一種基于水下無人航行器的多目標被動跟蹤算法
doi: 10.11999/JEIT190675 cstr: 32379.14.JEIT190675
-
1.
中國科學院聲學研究所 北京 100190
-
2.
中國科學院先進水下信息技術重點實驗室 北京 100190
-
3.
中國科學院大學 北京 100049
A Multi-target Passive Tracking Algorithm Based on Unmanned Underwater Vehicle
-
1.
Institute of Acoustics of Chinese Academy of Sciences, Beijing 100190, China
-
2.
Key Laboratory of Science and Technology on Advanced Underwater Information of Chinese Academy of Sciences, Beijing 100190, China
-
3.
University of Chinese Academy of Sciences, Beijing 100049, China
-
摘要:
被動聲吶信號處理中，致力于實現連續且穩定的目標方位跟蹤。在復雜的水下環境中，由于干擾和噪聲的存在，以及陣列孔徑的限制，方位檢測結果中不可避免地存在很多軌跡中斷、野值、干擾與目標間的方位交叉。該文提出了一種基于水下無人航行器的多目標被動跟蹤算法，使用基于航行器運動信息的粒子采樣預測方法進行軌跡中斷預測補齊，使用基于航行器運動信息的觀測門限設置方法自適應設置跟蹤門限，使用塊關聯跟蹤方法進行軌跡中斷關聯和方位交叉關聯。仿真和實驗結果表明，該算法能夠?qū)崿F(xiàn)正確的多目標跟蹤。
-
關鍵詞:
- 被動聲吶 /
- 水下多目標跟蹤 /
- 純方位跟蹤 /
- 水下無人航行器 /
- 純方位目標運動分析 /
- 數據關聯 /
- 粒子采樣
Abstract:In the passive tracking using acoustic arrays, continuous and stable tracking of targets is important. In complex underwater environments, there are inevitably many trajectory interruptions, outliers, interference and target azimuth crossings in the bearing detection results, due to interference, noise, and arrays aperture limitations. In this paper, a multi-target passive tracking algorithm based on unmanned underwater vehicle is proposed. The particle sampling prediction method based on the motion information of the vehicle is used to perform the interruption prediction. The observation threshold setting method based on the motion information of the vehicle is used to adaptively set the tracking threshold. The block association tracking method is used for association of trajectory break and azimuth cross. The experimental results show that the proposed algorithm achieves correct multi-target tracking.
-
表 1 檢測概率和算法性能(%)
方位連續段
檢測概率算法正確
跟蹤概率方位連續段
檢測概率算法正確
跟蹤概率100 100.00 40 80.810 80 100.00 35 63.420 50 98.21 30 24.140 45 91.55 25 0.037
下載: 導出CSV
表 2 檢測跟蹤概率和平均方位誤差統計結果
閾值檢測 傳統跟蹤算法 VI-BOTA VIP-BOTA 檢測跟蹤概率(%) 64.85 69.67* 84.70* 92.62 平均方位誤差(°) 1.54 1.59 3.12(1.47) 1.29
下載: 導出CSV
-
NORTHARDT T and NARDONE S C. Track-before-detect bearings-only localization performance in complex passive sonar scenarios: A case study[J]. IEEE Journal of Oceanic Engineering, 2019, 44(2): 482–491. doi: 10.1109/JOE.2018.2811419 BADRIASL L, ARULAMPALAM S, VAN DER HOEK J, et al. Bayesian WIV estimators for 3-D bearings-only TMA with speed constraints[J]. IEEE Transactions on Signal Processing, 2019, 67(13): 3576–3591. doi: 10.1109/TSP.2019.2917863 DIAMANT R, KIPNIS D, BIGAL E, et al. An active acoustic track-before-detect approach for finding underwater mobile targets[J]. IEEE Journal of Selected Topics in Signal Processing, 2019, 13(1): 104–119. doi: 10.1109/JSTSP.2019.2899237 李子高, 李淑秋, 聞疏琳. 基于無人平臺的水下目標自動檢測方法[J]. 哈爾濱工程大學學報, 2017, 38(1): 103–108. doi: 10.11990/jheu.201601012LI Zigao, LI Shuqiu, and WEN Shulin. Automatic detection of an underwater target based on UUV[J]. Journal of Harbin Engineering University, 2017, 38(1): 103–108. doi: 10.11990/jheu.201601012 金盛龍, 李宇, 黃海寧. 曲線機動情況下水下自主平臺的改進被動合成孔徑算法研究[J]. 電子與信息學報, 2018, 40(9): 2265–2272. doi: 10.11999/JEIT171225JIN Shenglong, LI Yu, and HUANG Haining. An improved passive synthetic aperture algorithm based on curvilinear maneuverability of autonomous underwater vehicles[J]. Journal of Electronics &Information Technology, 2018, 40(9): 2265–2272. doi: 10.11999/JEIT171225 NIAZI S and TOLOEI A. Estimation of LOS rates for target tracking problems using EKF and UKF algorithms-a comparative study[J]. International Journal of Engineering, Transactions B: Applications, 2015, 28(2): 172–179. doi: 10.5829/idosi.ije.2015.28.02b.02 JULIER S J and UHLMANN J K. Unscented filtering and nonlinear estimation[J]. Proceedings of the IEEE, 2004, 92(3): 401–422. doi: 10.1109/JPROC.2003.823141 SADHU S, MONDAL S, SRINIVASAN M, et al. Sigma point Kalman filter for bearing only tracking[J]. Signal Processing, 2006, 86(12): 3769–3777. doi: 10.1016/j.sigpro.2006.03.006 DO?AN?AY K. On the bias of linear least squares algorithms for passive target localization[J]. Signal Processing, 2004, 84(3): 475–486. doi: 10.1016/j.sigpro.2003.12.002 VAN DER MERWE R and WAN E A. The square-root unscented Kalman filter for state and parameter-estimation[C]. 2001 IEEE International Conference on Acoustics, Speech, and Signal Processing, Salt Lake City, USA, 2001: 3461–3464. doi: 10.1109/ICASSP.2001.940586. BREHARD T and LE CADRE J P. Hierarchical particle filter for bearings-only tracking[J]. IEEE Transactions on Aerospace and Electronic Systems, 2007, 43(4): 1567–1585. doi: 10.1109/TAES.2007.4441759 YARDIM C, MICHALOPOULOU Z H, and GERSTOFT P. An overview of sequential Bayesian filtering in ocean acoustics[J]. IEEE Journal of Oceanic Engineering, 2011, 36(1): 71–89. doi: 10.1109/JOE.2010.2098810 張穎, 高靈君. 基于格拉布斯準則和改進粒子濾波算法的水下傳感網目標跟蹤[J]. 電子與信息學報, 2019, 41(10): 2294–2301. doi: 10.11999/JEIT190079ZHANG Ying and GAO Lingjun. Target tracking with underwater sensor networks based on Grubbs criterion and improved particle filter algorithm[J]. Journal of Electronics &Information Technology, 2019, 41(10): 2294–2301. doi: 10.11999/JEIT190079 XIONG Zhengda, XU Ke, CHEN Yong, et al. Research on multi-target bearings-only tracking method based on passive sonar systems[C]. The 2nd IEEE Advanced Information Technology, Electronic and Automation Control Conference (IAEAC), Chongqing, China, 2017: 1326–1330. doi: 10.1109/IAEAC.2017.8054229. WANG Yujie, LI Yu, JU Donghao, et al. Continuous bearings-only tracking based on vehicle motion information correction[C]. OCEANS 2019-Marseille, Marseille, France, 2019: 1–5. doi: 10.1109/OCEANSE.2019.8867274. -
