空中可重構智能面輔助車輛通信信道建模研究

潘旭婷; 石旺旗; 熊柏蘋; 郭道省; 江浩

doi:10.11999/JEIT240874

空中可重構智能面輔助車輛通信信道建模研究

doi: 10.11999/JEIT240874 cstr: 32379.14.JEIT240874

潘旭婷¹,
石旺旗¹,
熊柏蘋²,
郭道省³,
江浩^{1, 2, ,}

1.
南京信息工程大學人工智能學院南京 210044
2.
東南大學移動通信國家重點實驗室南京 210096
3.
陸軍工程大學通信工程學院南京 210007

基金項目: 國家自然科學基金(62471238, U22A2002)，江西省科技創新基地資助計劃(20242BCC32016)

詳細信息

作者簡介:
潘旭婷：女，博士生，研究方向為RIS無線通信信道建模與仿真等

石旺旗：男，碩士生，研究方向為RIS無線通信信道建模與仿真等

熊柏蘋：男，博士生，研究方向為RIS無線信道建模與仿真、無人機通信等

郭道省：男，教授，研究方向為衛星通信、通信抗干擾、空天地一體化網絡、物理層安全、無人機通信等

江浩：男，副教授，研究方向為RIS無線信道建模與仿真、近場通信，高能效通信等

通訊作者:
江浩　jianghao@nuist.edu.com

中圖分類號: TN929.5
計量
- 文章訪問數: 358
- HTML全文瀏覽量: 139
- PDF下載量: 82
- 被引次數: 0
出版歷程
- 收稿日期: 2024-10-16
- 修回日期: 2025-01-04
- 網絡出版日期: 2025-01-17
- 刊出日期: 2025-03-01

Research on Channel Modeling for Aerial Reconfigurable Intelligent Surfaces-assisted Vehicle Communications

1.
School of Artificial Intelligence, Nanjing University of Information Science and Technology, Nanjing 210044, China
2.
National Mobile Communications Research Laboratory, Southeast University, Nanjing 210096, China
3.
College of Communication Engineering, Army Engineering University, Nanjing 210007, China

Funds: The National Natural Science Foundation of China (62471238, U22A2002), Jiangxi Province Science and Technology Development Programme (20242BCC32016)

摘要

摘要: 可重構智能表面(RIS)能夠調控入射電磁波以優化通信系統性能，是第6代(6G)無線通信技術的關鍵創新。將可重構智能表面部署于無人機(UAV)上，借助無人機的靈活運動軌跡和按需部署特性，可以有效解決因樹木和建筑等障礙物遮擋所引起的信息傳輸效率下降的問題。針對空中可重構智能表面輔助的車對車(V2V)通信場景，該文提出了一種基于幾何的3維信道模型，該模型綜合考慮了無人機在3個自由度下的旋轉和任意軌跡移動，以及無人姿態變化對于信道模型的影響，引入了時變空間相位。此外，還考慮了發射端、接收端和無人機的實時運動速度和方向，給出了復信道脈沖響應(CIRs)的表達式，并對空域互相關函數(CCFs)、時域自相關函數(ACFs)和信道容量等關鍵信道統計特性進行了詳細分析。仿真結果表明，所提信道模型能夠準確捕獲信道特性，為未來可重構智能面輔助無線通信的系統設計和優化提供了有價值的理論參考。
- 車對車通信 /
- 可重構智能表面 /
- 無人機 /
- 信道模型
Abstract: Objective The Internet of Vehicles (IoV) is a global innovation focus, enabling ubiquitous interconnection among vehicles, roads, and people, thereby reducing traffic congestion and improving traffic safety. Vehicle-to-Vehicle (V2V) communication represents one of the most prominent application scenarios in IoV. This study addresses the reduced efficiency of V2V communication caused by environmental obstacles such as buildings and trees. It proposes the deployment of Reconfigurable Intelligent Surfaces (RIS) on Unmanned Aerial Vehicles (UAVs), leveraging their high mobility and on-demand deployment capability to enhance V2V communication under 6G networks. The model improves communication link quality and stability by utilizing the reflective properties of aerial RIS to mitigate signal attenuation and interference. This research develops a geometry-based Three-Dimensional (3D) dynamic channel model that incorporates the effects of UAV rotation, trajectory movement, and attitude changes on channel characteristics, enabling adaptation to dynamic and non-stationary communication scenarios. The findings provide a theoretical foundation for designing and optimizing RIS-assisted wireless communication systems through statistical analyses in the temporal, spatial, and frequency domains. Methods RIS can regulate incident electromagnetic waves to optimize communication system performance and are regarded as a crucial innovation in Sixth Generation (6G) wireless communication technology. Deploying RIS on UAVs effectively addresses reduced information transmission efficiency caused by obstacles such as trees and buildings, leveraging UAVs’ flexible trajectories and on-demand deployment capabilities. This study proposes a geometry-based 3D dynamic channel model, considering the UAV’s trajectory, three degrees of rotational freedom (pitch, yaw, and roll angles), and attitude changes. Channel propagation components are divided into aerial RIS array components and Non-Line-of-Sight (NLoS) components. Each RIS unit is modeled as an independent reflector capable of altering the propagation path by adjusting its phase and amplitude. The model incorporates time-varying spatial phases and Doppler frequency shifts, capturing the characteristics of dynamic propagation environments. Mathematical expressions for the Complex Impulse Responses (CIRs) are derived, along with analytical formulas for spatial Cross-Correlation Functions (CCFs), temporal Auto-Correlation Functions (ACFs), Frequency Correlation Functions (FCFs), and channel capacity. Various V2V communication scenarios are simulated by adjusting the velocity, direction, and acceleration of transmitters, receivers, and UAVs. Numerical simulations validate the proposed model’s effectiveness by defining four UAV trajectories and various vehicle motion states. Additionally, the temporal, spatial, and frequency correlation characteristics under different motion states are investigated. Finally, the effects of RIS physical attributes, such as the number and size of units, and UAV altitude on channel capacity are analyzed, along with dynamic variations in the power delay profile. Results and Discussions Simulation results demonstrate that the proposed channel model accurately captures channel characteristics. Specifically, the model presents various UAV flight trajectories (Fig. 5) and analyzes the temporal autocorrelation properties under different motion states of the transmitter and receiver (Fig. 6). It is observed that the temporal correlation exhibits significant non-stationarity across different motion states. However, the introduction of RIS significantly mitigates the decline in correlation. The model also compares the temporal autocorrelation properties corresponding to different UAV flight attitudes and altitudes (Fig. 7, Fig. 9). It is found that as the UAV’s initial altitude increases, multipath effects decrease, and the rate of decline in temporal autocorrelation function values gradually slows. Subsequently, the spatial cross-correlation of the proposed channel model is investigated for different propagation paths, revealing an increase in correlation with the Rician factor (Fig. 8). The frequency correlation function values are also examined under varying distances between the transmitter and receiver (Fig. 10), showing that while the correlation declines, it gradually stabilizes as the frequency interval increases. Finally, the impact of the RIS’s physical properties on channel capacity and the power delay profile is studied (Fig. 11, Fig. 12). It is observed that increasing the size and number of RIS array elements enhances channel capacity. Additionally, as delay increases, the power exhibits multiple smaller peaks before gradually decaying. These findings provide a valuable theoretical foundation for the future design and optimization of RIS-assisted wireless communication systems. Conclusions This paper presents a geometry-based 3D non-stationary channel model for V2V communications, innovatively incorporating aerial RIS implemented by UAVs equipped with RIS. The model accounts for the time-varying motion trajectories of ground vehicle terminals and UAVs, as well as the fading effects due to UAV attitude variations. Analytical expressions for spatiotemporal-frequency correlation functions and channel capacity are derived from the proposed model, ensuring the accuracy of channel transmission characteristics. By adjusting the model’s parameter configurations, it can accurately characterize the effects of various motion trajectories, dynamic states, UAV flight altitudes, and rotational angles on channel properties. These findings provide valuable insights for the design and performance analysis of RIS-assisted V2V communication systems.
- Vehicle-to-Vehicle(V2V) communications /
- Reconfigurable Intelligent Surface (RIS) /
- Unmanned Aerial Vehicle(UAV) /
- Channel model

HTML全文

圖 1 空中智能超表面輔助V2V無線傳輸示意

下載: 全尺寸圖片幻燈片

圖 2 無人機3維旋轉角度的解釋

下載: 全尺寸圖片幻燈片

圖 3 發射端和接收端的傳播鏈路

下載: 全尺寸圖片幻燈片

圖 4 無人機姿態變化對于空中RIS陣列分量信號傳輸路徑的影響

下載: 全尺寸圖片幻燈片

圖 5 無人機搭載RIS的4種運動軌跡

下載: 全尺寸圖片幻燈片

圖 6 空中智能反射面使能V2V信道模型在車輛不同運動狀態下的時間自相關特性

下載: 全尺寸圖片幻燈片

圖 7 空中智能反射面使能V2V信道模型在不同t時刻無人機飛行姿態下的時間自相關性

下載: 全尺寸圖片幻燈片

圖 8 空中智能反射面使能V2V通信信道模型在不同K值的空間互相關特性

下載: 全尺寸圖片幻燈片

圖 9 空中智能反射面使能V2V通信信道模型在不同無人機高度下的時域自相關特性

下載: 全尺寸圖片幻燈片

圖 10 空中智能反射面使能V2V通信信道模型在不同發射機和接收機距離下的頻率相關特性

下載: 全尺寸圖片幻燈片

圖 11 空中智能反射面使能V2V通信信道在不同RIS陣列單元數量和尺寸下對應的信道容量

下載: 全尺寸圖片幻燈片

圖 12 空中智能反射面使能V2V信道模型在不同t時刻的功率延遲分布

下載: 全尺寸圖片幻燈片

參考文獻(16)

[1]	YOU Xiaohu, WANG Chengxiang, HUANG Jie, et al. Towards 6G wireless communication networks: Vision, enabling technologies, and new paradigm shifts[J]. Science China Information Sciences, 2021, 64(1): 110301. doi: 10.1007/s11432-020-2955-6.
[2]	JIANG Hao, XIONG Baiping, ZHANG Hongming, et al. Physics-based 3D end-to-end modeling for double-RIS assisted non-stationary UAV-to-ground communication channels[J]. IEEE Transactions on Communications, 2023, 71(7): 4247–4261. doi: 10.1109/TCOMM.2023.3266832.
[3]	JIANG Hao, MUKHERJEE M, ZHOU Jie, et al. Channel modeling and characteristics for 6G wireless communications[J]. IEEE Network, 2021, 35(1): 296–303. doi: 10.1109/MNET.011.2000348.
[4]	HUA Boyu, NI Haoran, ZHU Qiuming, et al. Channel modeling for UAV-to-ground communications with posture variation and fuselage scattering effect[J]. IEEE Transactions on Communications, 2023, 71(5): 3103–3116. doi: 10.1109/TCOMM.2023.3255900.
[5]	JIANG Hao, YING Wen, ZHOU Jie, et al. A 3D wideband two-cluster channel model for massive MIMO Vehicle-to-vehicle communications in semi-ellipsoid environments[J]. IEEE Access, 2020, 8: 23594–23600. doi: 10.1109/ACCESS.2020.2970190.
[6]	SUN Guiqi, HE Ruisi, MA Zhangfeng, et al. A 3D geometry-based non-dtationary MIMO channel model for RIS-assisted communications[C]. 2021 IEEE 94th Vehicular Technology Conference, Norman, OK, USA, 2021: 1–5. doi: 10.1109/VTC2021-Fall52928.2021.9625374.
[7]	XIONG Baiping, ZHANG Zaichen, JIANG Hao, et al. A 3D non-stationary MIMO channel model for reconfigurable intelligent surface auxiliary UAV-to-ground mmWave communications[J]. IEEE Transactions on Wireless Communications, 2022, 21(7): 5658–5672. doi: 10.1109/TWC.2022.3142437.
[8]	張在琛, 江浩. 智能超表面使能無人機高能效通信信道建模與傳輸機理分析[J]. 電子學報, 2023, 51(10): 2623–2634. doi: 10.12263/DZXB.20221352. ZHANG Zaichen and JIANG Hao. Channel modeling and characteristics analysis for high energy-efficient RIS-assisted UAV communications[J]. Acta Electronica Sinica, 2023, 51(10): 2623–2634. doi: 10.12263/DZXB.20221352.
[9]	MA Zhangfeng, AI Bo, HE Ruisi, et al. A non-stationary geometry-based MIMO channel model for millimeter-wave UAV networks[J]. IEEE Journal on Selected Areas in Communications, 2021, 39(10): 2960–2974. doi: 10.1109/JSAC.2021.3088659.
[10]	JIANG Hao, RUAN Chengyao, ZHANG Zaichen, et al. A general wideband non-stationary stochastic channel model for intelligent reflecting surface-assisted MIMO communications[J]. IEEE Transactions on Wireless Communications, 2021, 20(8): 5314–5328. doi: 10.1109/TWC.2021.3066806.
[11]	陳新穎, 盛敏, 李博, 等. 面向6G的無人機通信綜述[J]. 電子與信息學報, 2022, 44(3): 781–789. doi: 10.11999/JEIT210789. CHEN Xinying, SHENG Min, LI Bo, et al. Survey on unmanned aerial vehicle communications for 6G[J]. Journal of Electronics & Information Technology, 2022, 44(3): 781–789. doi: 10.11999/JEIT210789.
[12]	LIU Shaoyi, MA Nan, CHEN Yaning, et al. A wideband MIMO channel model for aerial intelligent reflecting surface-assisted wireless communications[C]. 2023 IEEE Globecom Workshops (GC Wkshps), Kuala Lumpur, Malaysia, 2023: 1487–1492. doi: 10.1109/GCWkshps58843.2023.10464958.
[13]	XIONG Baiping, ZHANG Zaichen, JIANG Hao, et al. A statistical MIMO channel model for reconfigurable intelligent surface assisted wireless communications[J]. IEEE Transactions on Communications, 2022, 70(2): 1360–1375. doi: 10.1109/TCOMM.2021.3129926.
[14]	XIONG Baiping, ZHANG Zaichen, PAN Cunhua, et al. Performance analysis of aerial RIS auxiliary mmWave mobile communications with UAV fluctuation[J]. IEEE Wireless Communications Letters, 2024, 13(4): 1183–1187. doi: 10.1109/LWC.2024.3364831.
[15]	CHANG Hengtai, WANG Chengxiang, LIU Yu, et al. A novel nonstationary 6G UAV-to-ground wireless channel model with 3-D arbitrary trajectory changes[J]. IEEE Internet of Things Journal, 2021, 8(12): 9865–9877. doi: 10.1109/JIOT.2020.3018479.
[16]	SHI Wangqi, JIANG Hao, XIONG Baiping, et al. RIS-empowered V2V communications: Three-dimensional beam domain channel modeling and analysis[J]. IEEE Transactions on Wireless Communications, 2024, 23(11): 15844–15857. doi: 10.1109/TWC.2024.3434568.
