基于卷積長短時記憶網絡的心律失常分類方法

柯麗; 王丹妮; 杜強; 姜楚迪

doi:10.11999/JEIT190712

基于卷積長短時記憶網絡的心律失常分類方法

doi: 10.11999/JEIT190712 cstr: 32379.14.JEIT190712

沈陽工業大學電氣工程學院沈陽 110870

基金項目: 國家自然科學基金(51377109)，遼寧省自然科學基金(2019-ZD-0204)

詳細信息

作者簡介:
柯麗：女，1977年生，博士，教授，博士生導師，研究方向?yàn)樯镫姽づc阻抗成像技術

王丹妮：女，1995年生，碩士生，研究方向?yàn)獒t(yī)學信號處理與分析

杜強：男，1975年生，博士，講師，研究方向?yàn)樯镝t(yī)學信號檢測與處理

姜楚迪：女，1996年生，碩士生，研究方向?yàn)獒t(yī)學電磁工程及醫療儀器

通訊作者:
柯麗　keli@sut.edu.cn

中圖分類號: TP391; R540.41
計量
- 文章訪問數: 5343
- HTML全文瀏覽量: 2955
- PDF下載量: 181
- 被引次數: 0
出版歷程
- 收稿日期: 2019-09-16
- 修回日期: 2020-02-20
- 網絡出版日期: 2020-03-23
- 刊出日期: 2020-08-18

Arrhythmia Classification Based on Convolutional Long Short Term Memory Network

School of Electrical Engineering, Shenyang University of Technology, Shenyang 110870, China

Funds: The National Natural Science Foundation of China (51377109), The Natural Science Foundation of Liaoning Province (2019-ZD-0204)

摘要

摘要:
心律失常等慢性心血管疾病嚴重影響人類健康，采用心電信號(ECG)實現心律失常自動分類可有效提高該類疾病的診斷效率，降低人工成本。為此，該文基于1維心電信號，提出一種改進的長短時記憶網絡(LSTM)方法實現心律失常自動分類。該方法首先設計深層卷積神經網絡(CNN)對心電信號進行深度編碼，提取心電信號形態特征。其次，搭建長短時記憶分類網絡實現基于心電信號特征的心律失常自動分類?；贛IT-BIH心律失常數據庫進行的實驗結果表明，該方法顯著縮短分類時間，并獲得超過99.2%的分類準確率，靈敏度等評價參數均得到不同程度的提高，滿足心電信號自動分類實時高效的要求。
- 心電信號 /
- 心律失常 /
- 深度學習 /
- 卷積神經網絡 /
- 長短時記憶網絡
Abstract:
Chronic cardiovascular diseases such as arrhythmia seriously affect human health. The automatic classification of ElectroCardioGram(ECG) signals can effectively improve the diagnostic efficiency of such diseases and reduce labor costs. To tackle this problem, an improved Long-Short Term Memory (LSTM) method is proposed to achieve automatic classification of one dimensional ECG signals. Firstly, deep Convolutional Neural Network (CNN) is designed to deeply encode the ECG signal, and ECG signal morphological features are extracted. Secondly, the LSTM classification network is used to realize automatic classification of arrhythmia of ECG signal features. Experimental studies based on the MIT-BIH arrhythmia database show that the training duration is significantly shortened and more than 99.2% classification accuracy is obtained. Sensitivity and other evaluation parameters are improved to meet the real-time and efficient requirements for automatic classification of ECG signals.
- ElectroCardioGram (ECG) signal /
- Arrhythmia /
- Deep learning /
- Convolutional Neural Network (CNN) /
- Long Short-Term Memory (LSTM)

HTML全文

圖 1 心電信號預處理

下載: 全尺寸圖片幻燈片

圖 2 C-LSTM網絡結構

下載: 全尺寸圖片幻燈片

圖 3 各類別心電信號分段結果

下載: 全尺寸圖片幻燈片

圖 4 CNN提取到的信號特征

下載: 全尺寸圖片幻燈片

圖 5 網絡訓練和驗證性能圖

下載: 全尺寸圖片幻燈片

圖 6 網絡測試集混淆矩陣

下載: 全尺寸圖片幻燈片

表 1 CNN模型的細節和參數

層數	層名稱	卷積核大小	卷積核個數	激活函數	步長	參數	輸出大小
0	輸入	–	–	–	–		300×1
1	1維卷積	5×1	16	ReLU	1	96	300×16
2	批歸一化	–	–	–	–	128	300×16
3	1維卷積	5×1	16	ReLU	1	1424	300×16
4	批歸一化	–	–	–	–	1456	300×16
5	最大池化	2	16	–	2	32	150×16
6	1維卷積	3×1	32	ReLU	1	3024	150×32
7	批歸一化	–	–	–	–	3088	150×32
8	1維卷積	3×1	32	ReLU	1	6192	150×32
9	批歸一化	–	–	–	–	6256	150×32
10	最大池化	2	32	–	2	64	75×32
11	1維卷積	5×1	64	ReLU	1	16560	75×64
12	批歸一化	–	–	–	–	16688	75×64
13	1維卷積	5×1	1	ReLU	1	28800	75×1
14	批歸一化	–	–	–	–	28928	75×1
15	最大池化	2	1	–	2	2	38×1

下載: 導出CSV

表 2 LSTM模型的細節和參數

層名稱	隱含單元	激活函數	參數
長短時記憶層	32	–	12
全連接	256	ReLU	9996
全連接	5	Softmax	11024

下載: 導出CSV

表 3 AAMI標準在心電信號分類中描述

AAMI類別	類別數量	MIT-BIH心跳節拍類別
Normal(N)	89972	正常(NOR)
		左束支傳導阻塞(LBBB)
		右束支傳導阻塞(RBBB)
		房性逸搏(AE)
		結性逸搏(NE)
Supraventricular(S)	2758	房性早搏(AP)
		異常房性早搏(aAP)
		交界性早搏(NP)
		室上性早搏(SP)
Ventricular(V)	7140	室性早搏(PVC)
Ventricular(V)	7140	室性逸搏(VE)
Fusion(F)	800	心室融合心跳(fVN)
Unknown(Q)	30	起搏心跳(P)
		起搏融合心跳(fPN)
		未分類心跳(U)

下載: 導出CSV

表 4 LSTM網絡和C-LSTM網絡測試集的相關評價參數(%)

網絡	評價參數	模型類別
網絡	評價參數	N	S	V	F	Q
LSTM	Acc	99.54	99.62	99.44	99.71	99.97
	Sen	99.87	91.06	95.66	80.19	0
	Spe	96.91	99.86	99.76	99.58	99.99
	PPV	99.61	95.09	97.00	78.70	0.00
C-LSTM	Acc	99.52	99.61	99.51	99.84	99.97
	Sen	99.78	92.11	96.63	88.52	0
	Spe	98.36	99.83	99.73	99.93	99.99
	PPV	99.68	94.08	96.45	91.53	0.00

下載: 導出CSV

表 5 自動檢測心律失常分類結果性能比較

研究	類型	分類器	信號長度	性能(%)
研究	類型	分類器	信號長度	Acc	Sen	Spe	PPV
文獻[19]	4	FFNN	250 samples (0.69 s)	96.94	97.78	96.31	–
文獻[17]	17	KNN	360 samples (1.00 s)	97.00	97.10	96.90	–
文獻[18]	5	SVM+RBF	200 samples (0.56 s)	98.91	98.91	97.85	–
文獻[4]	14	NPE+SVM	300 samples (0.83 s)	98.51	98.51	–	98.51
文獻[11]	5	CNN	360 samples (1.00 s)	94.03	96.71	91.54	97.86
文獻[20]	4	SVM	8×1071	98.39	96.86	98.92	96.85
文獻[12]	5	CNN	73×73	98.42	72.06	97.83	65.91
文獻[15]	5	FCMDBN	200 samples (0.56 s)	96.54	94.55	93.31	93.91
文獻[14]	2	CNN+RNN	211×24	95.76	87.85	87.85	94.99
本文方法	5	LSTM	300 sample (0.83 s)	99.14	91.70	99.22	92.60
本文方法	5	C-LSTM	300 →38 samples(0.83 s)→(0.12 s)	99.23	94.26	99.57	95.44

下載: 導出CSV

參考文獻(20)
