30(1): 126–133. doi: 10.1109/MWC.011.2100143.
[18]	DINAN M H, DI RENZO M, and FLANAGAN M F. RIS-assisted receive quadrature spatial modulation with low-complexity greedy detection[J]. IEEE Transactions on Communications, 2023, 71(11): 6546–6560. doi: 10.1109/TCOMM.2023.3303957.
[19]	LI Can, CAI Xiangming, KANG Peng, et al. Exploiting activation mode index for reconfigurable intelligent surface-aided spatial modulation[J]. IEEE Transactions on Vehicular Technology, 2024, 73(12): 19809–19814. doi: 10.1109/TVT.2024.3433609.
[20]	COGEN F, OZDEN B A, AYDIN E, et al. Reconfigurable intelligent surface-empowered code index modulation for high-rate SISO systems[J]. IEEE Transactions on Cognitive Communications and Networking, 2024, 10(5): 1856–1866. doi: 10.1109/TCCN.2024.3384495.
[21]	JIN Xiaoping, BIAN Lina, LI Zhengquan, et al. A novel RIS-aided code index modulation scheme with low-complexity detection[J]. IEEE Transactions on Vehicular Technology, 2023, 72(11): 14279–14288. doi: 10.1109/TVT.2023.3281636.
