利用可選擇多尺度圖卷積網絡的骨架行為識別

曹毅; 李杰; 葉培濤; 王彥雯; 呂賢海

doi:10.11999/JEIT240702

利用可選擇多尺度圖卷積網絡的骨架行為識別

doi: 10.11999/JEIT240702 cstr: 32379.14.JEIT240702

1.
江南大學機械工程學院無錫 214122
2.
江南大學江蘇省食品先進制造裝備技術重點實驗室無錫 214122

基金項目: 國家自然科學基金(51375209)，江蘇省“六大人才高峰”計劃(ZBZZ-012)，高等學校學科創新引智計劃(B18027)

詳細信息

作者簡介:
曹毅：男，教授，博士，研究方向為機器人機構學、深度學習

李杰：男，碩士生，研究方向為深度學習、行為識別

葉培濤：男，碩士生，研究方向為機器人控制系統、路徑規劃

王彥雯：男，碩士生，研究方向為深度學習、聲紋識別

呂賢海：男，碩士生，研究方向為機器人機構學、行為識別

通訊作者:
曹毅　caoyi@jiangnan.edu.cn

中圖分類號: TN911.73; TP391.41
計量
- 文章訪問數: 263
- HTML全文瀏覽量: 146
- PDF下載量: 61
- 被引次數: 0
出版歷程
- 收稿日期: 2024-08-12
- 修回日期: 2025-02-17
- 網絡出版日期: 2025-02-24
- 刊出日期: 2025-03-01

Skeleton-based Action Recognition with Selective Multi-scale Graph Convolutional Network

1.
School of Mechanical Engineering, Jiangnan University, Wuxi 214122, China
2.
Jiangsu Key Laboratory of Advanced Food Manufacturing Equipment and Technology, Jiangnan University, Wuxi 214122, China

Funds: The National Natural Science Foundation of China (51375209), The Six Talent Peaks Project in Jiangsu Province (ZBZZ-012), The Programme of Introducing Talents of Discipline to Universities (B18027)

摘要

摘要: 針對目前骨架行為識別方法忽視骨架關節點多尺度依賴關系和無法合理利用卷積核進行時間建模的問題，該文提出了一種可選擇多尺度圖卷積網絡(SMS-GCN)的行為識別模型。首先，介紹了人體骨架圖的構建原理和通道拓?fù)浼?xì)化圖卷積網絡的結構；其次，構建成對關節鄰接矩陣和多關節鄰接矩陣以生成多尺度通道拓?fù)浼?xì)化鄰接矩陣，并引入圖卷積網絡，進一步提出多尺度圖卷積(MS-GC)模塊，以期實現對骨架關節點的多尺度依賴關系的建模；然后，基于多尺度時序卷積和可選擇大核網絡，提出可選擇多尺度時序卷積(SMS-TC)模塊，以期實現對有用的時間上下文特征的充分提取，同時結合MS-GC和SMS-TC模塊，進而提出可選擇多尺度圖卷積網絡模型并在多支流數據輸入下進行訓練；最后，在NTU-RGB+D和NTU-RGB+D 120數據集上進行大量實驗，實驗結果表明，該模型能夠捕獲更多的關節特征和學習有用的時間信息，具有優異的準確率和泛化能力。
- 骨架行為識別 /
- 圖卷積網絡 /
- 多尺度通道拓?fù)浼?xì)化鄰接矩陣 /
- 可選擇多尺度時序卷積 /
- 可選擇多尺度圖卷積網絡
Abstract: Objective Human action recognition plays a key role in computer vision and has gained significant attention due to its broad range of applications. Skeleton data, derived from human action samples, is particularly robust to variations in camera viewpoint, illumination, and background occlusion, offering advantages over depth image and video data. Recent advancements in skeleton-based action recognition using Graph Convolutional Networks (GCNs) have demonstrated effective extraction of the topological relationships within skeleton data. However, limitations remain in some current approaches employing GCNs: (1) Many methods focus on the discriminative dependencies between pairs of joints, failing to effectively capture the multi-scale discriminative dependencies across the entire skeleton. (2) Some temporal modeling methods use dilated convolutions for simple feature fusion, but do not employ convolutional kernels in a manner suitable for effective temporal modeling. To address these challenges, a selective multi-scale GCN is proposed for action recognition, designed to capture more joint features and learn valuable temporal information. Methods The proposed model consists of two key modules: a multi-scale graph convolution module and a selective multi-scale temporal convolution module. First, the multi-scale graph convolution module serves as the primary spatial modeling component. It generates a multi-scale, channel-wise topology refinement adjacency matrix to enhance the model’s ability to learn multi-scale discriminative dependencies of skeleton joints, thereby capturing more joint features. Specifically, the pairwise joint adjacency matrix is used to capture the interactive relationships between joint pairs, enabling the extraction of local motion details. Additionally, the multi-joint adjacency matrix emphasizes the overall action feature changes, improving the model’s spatial representation of the skeleton data. Second, the selective multi-scale temporal convolution module is designed to capture valuable temporal contextual information. This module comprises three stages: feature extraction, temporal selection, and feature fusion. In the feature extraction stage, convolution and max-pooling operations are applied to obtain temporal features at different scales. Once the multi-scale temporal features are extracted, the temporal selection stage uses global max and average pooling to select salient features while preserving key details. This results in the generation of temporal selection masks without directly fusing temporal features across scales, thus reducing redundancy. In the feature fusion stage, the output temporal feature is obtained by weighted fusion of the temporal features and the selection masks. Finally, by combining the multi-scale graph convolution module with the selective multi-scale temporal convolution module, the proposed model extracts multi-stream data from skeleton data, generating various prediction scores. These scores are then fused through weighted summation to produce the final prediction outcome. Results and Discussions Extensive experiments are conducted on two large-scale datasets: NTU-RGB+D and NTU-RGB+D 120, demonstrating the effectiveness and strong generalization performance of the proposed model. When the convolution kernel size in the multi-scale graph convolution module is set to 3, the model performs optimally, capturing more representative joint features (Table 1). The results (Table 4) show that the temporal selection stage is critical within the selective multi-scale temporal convolution module, significantly enhancing the model’s ability to extract temporal contextual information. Additionally, ablation studies (Table 5) confirm the effectiveness of each component in the proposed model, highlighting their contributions to improving recognition performance. The results (Tables 6 and 7) demonstrate that the proposed model outperforms state-of-the-art methods, achieving superior recognition accuracy and strong generalization capabilities. Conclusions This study presents a selective multi-scale GCN model for skeleton-based action recognition. The multi-scale graph convolution module effectively captures the multi-scale discriminative dependencies of skeleton joints, enabling the model to fully extract more joint features. By selecting appropriate temporal convolution kernels, the selective multi-scale temporal convolution module extracts and fuses temporal contextual information, thereby emphasizing useful temporal features. Experimental results on the NTU-RGB+D and NTU-RGB+D 120 datasets demonstrate that the proposed model achieves excellent accuracy and robust generalization performance.

HTML全文

圖 1 多尺度圖卷積模塊結構示意圖

下載: 全尺寸圖片幻燈片

圖 2 可選擇多尺度時序卷積模塊結構示意圖

下載: 全尺寸圖片幻燈片

圖 3 SMS-GCN結構示意圖

下載: 全尺寸圖片幻燈片

表 1 不同卷積核尺寸的模型準確率對比(%)

模型	Top-1	Top-5
SMS-GCN(k=3)	95.09	99.41
SMS-GCN(k=5)	95.00	99.43
SMS-GCN(k=7)	94.99	99.40
SMS-GCN(k=9)	94.93	99.36

下載: 導出CSV

表 2 不同卷積核尺寸的準確率對比

模型	(k₁, k₂)	(d₁, d₂)	Top-1(%)	參數量(M)	時間	模型	(k₁, k₂)	(d₁, d₂)	Top-1(%)	參數量(M)	時間
1	(1, 3)	(1, 1)	94.58	1.77	277	9	(3, 11)	(1, 1)	94.87	1.93	277
2	(1, 5)	(1, 1)	94.79	1.80	275	10	(5, 7)	(1, 1)	94.69	1.90	278
3	(1, 7)	(1, 1)	94.92	1.83	277	11	(5, 9)	(1, 1)	94.82	1.93	277
4	(1, 9)	(1, 1)	94.78	1.87	282	12	(5, 11)	(1, 1)	94.89	1.97	277
5	(1, 11)	(1, 1)	95.04	1.90	276	13	(7, 9)	(1, 1)	94.84	1.97	270
6	(3, 5)	(1, 1)	94.92	1.83	287	14	(7, 11)	(1, 1)	94.83	2.00	285
7	(3, 7)	(1, 1)	94.74	1.87	281	15	(9, 11)	(1, 1)	95.03	2.03	272
8	(3, 9)	(1, 1)	94.91	1.90	271

下載: 導出CSV

表 3 不同卷積核尺寸和膨脹系數的準確率對比

模型	(k₁, k₂)	(d₁, d₂)	Top-1(%)	參數量(M)	時間	模型	(k₁, k₂)	(d₁, d₂)	Top-1(%)	參數量(M)	時間
1	(1, 1)	(1, 2)	92.95	1.74	747	7	(9, 9)	(1, 3)	95.07	2.00	761
2	(3, 3)	(1, 2)	94.69	1.80	886	8	(9, 9)	(1, 4)	95.09	2.00	1000
3	(5, 5)	(1, 2)	94.89	1.87	865	9	(9, 9)	(2, 3)	94.98	2.00	1466
4	(7, 7)	(1, 2)	94.66	1.93	854	10	(9, 9)	(2, 4)	94.96	2.00	1490
5	(9, 9)	(1, 2)	95.09	2.00	735	11	(9, 9)	(3, 4)	94.85	2.00	1479
6	(11, 11)	(1, 2)	94.97	2.06	767

下載: 導出CSV

表 4 不同結構的模型準確率對比

模型	參數量(M)	Top-1(%)
SMS-GCN	2.00	95.09
SMS-GCN(無SMS-TC)	3.76	94.46
SMS-GCN(無S)	1.96	94.97
SMS-GCN(無GMP)	2.00	94.90
SMS-GCN(無GAP)	2.00	94.93

下載: 導出CSV

表 5 添加不同模塊的模型準確率對比(%)

模型	關節流	骨骼流	雙流
CTR-GCN	94.74	94.70	96.07
CTR-GCN + MS-GC	94.91	94.90	96.30
CTR-GCN + SMS-TC	94.86	94.90	96.29
SMS-GCN	95.09	94.96	96.52

下載: 導出CSV

表 6 NTU-RGB+D數據集下模型的準確率對比(%)

模型	CS	CV	模型	CS	CV
CNC-LSTM^[5]	83.3	91.8	3D-GCN^[23]	89.4	93.3
LAGA-Net^[7]	87.1	93.2	ML-STGNet^[12]	91.9	96.2
ST-GCN^[15]	81.5	88.3	MADT-GCN^[19]	90.4	96.5
2s-AGCN^[9]	88.5	95.1	SMS-GCN(單流)	89.7	95.1
CTR-GCN^[10]	92.4	96.8	SMS-GCN(雙流)	91.9	96.5
VN-GAN^[22]	92.0	96.7	SMS-GCN(多流)	92.6	96.9

下載: 導出CSV

表 7 NTU-RGB+D 120數據集下模型的準確率對比(%)

模型	CSub	CSet	模型	CSub	CSet
GCA-LSTM^[6]	58.3	59.2	ML-STGNet^[12]	88.6	90.0
LAGA-Net^[7]	81.0	82.2	MADT-GCN^[19]	86.5	88.2
ST-GCN^[15]	70.7	73.2	VN-GAN^[22]	87.6	89.4
2s-AGCN^[9]	82.9	84.9	SMS-GCN(單流)	85.3	86.6
CTR-GCN^[10]	88.9	90.6	SMS-GCN(雙流)	88.8	90.0
STFE-GCN^[11]	84.1	86.3	SMS-GCN(多流)	89.3	90.7

下載: 導出CSV
