基于Ransac算法的捷變頻聯合正交頻分復用雷達高速多目標參數估計

全英匯; 高霞; 沙明輝; 方文; 李亞超; 邢孟道

doi:10.11999/JEIT200529

基于Ransac算法的捷變頻聯合正交頻分復用雷達高速多目標參數估計

doi: 10.11999/JEIT200529 cstr: 32379.14.JEIT200529

1.
西安電子科技大學電子工程學院西安 710071
2.
北京無線電測量研究所北京 100854
3.
西安電子科技大學雷達信號處理國家重點實驗室西安 710071

基金項目: 國家自然科學基金(61303035, 61772397)，中央高?；究蒲袠I(yè)務費專項資金，西安電子科技大學研究生創新基金

詳細信息

作者簡介:
全英匯：男，1981年生，博士，教授，研究方向?yàn)槔走_(dá)信號處理、主動波形對抗

高霞：女，1996年生，碩士生，研究方向?yàn)槔走_(dá)信號處理

沙明輝：男，1986年生，博士生，研究方向?yàn)槔走_(dá)抗干擾和信號處理

方文：男，1996年生，碩士生，研究方向?yàn)槔走_(dá)信號處理

李亞超：男，1981年生，博士，教授，研究方向?yàn)槔走_(dá)成像和實時信號處理

邢孟道：男，1975年生，博士，教授，研究方向?yàn)镾AR/ISAR成像、動目標檢測等

通訊作者:
高霞　2636897970@qq.com

中圖分類號: TN957.51
計量
- 文章訪問數: 1241
- HTML全文瀏覽量: 551
- PDF下載量: 71
- 被引次數: 0
出版歷程
- 收稿日期: 2020-06-29
- 修回日期: 2020-12-06
- 網絡出版日期: 2020-12-15
- 刊出日期: 2021-07-10

High Speed Multi-target Parameter Estimation for FA-OFDM Radar Based on Ransac Algorithm

1.
School of Electronic Engineering, Xidian University, Xi’an 710071, China
2.
Beijing Institute of Radio Measurement, Beijing 100854, China
3.
National Key Laboratory of Radar Signal Processing, Xidian University, Xi’an 710071, China

Funds: The National Natural Science Foundation of China (61303035, 61772397), The Foundation Research Funds for Central University, The Innovation Fund of Xidian University

摘要

摘要: 在現代雷達電子戰場中，目標檢測與其參數估計有著非常重要的意義。因此，該文提出了一種基于隨機抽樣一致算法(Ransac)的捷變頻聯合正交頻分復用(FA-OFDM)雷達高速多目標參數估計的方法。首先，在傳統捷變頻雷達的每個脈沖內同時發射多個頻率隨機跳變的窄帶OFDM子載波。將單個脈沖內所有子載波的回波信號進行脈沖壓縮后，采用迭代自適應譜估計(IAA)算法合成目標的高分辨距離。然后，分別對各個脈沖的回波進行脈沖壓縮和迭代自適應譜估計，得到不同脈沖時刻的高分辨距離，構成觀測數據集。再根據Ransac算法估計信號參數模型的步驟，擬合多條時間-距離直線，進而對高速運動的多個目標同時進行參數估計。最后，分別分析了信噪比(SNR)對檢測概率以及目標自身速度對其相對估計誤差的影響。仿真實驗驗證了所提算法的有效性。
- 參數估計 /
- 高速多目標 /
- 捷變頻聯合正交頻分復用雷達 /
- 迭代自適應譜估計算法 /
- 隨機抽樣一致算法
Abstract: In modern radar electronic battlefield, target detection and parameter estimation have great significance. Therefore, a high-speed multi-target parameter estimation method for Frequency Agile-Orthogonal Frequency Division Multiplexing (FA-OFDM) radar based on Random sampling consensus (Ransac) algorithm is proposed in this paper. Firstly, multiple narrowband OFDM subcarriers with random frequency hopping are simultaneously transmitted in each pulse of conventional frequency agile radar. The echo signals of all subcarriers in a single pulse are compressed, and then the high-resolution range of the target is synthesized by Iterative Adaptive Approach (IAA) algorithm. Furthermore, the echoes of each pulse are compressed and iterative adaptive spectrum estimated, and the high-resolution distance of different pulse time is obtained to form the observation data set. Then, according to the steps of the Ransac algorithm to estimate the signal parameter model, multiple time-distance lines are fitted, and then parameters of multiple high-speed moving targets are estimated at the same time. Finally, the influence of the Signal-to-Noise Ratio (SNR) on detection probability and the target velocity on relative error of estimation are analyzed, respectively. Simulations are provided to verify the effectiveness of the proposal.

HTML全文

圖 1 FA-OFDM雷達發射信號示意圖

下載: 全尺寸圖片幻燈片

圖 2 3個相鄰目標仿真結果圖

下載: 全尺寸圖片幻燈片

圖 3 基于Ransac算法的高速多目標參數估計方法的流程圖

下載: 全尺寸圖片幻燈片

圖 4 信噪比為–12 dB時的仿真結果

下載: 全尺寸圖片幻燈片

圖 5 信噪比為–28 dB時的仿真結果

下載: 全尺寸圖片幻燈片

圖 6 信噪比對檢測概率的影響

下載: 全尺寸圖片幻燈片

圖 7 目標速度對估計誤差的影響

下載: 全尺寸圖片幻燈片

圖 8 輸出SNR對RMSE的影響

下載: 全尺寸圖片幻燈片

表 1 仿真參數

參數	數值	參數	數值
脈沖寬度	4 μs	脈沖重復頻率	25 kHz
信號帶寬	24 MHz	采樣頻率	48 MHz
子載波個數	64	中心載頻	14 GHz
跳頻總數	128	跳頻帶寬	20 MHz
脈沖總數	64	輸入信噪比	–12 dB / –28 dB
目標距離	[3994, 4001, 4006] m	目標速度	[600, 1220, 5800] m/s

下載: 導出CSV

參考文獻(21)

[1]	JANKIRAMAN M, WESSELS B J, and VAN GENDEREN P. Design of a multifrequency FMCW radar[C]. The 28th European Microwave Conference, Amsterdam, Netherlands, 1998: 548–589. doi: 10.1109/EUMA.1998.338053.
[2]	JANKIRAMAN M, WESSELS B J, and VAN GENDEREN P. Pandora multifrequency FMCW/SFCW radar[C].IEEE National Radar Conference, Alexandria, USA, 2000: 750–757. doi: 10.1109/RADAR.2000.851929.
[3]	霍凱, 趙晶晶. OFDM新體制雷達研究現狀與發展趨勢[J]. 電子與信息學報, 2015, 37(11): 2776–2785. doi: 10.11999/JEIT150335 HUO Kai and ZHAO Jingjing. The Development and prospect of the new OFDM radar[J]. Jounal of Electronics &Information Technology, 2015, 37(11): 2776–2785. doi: 10.11999/JEIT150335
[4]	WANG Jun, ZHANG Bochen, and LEI Peng. Ambiguity function analysis for OFDM radar signals[C]. CIE International Conference on Radar, Guangzhou, China, 2016: 10-13. doi: 10.1109/RADAR.2016.8059592.
[5]	肖博, 霍凱, 劉永祥. 雷達通信一體化研究現狀與發展趨勢[J]. 電子與信息學報, 2019, 41(3): 739–749. doi: 10.11999/JEIT180515 XIAO Bo, HUO Kai, and LIU Yongxiang. Development and Prospect of Radar and Communication Integration[J]. Jounal of Electronics &Information Technology, 2019, 41(3): 739–749. doi: 10.11999/JEIT180515
[6]	劉冰凡, 陳伯孝. 基于OFDM-LFM信號的MIMO雷達通信一體化信號共享設計研究[J]. 電子與信息學報, 2019, 41(4): 801–808. doi: 10.11999/JEIT180547 LIU Bingfan and CHEN Baixiao. Integration of MIMO Radar and Communication with OFDM-LFM Signals[J]. Jounal of Electronics &Information Technology, 2019, 41(4): 801–808. doi: 10.11999/JEIT180547
[7]	SCHWEIZER B, SCHINDLER D, KNILL C, et al. Expanding the unambiguous velocity limitation of the stepped-carrier OFDM radar scheme[C]. The 15th European Radar Conference, Madrid, Spanish, 2018: 26–28. doi: 10.23919/EuRAD.2018.8546621.
[8]	SCHWEIZER B, KNILL C, SCHINDLER D et al. Stepped-Carrier OFDM-Radar processing scheme to retrieve high-resolution range-velocity profile at low sampling rate[J]. IEEE Transactions on Microwave Theory and Techniques, 2018, 66(3): 1610–1618. doi: 10.1109/TMTT.2017.2751463
[9]	LELLOUCH G, TRAN P, PRIBIC R, et al. OFDM waveforms for frequency agility and opportunities for Doppler processing in radar[C]. IEEE Radar Conference, Rome, Italy, 2008: 1–6. doi: 10.1109/RADAR.2008.4720798.
[10]	HUO Kai, DENG B, LIU Y, et al. The principle of synthesizing HRRP based on a new OFDM phase-coded stepped-frequency radar signal[C]. IEEE 10th International Conference On Signal Processing Proceedings, Beijing, China, 2010: 1994–1998. doi: 10.1109/ICOSP.2010.5655889.
[11]	LELLOUCH G, PRIBIC R and VAN GENDEREN P. Frequency agile stepped OFDM waveform for HRR[C]. 2009 International Waveform Diversity and Design Conference, Kissimmee, USA, 2009: 90–93. doi: 10.1109/WDDC.2009.4800321.
[12]	黃瑞, 杜小勇, 胡衛東. OFDM雷達多目標運動參數的近似最大似然估計[J]. 雷達學報, 2018, 7(4): 507–513. doi: 10.12000/JR17116 HUANG Rui, DU Xiaoyong and HU Weidong. Approximate maximum likelihood estimator of multi-target motion parameters for orthogonal frequency division multiplexing radar[J]. Journal Of Radars, 2018, 7(4): 507–513. doi: 10.12000/JR17116
[13]	全英匯, 高霞, 沙明輝, 等. 基于期望最大化算法的捷變頻聯合正交頻分復用雷達高速多目標參數估計[J]. 電子與信息學報, 2018, 7(4): 507–513. doi: 10.11999/JEIT190474 QUAN Yinghui, GAO Xia, SHA Minghui, et al. High Speed Multi-target Parameter Estimation for FA-OFDM Radar Based on Expectation Maximization Algorithm[J]. Jounal of Electronics &Information Technology, 2018, 7(4): 507–513. doi: 10.11999/JEIT190474
[14]	QUAN Yinghui, LI Yachao, WU Yaojun, et al. Moving target detection for frequency agility radar by sparse reconstruction[J]. Rev. Sci. Instrum., 2016, 87(9): 811–815. doi: 10.1049/el.2011.1293
[15]	QUAN Yinghui, WU Yaojun, LI Yachao, et al. Range–Doppler reconstruction for frequency agile and PRF-jittering radar[J]. IET Radar, Sonar & Navigation, 2018, 12(3): 348–352. doi: 10.1049/iet-rsn.2017.0421
[16]	章平亮. 自適應迭代譜估計的統一分析與拓展[D]. 復旦大學. 2013: 9–20. ZHANG Pingliang. Unified analysis and development of adaptive iterative spectrum estimation[D]. Fudan University. 2013: 9–20.
[17]	JENSEN J R, GLENTIS G O, CHRISTENSEN M G, et al. Computationally efficient IAA-based estimation of the fundamental frequency[C]. 2012 Proceedings of the 20th European Signal Processing Conference(EUSIPCO), Bucharest, Romania, 2012.
[18]	GLENTIS G O and JAKOBSSON A. Efficient implementation of iterative adaptive approach spectral estimation techniques[J]. IEEE Transactions on Signal Processing, 2011, 59(7): 4154–4167. doi: 10.1109/TSP.2011.2145376
[19]	XUE Ming, XU Luzhou, and LI Jian. IAA Spectral Estimation: Fast implementation using the Gohberg-Semencul factorization[J]. IEEE Transactions on Signal Processing, 2011, 59(7): 3251–3261. doi: 10.1109/ICASSP.2011.5947305
[20]	ZHAO Mingfu, CHEN Haijun, SONG Tao, et al. Research on image matching based on improved RANSAC-SIFT algorithm[C]. 2017 16th International Conference on Optical Communications and Networks (ICOCN), Wuzhen, China, 2017: 1–3. doi: 10.1109/ICOCN.2017.8121270.
[21]	RAZA M A, AWAIS REHMAN M, QURESHI I M, et al. Mahmood. A Simplified approach to Visual Odometry using Graph Cut RANSAC[C]. 2018 5th International Multi-Topic ICT Conference (IMTIC), Jamshoro, 2018: 1–7. doi: 10.1109/IMTIC.2018.8467263.
