基于強化學習的802.11ax上行鏈路調度算法

黃新林; 鄭人華

doi:10.11999/JEIT210590

基于強化學習的802.11ax上行鏈路調度算法

doi: 10.11999/JEIT210590 cstr: 32379.14.JEIT210590

黃新林,
鄭人華^,

同濟大學電子與信息工程學院上海 201800

基金項目: 國家自然科學基金(62071332)，上海市青年科技啟明星計劃(19QA1409100)，中央高?；究蒲袠I(yè)務費專項資金

詳細信息

作者簡介:
黃新林：男，1985年生，教授，博士生導師，研究方向?yàn)闄C(jī)器學習與智能通信

鄭人華：男，1996年生，碩士生，研究方向?yàn)閺?qiáng)化學習與智能通信

通訊作者:
鄭人華　471539350@qq.com

中圖分類號: TN915; TP393
計量
- 文章訪問數: 940
- HTML全文瀏覽量: 623
- PDF下載量: 120
- 被引次數: 0
出版歷程
- 收稿日期: 2021-06-17
- 修回日期: 2022-01-16
- 錄用日期: 2022-01-14
- 網絡出版日期: 2022-02-02
- 刊出日期: 2022-05-25

802.11ax Uplink Scheduling Algorithm Based on Reinforcement Learning

HUANG Xinlin,
ZHENG Renhua^,

College of Electronic and Information Engineering, Tongji University, Shanghai 201800, China

Funds: The National Natural Science Foundation of China (62071332), Shanghai Rising-Star Program (19QA1409100), The Fundamental Research Funds for the Central Universities

摘要

摘要: 隨著物聯網(IoT)時代的到來，無線網絡飽和的問題已經越來越嚴重。為了克服終端密集接入問題，IEEE標準協會(IEEE-SA)制定了無線局域網的最新標準—IEEE 802.11ax。該標準使用正交頻分多址(OFDMA)技術對無線信道資源進行了更細致的劃分，劃分出的子信道被稱為資源單元(RU)。為解決密集用戶環境下802.11ax 上行鏈路的信道資源調度問題，該文提出一種基于強化學習的RU調度算法。該算法使用演員-評論家(Actor-Critic)算法訓練指針網絡，解決了自適應RU調度問題，最終合理分配RU資源給各用戶，兼具優先級和公平性的保障。仿真結果表明，該調度算法在IEEE 802.11ax上行鏈路中比傳統的調度方式更有效，具有較強的泛化能力，適合應用在密集用戶環境下的物聯網場景中。
- 物聯網 /
- IEEE 802.11ax /
- 強化學習 /
- 上行鏈路 /
- 演員-評論家
Abstract: With the arrival of the Internet of Things (IoT) era, the problem of wireless network saturation has become more and more serious. In order to overcome this problem, the IEEE Standards Association (IEEE-SA) has formulated the latest standard for wireless local area networks—IEEE 802.11ax. In this standard, the Orthogonal Frequency Division Multiple Access (OFDMA) technology is utilized to divide wireless channel into several groups of tones, and the divided sub-channels are called Resource Units (RUs). In order to solve the channel resource scheduling problem of 802.11ax uplink in dense user environments, an RU scheduling algorithm based on reinforcement learning is proposed in this paper. The Actor-Critic algorithm is used to train the pointer network and solve the adaptive allocation problem of RU. Finally, RUs are allocated to each user reasonably with the guarantee of priority and fairness. The simulation results show that the scheduling algorithm is more effective than traditional scheduling methods in the IEEE 802.11ax uplink and has a strong generalization ability, which is suitable for the IoT scenario in dense user environments.
- Internet of Things (IoT) /
- IEEE 802.11ax /
- Reinforcement learning /
- Uplink /
- Actor-Critic

HTML全文

圖 1 使用各種大小的RU劃分20 MHz的信道

下載: 全尺寸圖片幻燈片

圖 2 基于OFDMA的802.11ax上行鏈路調度接入過程

下載: 全尺寸圖片幻燈片

圖 3 指針網絡結構圖

下載: 全尺寸圖片幻燈片

圖 4 本文算法的吞吐量隨時間變化的仿真結果

下載: 全尺寸圖片幻燈片

圖 5 4種算法下STA₁和STA₆₃的吞吐量隨時間變化的仿真結果

下載: 全尺寸圖片幻燈片

圖 6 4種算法上行鏈路數據流總價值隨時間變化的仿真結果

下載: 全尺寸圖片幻燈片

圖 7 4種算法上行鏈路數據流平均總價值與STA數量的關系

下載: 全尺寸圖片幻燈片

表 1 QoS值與業務類型對應關系

QoS	業務類型
1	探測請求、火災報警、交通事故報警等
2	患者監測、工業設備監測等
3	智能家居、智慧農業、倉儲管理等
4	監控視頻、智能水表、智能電表等
5	信道質量指示符、無線電測量服務等

下載: 導出CSV

表 2 不同MCS與不同RU大小情況下的數據傳輸速率(Mbps)

MCS索引	MCS	26 tones	52 tones	106 tones	242 tones	484 tones	996 tones
1	BPSK, 1/2	0.8	1.7	3.5	8.1	46.3	34.0
2	QPSK, 1/2	1.7	3.3	7.1	16.3	32.5	68.1
3	QPSK, 3/4	2.5	5.0	10.6	24.4	48.8	102.1
4	16-QAM, 1/2	3.3	6.7	14.2	32.5	65.0	136.1
5	16-QAM, 3/4	5.0	10.0	21.3	48.8	97.5	204.2
6	64-QAM, 2/3	6.7	13.3	28.3	65.0	130.0	272.2
7	64-QAM, 3/4	7.5	15.0	31.9	73.1	146.3	306.3
8	64-QAM, 5/6	8.3	16.7	35.4	81.3	162.5	340.3
9	256-QAM, 3/4	10.0	20.0	42.5	97.5	195.0	408.3
10	256-QAM, 5/6	11.1	22.2	47.2	108.3	216.7	453.7
11	1024-QAM, 3/4	–	–	–	121.9	243.8	510.4

下載: 導出CSV

表 3 Actor-Critic算法訓練指針網絡的過程

(1) 初始化超參數，初始化訓練集$ {C^{{\text{in}}}} $，設置訓練總步長$ T $，設置　　批次數$ N $
(2) 初始化指針網絡參數$ \theta $
(3) 初始化Critic網絡參數$ {\theta _v} $
(4) for t = 1 to $ T $：
(5) 從訓練集中獲取輸入：
${c_i}{ {\sim {\rm{SampleInput} }(} }{C^{ {\text{in} } } }){\text{ for } }i \in \{ 1,2,\cdots,N\}$
(6) 　　使用$ \theta $選出物品子集：　${\pi _i}\sim{\text{SampleSolution(} }{p_\theta }(.\|{c_i}){\text{) for } }i \in \{ 1,2,\cdots,N\}$
(7) 　　使用$ {\theta _v} $計算基線值：　　　　 $b({c_i}) = {b_{ {\theta _v} } }({{\boldsymbol{c}}_i}){\text{ for } }i \in \{ 1,2,\cdots,N\}$
(8) 　　計算Actor目標函數的梯度：　　　　${{\text{?}}_\theta }J(\theta ) = \dfrac{1}{N}\displaystyle\sum\limits_{i = 1}^N ( V({\pi _i}\|{{\boldsymbol{c}}_i}) - b({c_i})){{\text{?}}_\theta }\ln {p_\theta }({\pi _i}\|{{\boldsymbol{c}}_i})$
(9) 　　計算Critic的損失函數：　　　　$L({\theta _v}) = \frac{1}{N}\displaystyle\sum\limits_{i = 1}^N \parallel {b_{ {\theta _v} } }({{\boldsymbol{c}}_i}) - V({\pi _i}\|{{\boldsymbol{c}}_i})\parallel _2^2$
(10) 　　使用Adam優化器對參數$ \theta $進行更新：
$\theta = {\text{Adam(} }\theta ,{{\text{?}}_\theta }J(\theta ){\text{)} }$
(11) 　　　使用Adam優化器對參數$ {\theta _v} $進行更新：
${\theta _v} = {\text{Adam(} }{\theta _v},{{\text{?}}_{ {\theta _v} } }L({\theta _v}){\text{)} }$
(12) end

下載: 導出CSV

表 4 4種算法下5個STA代表的平均等待時間

算法名	STA₁	STA₂₁	STA₄₁	STA₆₁	STA₈₁
輪詢算法	8.73	8.83	8.73	8.60	9.01
PRA算法	5.42	7.36	10.87	13.84	16.90
自適應分組算法	9.10	9.14	9.12	9.13	9.61
本文算法	4.49	5.65	7.97	9.31	11.56

下載: 導出CSV

參考文獻(17)

[1]	LEE J. OFDMA-based hybrid channel access for IEEE 802.11ax WLAN[C]. 2018 14th International Wireless Communications & Mobile Computing Conference (IWCMC), Limassol, Cyprus, 2018: 188–193.
[2]	BHATTARAI S, NAIK G, and PARK J M J. Uplink resource allocation in IEEE 802.11ax[C]. ICC 2019-2019 IEEE International Conference on Communications (ICC), Shanghai, China, 2019: 1–6.
[3]	PIRO G, GRIECO L A, BOGGIA G, et al. Two-level downlink scheduling for real-time multimedia services in LTE networks[J]. IEEE Transactions on Multimedia, 2011, 13(5): 1052–1065. doi: 10.1109/TMM.2011.2152381
[4]	SAFA H and TOHME K. LTE uplink scheduling algorithms: Performance and challenges[C]. 2012 19th International Conference on Telecommunications (ICT), Jounieh, Lebanon, 2012: 1–6.
[5]	KARTHIK R M and PALANISWAMY S. Resource unit (RU) based OFDMA scheduling in IEEE 802.11ax system[C]. 2018 International Conference on Advances in Computing, Communications and Informatics (ICACCI), Bangalore, India, 2018: 1297–1302.
[6]	BANKOV D, DIDENKO A, KHOROV E, et al. OFDMA uplink scheduling in IEEE 802.11ax Networks[C]. 2018 IEEE International Conference on Communications (ICC), Kansas City, USA, 2018: 1–6.
[7]	WANG Kaidong and PSOUNIS K. Scheduling and Resource Allocation in 802.11ax[C]. IEEE INFOCOM 2018-IEEE Conference on Computer Communications, Honolulu, USA, 2018: 279–287.
[8]	唐倫, 賀小雨, 王曉, 等. 基于遷移演員-評論家學習的服務功能鏈部署算法[J]. 電子與信息學報, 2020, 42(11): 2671–2679. doi: 10.11999/JEIT190542 TANG Lun, HE Xiaoyu, WANG Xiao, et al. Deployment algorithm of service function chain based on transfer actor-critic learning[J]. Journal of Electronics &Information Technology, 2020, 42(11): 2671–2679. doi: 10.11999/JEIT190542
[9]	AFAQUI M S, GARCIA-VILLEGAS E, and LOPEZ-AGUILERA E. IEEE 802.11ax: Challenges and requirements for future high efficiency WiFi[J]. IEEE Wireless Communications, 2017, 24(3): 130–137. doi: 10.1109/MWC.2016.1600089WC
[10]	MACHROUH Z and NAJID A. High efficiency WLANs IEEE 802.11ax performance evaluation[C]. 2018 International Conference on Control, Automation and Diagnosis (ICCAD), Marrakech, Morocco, 2018: 1–5.
[11]	ZHOU Hu, LI Bo, YAN Zhongjiang, et al. An OFDMA based multiple access protocol with QoS guarantee for next generation WLAN[C]. 2015 IEEE International Conference on Signal Processing, Communications and Computing (ICSPCC), Ningbo, China, 2015: 1–6.
[12]	FILOSO D G, KUBO R, HARA K, et al. Proportional-based resource allocation control with QoS adaptation for IEEE 802.11ax[C]. ICC 2020-2020 IEEE International Conference on Communications (ICC), Dublin, Ireland, 2020: 1–6.
[13]	BAI Jiyang, FANG He, SUH J, et al. An adaptive grouping scheme in ultra-dense IEEE 802.11ax network using buffer state report based two-stage mechanism[J]. China Communications, 2019, 16(9): 31–44. doi: 10.23919/JCC.2019.09.003
[14]	DUAN Ren, CHEN Xiaojiang, and XING Tianzhang. A QoS architecture for IOT[C]. 2011 International Conference on Internet of Things and 4th International Conference on Cyber, Physical and Social Computing, Dalian, China, 2011: 717–720.
[15]	VINYALS O, FORTUNATO M, and JAITLY N. Pointer networks[J]. arXiv: 1506.03134, 2015.
[16]	BELLO I, PHAM H, LE Q V, et al. Neural combinatorial optimization with reinforcement learning[J]. arXiv: 1611.09940, 2017.
[17]	李晨溪, 曹雷, 陳希亮, 等. 基于云推理模型的深度強化學習探索策略研究[J]. 電子與信息學報, 2018, 40(1): 244–248. doi: 10.11999/JEIT170347 LI Chenxi, CAO Lei, CHEN Xiliang, et al. Cloud reasoning model-based exploration for deep reinforcement learning[J]. Journal of Electronics &Information Technology, 2018, 40(1): 244–248. doi: 10.11999/JEIT170347
