基于多域雷達回波數據融合的海面小目標分類網絡模型

趙子健; 許述文; 水鵬朗

doi:10.11999/JEIT240818

基于多域雷達回波數據融合的海面小目標分類網絡模型

doi: 10.11999/JEIT240818 cstr: 32379.14.JEIT240818

西安電子科技大學雷達信號處理全國重點實驗室西安 710071

基金項目: 國家自然科學基金(62371382)

詳細信息

作者簡介:
趙子?。耗?，博士生，研究方向?yàn)楹Ｃ嫘∧繕?biāo)識別、深度學習、機器學習、目標檢測等

許述文：男，教授，研究方向?yàn)槔走_(dá)目標檢測與識別、機器學習、時頻分析、SAR圖像處理等

水鵬朗：男，教授，研究方向?yàn)楹ｋs波建模、雷達目標檢測與識別、圖像處理等

通訊作者:
水鵬朗　plshui@xidian.edu.cn

中圖分類號: TN957.52
計量
- 文章訪問數: 412
- HTML全文瀏覽量: 136
- PDF下載量: 70
- 被引次數: 0
出版歷程
- 收稿日期: 2024-09-24
- 修回日期: 2025-02-21
- 網絡出版日期: 2025-03-06
- 刊出日期: 2025-03-01

A Network Model for Sea Surface Small Targets Classification Based on Multidomain Radar Echo Data Fusion

National Key Laboratory of Radar Signal Processing, Xidian University, Xi’an 710071, China

Funds: The National Natural Science Foundation of China (62371382)

摘要

摘要: 海面小目標識別是海事雷達監視任務中一個重要且具有挑戰性的問題。由于海面小目標類型多樣、環境復雜多變，對其進行有效分類存在較大困難。在高分辨體制雷達下，海面小目標通常只占據一或幾個距離單元，缺乏足夠的空間散射結構信息，因此目標的雷達截面積(RCS)起伏和徑向速度變化成為分類的主要依據。為此，該文提出一種基于多域雷達回波數據融合的分類網絡模型，用于海面小目標的分類任務。由于不同域的數據具有其特殊的物理意義，因此該文構建了時域LeNet(T-LeNet)神經網絡模塊和時頻特征提取神經網絡模塊，分別從雷達海面回波信號的幅度序列和時頻分布(TFD)即時頻圖中提取特征。其中幅度序列主要反映了目標RCS的起伏特性，而時頻圖不僅反映RCS起伏特性，還能體現目標徑向速度的變化。最后，利用IPIX, CSIR數據庫和自測的無人機數據集構建了包括4種海面小目標的數據集：錨定漂浮小球、漂浮船只、低空無人機(UAV)和移動的快艇。實驗結果表明所提方法具有良好的識別能力。
- 海面小目標 /
- 目標分類 /
- 多特征融合 /
- 神經網絡
Abstract: Objective Small target recognition on the sea surface is a critical and challenging task in maritime radar surveillance. The variety of small targets and the complexity of the sea surface environment make their classification difficult. Due to the small size of these targets, typically occupying only one or a few range cells under high-resolution radar systems, there is insufficient spatial scattering structure information for classification. The primary information for classification comes from the target’s Radar Cross Section (RCS) fluctuation and radial velocity change. This study proposes a classification network model based on multidomain radar echo data fusion, providing a theoretical foundation for small target recognition in complex sea surface environments. Methods A small marine target classification network model is proposed, based on multidomain radar echo data fusion, incorporating both time domain and time-frequency domain. Given that data from different domains hold distinct physical significance, a Time-domain LeNet (T-LeNet) neural network module and a time-frequency feature extraction neural network module are designed to extract features from the amplitude sequence and the Time-Frequency Distribution (TFD), respectively. The amplitude sequence primarily reflects the fluctuation characteristics of the target’s RCS, while the TFD captures both the RCS fluctuations and variations in the target’s radial velocity. By extracting deep information from small sea surface targets, effective differential features are obtained, leading to improved classification results. The advantages of the multidomain data fusion approach are validated through ablation experiments, where the amplitude sequence is fused with the input TFD, or the TFD is fused with the input amplitude sequence. Additionally, the effect of network depth on recognition performance is explored by using ResNet architectures with varying depths for time-frequency feature extraction. Results and Discussions A dataset containing four types of small sea surface targets is constructed using measured data to evaluate the effectiveness of the proposed method. Six evaluation metrics are used to assess the model’s classification ability. The experimental results show that when only the TFD is input, the best recognition performance is achieved by the ResNet18 network. This is due to ResNet18’s ability to prevent gradient vanishing and explosion through residual connections, enabling a deeper network capable of more effectively extracting differential features between targets. When only the amplitude sequence is input, the recognition performance of the T-LeNet network improves significantly compared to the performance with only the TFD input. Fusing the amplitude sequence with the T-LeNet network, based solely on the input of the TFD, leads to a notable increase in recognition performance. Thus, incorporating information from other domains, such as time-domain information (amplitude sequence), and extracting abstract features from one-dimensional data with T-LeNet, while also capturing deeper target features from multidomain and multidimensional aspects, significantly enhances the network’s recognition capability. The best recognition performance occurs when both the amplitude sequence and TFD are input using the ResNet18 network, achieving an accuracy of 97.21%, which represents a 21.1% improvement over the TFD-only input with the Vgg16 network (Table 3). The confusion matrix reveals that Class I and Class II targets are more accurately classified when using only the amplitude sequence, with average accuracy improvements of 5.5% and 85.1%, respectively, compared to the TFD-only input. Class IV targets are better classified when using only the TFD, with an average accuracy improvement of 5.5% compared to the amplitude sequence input. There is no significant difference in the accuracy of Class III targets (Fig. 5). Comparing the classification results of different ResNet networks shows that increasing the depth of the ResNet network does not significantly enhance recognition performance (Table 4). Analyzing the loss and accuracy of the various experiments in both the training and validation sets reveals that combining the T-LeNet network improves performance further. Specifically, the accuracy of AlexNet, Vgg16, and ResNet18 in the validation set improves by approximately 7.7%, 5.3% and 3.6%, respectively, while the loss in both the training and validation sets decreases (Fig. 6). Conclusions This paper proposes a small sea surface target classification method based on Convolutional Neural Networks (CNN) and data fusion. The method considers both the time domain and time-frequency domain, leveraging their distinct physical significance. It constructs the T-LeNet network module and the time-frequency feature extraction network module to extract deep information from small sea surface targets across multiple domains and dimensions. The abstract features jointly extracted from the time domain and time-frequency domain are fused for multidomain and multidimensional classification. The experimental results demonstrate that the proposed method exhibits strong recognition capability for small sea surface targets.
- Sea Surface Small target /
- Target classification /
- Multi-feature fusion /
- Neural network

HTML全文

圖 1 4種海面小目標

下載: 全尺寸圖片幻燈片

圖 2 4類目標的幅度序列和時頻圖示例

下載: 全尺寸圖片幻燈片

圖 3 目標識別網絡流程圖

下載: 全尺寸圖片幻燈片

圖 4 網絡結構

下載: 全尺寸圖片幻燈片

圖 5 混淆矩陣

下載: 全尺寸圖片幻燈片

圖 6 不同實驗在訓練集和驗證集的損失與準確率

下載: 全尺寸圖片幻燈片

表 1 4類目標與其對應的雷達參數

目標類型	數據來源	距離分辨率	重頻(kHz)	載頻(GHz)	極化方式	工作模式	波束寬度(°)	海況(級)	訓練樣本數	測試樣本數
錨定漂浮小球	IPIX93	30	1	9.39	HH/HV/VH/VV	駐留模式	0.9	2/3	21940	6560
漂浮船只	IPIX98	30	1	9.39	HH/HV/VH/VV	駐留模式	0.9	/	12768	3416
低空無人機	靈山島	3	4	10.00	HH/VV	駐留模式	1.1	2	7569	1 893
移動的快艇	CSIR	15	2.5/5	6.90	VV	跟蹤模式	1.8	3	2920	964

下載: 導出CSV

表 2 混淆矩陣

		預測類別
		目標1	目標2	目標3	目標4
真實類別	目標1	T₁P₁	F₁P₂	F₁P₃	F₁P₄
	目標2	F₂P₁	T₂P₂	F₂P₃	F₂P₄
	目標3	F₃P₁	F₃P₂	T₃P₃	F₃P₄
	目標4	F₄P₁	F₄P₂	F₄P₃	T₄P₄

下載: 導出CSV

表 3 不同實驗在6個評價指標下的分類結果

	準確率	誤差	精確度	召回率	F1-measure	Kappa
時頻圖+AlexNet	0.7773	0.2227	0.8139	0.7912	0.8024	0.6403
時頻圖+Vgg16^[5]	0.8022	0.1978	0.8461	0.8202	0.8330	0.6792
時頻圖+ResNet18	0.8145	0.1855	0.8487	0.8238	0.8361	0.7006
幅度序列+T-LeNet	0.9250	0.0750	0.9145	0.9130	0.9138	0.8823
幅度序列+時頻圖+T-LeNet+AlexNet	0.9426	0.0574	0.9440	0.9528	0.9484	0.9106
幅度序列+時頻圖+T-LeNet+Vgg16	0.9549	0.0451	0.9558	0.9578	0.9568	0.9296
幅度序列+時頻圖+T-LeNet+ResNet18	0.9721	0.0279	0.9708	0.9776	0.9742	0.9567

下載: 導出CSV

表 4 不同ResNet網絡在6個評價指標下的分類結果

	準確率	誤差	精確度	召回率	F1-measure	Kappa
時頻圖+ResNet18	0.8145	0.1855	0.8487	0.8238	0.8361	0.7006
時頻圖+ResNet34	0.8245	0.1755	0.8677	0.8379	0.8525	0.7165
時頻圖+ResNet50	0.8202	0.1798	0.8619	0.8359	0.8487	0.7100
幅度序列+時頻圖+T-LeNet+ResNet18	0.9721	0.0279	0.9708	0.9776	0.9742	0.9567
幅度序列+時頻圖+T-LeNet+ResNet34	0.9726	0.0274	0.9729	0.9775	0.9752	0.9574
幅度序列+時頻圖+T-LeNet+ResNet50	0.9736	0.0264	0.9707	0.9777	0.9742	0.9589

下載: 導出CSV

表 5 網絡的參數量、訓練時間、測試時間和單個樣本測試時間

網絡	參數量(M)	訓練時間	測試時間	單個樣本測試時間
T-LeNet	8.4669	7.25	23.87	1.86
AlexNet	61.1048	87.13	46.97	3.66
Vgg16	138.3651	216.15	55.05	4.29
ResNet18	11.1786	120.12	45.94	3.58
ResNet34	21.2867	195.19	72.65	5.66
ResNet50	23.5162	330.33	136.33	10.62
T-LeNet+AlexNet	71.7922	95.37	51.46	4.01
T-LeNet+Vgg16	149.0489	233.67	59.67	4.65
T-LeNet+ResNet18	21.7429	130.32	50.69	3.95
T-LeNet+ResNet34	31.8511	203.62	85.37	6.65
T-LeNet+ResNet50	34.4677	342.09	145.39	11.33

下載: 導出CSV
