密集低軌衛星網絡輔助地面通信的魯棒波束賦形方法

鄭斌; 曾令昕; 黃輝; 王曉洪; 丁昌峰; 王金元

doi:10.11999/JEIT240732

密集低軌衛星網絡輔助地面通信的魯棒波束賦形方法

doi: 10.11999/JEIT240732 cstr: 32379.14.JEIT240732

1.
中國星網網絡應用有限公司重慶 401123
2.
南京郵電大學通信與信息工程學院南京 210003

基金項目: 重慶市自然科學聯合基金項目(CSTB2023NSCQ-LZX0121)，南京郵電大學引進人才科研啟動基金項目(自然科學)(NY223024)，東南大學移動通信全國重點實驗室開放研究基金資助課題(2024D11)，交通物聯網技術湖北省重點實驗室開放基金

詳細信息

作者簡介:
鄭斌：男，高級工程師，研究方向?yàn)榛鶐酒?、衛星通信算法

曾令昕：男，高級工程師，研究方向?yàn)樯漕l芯片、衛星通信算法

黃輝：女，高級工程師，研究方向?yàn)樾l(wèi)星通信算法、數字信號處理與實現

王曉洪：女，高級工程師，研究方向?yàn)樾l(wèi)星通信、衛星導航信號處理

丁昌峰：男，講師，研究方向?yàn)樾l(wèi)星通信、邊緣計算和通感一體化技術等

王金元：男，副教授，研究方向?yàn)榭梢?jiàn)光通信、無線通信資源優化等

通訊作者:
丁昌峰　cfding@njupt.edu.cn

中圖分類號: TN927.2
計量
- 文章訪問數: 314
- HTML全文瀏覽量: 112
- PDF下載量: 62
- 被引次數: 0
出版歷程
- 收稿日期: 2024-08-26
- 修回日期: 2025-02-11
- 網絡出版日期: 2025-02-19
- 刊出日期: 2025-03-01

Robust Beamforming Method for Dense LEO Satellite Network Assisted Terrestrial Communication

1.
China Satellite Network Exploration Co., Ltd., Chongqing 401123, China
2.
School of Communications and Information Engineering, Nanjing University of Posts and Telecommunications, Nanjing 210003, China

Funds: Chongqing Natural Science Joint Fund Project (CSTB2023NSCQ-LZX0121), The Natural Science Research Start-up Foundation of Recruiting Talents of Nanjing University of Posts and Telecommunications (NY223024). The Open Research Fundation of National Mobile Communications Research Laboratory, Southeast University (2024D11), The Open Research Fundation of Hubei Key Laboratory of Transportation Internet of Things, China

摘要

摘要: 面向密集低軌道衛星網絡輔助的星地?zé)o線通信系統，該文提出一種基于非完美信道狀態信息的多低軌衛星魯棒波束賦形方法來改善頻譜效率。具體地，在多低軌衛星全頻復用場景下，提出了一個多衛星下行通信系統和速率最大化問題，并聯合考慮衛星發射功率、衛星與用戶關聯關系，以及饋線鏈路容量約束。為了求解該優化問題，原優化問題被分解成衛星-用戶關聯和衛星傳輸波束賦形兩個子問題，然后使用加權最小均方誤差方法和連續凸近似方法對問題進行求解。仿真結果驗證了即使在非理想信道條件下，該文所提出的多星頻率復用和魯棒波束賦形設計方法能有效提高系統吞吐量。
- 密集LEO衛星 /
- MIMO /
- 魯棒波束賦形 /
- 頻率復用
Abstract: A robust beamforming method based on imperfect Channel State Information (CSI) is proposed for dense Low-Earth Orbit (LEO) satellite network-assisted terrestrial wireless communication systems to enhance spectral efficiency. Specifically, in scenarios where multiple LEO satellites use full frequency reuse, a multi-LEO satellite downlink sum rate maximization problem is formulated, considering constraints on satellite transmit power, satellite-User Terminal (UT) association, and satellite feeder link capacity. To solve the optimization problem, it is decomposed into two subproblems: satellite-UT association and satellite transmit beamforming. Weighted minimum mean-squared error and successive convex approximation methods are then employed to address the non-convex challenges. Simulation results confirm that the proposed multi-satellite full frequency reuse scheme and robust beamforming design effectively improve system throughput, even under non-ideal channel conditions. Objective As the LEO satellite constellation becomes denser, spectrum resources will become scarcer, and co-channel interference among satellites will intensify. Therefore, transmission methods with higher spectrum efficiency are needed. To mitigate the effects of severe satellite-terrestrial wireless channels and enhance system throughput, multi-beam beamforming and phased-array antennas are employed in LEO satellites to achieve higher antenna gain. However, most existing studies assume perfect knowledge of CSI, which is often impractical. Therefore, considering the complex satellite-terrestrial channel conditions and channel estimation errors, a robust beamforming method is preferable. Under dense satellite constellations, the increasing number of satellites and the presence of inter-satellite co-channel interference make the design of robust transmission methods for multi-LEO satellite networks essential. Thus, this paper aims to investigate the design of an efficient robust beamforming method for dense LEO satellite networks under given channel uncertainty. Methods To enable frequency reuse across multiple LEO satellites, this paper proposes a dense LEO satellite network architecture that incorporates a gateway or Geostationary Earth Orbit (GEO) satellite as the centralized controller. In this system architecture, multiple LEO satellites can reuse spectrum, thereby improving spectral efficiency. Additionally, a system sum-rate maximization problem is formulated, considering imperfect Angular-Of-Arrival (AoA) based CSI. The problem incorporates constraints on satellite-user association, multi-satellite downlink transmit beamforming, and satellite feeder link capacity. Results and Discussions The simulation results show that the system sum-rate increases with the satellite transmit power budget, as higher transmit power improves received signal quality (Fig. 3). Additionally, the proposed robust beamforming method significantly enhances the system sum-rate compared to existing methods (Fig. 3). Furthermore, the results indicate that the communication rate of the UT is constrained by satellite feeder link capacity, and higher feeder link capacity leads to an increase in the system sum-rate (Fig. 4). However, the rate of increase in the system sum-rate slows once the satellite feeder link capacity exceeds a certain threshold. The results also reveal that larger AoA uncertainty reduces the system sum-rate, highlighting the significant impact of AoA uncertainty on system performance (Fig. 5). Lastly, increasing the number of antennas effectively improves channel quality and further increases the system sum-rate (Fig. 6). Conclusions This paper investigates a robust beamforming method for dense LEO satellite networks and proposes a full frequency reuse scheme to enhance spectral efficiency and increase system throughput. Given the challenges in obtaining accurate CSI, an angular-information-based channel uncertainty model is adopted to reflect non-ideal channel conditions. A system sum-rate maximization problem is then formulated to evaluate system performance, considering satellite-UT association and satellite transmit beamforming. To address the non-convex optimization problem, the WMMSE and SCA methods are employed. Simulation results demonstrate that channel uncertainty significantly impacts system performance. When channel uncertainty is small, the performance gap between the proposed robust beamforming method and the ideal CSI case is minimal. Furthermore, the proposed multi-LEO satellite robust beamforming method outperforms other existing schemes.
- Dense LEO satellites /
- MIMO /
- Robust beamforming /
- Frequency reuse

HTML全文

圖 1 密集LEO衛星輔助地面通信網絡模型

下載: 全尺寸圖片幻燈片

圖 2 衛星和UT的幾何關系

下載: 全尺寸圖片幻燈片

圖 3 系統和速率與衛星發射功率的關系

下載: 全尺寸圖片幻燈片

圖 4 系統和速率與衛星發射功率以及回程鏈路容量的關系

下載: 全尺寸圖片幻燈片

圖 5 系統和速率與AoA不確定性$\varDelta $的關系

下載: 全尺寸圖片幻燈片

圖 6 系統和速率與衛星天線數量的關系

下載: 全尺寸圖片幻燈片

1 求解問題式(9)的迭代優化算法

1：初始化:給定可行的波束賦形向量$\left\{ {{\boldsymbol{w}}_{s,i}^{\left( 0 \right)}} \right\}$和二進制關聯值$\left\{ {a_{i,s}^{\left( 0 \right)}} \right\}$，設置容差$\varepsilon \gt 0$，迭代索引$n = 0$，最大迭代次數${N_{\max }}$。
2：repeat
3：根據式(10)，將不確定信道進行均勻離散化；
4：給定$\left\{ {{\boldsymbol{w}}_{s,i}^{\left( n \right)}} \right\}$，更新$v_{s,i}^{{\text{opt}}}$, $ u_{s,i}^{{\text{opt}}} $和$e_{s,i}^{{\text{opt}}}$，得到式(14)中的$ {\tilde R_{s,i}} $；
5：給定$\left\{ {{\boldsymbol{w}}_{s,i}^{\left( n \right)}} \right\}$和$\left\{ {a_{i,s}^{\left( n \right)}} \right\}$，利用內點法求解問題式(15)得到$\left\{ {a_{i,s}^{\left( {n + 1} \right)}} \right\}$。
6：給定$\left\{ {a_{i,s}^{\left( {n + 1} \right)}} \right\}$，得到式(16)中的$ {\tilde R_{s,i}} $；
7：給定$\left\{ {{\boldsymbol{w}}_{s,i}^{\left( n \right)}} \right\}$和$\left\{ {a_{i,s}^{\left( {n + 1} \right)}} \right\}$，采用式(19)，得到${\tilde R_{s,i}}$的上界$\tilde R_{s,i}^{\mathrm{U}}$；
8：給定$\left\{ {{\boldsymbol{w}}_{s,i}^{\left( n \right)}} \right\}$和$\left\{ {a_{i,s}^{\left( {n + 1} \right)}} \right\}$，利用內點法求解問題式(20)得到$\left\{ {{\boldsymbol{w}}_{s,i}^{\left( {n + 1} \right)}} \right\}$。
9：設置$ n = n + 1 $。
10：Until：目標函數式(9)收斂或者$n = {N_{\max }}$。

下載: 導出CSV

參考文獻(23)

[1]	ALSENWI M, LAGUNAS E, and CHATZINOTAS S. Robust beamforming for massive MIMO LEO satellite communications: A risk-aware learning framework[J]. IEEE Transactions on Vehicular Technology, 2024, 73(5): 6560–6571. doi: 10.1109/TVT.2023.3338065.
[2]	SU Yongtao, LIU Yaoqi, ZHOU Yiqing, et al. Broadband LEO satellite communications: Architectures and key technologies[J]. IEEE Wireless Communications, 2019, 26(2): 55–61. doi: 10.1109/MWC.2019.1800299.
[3]	WITZE A. SpaceX launch highlights threat to astronomy from ‘megaconstellations’[J]. Nature, 2019, 575(7782): 268–269. doi: 10.1038/d41586-019-03446-y.
[4]	DAHM J M. China C4ISR and counter-intervention[R]. 2024.
[5]	HEO J, SUNG S, LEE H, et al. MIMO satellite communication systems: A survey from the PHY layer perspective[J]. IEEE Communications Surveys & Tutorials, 2023, 25(3): 1543–1570. doi: 10.1109/COMST.2023.3294873.
[6]	王朝煒, 龐明亮, 王粟, 等. 基于決策性能評估的多波束低地球軌道衛星網絡資源分配算法[J]. 通信學報, 2024, 45(7): 37–47. doi: 10.11959/j.issn.1000-436x.2024040. WANG Chaowei, PANG Mingliang, WANG Su, et al. Resource allocation algorithm for multi-beam LEO satellite based on decision performance evaluation[J]. Journal on Communications, 2024, 45(7): 37–47. doi: 10.11959/j.issn.1000-436x.2024040.
[7]	VáZQUEZ M á, PéREZ-NEIRA A, CHRISTOPOULOS D, et al. Precoding in multibeam satellite communications: Present and future challenges[J]. IEEE Wireless Communications, 2016, 23(6): 88–95. doi: 10.1109/MWC.2016.1500047WC.
[8]	PEREZ-NEIRA A I, VAZQUEZ M A, SHANKAR M R B, et al. Signal processing for high-throughput satellites: Challenges in new interference-limited scenarios[J]. IEEE Signal Processing Magazine, 2019, 36(4): 112–131. doi: 10.1109/MSP.2019.2894391.
[9]	YOU Li, LI Kexin, WANG Jiaheng, et al. Massive MIMO transmission for LEO satellite communications[J]. IEEE Journal on Selected Areas in Communications, 2020, 38(8): 1851–1865. doi: 10.1109/JSAC.2020.3000803.
[10]	DI Boya, ZHANG Hongliang, SONG Lingyang, et al. Ultra-dense LEO: Integrating terrestrial-satellite networks into 5G and beyond for data offloading[J]. IEEE Transactions on Wireless Communications, 2019, 18(1): 47–62. doi: 10.1109/TWC.2018.2875980.
[11]	LIN Zhiyuan, NI Zuyao, KUANG Linling, et al. Multi-satellite beam hopping based on load balancing and interference avoidance for NGSO satellite communication systems[J]. IEEE Transactions on Communications, 2023, 71(1): 282–295. doi: 10.1109/TCOMM.2022.3226190.
[12]	ZHANG Xuan, SUN Shu, TAO Meixia, et al. Multi-satellite cooperative networks: Joint hybrid beamforming and user scheduling design[J]. IEEE Transactions on Wireless Communications, 2024, 23(7): 7938–7952. doi: 10.1109/TWC.2023.3346463.
[13]	HUANG Jing and SWINDLEHURST A L. Robust secure transmission in MISO channels based on worst-case optimization[J]. IEEE Transactions on Signal Processing, 2012, 60(4): 1696–1707. doi: 10.1109/TSP.2011.2182344.
[14]	LIN Zhi, LIN Min, HUANG Yongming, et al. Robust multi-objective beamforming for integrated satellite and high altitude platform network with imperfect channel state information[J]. IEEE Transactions on Signal Processing, 2019, 67(24): 6384–6396. doi: 10.1109/TSP.2019.2952045.
[15]	吳翠先, 董燚恒, 徐勇軍, 等. 基于不完美CSI的低軌衛星通信系統魯棒資源分配算法[J]. 電子與信息學報, 2024, 46(2): 671–679. doi: 10.11999/JEIT230086. WU Cuixian, DONG Yiheng, XU Yongjun, et al. Robust resource allocation algorithm for low orbit satellite communication system based on imperfect CSI[J]. Journal of Electronics & Information Technology, 2024, 46(2): 671–679. doi: 10.11999/JEIT230086.
[16]	LIN Min, LIN Zhi, ZHU Weiping, et al. Joint beamforming for secure communication in cognitive satellite terrestrial networks[J]. IEEE Journal on Selected Areas in Communications, 2018, 36(5): 1017–1029. doi: 10.1109/JSAC.2018.2832819.
[17]	蘇昭陽, 劉留, 艾渤, 等. 面向低軌衛星的星地信道模型綜述[J]. 電子與信息學報, 2024, 46(5): 1684–1702. doi: 10.11999/JEIT230941. SU Zhaoyang, LIU Liu, AI Bo, et al. Survey of satellite-ground channel models for low earth orbit satellites[J]. Journal of Electronics & Information Technology, 2024, 46(5): 1684–1702. doi: 10.11999/JEIT230941.
[18]	CLERCKX B and OESTGES C. MIMO Wireless Networks: Channels, Techniques and Standards for Multi-Antenna, Multi-User and Multi-Cell Systems[M]. 2nd ed. Amsterdam: Elsevier, 2013. doi: 10.1016/C2010-0-66925-2.
[19]	FONTAN F P, VáZQUEZ-CASTRO M, CABADO C E, et al. Statistical modeling of the LMS channel[J]. IEEE Transactions on Vehicular Technology, 2001, 50(6): 1549–1567. doi: 10.1109/25.966585.
[20]	ITU-R. ITU-R REPORT M. 2135 Guidelines for evaluation of radio interface technologies for IMT-Advanced[S]. Geneva: ITU-R, 2009.
[21]	SHI Qingjiang, RAZAVIYAYN M, LUO Zhiquan, et al. An iteratively weighted MMSE approach to distributed sum-utility maximization for a MIMO interfering broadcast channel[J]. IEEE Transactions on Signal Processing, 2011, 59(9): 4331–4340. doi: 10.1109/TSP.2011.2147784.
[22]	MA Shuai, HONG Mingyi, SONG Enbin, et al. Outage constrained robust secure transmission for MISO wiretap channels[J]. IEEE Transactions on Wireless Communications, 2014, 13(10): 5558–5570. doi: 10.1109/TWC.2014.2326415.
[23]	CAO Xuelin, YANG Bo, SHEN Yulong, et al. Edge-assisted multi-layer offloading optimization of LEO satellite-terrestrial integrated networks[J]. IEEE Journal on Selected Areas in Communications, 2023, 41(2): 381–398. doi: 10.1109/JSAC.2022.3227032.
