機載多通道SAR運動目標方位向速度和法向速度聯合估計算法

姜文; 牛杰; 吳一戎; 梁興東

doi:10.11999/JEIT190672

機載多通道SAR運動目標方位向速度和法向速度聯合估計算法

doi: 10.11999/JEIT190672 cstr: 32379.14.JEIT190672

姜文^{1, 2, 3, ,},
牛杰^{1, 2, 3},
吳一戎^{1, 2},
梁興東^{1, 2}

1.
中國科學院空天信息創新研究院北京 100094
2.
微波成像技術國家重點實驗室北京 100190
3.
中國科學院大學北京 100049

詳細信息

作者簡介:
姜文：男，1990年生，博士生，研究方向為機載多通道SAR地面動目標參數估計

牛杰：男，1993年生，博士生，研究方向為新體制SAR海面紋理增強

吳一戎：男，1963年生，中國科學院院士，研究方向為微波成像理論、微波成像技術、雷達信號處理等

梁興東：男，1973年生，研究員，研究方向為高分辨率SAR系統、干涉SAR系統、成像處理及應用、實時數字信號處理等

通訊作者:
姜文　jiangwen13@mails.ucas.ac.cn

中圖分類號: TN957.52
計量
- 文章訪問數: 2808
- HTML全文瀏覽量: 1111
- PDF下載量: 115
- 被引次數: 0
出版歷程
- 收稿日期: 2019-09-02
- 修回日期: 2020-02-14
- 網絡出版日期: 2020-03-04
- 刊出日期: 2020-06-22

Joint Estimation Algorithm for Azimuth Velocity and Normal Velocity of Moving Targets in Airborne Multi-channel SAR

Wen JIANG^{1, 2, 3
, ,},
Jie NIU^{1, 2, 3},
Yirong WU^{1, 2},
Xingdong LIANG^{1, 2}

1.
Aerospace Information Research Institute, Chinese Academy of Sciences, Beijing 100094, China
2.
National Key Laboratory of Microwave Imaging Technology, Beijing 100190, China
3.
University of Chinese Academy of Sciences, Beijing 100049, China

摘要

摘要:
對運動目標進行SAR成像時，參數估計是必不可少的?，F有算法主要針對運動目標的徑向速度和方位向速度進行估計，而對3維運動目標的法向速度無法估計。該文利用L型基線的機載多通道SAR系統，提出一種方位向速度和法向速度的聯合估計算法。該算法在距離-多普勒域提取運動目標信號，并利用多幅SAR圖像之間的相位差進行方位向速度和法向速度的聯合估計。該算法不依賴圖像配準，不需要解多普勒模糊，因此具有較高的估計精度和魯棒性，有較強的實際意義和應用價值。
- 機載多通道SAR /
- 運動目標檢測 /
- 方位向速度 /
- 法向速度 /
- 速度估計
Abstract:
Parameter estimation is essential for SAR imaging of moving targets. The existing algorithms mainly estimate the radial velocity and azimuth velocity of the moving target, but the normal velocity of the three-dimensional moving target can not be estimated. In this paper, a joint estimation algorithm of azimuth velocity and normal velocity is proposed by using an airborne multi-channel SAR system with L-shaped baseline. The algorithm extracts the moving target signal in Range-Doppler domain, and estimates the azimuth and normal velocity jointly using the phase differences between multiple SAR images. The algorithm does not rely on image registration, does not need to solve Doppler ambiguity. Therefore, the algorithm has high estimation accuracy and robustness, and has strong practical significance and application value.
- Airborne multi-channel SAR /
- Moving target detection /
- Azimuth velocity /
- Normal velocity /
- Velocity estimation

HTML全文

圖 1 機載SAR 3維運動目標成像模型

下載: 全尺寸圖片幻燈片

圖 2 機載多通道SAR 3維運動目標成像模型

下載: 全尺寸圖片幻燈片

圖 3 速度聯合估計算法處理流程

下載: 全尺寸圖片幻燈片

圖 4 運動目標1的多普勒域相位差

下載: 全尺寸圖片幻燈片

圖 5 運動目標2的多普勒域相位差

下載: 全尺寸圖片幻燈片

圖 6 運動目標3的多普勒域相位差

下載: 全尺寸圖片幻燈片

圖 7 運動目標聚焦前后的SAR圖像

下載: 全尺寸圖片幻燈片

圖 8 運動目標方位向剖面圖

下載: 全尺寸圖片幻燈片

表 1 SAR系統仿真基本參數

中心頻率	飛行速度	飛行高度	最近斜距	PRF	信噪比	多普勒帶寬	順軌基線	交軌基線
9.6 GHz	150 m/s	7500 m	20 km	2000	10 dB	500 Hz	1 m	1 m

下載: 導出CSV

表 2 目標3維運動參數(m/s)

	徑向向速度	方位向速度	法向速度
運動目標1	0	10	10
運動目標2	0	10	0
運動目標3	0	0	10

下載: 導出CSV

表 3 運動目標速度估計結果及誤差(m/s)

	理論方位向速度	理論法向速度	估計方位向速度	估計法向速度	方位向速度估計誤差	法向速度估計誤差
運動目標1	10.00	10.00	9.85	10.00	0.15	0
運動目標2	10.00	0	9.84	1.15×10^–15	0.16	1.15×10^–15
運動目標3	0	10.00	7.93×10^–2	9.90	7.93×10^–2	0.10

下載: 導出CSV

表 4 SAR平臺部分參數

距離向采樣點數	PRF	天線間距	飛行速度	飛行高度	帶寬
16384	781	1 m	146 m/s	7544 m	300 MHz

下載: 導出CSV

參考文獻(19)

PERRY R P, DIPIETRO R C, and FANTE R L. SAR imaging of moving targets[J]. IEEE Transactions on Aerospace and Electronic Systems, 1999, 35(1): 188–200. doi: 10.1109/7.745691

FIENUP J R. Detecting moving targets in SAR imagery by focusing[J]. IEEE Transactions on Aerospace and Electronic Systems, 2001, 37(3): 794–809. doi: 10.1109/7.953237

JAO J K. Theory of synthetic aperture radar imaging of a moving target[J]. IEEE Transactions on Geoscience and Remote Sensing, 2001, 39(9): 1984–1992. doi: 10.1109/36.951089

MARQUES P A C and DIAS J M B. Velocity estimation of fast moving targets using a single SAR sensor[J]. IEEE Transactions on Aerospace and Electronic Systems, 2005, 41(5): 75–89. doi: 10.1109/TAES.2005.1413748

BARBAROSSA S and FARINA A. Detection and imaging of moving objects with synthetic aperture radar. 2. Joint time-frequency analysis by wigner-ville distribution[J]. IEE Proceedings F - Radar and Signal Processing, 1992, 139(1): 89–97. doi: 10.1049/ip-f-2.1992.0011

WANG Zhirui, XIA Xianggen, XU Jia, et al. Ground moving target imaging based on 2-D velocity search in high resolution SAR[C]. 2017 IEEE Radar Conference, Seattle, USA, 2017: 68–72.

SHI Hongyin, YANG Xiaoyan, ZHOU Qiuxiao, et al. SAR slow moving target imaging based on over-sampling smooth algorithm[J]. Chinese Journal of Electronics, 2017, 26(4): 876–882. doi: 10.1049/cje.2017.06.005

YANG Wei, CHEN Jie, LIU Wei, et al. Moving target azimuth velocity estimation for the MASA mode based on sequential SAR images[J]. IEEE Journal of Selected Topics in Applied Earth Observations and Remote Sensing, 2017, 10(6): 2780–2790. doi: 10.1109/JSTARS.2016.2641744

SU Jia, TAO Haihong, WANG Ling, et al. Coherently integrated cubic function based doppler parameters estimation for moving-target imaging[C]. 2017 International Applied Computational Electromagnetics Society Symposium, Suzhou, China, 2017: 1–2.

WANG Hanyun and JIANG Yicheng. Real-time parameter estimation for SAR moving target based on WVD slice and FrFT[J]. Electronics Letters, 2018, 54(1): 47–49. doi: 10.1049/el.2017.1740

LI Zhongyu, WU Junjie, LIU Zhutian, et al. An optimal 2-D spectrum matching method for SAR ground moving target imaging[J]. IEEE Transactions on Geoscience and Remote Sensing, 2018, 56(10): 5961–5974. doi: 10.1109/TGRS.2018.2829166

魏翔飛, 王小青, 種勁松. 一種基于局域中心頻率的SAR圖像艦船方位向速度估計方法[J]. 電子與信息學報, 2018, 40(9): 2242–2249. doi: 10.11999/JEIT170991

WEI Xiangfei, WANG Xiaoqing, and CHONG Jinsong. Ship azimuthal speed estimation method based on local region doppler centroid in SAR images[J]. Journal of Electronics &Information Technology, 2018, 40(9): 2242–2249. doi: 10.11999/JEIT170991

王超, 王巖飛, 王琦, 等. 基于回波序列最小二乘擬合的高分辨率SAR運動目標速度估計[J]. 電子與信息學報, 2019, 41(5): 1055–1062. doi: 10.11999/JEIT180695

WANG Chao, WANG Yanfei, WANG Qi, et al. Velocity estimation of moving targets based on least square fitting of high-resolution SAR echo sequences[J]. Journal of Electronics &Information Technology, 2019, 41(5): 1055–1062. doi: 10.11999/JEIT180695

HE Xiongpeng, LIAO Guisheng, XU Jingwei, et al. Robust radial velocity estimation based on joint-pixel normalized sample covariance matrix and shift vector for moving targets[J]. IEEE Geoscience and Remote Sensing Letters, 2019, 16(2): 221–225. doi: 10.1109/LGRS.2018.2871950

WANG Genyuan, XIA Xianggen, and CHEN V C. Three-dimensional ISAR imaging of maneuvering targets using three receivers[J]. IEEE Transactions on Image Processing, 2001, 10(3): 436–447. doi: 10.1109/83.908519

ZHANG Qun and YEO T S. Three-dimensional SAR imaging of a ground moving target using the InISAR technique[J]. IEEE Transactions on Geoscience and Remote Sensing, 2004, 42(9): 1818–1828. doi: 10.1109/TGRS.2004.831863

ZHANG Qun, YEO T S, DU Gan, et al. Estimation of three-dimensional motion parameters in interferometric ISAR imaging[J]. IEEE Transactions on Geoscience and Remote Sensing, 2004, 42(2): 292–300. doi: 10.1109/TGRS.2003.815669

湯立波, 李道京, 洪文, 等. 基于順軌-交軌InSAR技術的運動艦船目標三維成像[J]. 系統工程與電子技術, 2008, 30(9): 1669–1673. doi: 10.3321/j.issn:1001-506X.2008.09.017

TANG Libo, LI Daojing, HONG Wen, et al. Three-dimensional imaging of moving ships with 3D motion based on AT-CT InSAR[J]. Systems Engineering and Electronics, 2008, 30(9): 1669–1673. doi: 10.3321/j.issn:1001-506X.2008.09.017

尹建鳳, 李道京, 王愛明, 等. 基于星載毫米波順軌-交軌InISAR的空間運動目標三維成像技術研究[J]. 宇航學報, 2013, 34(2): 237–245. doi: 10.3873/j.issn.1000-1328.2013.02.013

YIN Jianfeng, LI Daojing, WANG Aiming, et al. Three-dimensional imaging technique of space moving target based on spaceborne along-cross track millimeter-wave In-ISAR[J]. Journal of Astronautics, 2013, 34(2): 237–245. doi: 10.3873/j.issn.1000-1328.2013.02.013
