基于特征時序性的海雜波環境小目標檢測方法

董云龍; 羅霄; 丁昊; 王國慶; 劉寧波

doi:10.11999/JEIT240528

基于特征時序性的海雜波環境小目標檢測方法

doi: 10.11999/JEIT240528 cstr: 32379.14.JEIT240528

海軍航空大學 煙臺 264001

基金項目: 國家自然科學基金(62388102, 62101583)

詳細信息

作者簡介:
董云龍：男，博士，教授，研究方向?yàn)槔走_(dá)目標組網檢測等

羅霄：男，碩士生，研究方向?yàn)槔走_(dá)信號處理、目標檢測等

丁昊：男，博士，副教授，研究方向?yàn)楹ｋs波特性認知、雷達目標檢測等

王國慶：男，博士，副教授。研究方向?yàn)槔走_(dá)信號目標檢測、電路系統設計等

劉寧波：男，博士，教授，研究方向?yàn)槔走_(dá)信號處理、海雜波抑制與目標智能檢測

通訊作者:
丁昊　hao3431@tom.com

中圖分類號: TN957.51
計量
- 文章訪問數: 242
- HTML全文瀏覽量: 93
- PDF下載量: 60
- 被引次數: 0
出版歷程
- 收稿日期: 2024-06-25
- 修回日期: 2025-02-15
- 網絡出版日期: 2025-02-24
- 刊出日期: 2025-03-01

A Detection Method of Small Target in Sea Clutter Environment Based on Feature Temporal Sequence

Naval Aviation University, Yantai 264001, China

Funds: The National Natural Science Foundation of China (62388102, 62101583)

摘要

摘要: 特征檢測作為海雜波環境下小目標檢測的有效手段，受到了廣泛關注與深入研究。過去對特征的研究大多關注于當前幀，近年來使用幀間時序信息融合當前幀特征的方法也被提出并在檢測方面取得一定效果。但該方法不能很好地適應具有時變性的海雜波數據，且僅采用靜態加權算法融合特征，對歷史幀信息的利用不夠充分。針對上述問題，該文提出基于模型穩定的修正Burg方法進行特征自回歸(AR)建模與一步預測，使模型能夠自適應調整極點分布，提高了海雜波特征預測的準確性，并基于求解多變量極值問題提出了一種動態加權算法得到了最小方差的融合特征。該文結合IPIX數據集和海軍航空大學共享數據集進行實驗，利用相對平均幅度(RAA)、相對多普勒峰高(RDPH)、頻域峰均值比(FPAR)3特征構建凸包檢測器驗證了所提方法的有效性。
- 小目標檢測 /
- 海雜波 /
- 特征時序信息 /
- 修正Burg方法 /
- 動態加權
Abstract: Objective Feature detection has become an effective approach for detecting small targets in sea clutter environments, attracting significant attention and research. Previous studies primarily focused on extracting differential features between targets and clutter from the current pulse frame for detection. Recent methods have integrated temporal information from multiple frames with current frame features, demonstrating improved detection performance. However, these methods rely on fixed-order Auto Regressive (AR) models, which do not effectively adapt to the time-varying nature of sea clutter. Moreover, the use of static weighting algorithms for feature fusion fails to account for clutter characteristics in the current scene, leading to suboptimal utilization of temporal information. To address these issues, this study proposes a feature AR modeling and one-step prediction method based on a model-stable modified Burg algorithm, enabling adaptive pole distribution adjustment and enhancing the accuracy of sea clutter feature prediction. Additionally, a dynamic weighting algorithm is developed by solving multivariable extreme value problems to obtain minimum variance fused features, fully leveraging historical frame temporal information and improving radar target detection performance. Methods This study employs a modified Burg method to predict sea clutter, incorporating a stability factor in the derivation of reflection coefficients to constrain the model’s poles within the unit circle. This enhances model stability, improving its adaptability to the time-varying nature of sea clutter and increasing the accuracy of feature prediction. A dynamic weighting algorithm is introduced to adaptively adjust fusion weights based on data volatility around the current frame by solving a multivariable extremum problem, thereby minimizing the local variance of fused features. Temporal fusion is performed using the features Relative Average Amplitude (RAA), Frequency Peak to Average Ratio (FPAR), and Relative Doppler Peak Height (RDPH) to generate a fused feature. The fused clutter features are then used to construct a three-dimensional convex hull decision region, where target presence is determined by assessing whether the detection unit’s feature point lies within this region. Detection results are compared with commonly used feature detection methods. Additionally, the study evaluates the boundary performance of the proposed method and contrasts it with the traditional energy-domain CFAR method, providing a comprehensive analysis of its usability and effectiveness. Results and Discussions The proposed method achieves the following results: (1) For clutter data, the temporal fusion algorithm reduces data variance by an average of 0.024 5 compared to no temporal fusion and by 0.003 5 compared to the original temporal fusion algorithm. For target data, it reduces data variance by an average of 1.126 6 compared to no temporal fusion and by 0.179 compared to the original temporal fusion algorithm. (2) The Bhattacharyya distance of the proposed temporal fusion algorithm improves by an average of 0.237 3 compared to no temporal fusion and by 0.109 3 compared to the original temporal fusion algorithm. Under VV polarization, the Bhattacharyya distance improves by an average of 0.219 9 compared to no temporal fusion and by 0.090 8 compared to the original temporal fusion algorithm. (3) The proposed method outperforms other feature detectors in detection performance by effectively utilizing temporal information from historical frames, thereby enhancing the echo information used. Compared to energy-domain CFAR methods, it maintains a strong competitive advantage. Conclusions This study presents innovative solutions to two key challenges in existing sea clutter feature modeling and fusion methods. First, to address the time-varying nature of sea clutter features, a model-stable modified Burg method is proposed for Autoregressive (AR) feature modeling. This approach enables adaptive adjustment of model pole distribution, improving the accuracy of one-step sea clutter feature predictions and simplifying model order estimation. Second, to enhance the utilization of inter-frame temporal information during feature fusion, a dynamic weighted fusion algorithm is introduced to integrate predicted and observed features. This method reduces the variance of fused features and fully exploits historical temporal information. Validation using the IPIX dataset and the shared dataset from the Naval Aeronautical University demonstrates that the fused features obtained through these methods exhibit improved separability compared to the original features, significantly enhancing detector performance.
- Small target detection /
- Sea clutter /
- Temporal feature information /
- Modified burg /
- Dynamic weighting

HTML全文

圖 1 航道浮標圖

下載: 全尺寸圖片幻燈片

圖 2 不同海況時域回波圖

下載: 全尺寸圖片幻燈片

圖 3 加入穩定因子后AR模型極點變化

下載: 全尺寸圖片幻燈片

圖 4 特征頻譜對比

下載: 全尺寸圖片幻燈片

圖 5 特征相對預測誤差隨穩定參數變化曲線

下載: 全尺寸圖片幻燈片

圖 6 修正Burg方法的AR預測曲線與觀測曲線對比

下載: 全尺寸圖片幻燈片

圖 7 動態加權算法檢測器流程

下載: 全尺寸圖片幻燈片

圖 8 不同滑窗寬度對應的數據方差曲線

下載: 全尺寸圖片幻燈片

圖 9 3種算法計算后數據方差對比

下載: 全尺寸圖片幻燈片

圖 10 凸包檢測器圖示

下載: 全尺寸圖片幻燈片

圖 11 不同極化3種算法計算后特征巴氏距離對比

下載: 全尺寸圖片幻燈片

圖 12 融合特征后平均檢測概率隨AR階數增加的變化曲線

下載: 全尺寸圖片幻燈片

圖 13 不同極化本文所提方法與其他特征組合的檢測效果對比

下載: 全尺寸圖片幻燈片

圖 14 不同海況背景下本文所提方法與其他檢測方法的邊界性能對比

下載: 全尺寸圖片幻燈片

表 1 IPIX數據集信息

文件序號	采樣數	浪高		風力		目標影響單元	目標所在單元	總距離
文件序號	采樣數	最大	一般	風向(°)	風速(m/s)	目標影響單元	目標所在單元	單元個數
17	131 072	3.1	2.1	301	10	8:11	9	14
26	131 072	1.56	1.03	211	9	6:9	7	14
30	131 072	1.25	0.89	210	19	6:8	7	14
31	131 072	1.28	0.89	206	15	6:9	7	14
54	131 072	0.97	0.66	308	20	7:10	8	14
280	131 072	2.4	1.44	216	11	7:10	8	14
310	131 072	1.38	0.9	313	33	6:9	7	14
311	131 072	1.38	0.9	310	33	6:9	7	14
320	131 072	1.34	0.91	317	27	6:9	7	14

下載: 導出CSV

表 2 LSTM訓練參數設置

預設參數	設置值
最大訓練次數	150
梯度閾值	1
使用歷史幀數	20
初始學習率	0.01
調整學習率節點	60次以后
學習率調整因子	0.2

下載: 導出CSV

表 3 不同預測方法下雜波特征的平均相對預測誤差

AR預測方法	不同特征的平均相對預測誤差
AR預測方法	RAA	FPAR	RDPH
本文所提方法	0.128 3	0.204 7	0.319 4
未修正Burg方法	0.153 0	0.225 6	0.345 0
文獻[10]方法	0.198 3	0.260 3	0.338 4
LSTM	0.263 2	0.198 5	0.296 0

下載: 導出CSV

表 4 不同預測方法下目標特征的平均相對預測誤差

AR預測方法	不同特征的平均相對預測誤差
AR預測方法	RAA	FPAR	RDPH
本文方法	0.112 6	0.183 1	0.285 8
未修正Burg方法	0.126 9	0.199 9	0.315 8
文獻[10]方法	0.198 3	0.260 3	0.338 4
LSTM	0.152 7	0.183 2	0.310 7

下載: 導出CSV

表 5 IPIX數據檢測結果

檢測器	使用脈沖數	不同極化方式下的平均檢測概率				平均檢測概率
檢測器	使用脈沖數	HH	HV	VH	VV	平均檢測概率
原3特征檢測器	64	0.245 9	0.349 1	0.339 3	0.177 2	0.277 9
	128	0.437 2	0.574 3	0.569 9	0.368 7	0.487 5
	256	0.569 4	0.699 6	0.696 7	0.496 2	0.615 5
文獻[10]檢測器	64	0.348 1	0.472 8	0.456 1	0.276 4	0.388 4
	128	0.629 2	0.743 9	0.735 4	0.535 6	0.661 0
	256	0.709 9	0.813 9	0.809 3	0.642 0	0.743 8
本文檢測器	64	0.417 7	0.543 2	0.537 3	0.347 4	0.461 4
	128	0.692 1	0.794 1	0.792 6	0.630 0	0.727 2
	256	0.776 3	0.856 3	0.854 4	0.732 1	0.804 8

下載: 導出CSV

表 6 海軍航空大學共享數據集檢測結果

檢測器	使用脈沖數	檢測概率				平均檢測概率
檢測器	使用脈沖數	4級HH	4級VV	5級HH	5級VV	平均檢測概率
原3特征檢測器	64	0.305 5	0.682 0	0.218 2	0.155 8	0.340 4
	128	0.456 7	0.808 4	0.453 1	0.334 8	0.513 2
	256	0.632 7	0.907 1	0.647 5	0.459 4	0.661 7
文獻[10]檢測器	64	0.400 7	0.718 6	0.334 7	0.208 9	0.415 7
	128	0.592 3	0.886 5	0.644 5	0.443 3	0.641 7
	256	0.753 3	0.959 1	0.820 8	0.534 6	0.767 0
本文檢測器	64	0.442 4	0.778 5	0.434 1	0.255 6	0.477 7
	128	0.647 1	0.922 5	0.727 6	0.497 5	0.698 7
	256	0.803 1	0.976 6	0.866 4	0.597 9	0.811 0

下載: 導出CSV

參考文獻(17)

[1]	關鍵. 雷達海上目標特性綜述[J]. 雷達學報, 2020, 9(4): 674–683. doi: 10.12000/JR20114. GUAN Jian. Summary of marine radar target characteristics[J]. Journal of Radars, 2020, 9(4): 674–683. doi: 10.12000/JR20114.
[2]	BI Xiaowen, GUO Shenglong, YANG Yunxiu, et al. Adaptive target extraction method in sea clutter based on fractional Fourier filtering[J]. IEEE Transactions on Geoscience and Remote Sensing, 2022, 60: 5115609. doi: 10.1109/TGRS.2022.3192893.
[3]	SHI Sainan and SHUI Penglang. Sea-surface floating small target detection by one-class classifier in time-frequency feature space[J]. IEEE Transactions on Geoscience and Remote Sensing, 2018, 56(11): 6395–6411. doi: 10.1109/ TGRS.2018.2838260. doi: 10.1109/TGRS.2018.2838260.
[4]	XU Shuwen, ZHENG Jibin, PU Jia, et al. Sea-surface floating small target detection based on polarization features[J]. IEEE Geoscience and Remote Sensing Letters, 2018, 15(10): 1505–1509. doi: 10.1109/LGRS.2018.2852560.
[5]	陳世超, 高鶴婷, 羅豐. 基于極化聯合特征的海面目標檢測方法[J]. 雷達學報, 2020, 9(4): 664–673. doi: 10.12000/ JR20072. doi: 10.12000/JR20072. CHEN Shichao, GAO Heting, and LUO Feng. Target detection in sea clutter based on combined characteristics of polarization[J]. Journal of Radars, 2020, 9(4): 664–673. doi: 10.12000/JR20072.
[6]	LO T, LEUNG H, LITVA J, et al. Fractal characterisation of sea-scattered signals and detection of sea-surface targets[J]. IEE Proceedings F: Radar and Signal Processing, 1993, 140(4): 243–250. doi: 10.1049/ip-f-2.1993.0034.
[7]	FAN Yifei, TAO Mingliang, and SU Jia. Multifractal correlation analysis of autoregressive spectrum-based feature learning for target detection within sea clutter[J]. IEEE Transactions on Geoscience and Remote Sensing, 2022, 60: 5108811. doi: 10.1109/TGRS.2021.3137466.
[8]	關鍵, 伍僖杰, 丁昊, 等. 基于對角積分雙譜的海面慢速小目標檢測方法[J]. 電子與信息學報, 2022, 44(7): 2449–2460. doi: 10.11999/JEIT210408. GUAN Jian, WU Xijie, DING Hao, et al. A method for detecting small slow targets in sea surface based on diagonal integrated bispectrum[J]. Journal of Electronics & Information Technology, 2022, 44(7): 2449–2460. doi: 10.11999/JEIT210408.
[9]	關鍵, 姜星宇, 劉寧波, 等. 海雜波背景下的雙極化最大特征值目標檢測[J]. 系統工程與電子技術, 2024, 46(11): 3715–3725. doi: 10.12305/j.issn.1001-506X.2024.11.13. GUAN Jian, JIANG Xingyu, LIU Ningbo, et al. Target detection using dual-polarization maximum eigenvalue in sea clutter background[J]. Systems Engineering and Electronics, 2024, 46(11): 3715–3725. doi: 10.12305/j.issn.1001-506X.2024.11.13.
[10]	董云龍, 張兆祥, 丁昊, 等. 基于三特征預測的海雜波中小目標檢測方法[J]. 雷達學報, 2023, 12(4): 762–775. doi: 10.12000/JR23037. DONG Yunlong, ZHANG Zhaoxiang, DING Hao, et al. Target detection in sea clutter using a three-feature prediction-based method[J]. Journal of Radars, 2023, 12(4): 762–775. doi: 10.12000/JR23037.
[11]	SHUI Penglang, LI Dongchen, and XU Shuwen. Tri-feature-based detection of floating small targets in sea clutter[J]. IEEE Transactions on Aerospace and Electronic Systems, 2014, 50(2): 1416–1430. doi: 10.1109/TAES.2014.120657.
[12]	IPIX Radar. The IPIX radar database[EB/OL]. http://soma.ece.mcmaster.ca/ipix/, 2021.
[13]	關鍵, 劉寧波, 王國慶, 等. 雷達對海探測試驗與目標特性數據獲取——海上目標雙極化多海況散射特性數據集[J]. 雷達學報, 2023, 12(2): 456–469. doi: 10.12000/JR23029. GUAN Jian, LIU Ningbo, WANG Guoqing, et al. Sea-detecting radar experiment and target feature data acquisition for dual polarization multistate scattering dataset of marine targets[J]. Journal of Radars, 2023, 12(2): 456–469. doi: 10.12000/JR23029.
[14]	BARBARESCO F. Algorithme de burg regularise fsds (fonctionnelle stabilisatrice de douceur spectrale) Comparaison avec l'algorithme de burg mfe (Minimum free energy)[C]. Quinzieme Colloque Gretsi - Juan-Les-Pins, 1995: 29–32.
[15]	LI Yuzhou, XIE Pengcheng, TANG Zeshen, et al. SVM-based sea-surface small target detection: A false-alarm-rate-controllable approach[J]. IEEE Geoscience and Remote Sensing Letters, 2019, 16(8): 1225–1229. doi: 10.1109/LGRS.2019.2894385.
[16]	王鑫, 吳際, 劉超, 等. 基于LSTM循環神經網絡的故障時間序列預測[J]. 北京航空航天大學學報, 2018, 44(4): 772–784. doi: 10.13700/j.bh.1001-5965.2017.0285. WANG Xin, WU Ji, LIU Chao, et al. Exploring LSTM based recurrent neural network for failure time series prediction[J]. Journal of Beijing University of Aeronautics and Astronautics, 2018, 44(4): 772–784. doi: 10.13700/j.bh.1001-5965.2017.0285.
[17]	胡學駿, 羅中良. 基于統計理論的多傳感器信息融合方法[J]. 傳感器技術, 2002(8): 38–39,43. doi: 10.13873/j.1000-97872002.08.013. HU Xuejun and LUO Zhongliang. Method of multi-sensor information fusion based on statistics theory[J]. Transducer and Microsystem Technologies, 2002(8): 38–39,43. doi: 10.13873/j.1000-97872002.08.013.
