基于多目標進化策略算法的DNA核酸編碼設計

張凱; 陳彬; 許志偉

doi:10.11999/JEIT190869

基于多目標進化策略算法的DNA核酸編碼設計

doi: 10.11999/JEIT190869 cstr: 32379.14.JEIT190869

張凱^{1, 2},
陳彬¹,
許志偉^1, ,

1.
武漢科技大學計算機科學與技術學院武漢 430065
2.
智能信息處理和實時工業系統湖北省重點實驗室武漢 430065

基金項目: 國家自然科學基金(61472293, 61702383, 61602328)

詳細信息

作者簡介:
張凱：男，1979年生，教授，研究方向為DNA計算、多目標進化算法

陳彬：男，1982年生，碩士生，研究方向為智能優化算法

許志偉：男，1995年生，博士生，研究方向為DNA編碼、演化計算

通訊作者:
許志偉　xuzhiwei@wust.edu.cn

中圖分類號: TP301
計量
- 文章訪問數: 3933
- HTML全文瀏覽量: 1474
- PDF下載量: 114
- 被引次數: 0
出版歷程
- 收稿日期: 2019-11-01
- 修回日期: 2020-03-01
- 網絡出版日期: 2020-04-09
- 刊出日期: 2020-06-22

A Multiobjective Evolution Strategy Algorithm for DNA Sequence Design

Kai ZHANG^{1, 2},
Bin Chen¹,
Zhiwei Xu^{1
, ,}

1.
School of Computer Science and Technology, Wuhan University of Science and Technology, Wuhan 430065, China
2.
Hubei Province Key Laboratory of Intelligent Information Processing and Real-time Industrial System, Wuhan 430065, China)

Funds: The National Natural Science Foundation of China (61472293, 61702383, 61602328)

摘要

摘要: 設計高質量的核酸分子集合能有效提高DNA計算的可靠性、有效性和可求解問題的規模。DNA分子需要滿足熱力學約束、相似度約束、GC含量約束等多個相互沖突的目標函數，是典型的多目標優化問題。該文提出一種多目標進化策略(MOES)算法求解DNA分子序列設計問題，算法設計了隨機堿基變異算子實現高效的局部搜索和全局搜索。改進的評價函數綜合考慮了候選解的支配關系和沖突目標的平衡程度，選取符合DNA編碼約束的核酸序列。實驗結果證明，該文提出的算法具有高效的搜索效率和快速收斂能力，可以產生高質量的DNA序列集合，優于其他對比算法產生的DNA分子序列集合。
- DNA計算 /
- DNA序列設計 /
- 多目標進化算法 /
- 進化策略
Abstract: It is important to design high-quality DNA sequences set, which can improve the reliability and efficiency of DNA computing. DNA sequence design problem is an multiobjective optimization problem that needs to satisfy multiple conflict objectives which are thermodynamic constraint, similarity constraint and GC content constraint simultaneously. A MultiObjective Evolutionary Strategy (MOES) is proposed to solve the DNA sequence design problem. The random base mutation operator is designed for exploration and exploitation the search space. The fitness function is improved for obtaining balanced similarity and H-measure objective functions. Some state-of-the-art approaches are chosen to evaluate the effectivity of proposed algorithm. The experiment results show that the proposed multiobjective evolution strategy algorithm obtains very promising DNA sequences and outperforms previous approaches.
- DNA Computing /
- DNA sequence design /
- Multiobjective evolutionary algorithm /
- Evolution strategy

HTML全文

圖 1 非支配解集中的邊界點和理想解

下載: 全尺寸圖片幻燈片

圖 2 目標函數收斂過程

下載: 全尺寸圖片幻燈片

表 1 個體變異算子偽代碼

　輸入: X=$5' $–x₁x₂$ \cdots $x_n–$3' $

　輸出: Y=$5' $–y₁y₂$ \cdots $y_n–$3' $

　1: for j=1 to n

　2:　List.add(j)

　3: end for

　4: k=random(n)

　5: for j=1 to k

　6:　i = random(List.count)

　7:　y_i=(x_i+random(3)+1) mod 4

　8:　List.delete(i)

　9: end for

下載: 導出CSV

表 2 算法總體流程偽代碼

　1: Initialization

　2: while (t < max iteration)

　3:　for i=1 to P

　4:　　p = P_t(i)

　5:　　q = Individual Mutation(p)

　6:　　if q ? p then

　7:　　　P_t(i)=q

　8:　　else if (q ? p) and (p ? q) then

　9:　　　if Fitness(q) > Fitness(p) then

　10:　　　　P_t(i)=q

　11:　　　end if

　12:　　end if

　13:　end for

　14:　t=t+1

　15: end while

下載: 導出CSV

表 3 7條長度為20的DNA序列的結果比較

方法(序列)	連續性	發卡結構	H-measure	相似度	Tm	GC(%)
MGA^[7]
TAGACCACTGTTGCACATGG	0	0	58	52	50.2794	50
ATTCGGTCAGACTTGCTGTG	0	0	64	52	48.6650	50
ATAGTGCGGACAGTAGTTCC	0	0	66	59	50.1634	50
AATACGCGGAACGTAACCTC	0	0	61	85	50.4158	50
AATACGCGGAACGTAACCTC	0	0	61	85	50.4158	50
ACAGCCTTAAGCCTAACTCC	0	3	65	54	49.0641	50
ATGCTTCCGACATGGAATGG	0	3	63	57	49.8160	50
f (x)	0	6	438	444	1.7508	0
IWO^[8]
ACACCAGCACACCAGAAACA	9	0	55	55	48.4670	50
GTTCAATCGCCTCTCGGTAT	0	0	57	57	49.3935	50
GCTACCTCTTCCACCATTCT	0	0	55	55	49.2453	50
GAATCAATGGCGGTCAGAAG	0	0	66	66	49.9440	50
TTGGTCCGGTTATTCCTTCG	0	0	65	65	50.6418	50
CCATCTTCCGTACTTCACTG	0	0	56	56	51.0993	50
TTCGACTCGGTTCCTTGCTA	0	0	58	58	47.6049	50
f (x)	9	0	412	412	3.4944	0
pMO-ABC^[10]
TGTGGTTGGTTAGTCGGTTG	0	0	46	49	51.0421	50
GGTGGTATTGGTGGTATTGG	0	0	47	47	53.8027	50
CTTCTCTTCTCTTGCCGCTT	0	0	39	56	46.4112	50
AACAACCTCCACACCGAACA	0	0	62	32	49.1737	50
CTCTCTCTCTCACTCTCTCA	0	0	41	48	46.5220	50
CTCTCATTCCTTCTTACCCC	16	0	43	51	50.8283	50
TGGTGTTGCTGGTGTAGGTT	0	0	48	51	49.3985	50
f (x)	16	0	326	334	7.3915	0
MOES
GGAGAGGAGAAGAAGAAGAG	0	0	52	25	48.1727	50
CCTCCACATCACCATTAACC	0	0	56	31	52.3807	50
CTCTCTCTCTCTCTCTCTCT	0	0	34	37	45.6658	50
TTCCTTCCTTCCTTCCTTCC	0	0	36	39	48.7500	50
TTGGTTGGTTGGTTGGTTGG	0	0	30	46	51.3054	50
TTGTTGTTGGTGGTGGTGGT	0	0	30	48	50.2236	50
TGTGTGTGGTGTGTGTTGTG	0	0	30	46	51.0025	50
f (x)	0	0	268	272	6.7149	0

下載: 導出CSV

表 4 14條長度為20的DNA序列的結果比較

方法(序列)	連續性	發卡結構	H-measure	相似度	Tm	GC(%)
MGA^[7]
CTCATCTAATCAGCCTCGCA	0	0	135	114	48.1554	50
CTAATAGTGACAGCTGCGTG	0	3	131	119	50.2421	50
GCATCGTTAGAGACACCTAC	0	3	134	124	50.7932	50
GCATCAATATGCGCGACTAC	0	0	131	125	50.2815	50
CATTAAGTAGACGCTGTCGG	0	3	132	114	50.9507	50
TATGGATGAGGAGGACCTAG	0	3	133	117	50.6387	50
CAGAGATGTTCTGTACCACC	0	3	128	117	51.2232	50
CGTCGAGAATTCGTAGCTCA	0	0	137	119	48.3224	50
TCTGTTACCGTATCGGATCG	0	3	129	115	50.8791	50
AGAAGAGTTCGACTTGCTGG	0	3	134	121	47.5507	50
GCAAGGAATTCACCGTCTGT	0	3	133	129	48.9881	50
CGTGTGAAGAGAGTGGTTCA	0	0	127	123	48.9355	50
CGACTGAATCATGGACCTGT	0	3	134	126	49.7624	50
TACCGAGAAGTAGGACTGCA	0	3	134	124	48.3847	50
f (x)	0	30	1852	1687	3.6725	0
INSGA-II^[9]
CGAGACATCGTGCATATCGT	0	4	143	124	49.6393	50
TATAGCACGAGTGCGCGTAT	0	3	137	130	48.5659	50
GATCTACGATCATGAGAGCG	0	4	135	126	49.6673	50
TCTGTACTGCTGACTCGAGT	0	3	163	124	47.1312	50
CGAGTAGTCACACGATGAGA	0	0	152	132	49.2836	50
AGATGATCAGCAGCGACACT	0	3	133	133	46.5546	50
TGTGCTCGTCTCTGCATACT	0	4	159	130	47.1507	50
AGACGAGTCGTACAGTACAG	0	0	152	134	49.9091	50
ATGTACGTGAGATGCAGCAG	0	0	139	121	48.9270	50
ATCACTACTCGCTCGTCACT	0	3	141	132	47.5190	50
TCAGAGATACTCACGTCACG	0	3	142	123	49.2836	50
GACAGAGCTATCAGCTACTG	0	3	129	124	49.2927	50
GCTGACATAGAGTGCGATAC	0	0	130	133	50.1725	50
ACATCGACACTACTACGCAC	0	3	133	144	50.1554	50
f (x)	0	33	1988	1810	3.6179	0
pMO-ABC^[10]
GTTATTGGTGGTGTGCGTTG	0	0	143	82	51.9305	50
ACGGAAGTAGGAAGGAGAGA	0	0	137	106	47.8089	50
GGAAGACGCAGAAGAGAAAG	9	0	121	110	48.2609	50
CCTCCTTATTGCCTTCCTTC	0	0	114	102	50.3081	50
AACTAACCACCGACCAACCA	0	0	95	118	50.1102	50
ACACACAACACACACACTCC	0	0	88	119	50.4577	50
ACACCACCACATTACCACAC	0	0	97	119	51.9161	50
CTTCCGTCTCTTCTCTCTCT	0	0	134	105	46.9561	50
AAGGAGCGAGGAAGCGAAAA	16	0	107	95	45.8306	50
AACACCAGAACATCCACACC	0	0	90	131	50.5474	50
CCAACACCATACAACAGACC	0	0	95	130	52.3720	50
AAGGCGGAAGGATAGAAGAG	0	0	128	115	48.5370	50
TCTGCCGCTTCTTCTTCTTC	0	0	118	95	46.4000	50
TCCTCTCGTCTATTCTCCTC	0	0	111	98	48.4427	50
f (x)	25	0	1578	1525	6.5414	0
MOES
CATACACACTCACACTCACC	0	0	112	89	51.6792	50
TTGTTGTGGGTTGTCCGGTT	9	0	105	90	49.7949	50
ACACACACACACACACACAC	0	0	93	78	50.9244	50
TTGTGGTCCTGGTGTTCTCT	0	0	112	90	48.4957	50
GAGAGAGAGAGAGAGAGAGA	0	0	72	100	45.6568	50
TGGTGTGGTGTGGTTAGGTT	0	0	96	93	50.5325	50
TTGGTGGTGGTGGTTGTAGT	0	0	96	95	50.5325	50
CCAACCAACCAACCAACCAA	0	0	95	78	51.3054	50
AACAAGCCAGAAGCCAGAAG	0	0	94	102	47.5066	50
GTTGGTGCTGTTGTTGAGGT	0	0	101	99	49.4550	50
GAAGAAGGGAGGAGAGAAGA	9	0	77	108	47.4961	50
AATGGAAGCGAAGCGAAGTG	0	0	93	104	47.6766	50
AACCATCAACCGCCGAAGAA	0	3	104	95	48.1694	50
AAGGTGGAGAGGAAGGAGAA	0	0	82	111	47.4098	50
f (x)	18	3	1332	1332	6.0224	0

下載: 導出CSV

參考文獻(20)

ADLEMAN L M. Molecular computation of solutions to combinatorial problems[J]. Science, 1994, 266(5187): 1021–1024. doi: 10.1126/science.7973651

DE SILVA P Y and GANEGODA G U. New trends of digital data storage in DNA[J]. BioMed Research International, 2016: 8072463.

BRAICH R S, CHELYAPOV N, JOHNSON C, et al. Solution of a 20-variable 3-SAT problem on a DNA computer[J]. Science, 2002, 296(5567): 499–502. doi: 10.1126/science.1069528

ZIMMERMANN K H. Efficient DNA sticker algorithms for NP-complete graph problems[J]. Computer Physics Communications, 2002, 144(3): 297–309. doi: 10.1016/S0010-4655(02)00270-9

XU Jin, QIANG Xiaoli, ZHANG Kai, et al. A DNA computing model for the graph vertex coloring problem based on a probe graph[J]. Engineering, 2018, 4(1): 61–77. doi: 10.1016/j.eng.2018.02.011

CHAVES-GONZáLEZ J M and VEGA-RODRíGUEZ M A. A multiobjective approach based on the behavior of fireflies to generate reliable DNA sequences for molecular computing[J]. Applied Mathematics and Computation, 2014, 227: 291–308. doi: 10.1016/j.amc.2013.11.032

PENG Ximei, ZHENG Xuedong, WANG Bin, et al. A micro-genetic algorithm for DNA encoding sequences design[C]. The 2nd International Conference on Control Science and Systems Engineering, Singapore, 2016: 10–14.

YANG Gaijing, WANG Bin, ZHENG Xuedong, et al. IWO algorithm based on niche crowding for DNA sequence design[J]. Interdisciplinary Sciences: Computational Life Sciences, 2017, 9(3): 341–349. doi: 10.1007/s12539-016-0160-0

WANG Yanfeng, SHEN Yongpeng, ZHANG Xuncai, et al. An improved non-dominated sorting genetic algorithm-Ⅱ (INSGA-Ⅱ) applied to the design of DNA codewords[J]. Mathematics and Computers in Simulation, 2018, 151: 131–139. doi: 10.1016/j.matcom.2018.03.011

CHAVES-GONZáLEZ J M and MARTíNEZ-GIL J. An efficient design for a multi-objective evolutionary algorithm to generate DNA libraries suitable for computation[J]. Interdisciplinary Sciences: Computational Life Sciences, 2018, 11(3): 542–558.

YANG Shuming, SHAO Dongguo, and LUO Yangjie. A novel evolution strategy for multiobjective optimization problem[J]. Applied Mathematics and Computation, 2005, 170(2): 850–873. doi: 10.1016/j.amc.2004.12.025

ARNOLD D V and BEYER H G. Investigation of the (μ, λ)-ES in the presence of noise[C]. The 2001 Congress on Evolutionary Computation, Seoul, South Korea, 2001, 1: 332–339.

EBENAU C, ROTTSCH?FER J, and THIERAUF G. An advanced evolutionary strategy with an adaptive penalty function for mixed-discrete structural optimisation[J]. Advances in Engineering Software, 2005, 36(1): 29–38. doi: 10.1016/j.advengsoft.2003.10.008

MEZURA-MONTES E and COELLO C A C. A simple multimembered evolution strategy to solve constrained optimization problems[J]. IEEE Transactions on Evolutionary Computation, 2005, 9(1): 1–17. doi: 10.1109/TEVC.2004.836819

XIAO J, XU Jin, CHEN Zhihua, et al. A hybrid quantum chaotic swarm evolutionary algorithm for DNA encoding[J]. Computers & Mathematics with Applications, 2009, 57(11/12): 1949–1958.

CHAVES-GONZáLEZ J M, VEGA-RODRíGUEZ M A, and GRANADO-CRIADO J M. A multiobjective swarm intelligence approach based on artificial bee colony for reliable DNA sequence design[J]. Engineering Applications of Artificial Intelligence, 2013, 26(9): 2045–2057. doi: 10.1016/j.engappai.2013.04.011

MUHAMMAD M S, SELVAN K V, MASRA S M W, et al. An improved binary particle swarm optimization algorithm for DNA encoding enhancement[C]. 2011 IEEE Symposium on Swarm Intelligence, Paris, France, 2011: 1–8.

CHAVES-GONZáLEZ J M and VEGA-RODRíGUEZ M A. DNA strand generation for DNA computing by using a multi-objective differential evolution algorithm[J]. Biosystems, 2014, 116: 49–64. doi: 10.1016/j.biosystems.2013.12.005

BUI L T and ALAM S. Multi-Objective Optimization in Computational Intelligence: Theory and Practice[M]. Hershey: IGI Global, 2008.

SHIN S Y, LEE I H, KIM D, et al. Multiobjective evolutionary optimization of DNA sequences for reliable DNA computing[J]. IEEE Transactions on Evolutionary Computation, 2005, 9(2): 143–158. doi: 10.1109/TEVC.2005.844166
