利用全球開源數字高程模型的高程誤差預測數據集
doi: 10.11999/JEIT240062 cstr: 32379.14.JEIT240062
-
中山大學電子與通信工程學院 深圳 518107
基金項目: 國家自然科學基金(62273365, 62071499)，“小米青年學者”項目
Elevation Error Prediction Dataset Using Global Open-source Digital Elevation Model
-
School of Electronics and Communication Engineering, Sun Yat-sen University, Shenzhen 518107, China
Funds: The National Natural Science Foundation of China (62273365, 62071499), Xiaomi Young Talents Program
-
摘要: 數字高程模型(DEM)校正一直是遙感地學研究中的重要內容，近年來蓬勃發展的機器學習新方法為DEM高程誤差校正提供了新的解決途徑。由于機器學習等人工智能方法依賴大量的訓練數據，考慮到目前缺少大區域公開的、統一的、大規模和規范化多源 DEM 高程誤差預測數據集，針對數據集缺失的問題，該文公開了多源DEM高程誤差預測數據集(DEEP-Dataset)。該數據集包括4個子數據集，分別基于中國廣東省研究區域的 數字高程測量的 TerraSAR-X 附加組件(TanDEM-X) DEM和先進陸地觀測衛星世界3D-30米(AW3D30) DEM以及澳大利亞北領地研究區域的航天飛機雷達地形測繪任務(SRTM) DEM和先進星載熱發射和反射輻射計全球數字高程模型 (ASTER) DEM構成。其中，廣東省研究區域的樣本數量約為40 000，北領地研究區域的樣本數約量為1 600 000。數據集中的每個樣本均由10個特征組成，涵蓋了地理空間、地物種類以及地表形態等特征信息。通過設置機器學習模型測試、DEM校正以及特征重要性評估等對比實驗，驗證了DEEP-Dataset在實際模型訓練和DEM校正中的有效性，也證明了該數據集的合理性和豐富性。
-
關鍵詞:
- 數字高程模型 /
- 人工智能 /
- 機器學習 /
- 預測數據集
Abstract: The correction in Digital Elevation Models (DEMs) has always been a crucial aspect of remote sensing geoscience research. The burgeoning development of new machine learning methods in recent years has provided novel solutions for the correction of DEM elevation errors. Given the reliance of machine learning and other artificial intelligence methods on extensive training data, and considering the current lack of publicly available, unified, large-scale, and standardized multisource DEM elevation error prediction datasets for large areas, the multi-source DEM Elevation Error Prediction Dataset (DEEP-Dataset) is introduced in this paper. This dataset comprises four sub-datasets, based on the TerraSAR-X add-on for Digital Elevation Measurements (TanDEM-X) DEM and Advanced land observing satellite World 3D-30 m (AW3D30) DEM in the Guangdong Province study area of China, and the Shuttle Radar Topography Mission (SRTM) DEM and Advanced Spaceborne Thermal Emission and reflection Radiometer (ASTER) DEM in the Northern Territory study area of Australia. The Guangdong Province sample comprises approximately 40 000 instances, while the Northern Territory sample includes about 1 600 000 instances. Each sample in the dataset consists of ten features, encompassing geographic spatial information, land cover types, and topographic attributes. The effectiveness of the DEEP-Dataset in actual model training and DEM correction has been validated through a series of comparative experiments, including machine learning model testing, DEM correction, and feature importance assessment. These experiments demonstrate the dataset’s rationality, effectiveness, and comprehensiveness. -
表 1 DEM和ICESat-2產品基本屬性介紹
DEM 傳感器類型 空間分辨率 坐標系 覆蓋范圍 SRTM 雷達 30 WGS84 56°S～60°N ASTER 光學 30 WGS84 $ 83^\circ {\text{S}}{\text{～}}83^\circ {\text{N}} $ TanDEM-X 雷達 30 WGS84 $ 90^\circ {\text{S}}{\text{～}}90^\circ {\text{N}} $ AW3D30 光學 30 WGS84 $ 84^\circ {\text{S}}{\text{～}}84^\circ {\text{N}} $ ICESat-2 激光 – WGS84 $ 88^\circ {\text{S}}{\text{～}}88^\circ {\text{N}} $
下載: 導出CSV
表 2 DEEP-Dataset介紹
研究區域 面積(km2) 地形特點 DEM 樣本數量 特征屬性 目標變量 中國廣東省 179 725 高山、丘陵、臺地和平原 TanDEM-X 18 415 經度、緯度、地物種類、坡度、
坡向、坡位、地形起伏度、地表粗糙度、
坡度變率、坡向變率高程誤差 AW3D30 18 439 澳大利亞北領地 1 420 968 平原、高原、山地和沙漠 SRTM 795 391 ASTER 795 495
下載: 導出CSV
表 3 ICESat-2 激光控制點粗篩標準
指標 參考值 與原有參考 DEM 對比高差 abs(h_te_best_fit–dem_h)<30 m 表征地表高度統計量之間的差距 max_diff(h_te_best_fit, h_te_interp, h_median)<0.5 地表光子絕對數量和占比 n_te_ photons >50, ratio_te_photos>50% 云量 cloud_flag_atm <10% h_uncertainty 離群值篩除 <2×RMSE (h_uncertainty)
下載: 導出CSV
表 4 特征屬性介紹
特征屬性 公式 含義說明 符號 經度 / 經度是從本初子午線向東或向西測量的角度。 X 緯度 / 緯度是從赤道向北或向南測量的角度。 Y 地物種類 / 表示DEM單元格內覆蓋的地表類型，如森林、城市、水體等9種。 $ \omega $ 坡度 $ \arctan \left( {\sqrt {{{\left( {\dfrac{{\partial Z}}{{\partial X}}} \right)}^2} + {{\left( {\dfrac{{\partial Z}}{{\partial Y}}} \right)}^2}} } \right) $ 坡度是指坡面的傾斜與陡峭程度，即高程變化值與距離的比值。Z是高程值，X和Y分別是東西方向和南北方向的空間坐標。$ (\partial Z/\partial X) $和$ (\partial Z/\partial Y) $表示沿格網的高程變化率。 $ \theta $ 坡向 $ {\text{atan}} 2\left( {\dfrac{{\partial Z}}{{\partial Y}},\dfrac{{\partial Z}}{{\partial X}}} \right) $ 坡向是指地面某一點的最大降水方向，即水流從該點流向的方向。atan2是兩參數的反正切函數，處理了四個象限的坡向計算。 $ \kappa $ 坡位 / 坡位是指某一點相對于周圍點的高度位置，通過分析鄰近的坡度和高程值來確的，沒有固定的公式，需要確定局部最大值和最小值以識別山脊、山谷和山坡。 $ \psi $ 地形起伏度 $ {Z_{{\text{ref}}}}(i, j){\text{ }} = {Z_{{\text{max}}}} - {Z_{{\text{min}}}} $ 地形起伏度是指在一個特定的區域內，最高點海拔高度Zmax與最低點海拔高度Zmin的差值。 $ \alpha $ 地表粗糙度 $ \sqrt{\dfrac{1}{n}\displaystyle\sum _{i=1}^{n}{\left({Z}_{i}-\overline{Z}\right)}^{2}} $ 地表粗糙度是指地表表面的不規則程度，即地表表面起伏程度的大小。$ {Z_i} $是鄰近像素的高程值，$ \bar Z $是這些高程值的平均，n是像素?cái)?shù)量。 $ \beta $ 坡度變率 $ \sqrt{\dfrac{1}{n}\displaystyle\sum _{i=1}^{n}{\left({\theta }_{i}-\overline{\theta }\right)}^{2}} $ 坡度變率是指地面坡度在微分空間的變化率。$ {\theta _i} $是周圍像素的坡度值，$ \bar \theta $是平均坡度值，n是周圍像素的數量。 $ \varphi $ 坡向變率 $ \sqrt {{\text{Var}}(\cos (\kappa )) + {\text{Var}}(\sin (\kappa ))} $ 坡向變率是提取坡向基礎上提取坡向的變化率。$ \kappa $是坡向角度值，Var是方差。 $ \lambda $
下載: 導出CSV
表 5 中國廣東省研究區域模型測試和DEM校正實驗結果
單位 DEM校正前 方法 模型測試 DEM校正后 提升精度(%) TanDEM-X AW3D30 TanDEM-X AW3D30 TanDEM-X AW3D30 TanDEM-X AW3D30 MAE 4.734 3.094 RF 3.931 2.513 3.524 2.876 25.56 7.05 ET 3.879 2.522 3.025 2.471 36.10 20.14 ANN 4.157 2.821 4.614 2.672 2.53 13.64 BA 3.935 2.515 3.507 1.838 25.92 40.59 SD 8.388 4.711 RF 6.881 4.223 7.825 4.542 6.71 3.59 ET 6.835 4.212 7.900 4.578 5.82 2.82 ANN 7.282 4.775 8.376 4.760 0.14 –1.04 BA 6.882 4.213 7.804 3.952 6.96 16.11 RMSE 8.388 4.712 RF 6.881 4.225 7.826 4.543 6.70 3.59 ET 6.836 4.214 7.901 4.590 5.81 2.59 ANN 7.287 4.782 8.381 4.761 0.08 –1.04 BA 6.883 4.213 7.810 3.963 6.89 15.90
下載: 導出CSV
表 6 澳大利亞北領地研究區域模型測試和DEM校正實驗結果
單位 DEM校正前 方法 模型測試 DEM校正后 提升精度(%) SRTM ASTER SRTM ASTER SRTM ASTER SRTM ASTER MAE 2.341 6.507 RF 0.892 1.998 2.036 3.282 13.03 49.56 ET 0.893 1.997 0.395 0.840 83.13 87.09 ANN 1.060 2.646 1.127 3.659 51.86 43.77 BA 0.883 1.917 0.559 1.319 76.12 79.73 SD 2.955 7.756 RF 1.314 2.800 2.586 4.289 12.49 44.70 ET 1.315 2.813 0.972 2.361 67.11 69.56 ANN 1.493 3.573 2.436 4.798 17.56 38.14 BA 1.311 2.706 1.019 2.268 65.52 70.76 RMSE 2.960 7.762 RF 1.315 2.801 2.586 4.289 12.64 44.74 ET 1.317 2.816 0.973 2.362 67.13 69.57 ANN 1.494 3.573 2.437 4.807 17.67 38.07 BA 1.312 2.708 1.020 2.269 65.54 70.77
下載: 導出CSV
-
[1] OKOLIE C J and SMIT J L. A systematic review and meta-analysis of Digital elevation model (DEM) fusion: Pre-processing, methods and applications[J]. ISPRS Journal of Photogrammetry and Remote Sensing, 2022, 188: 1–29. doi: 10.1016/j.isprsjprs.2022.03.016. [2] ZHAO Yaqi and YE Hongxia. SqUNet: An high-performance network for crater detection with DEM data[J]. IEEE Journal of Selected Topics in Applied Earth Observations and Remote Sensing, 2023, 16: 8577–8585. doi: 10.1109/JSTARS.2023.3314128. [3] LUEDELING E, SIEBERT S, and BUERKERT A. Filling the voids in the SRTM elevation model — A TIN-based delta surface approach[J]. ISPRS Journal of Photogrammetry and Remote Sensing, 2007, 62(4): 283–294. doi: 10.1016/j.isprsjprs.2007.05.004. [4] FREY H and PAUL F. On the suitability of the SRTM DEM and ASTER GDEM for the compilation of topographic parameters in glacier inventories[J]. International Journal of Applied Earth Observation and Geoinformation, 2012, 18: 480–490. doi: 10.1016/J.JAG.2011.09.020. [5] SCHREYER J, BYRON WALKER B, and LAKES T. Implementing urban canopy height derived from a TanDEM-X-DEM: An expert survey and case study[J]. ISPRS Journal of Photogrammetry and Remote Sensing, 2022, 187: 345–361. doi: 10.1016/J.ISPRSJPRS.2022.02.015. [6] HUANG Huabing, CHEN Peimin, XU Xiaoqing, et al. Estimating building height in China from ALOS AW3D30[J]. ISPRS Journal of Photogrammetry and Remote Sensing, 2022, 185: 146–157. doi: 10.1016/j.isprsjprs.2022.01.022. [7] GONZALEZ J H, BACHMANN M, SCHEIBER R, et al. Definition of ICESat selection criteria for their use as height references for TanDEM-X[J]. IEEE Transactions on Geoscience and Remote Sensing, 2010, 48(6): 2750–2757. doi: 10.1109/TGRS.2010.2041355. [8] 劉燕, 林赟, 譚維賢, 等. 基于圓跡干涉SAR的DEM提取[J]. 電子與信息學報, 2015, 37(6): 1463–1469. doi: 10.11999/JEIT141022.LIU Yan, LIN Yun, TAN Weixian, et al. DEM extraction based on interferometric circular SAR[J]. Journal of Electronics & Information Technology, 2015, 37(6): 1463–1469. doi: 10.11999/JEIT141022. [9] HUESO GONZALEZ J, BACHMANN M, KRIEGER G, et al. Development of the TanDEM-X calibration concept: Analysis of systematic errors[J]. IEEE Transactions on Geoscience and Remote Sensing, 2010, 48(2): 716–726. doi: 10.1109/TGRS.2009.2034980. [10] LI Binbin, XIE Huan, TONG Xiaohua, et al. A global-scale DEM elevation correction model using ICESat-2 laser altimetry data[J]. IEEE Transactions on Geoscience and Remote Sensing, 2023, 61: 1–15. doi: 10.1109/TGRS.2023.3321956. [11] BAGHERI H, SCHMITT M, and ZHU Xiaoxiang. Fusion of TanDEM-X and cartosat-1 elevation data supported by neural network-predicted weight maps[J]. ISPRS Journal of Photogrammetry and Remote Sensing, 2018, 144: 285–297. doi: 10.1016/j.isprsjprs.2018.07.007. [12] TIAN Yu, LEI Shaogang, BIAN Zhengfu, et al. Improving the accuracy of open source digital elevation models with multi-scale fusion and a slope position-based linear regression method[J]. Remote Sensing, 2018, 10(12): 1861. doi: 10.3390/rs10121861. [13] POURSHAMSI M, XIA Junshi, YOKOYA N, et al. Tropical forest canopy height estimation from combined polarimetric SAR and LiDAR using machine-learning[J]. ISPRS Journal of Photogrammetry and Remote Sensing, 2021, 172: 79–94. doi: 10.1016/j.isprsjprs.2020.11.008. [14] MA Xiaojie, JI Kefeng, ZHANG Linbin, et al. SAR target open-set recognition based on joint training of class-specific sub-dictionary learning[J]. IEEE Geoscience and Remote Sensing Letters, 2024, 21: 1–5. doi: 10.1109/LGRS.2023.3342904. [15] HU Peng, ZHEN Liangli, PENG Xi, et al. Deep supervised multi-view learning with graph priors[J]. IEEE Transactions on Image Processing, 2024, 33: 123–133. doi: 10.1109/TIP.2023.3335825. [16] CHEN Yucong. Analysis and forecasting of California housing[J]. Highlights in Business, Economics and Management, 2023, 3: 128–135. doi: 10.54097/hbem.v3i.4704. [17] BALTRU?AITIS T, AHUJA C, and MORENCY L P. Multimodal machine learning: A survey and taxonomy[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2019, 41(2): 423–443. doi: 10.1109/TPAMI.2018.2798607. [18] USGS. https://earthexplorer.usgs.gov/, 2014. [19] GSCloud. Geospatial data cloud[EB/OL]. https://www.gscloud.cn/search, 2009. [20] EOC. Eoc geoservice[EB/OL]. https://download.geoservice.dlr.de/TDM90/, 2016. [21] ALOS. Aw3d30 dsm data map[EB/OL]. https://www.eorc.jaxa.jp/ALOS/en/aw3d30/data/index.htm, 2021. [22] NASA. Icesat-2 (ice, cloud, and land elevation satellite2)[EB/OL]. https://icesat-2.gsfc.nasa.gov/science/specs, 2018. [23] 王密, 韋鈺, 楊博, 等. ICESat-2/ATLAS全球高程控制點提取與分析[J]. 武漢大學學報(信息科學版), 2021, 46(2): 184–192. doi: 10.13203/j.whugis20200531.WANG Mi, WEI Yu, YANG Bo, et al. Extraction and analysis of global elevation control points from ICESat-2 /ATLAS data[J]. Geomatics and Information Science of Wuhan University, 2021, 46(2): 184–192. doi: 10.13203/j.whugis20200531. [24] ESA. Esa worldcover 10m 2020[EB/OL]. https://esa-worldcover.org/en, 2020. [25] National Earth System Science Data Center. Global 30-meter fine surface coverage products[EB/OL]. https://doi.org/10.12041/geodata.4200772.ver1.db, 2015. [26] ZHU Simin, GUENDEL R G, YAROVOY A, et al. Continuous human activity recognition with distributed radar sensor networks and CNN-RNN architectures[J]. IEEE Transactions on Geoscience and Remote Sensing, 2022, 60: 5115215. doi: 10.1109/TGRS.2022.3189746. [27] QUADRIANTO N and GHAHRAMANI Z. A very simple safe-Bayesian random forest[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2015, 37(6): 1297–1303. doi: 10.1109/TPAMI.2014.2362751. [28] GEURTS P, ERNST D, and WEHENKEL L. Extremely randomized trees[J]. Machine Learning, 2006, 63(1): 3–42. doi: 10.1007/s10994-006-6226-1. [29] FUMERA G, ROLI F, and SERRAU A. A theoretical analysis of bagging as a linear combination of classifiers[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2008, 30(7): 1293–1299. doi: 10.1109/TPAMI.2008.30. -
