一種基于有限內存擬牛頓法的混合波束成形算法

嚴軍榮; 江沛蓮; 李沛

doi:10.11999/JEIT230656

一種基于有限內存擬牛頓法的混合波束成形算法

doi: 10.11999/JEIT230656 cstr: 32379.14.JEIT230656

杭州電子科技大學通信工程學院杭州 310000

基金項目: 國家自然科學基金(U21A20450, 62301204)

詳細信息

作者簡介:
嚴軍榮：男，講師，研究方向?yàn)闊o(wú)線通信網絡、軟件定義網絡、視覺目標跟蹤等

江沛蓮：女，碩士生，研究方向?yàn)闊o(wú)線電通信系統、毫米波大規模MIMO系統中的預編碼技術

李沛：女，講師，研究方向?yàn)槎嗖ㄊ鴤鬏?、空間資源優化、延時感知節能方案等

通訊作者:
嚴軍榮　yjrcn@163.com

中圖分類號: TN929.5
計量
- 文章訪問數: 234
- HTML全文瀏覽量: 282
- PDF下載量: 31
- 被引次數: 0
出版歷程
- 收稿日期: 2023-07-03
- 修回日期: 2023-11-13
- 錄用日期: 2023-11-14
- 網絡出版日期: 2023-11-21
- 刊出日期: 2024-06-30

A Hybrid Beamforming Algorithm Based on Limited-Broyden-Fletcher-Goldfarb-Shanno

School of Communication Engineering, Hangzhou Dianzi University, Hangzhou 310000, China

Funds: The National Natural Science Foundation of China (U21A20450, 62301204)

摘要

摘要: 針對現有混合波束成形算法運行時間長、頻譜效率低、誤碼率高的問題，該文提出一種基于有限內存擬牛頓法的混合波束成形算法(LBFGS)。該算法首先通過數字預編碼器的最小二乘解構建單變量目標函數；然后采用目標函數的梯度近似黑塞矩陣的逆得到搜索方向并沿搜索方向更新模擬預編碼器，直到滿足停止條件；最后固定模擬預編碼器得到數字預編碼器。MATLAB仿真結果表明，LBFGS算法較現有MO算法減少了28%的運行時間，頻譜效率提高了1.05%，誤碼率降低了1.06%。
- 毫米波 /
- 大規模MIMO /
- 混合波束成形 /
- 重疊天線陣列
Abstract: To solve the problems of long runtime, low spectral rate and high bit error rate, which exist in conventional hybrid beamforming schemes, a hybrid beamforming algorithm based on Limited-Broyden-Fletcher-Goldfarb-Shanno (LBFGS) is proposed. Firstly, a single variable objective function is constructed through the least squares solution of the digital precoder. Then, the gradient of the objective function is used to approximate the inverse of the Hessian matrix for obtaining the search direction and the analog precoder is updated along the search direction until the stop condition is satisfied. Finally, the analog precoder is fixed to obtain the digital precoder. The MATLAB simulation analysis indicate that LBFGS algorithm reduces the running time by 28%, increases spectral rate by 1.05%, and reduces bit error rate by 1.06%, compared to MO algorithm.
- Millimeter wave /
- Massive MIMO /
- Hybrid beamforming /
- Overlapped antenna arrays

HTML全文

圖 1 點對點毫米波混合波束成形系統

下載: 全尺寸圖片幻燈片

圖 2 不同波束成形算法的內部循環總次數隨信噪比變化曲線

下載: 全尺寸圖片幻燈片

圖 3 不同波束成形算法的運行時間隨信噪比的變化曲線

下載: 全尺寸圖片幻燈片

圖 4 不同波束成形算法的頻譜效率隨信噪比的變化曲線

下載: 全尺寸圖片幻燈片

圖 5 不同波束成形算法的誤碼率隨信噪比的變化曲線

下載: 全尺寸圖片幻燈片

算法1　計算搜索方向
輸入：${\gamma _0}{\text{ = }}1$，${\mathrm{grad}}{{\boldsymbol{\mathcal{J}}}_{{{\boldsymbol{v}}_k}}}$，已存儲的梯度向量　$ \{ {\boldsymbol{s}}_i^{(k)},{\boldsymbol{y}}_i^{(k)}\} _{i = k - m}^{k - 1} $
輸出：搜索方向${{\boldsymbol{\eta}} _k}$
${\boldsymbol{\mathcal{H}}}_k^0 = {\gamma _k}$；
$ {\boldsymbolq7j3ldu95} \leftarrow {\mathrm{grad}}{{\boldsymbol{\mathcal{J}}}_{{v_k}}} $；
If $m \ne 0$
for $i = k - 1,k - 2, \cdots ,k - m$do
${\boldsymbol{\alpha}} \leftarrow {\rho _i} < {\boldsymbol{s}}_i^{(k)},{\boldsymbolq7j3ldu95} > $
${\boldsymbolq7j3ldu95} \leftarrow {\boldsymbolq7j3ldu95} - {\alpha _i}{\boldsymbol{y}}_i^{(k)}$
end for
${\boldsymbol{e}} \leftarrow {\boldsymbol{\mathcal{H}}}_k^0{\boldsymbolq7j3ldu95}$
for $i = k - m,k - m + 1, \cdots ,k - 1$
$\beta \leftarrow {\rho _i} < {\boldsymbol{y}}_i^{(k)},{\boldsymbol{e}} > $
$ {\boldsymbol{e}} \leftarrow {\boldsymbol{e}} + {\boldsymbol{s}}_i^{(k)} < {\varepsilon _i} - \beta > $
end for
${{\boldsymbol{\eta}} _k} = - {\boldsymbol{e}}$
else
${{\boldsymbol{\eta}} _k} = - {\boldsymbol{\mathcal{H}}}_k^0{\boldsymbolq7j3ldu95}$
end if

下載: 導出CSV

算法2　基于有限內存擬牛頓法的模擬預編碼器算法
輸入：最優全數字矩陣${{\boldsymbol{V}}_{\rm{opt}}}$，初始模擬波束成形矩陣${\boldsymbol{V}}_{\rm{RF}}^0$，內存　容量$\forall M \in \mathbb{Z}$且$M > 0$。
輸出：${{\boldsymbol{V}}_{\rm{RF}}}$
初始化：內部循環次數$k = 0$，內存占用量$m = 0$
根據式(10)計算黎曼梯度${\mathrm{grad}}{{\boldsymbol{\mathcal{J}}}_{{{\boldsymbol{v}}_0}}}$
while梯度的范數達到閾值${\mu _2}$
根據算法1計算搜索方向${{\boldsymbol{\eta}} _k}$
線搜索并回縮得到${{\boldsymbol{v}}_{k + 1}}{\text{ = }}{{{R}}_{{{\boldsymbol{v}}_k}}}({\alpha _k}{{\boldsymbol{\eta}} _k})$
計算黎曼梯度${\mathrm{grad}}{{\boldsymbol{\mathcal{J}}}_{{{\boldsymbol{v}}_{k + 1}}}}$
計算$ {\boldsymbol{s}}_k^{(k + 1)} $，$ {\boldsymbol{y}}_k^{(k + 1)} $，${\rho _{k + 1}} = 1/ < {\boldsymbol{s}}_k^{(k + 1)},{\boldsymbol{y}}_k^{(k + 1)} > $
if 滿足存儲條件
計算${\gamma _{k + 1}} = < {\boldsymbol{s}}_k^{(k + 1)},{\boldsymbol{y}}_k^{(k + 1)} > /\|\|{\boldsymbol{y}}_k^{(k + 1)}\|{\|^2}$
if溢出
丟棄$ {\boldsymbol{s}}_{k - M}^{(k)} $，$ {\boldsymbol{y}}_{k - M}^{(k)} $；
end if
歷史梯度向量傳輸
存儲$ {\text{\{ }}{\boldsymbol{s}}_k^{(k + 1)},{\boldsymbol{y}}_k^{(k + 1)}{\text{\} }} $
若$m < M$，那么$m = m + 1$，否則$m = M$
else
${\gamma _{k + 1}} = {\gamma _k}$；
end if
$k \leftarrow k + 1$
end

下載: 導出CSV

參考文獻(20)

[1]	SAAD W, BENNIS M, and CHEN Mingzhe. A vision of 6G wireless systems: Applications, trends, technologies, and open research problems[J]. IEEE Network, 2020, 34(3): 134–142. doi: 10.1109/MNET.001.1900287.
[2]	ZHANG Jun, YU Xianghao, and LETAIEF K B. Hybrid beamforming for 5G and beyond millimeter-wave systems: A holistic view[J]. IEEE Open Journal of the Communications Society, 2020, 1: 77–91. doi: 10.1109/OJCOMS.2019.2959595.
[3]	ABDULLAH Q, SALH A, MOHDSHAH N S, et al. A brief survey and investigation of hybrid beamforming for millimeter waves in 5G massive MIMO systems[J]. arXiv: 2105.00180, 2021. doi: 10.48550/arXiv.2105.00180.
[4]	RIHAN M, SOLIMAN T A, XU Chen, et al. Taxonomy and performance evaluation of hybrid beamforming for 5G and beyond systems[J]. IEEE Access, 2020, 8: 74605–74626. doi: 10.1109/ACCESS.2020.2984548.
[5]	UWAECHIA A N and MAHYUDDIN N M. A comprehensive survey on millimeter wave communications for fifth-generation wireless networks: feasibility and challenges[J]. IEEE Access, 2020, 8: 62367–62414. doi: 10.1109/ACCESS.2020.2984204.
[6]	ULLAH M S, SARKER S C, ASHRAF Z B, et al. Spectral efficiency of multiuser massive MIMO-OFDM THz wireless systems with hybrid beamforming under inter-carrier interference[C]. Proceedings of the 12th International Conference on Electrical and Computer Engineering (ICECE), Dhaka, Bangladesh, 2022: 228–231. doi: 10.1109/ICECE57408.2022.10089136.
[7]	LIU Ying and WANG Jintao. Low-complexity OFDM-based hybrid precoding for multiuser massive MIMO systems[J]. IEEE Wireless Communications Letters, 2020, 9(3): 263–266. doi: 10.1109/lwc.2019.2929518.
[8]	ZHAO Xingyu, LIN Tian, ZHU Yu, et al. Partially-connected hybrid beamforming for spectral efficiency maximization via a weighted MMSE equivalence[J]. IEEE Transactions on Wireless Communications, 2021, 20(12): 8218–8232. doi: 10.1109/TWC.2021.3091524.
[9]	趙峰, 何曉華. 混合動態連接結構的多用戶多流混合預編碼[J]. 電子與信息學報, 2021, 43(9): 2647–2653. doi: 10.11999/JEIT 200441. ZHAO Feng and HE Xiaohua. Multi-user multi-stream hybrid precoding with hybrid dynamic connection structure[J]. Journal of Electronics & Information Technology, 2021, 43(9): 2647–2653. doi: 10.11999/JEIT 200441.
[10]	AYACH O E, RAJAGOPAL S, ABU-SURRA S, et al. Spatially sparse precoding in millimeter wave MIMO systems[J]. IEEE Transactions on Wireless Communications, 2014, 13(3): 1499–1513. doi: 10.1109/TWC.2014.011714.130846.
[11]	YU Xianghao, SHEN J C, ZHANG Jun, et al. Alternating minimization algorithms for hybrid precoding in millimeter wave MIMO systems[J]. IEEE Journal of Selected Topics in Signal Processing, 2016, 10(3): 485–500. doi: 10.1109/JSTSP.2016.2523903.
[12]	JIN Juening, ZHENG Y R, CHEN Wen, et al. Hybrid precoding for millimeter wave MIMO systems: A matrix factorization approach[J]. IEEE Transactions on Wireless Communications, 2018, 17(5): 3327–3339. doi: 10.48550/arXiv.2003.11972.
[13]	LI Jinmeng, CHENG Zhiqun, and LI Hang. Hybrid precoding scheme in millimeter wave massive MIMO based on stochastic gradient descent[C]. Proceedings of 2021 IEEE Asia Conference on Information Engineering (ACIE), Sanya, China, 2021: 22–26. doi: 10.1109/ACIE51979.2021.9381072.
[14]	劉文龍, 黃雯靜, 王本巍, 等. 毫米波單用戶多天線系統的混合預編碼設計[J]. 電子與信息學報, 2022, 44(2): 620–626. doi: 10.11999/JEIT202019. LIU Wenlong, HUANG Wenjing, WANG Benwei, et al. Hybrid precoding design in millimeter wave single-user large-scale multiple-input multiple-output system[J]. Journal of Electronics & Information Technology, 2022, 44(2): 620–626. doi: 10.11999/JEIT202019.
[15]	HUANG Wen. Optimization algorithms on Riemannian manifolds with applications[D]. [Ph. D. dissertation], Florida State University, 2013.
[16]	ZANG Guangda, HU Lingna, YANG Feng, et al. Partially-connected hybrid beamforming for multi-user massive MIMO systems[J]. IEEE Access, 2020, 8: 215287–215298. doi: 10.1109/ACCESS.2020.3040508.
[17]	SONG Nuan, YANG Tao, and SUN Huan. Overlapped subarray based hybrid beamforming for millimeter wave multiuser massive MIMO[J]. IEEE Signal Processing Letters, 2017, 24(5): 550–554. doi: 10.1109/LSP.2017.268 1689.
[18]	BOUMAL N. An Introduction to Optimization on Smooth Manifolds[M]. Cambridge: Cambridge University Press, 2023: 5–151. doi: 10.1017/9781009166164.
[19]	KASAI H. Fast optimization algorithm on complex oblique manifold for hybrid precoding in millimeter wave MIMO systems[C]. Proceedings of 2018 IEEE Global Conference on Signal and Information Processing (GlobalSIP), Anaheim, USA, 2018: 1266–1270. doi: 10.1109/GlobalSIP.2018.8646553.
[20]	LIN Tian, CONG Jiaqi, ZHU Yu, et al. Hybrid beamforming for millimeter wave systems using the MMSE criterion[J]. IEEE Transactions on Communications, 2019, 67(5): 3693–3708. doi: 10.1109/TCOMM.2019.2893632.
