蜂窩網絡下同時同頻全雙工設備到設備組網的干擾協調算法

周閱天; 邵士海; 齊飛; 時成哲

doi:10.11999/JEIT240120

蜂窩網絡下同時同頻全雙工設備到設備組網的干擾協調算法

doi: 10.11999/JEIT240120 cstr: 32379.14.JEIT240120

周閱天^{1, 2},
邵士海^1, ,,
齊飛²,
時成哲¹

1.
電子科技大學通信抗干擾全國重點實驗室成都 611731
2.
中國電信股份有限公司研究院移動與終端技術研究所北京 102200

詳細信息

作者簡介:
周閱天：男，博士生，研究方向為全雙工組網技術、通信抗干擾技術等

邵士海：男，教授，博士生導師，研究方向為無線通信信號處理、抗干擾與安全通信等

齊飛：男，博士，高級工程師，研究方向為天地一體化網絡、通信感知一體化技術等

時成哲：男，博士生，研究方向為通信抗干擾技術、MIMO陣列天線技術等

通訊作者:
邵士?！?a href="mailto:ssh@uestc.edu.cn">ssh@uestc.edu.cn

中圖分類號: TN92
計量
- 文章訪問數: 263
- HTML全文瀏覽量: 131
- PDF下載量: 42
- 被引次數: 0
出版歷程
- 收稿日期: 2024-02-29
- 修回日期: 2024-07-11
- 網絡出版日期: 2024-07-23
- 刊出日期: 2024-09-26

Interference Coordination Algorithm of Co-frequency and Co-time Full Duplex Device-to-Device underlaying Cellular Network

ZHOU Yuetian^{1, 2},
SHAO Shihai^{1
, ,},
QI Fei²,
SHI Chengzhe¹

1.
National Key Laboratory of Science and Technology on Communications, University of Electronic Science and Technology of China, Chengdu 611731, China
2.
Institute of Mobile and Terminal Technology, China Telecom Research Institute, Beijing 102200, China

摘要

摘要: 蜂窩網絡下的同時同頻全雙工(CCFD)設備到設備(D2D)組網可以進一步提升網絡頻譜效率，然而由此引入的殘余自干擾(RSI)及蜂窩用戶(CU)與D2D用戶(DU)之間共享頻譜的干擾會嚴重影響到蜂窩用戶的體驗。因此，該文為蜂窩網絡下同時同頻全雙工組網設計了兩種干擾協調算法，即CU和速率最大化算法(MaxSumCU)與CU最小速率最大化算法(MaxMinCU)，在小區頻譜效率得到提升的同時盡可能地保證CU的體驗。對于MaxSumCU算法，該文以CU和速率為優化目標建立混合整數非線性規劃問題(MINLP)，其在數學上為非確定性多項式(NP-hard)問題。算法將其分解為功率控制與頻譜資源分配兩個子問題，并用圖形規劃找到最優功率解后，使用二向圖最大權值匹配算法決定頻譜共享的CU與DU。為了保證每一個蜂窩用戶體驗的公平性，該文設計了MaxMinCU算法用以最大化所有CU速率中的最小值，該算法基于二分查找與二向圖最小權值匹配算法來完成用戶的資源分配。數值結果表明，與小區和速率最大化(MaxSumCell)設計相比，該文所提的兩種算法在提升小區和速率的同時均有效地提升了蜂窩用戶的體驗。
- 蜂窩網絡下設備到設備組網 /
- 同時同頻全雙工 /
- 二向圖最大(小)權值匹配 /
- 公平性算法
Abstract: The Residual Self-Interference (RSI) caused by Co-frequency and Co-time Full Duplex Device-to-Device (CCFD-D2D) and the interference introduced by spectrum sharing between D2D User (DU) and Cellular User (CU) lead to a degradation in the quality of experience for CUs. Therefore, the CCFD-D2D underlaying cellular system is considered and two algorithms are proposed, that is Maximizing Sum-rate of CU (MaxSumCU) and Maximizing Minimum-rate of CU (MaxMinCU) algorithm, to enhance the experience for CUs while spectral efficiency of the system is improved. For the MaxSumCU algorithm, an optimization problem is investigated to maximize the sum rate of CUs in the system, and formulate it as a Mixed Integer NonLinear Programming problem (MINLP) which is NP-hard in mathematics. MaxSumCU is designed to decompose it into two sub-problems as power control and spectral resource allocation. The power control is solved by geometric programming, and the resource allocation is achieved by employing Kuhn-Munkres algorithm to determine the spectrum sharing pairs of CUs and DUs. To provide a more uniform rate performance across all CUs, the MaxMinCU algorithm is designed to maximize the minimum rate among the CUs. The novel spectrum resource allocation algorithm based on bisection searching and Kuhn-Munkres minimum-weight algorithm is proposed to solve this optimization problem. Numerical results show that, compared with Maximizing Sum-rate of Cell (MaxSumCell) design, our proposed algorithm effectively optimize the CU’s experience while improve the spectral efficiency of system in CCFD-D2D underlaying cellular networks.
- Device-to-Device (D2D) underlaying cellular networks /
- Co-frequency and Co-time Full Duplex (CCFD) /
- Kuhn-Munkres algorithm /
- Fairness algorithm.

HTML全文

圖 1 蜂窩網絡下FD-D2D組網系統模型干擾分析示意圖

下載: 全尺寸圖片幻燈片

圖 2 每一組DU-CU配對功率控制結果的可行域類型

下載: 全尺寸圖片幻燈片

圖 3 蜂窩網絡下FD-D2D與HD-D2D組網的小區和速率性能對比

下載: 全尺寸圖片幻燈片

圖 4 蜂窩網絡下FD-D2D組網中3種算法的CU和速率對比

下載: 全尺寸圖片幻燈片

圖 5 蜂窩網絡下FD-D2D組網中3種算法的最小CU速率對比

下載: 全尺寸圖片幻燈片

1 公平性算法

(1) 計算已配對CU的速率矩陣$ {{\{R}_{i,j}^{\mathrm{C}}\}}_{Q\times P} $。
(2) 對$ {{\{R}_{i,j}^{\mathrm{C}}\}}_{Q\times P} $中元素降序排列成向量$ \mathit{v} $，并初始化索引　　 $ m=1,n=QP $。
(3) while $ (n-m) > 1 $ do
(4) 　$ l=(n-m)/2 $;
(5) 　初始化一個矩陣$ {\left\{{F}_{i,j}\right\}}_{Q\times P} $，并為其中元素賦值，　　　 $ {R}_{i,j}^{{\mathrm{C}}} < \mathit{v}\left(l\right) $時對應位置賦1，否則為0
(6) 　對$ {\left\{{F}_{i,j}\right\}}_{Q\times P} $使用KM最小權值算法，返回分配指示矩陣　　　 $ {\mathit{E}}_{Q\times P} $與對應的權值$ w $。
(7) 　if $ w=0 $ then
(8) 　　$ n=l $;
(9) 　else
(10) 　 $ m=l $;
(11) 　 $ {\left\{{\rho }_{i,j}\right\}}_{Q\times P}=\mathit{E} $;
(12) end if
(13)end while
(14)在$ {{\{R}_{i,j}^{\mathrm{C}}\cdot {\rho }_{i,j}\}}_{Q\times P} $中搜索除0元素外最小的元素，即為最大　　 CU最小速率$ {R}_{i,j}^{{\mathrm{C}},\mathrm{m}\mathrm{i}\mathrm{n}} $。
(15)返回$ {\left\{{\rho }_{i,j}\right\}}_{Q\times P} $與$ \mathrm{max}{R}_{i,j}^{\mathrm{C},\mathrm{m}\mathrm{i}\mathrm{n}} $。

下載: 導出CSV
