DroneRFb-DIR: 用于非合作無人機個體識別的射頻信號數據集

任俊宇; 俞寧寧; 周成偉; 史治國; 陳積明

doi:10.11999/JEIT240804

DroneRFb-DIR: 用于非合作無人機個體識別的射頻信號數據集

doi: 10.11999/JEIT240804 cstr: 32379.14.JEIT240804

任俊宇^{1, 2},
俞寧寧^{1, 2},
周成偉^{1, 2},
史治國^{1, 4, ,},
陳積明^{2, 3}

1.
浙江大學信息與電子工程學院杭州 310027
2.
浙江大學工業控制技術全國重點實驗室杭州 310027
3.
杭州電子科技大學自動化學院杭州 310018
4.
浙江大學金華研究院金華 321037

基金項目: 國家自然科學基金(U21A20456, 62271444)，中央高?；究蒲袠I(yè)務費(226-2023-00111, 226-2024-00004)

詳細信息

作者簡介:
任俊宇：男，博士生，研究方向?yàn)榉礋o人機檢測識別、信號估計等

俞寧寧：男，博士生，研究方向?yàn)榉礋o人機檢測、電磁頻譜認知、信號識別等

周成偉：男，博士，研究員，研究方向?yàn)殛嚵行盘?hào)處理、張量信號處理、無人機智能監測技術等

史治國：男，博士，教授，研究方向?yàn)樾盘?hào)處理及其定位應用、物聯網等

陳積明：男，博士，教授，研究方向?yàn)榫W(wǎng)絡優化與控制、網絡系統安全、工業大數據與物聯網等

通訊作者:
史治國　shizg@zju.edu.cn

中圖分類號: TN975
計量
- 文章訪問數: 1322
- HTML全文瀏覽量: 399
- PDF下載量: 303
- 被引次數: 0
出版歷程
- 收稿日期: 2024-09-19
- 修回日期: 2025-02-21
- 網絡出版日期: 2025-02-26
- 刊出日期: 2025-03-01

DroneRFb-DIR: An RF Signal Dataset for Non-cooperative Drone Individual Identification

REN Junyu^{1, 2},
YU Ningning^{1, 2},
ZHOU Chengwei^{1, 2},
SHI Zhiguo^{1, 4
, ,},
CHEN Jiming^{2, 3}

1.
College of Information Science and Electronic Engineering, Zhejiang University, Hangzhou 310027, China
2.
State Key Laboratory of Industrial Control Technology, Zhejiang University, Hangzhou 310027, China
3.
School of Automation, Hangzhou Dianzi University, Hangzhou 310018, China
4.
Jinhua Institute of Zhejiang University, Jinhua 321037, China

Funds: The National Natural Science Foundation of China (U21A20456, 62271444), The Fundamental Research Funds for Central Universities (226-2023-00111, 226-2024-00004)

摘要

摘要: 無人機射頻檢測是實現非合作無人機管控的手段之一，而基于射頻信號的無人機個體識別(DIR)是無人機檢測的重要環節。鑒于當前DIR開源數據集缺失，該文公開了一個名為DroneRFb-DIR的無人機射頻信號數據集。該數據集使用軟件無線電設備采集無人機與遙控器間通信的射頻信號，包含城市場景下的無人機種類共6類(每類無人機各包含3架不同個體)以及1類背景參考信號。采樣信號存儲為最原始的I/Q數據，每類數據包含不少于40個片段，每個片段包含不少于4 M個采樣點。信號采集范圍為2.4～2.48 GHz，包含無人機飛控信號、圖傳信號以及周圍干擾設備的信號。該數據集包含詳細的個體編號和視距或非視距場景標注，并已劃分訓練集與測試集，以便于用戶進行識別算法驗證和性能對比分析。與此同時，該文提供了一種基于快速頻率估計和時域相關分析的無人機個體識別方法，并在該數據集上驗證了所提方法的有效性。
- 無人機個體識別 /
- 頻譜感知 /
- 非合作無人機 /
- 射頻檢測數據集
Abstract: RF-based drone detection is an essential method for managing non-cooperative drones, with Drone Individual Recognition (DIR) via RF signals being a key component in the detection process. Given the current scarcity of DIR datasets, this paper proposes an open-source DroneRFb-DIR dataset for RF-based DIR. The dataset is constructed by capturing RF signals exchanged between drones and their remote controllers using a Software-Defined Radio (SDR). It includes signals from six types of drones, each with three different individuals, as well as background signals from urban environments. The captured signals are stored in raw I/Q format, and each drone type consists of over 40 signal segments, with each segment containing more than 4 million sample points. The RF sampling range spans from 2.4 GHz to 2.48 GHz, covering Flight Control Signals (FCS), Video Transmission Signals (VTS), and interference from surrounding devices. The dataset is annotated with entity identifiers (e.g., drone type and individual) and environmental labels (line-of-sight vs. non-line-of-sight). A DIR method based on fast frequency estimation and time-domain correlation analysis is also proposed and validated using this dataset. Objective: Drones are increasingly used in sectors such as geospatial mapping, aerial photography, traffic monitoring, and disaster relief, playing a significant role in modern industries and daily life. However, the rise in unauthorized drone operations presents serious threats to national security, public safety, and privacy, especially in urban areas. While existing methods emphasize general drone detection and classification, they struggle to distinguish individual drones of the same type, which is crucial for distinguishing friend from foe, analyzing swarm dynamics, and implementing effective countermeasures. This study addresses this gap by introducing the DroneRFb-DIR dataset, a large-scale, open-source RF signal dataset for non-cooperative DIR. Additionally, a novel method based on fast frequency estimation and time-domain correlation analysis is proposed to achieve accurate drone identification in urban environments. Methods: The DroneRFb-DIR dataset is developed using SDR device to capture RF signals in an urban environment with interference from devices like Wi-Fi and Bluetooth. It includes signals from six drone types, each with three individual units, as well as background reference signals. The dataset is collected at an 80 MHz sampling rate in the 2.4～2.48 GHz band and stored in raw I/Q format for detailed analysis. Each signal is annotated with identifiers (e.g., drone type and individual) and scene labels (line-of-sight and non-line-of-sight). For algorithm validation, the dataset is partitioned into training and testing sets. The proposed method consists of three key stages: (1) Signal Detection: A dynamic bandpass or band-stop filter isolates drone control signals from background noise and interference. (2) Frequency Localization: Adaptive filtering and frequency estimation to identify the spectral location of drone signals. (3) Identity Feature Extraction: Correlation analysis extracts identity features from control signal segments to differentiate individual drones, focusing on unique frequency modulation patterns. Results and Discussions: The dataset comprises 4,690 signal segments, each containing with over 4 million sample points. Experiments demonstrated the effectiveness of the proposed method (Table 3), showing high rejection rates of background signals and accurate identification of specific drone types. However, performance varied across drone types due to factors such as signal quality, environmental interference, and control signal characteristics. For instance, drones with low-SNR signals or less distinct frequency modulation patterns posed greater challenges for identification. Despite these difficulties, the method achieved competitive accuracy in identifying individual drones, even in non-line-of-sight conditions. These findings underscore the importance of advanced filtering and feature extraction for robust DIR in complex urban environments. Conclusions: This study addresses the critical need for DIR technologies by introducing the DroneRFb-DIR dataset and a novel identification method. Featuring six drone types, 18 individual drones, and one background signal class, the dataset is the first large-scale open-source resource for non-cooperative DIR in urban scenarios (Table 2). The proposed method effectively separates drone signals from interference and accurately identifies individual drones. Future work will focus on expanding the dataset with more diverse drone types, additional environmental scenarios (e.g., multipath interference and dynamic drone states), and machine learning models for improved recognition. Optimization of non-learning methods will also be explored to enhance feature extraction and identification rates, especially for drones with weaker signal characteristics.
- Drone individual Recognition (DIR) /
- Spectrum sensing /
- Non-cooperative drone /
- RF detection dataset

HTML全文

圖 1 數據采集場景

下載: 全尺寸圖片幻燈片

圖 2 DJI Mavic 3 Pro無人機信號時頻圖

下載: 全尺寸圖片幻燈片

圖 3 無人機圖傳(紅色實線框)與飛控信號(藍色實線框)特征示意

下載: 全尺寸圖片幻燈片

圖 4 寬帶信號的檢出流程

下載: 全尺寸圖片幻燈片

圖 5 DJI Mavic 3 Pro的無人機飛控信號時頻圖

下載: 全尺寸圖片幻燈片

圖 6 相鄰兩個時間窗FFT譜圖

下載: 全尺寸圖片幻燈片

圖 7 無人機飛控信號組成

下載: 全尺寸圖片幻燈片

圖 8 無人機個體飛控信號相關性曲線

下載: 全尺寸圖片幻燈片

表 1 無人機探測手段特點

探測手段	最大有效距離	原理	缺點
雷達	8000	微多普勒	無人機雷達截面積小，成本高，不適合城市場景
音頻	200	時頻特征	覆蓋范圍小，受噪聲影響大
視覺	1500	外觀特征和運動特征	受遮擋、天氣環境影響大
射頻	5000	通信信道	易受城市環境下干擾信號影響

下載: 導出CSV

表 2 個體標簽與型號對應關系

個體標簽	型號
A1, A2, A3	DJI Mavic 3 Pro
B	背景
C1, C2, C3	DJI Mini 2 SE
D1, D2, D3	DJI Mini 4 Pro
E1, E2, E3	DJI Mini 3
F1, F2, F3	DJI Air 3
G1, G2, G3	DJI Air 2S

下載: 導出CSV

表 3 無人機個體識別結果

種類標簽	識別率(%)
A	63.96
B	100.00
C	60.74
D	29.63
E	68.62
F	37.50
G	67.95

下載: 導出CSV
