基于同步壓縮小波變換的主信號抑制技術

吳龍文; 牛金鵬; 王昭; 何勝陽; 趙雅琴

doi:10.11999/JEIT190650

基于同步壓縮小波變換的主信號抑制技術

doi: 10.11999/JEIT190650 cstr: 32379.14.JEIT190650

1.
哈爾濱工業大學電子與信息工程學院哈爾濱 150001
2.
中國電子科技集團公司第二十九研究所成都 610036

基金項目: 國家自然科學基金(61671185)

詳細信息

作者簡介:
吳龍文：男，1988年生，工程師，研究方向?yàn)檩椛湓磦€(gè)體識別

牛金鵬：男，1997年生，碩士生，研究方向?yàn)檩椛湓磦€(gè)體識別

王昭：男，1995年生，工程師，研究方向?yàn)檩椛湓磦€(gè)體識別

何勝陽：男，1983年生，高級工程師，研究方向?yàn)闊o(wú)線光通信

趙雅琴：女，1976年生，教授，研究方向?yàn)檩椛湓醋R(shí)別和光通信

通訊作者:
趙雅琴　yaqinzhao@hit.edu.cn

中圖分類號: TN971
計量
- 文章訪問數: 1882
- HTML全文瀏覽量: 1457
- PDF下載量: 70
- 被引次數: 0
出版歷程
- 收稿日期: 2019-08-28
- 修回日期: 2020-05-05
- 網絡出版日期: 2020-05-17
- 刊出日期: 2020-08-18

Primary Signal Suppression Based on Synchrosqueezed Wavelet Transform

1.
School of Electronics & Information Engineering, Harbin Institute of Technology, Harbin 150001, China
2.
The 29th Research Institute of China Electronics Technology Group Corporation, Chengdu 610036, China

Funds: The National Natural Science Foundation of China (61671185)

摘要

摘要:
在輻射源個體識別(SEI)技術中，能量較高的主信號往往導致微弱個體特征穩定性降低，進而影響最終的個體識別效果。為了解決該問題并提升輻射源個體識別性能，該文提出基于同步壓縮小波變換的主信號抑制技術。首先，利用靜態小波變換完成對帶噪信號的去噪預處理；然后，利用同步壓縮小波變換完成對主信號的檢測和抑制，并以均方根誤差和皮爾遜相關系數為數值指標，驗證算法的有效性；最后，在主信號抑制的基礎上，利用分形理論中盒維數完成對信號的特征提取，并利用單核支持向量機驗證個體識別性能。實驗結果表明，與主信號抑制之前相比，主信號抑制算法下個體識別率提升了10%左右，驗證了同步壓縮小波變換的主信號抑制算法對輻射源個體識別率提升的有效性。
- 輻射源個體識別 /
- 主信號抑制 /
- 同步壓縮小波變換 /
- 特征提取
Abstract:
In Specific Emitter Identification (SEI), the stability of individual features and final correct identification rate are always declined due to the influence of the primary signal with high energy on the individual features. To solve the problem above, a primary signal suppression algorithm based on synchrosqueezed wavelet transform is exploited for specific emitter identification in this paper. Firstly, a denoising method based on stationary wavelet transform is applied to preprocess the noised signal; Then, the detection and suppression of the primary signal from time-frequency distribution are developed, where root mean square error and Pearson correlation coefficient are used as numerical indicators to measure the effectiveness of the proposed primary signal suppression algorithm; Finally, a feature extraction based on box-counting dimension and a classification based on support vector machine are exploited to verify the identification performance. The simulation results show that the correct identification rate of SEI using the proposed primary signal suppression outperforms the conventional SEI with 10%, which proves the practical improvement of the proposed primary signal suppression algorithm on specific emitter identification.
- Specific Emitter Identification(SEI) /
- Primary signal suppression /
- Synchrosqueezed wavelet transform /
- Feature extraction

HTML全文

圖 1 SWT分解過程示意圖

下載: 全尺寸圖片幻燈片

圖 2 LFM信號下SST主信號抑制效果仿真

下載: 全尺寸圖片幻燈片

圖 3 SST主信號抑制仿真(擴大相位噪聲頻1偏后)

下載: 全尺寸圖片幻燈片

圖 4 LFM信號源個體分形盒維數特征識別結果

下載: 全尺寸圖片幻燈片

圖 5 實測數據特征規范化后特征分布

下載: 全尺寸圖片幻燈片

表 1 加性相位噪聲參數

輻射源個體	與頻偏對應的相位噪聲幅度(信相噪比(dB))
	f₁=±2.75 MHz	f₂=±2.80 MHz	f₃=±3.10 MHz
E₁	11.9897	12.7815	15.7918
E₂	10.4845	11.6722	16.1877
	f₂₁=±2.8 MHz	f₂₂=±2.9 MHz	f₂₃=±3.15 MHz
E₃	12.7815	14.0308	16.1394

下載: 導出CSV

表 2 實測數據特征結構與來源

特征序號	特征來源
1～4	RF-DNA^[19]
4～8	IMF-DNA^[20]
9～12	BCD^[18]
13～20	SIB^[21]

下載: 導出CSV

參考文獻(21)

WANG Xuebao, HUANG Gaoming, ZHOU Zhiwen, et al. Radar emitter recognition based on the short time fourier transform and convolutional neural networks[C]. The 10th International Congress on Image and Signal Processing, BioMedical Engineering and Informatics, Shanghai, China, 2017: 1–5. doi: 10.1109/CISP-BMEI.2017.8302111.

LIANG Kaiqiang, HUANG Zhen, HU Dexiu, et al. An individual emitter recognition method combining bispectrum with wavelet entropy[C]. 2015 IEEE International Conference on Progress in Informatics and Computing, Nanjing, China, 2015: 206–210. doi: 10.1109/PIC.2015.7489838.

GUO Haizhao, ZHANG Xiaonu, YANG Libo, et al. Improved fisher linear discriminant analysis for feature extraction of unintentional modulation on pulse by combining ambiguity function with wavelet transform[C]. IET International Radar Conference 2015, Hangzhou, China, 2015: 1–4. doi: 10.1049/cp.2015.1108.

LI Yibing, GE Juan, LIN Yun, et al. Radar emitter signal recognition based on multi-scale wavelet entropy and feature weighting[J]. Journal of Central South University, 2014, 21(11): 4254–4260. doi: 10.1007/s11771-014-2422-5

曹銀萍, 郭璐. 基于MATLAB的小波分析在信號去噪中的應用[J]. 信息記錄材料, 2018, 19(7): 85–87. doi: 10.16009/j.cnki.cn13-1295/tq.2018.07.056

CAO Yinping and GUO Lu. Application of wavelet analysis based on MATLAB in signal denoising[J]. Information Recording Materials, 2018, 19(7): 85–87. doi: 10.16009/j.cnki.cn13-1295/tq.2018.07.056

DUDCZYK J and KAWALEC A. Fractal features of specific emitter identification[J]. Acta Physica Polonica A, 2013, 124(2): 406–409. doi: 10.12693/APhysPolA.124.406

DUDCZYK J and KAWALEC A. Identification of emitter sources in the aspect of their fractal features[J]. Bulletin of the Polish Academy of Sciences: Technical Sciences, 2013, 61(3): 623–628. doi: 10.2478/bpasts-2013-0065

WU Xiaopo, SHI Yangming, MENG Weibo, et al. Specific emitter identification for satellite communication using probabilistic neural networks[J]. International Journal of Satellite Communications and Networking, 2019, 37(3): 283–291. doi: 10.1002/sat.1286

王歡歡, 張濤, 孟凡玉. 基于時頻域細微特征的輻射源個體識別[J]. 信息工程大學學報, 2018, 19(1): 23–29. doi: 10.3969/j.issn.1671-0673.2018.01.006

WANG Huanhuan, ZHANG Tao, and MENG Fanyu. Specific emitter identification based on time-frequency domain characteristic[J]. Journal of Information Engineering University, 2018, 19(1): 23–29. doi: 10.3969/j.issn.1671-0673.2018.01.006

WANG Huanhuan and ZHNAG Tao. Specific emitter identification based on fractal and wavelet theories[C]. The 2nd IEEE Advanced Information Technology, Electronic and Automation Control Conference, Chongqing, China, 2017: 1613–1617. doi: 10.1109/IAEAC.2017.8054286.

WANG Wei, LIU Hui, YANG Jun’an, et al. Specific emitter identification using decomposed hierarchical feature extraction methods[C]. The 13th International Conference on Natural Computation, Fuzzy Systems and Knowledge Discovery, Guilin, China, 2017: 1639–1643. doi: 10.1109/FSKD.2017.8393011.

HE Boxiang, WANG Fanggang, LIU Yu, et al. Specific emitter identification via multiple distorted receivers[C]. 2019 IEEE International Conference on Communications Workshops, Shanghai, China, 2019: 1–6. doi: 10.1109/ICCW.2019.8757066.

潘一葦, 彭華, 李天昀, 等. 一種新的時分多址信號射頻特征及其在特定輻射源識別中的應用[J]. 電子與信息學報, 2019, 41(11): 2661–2668. doi: 10.11999/JEIT190163

PAN Yiwei, PENG Hua, LI Tianyun, et al. A novel radiometric signature of time-division multiple access signals and its application to specific emitter identification[J]. Journal of Electronics &Information Technology, 2019, 41(11): 2661–2668. doi: 10.11999/JEIT190163

潘一葦, 楊司韓, 彭華, 等. 基于矢量圖的特定輻射源識別方法[J]. 電子與信息學報, 2020, 42(4): 941–949. doi: 10.11999/JEIT190329

PAN Yiwei, YANG Sihan, PENG Hua, et al. Specific emitter identification using signal trajectory image[J]. Journal of Electronics &Information Technology, 2020, 42(4): 941–949. doi: 10.11999/JEIT190329

LI Suyi, LIU Guangda, and LIN Zhenbao. Comparisons of wavelet packet, lifting wavelet and stationary wavelet transform for de-noising ECG[C]. The 2009 2nd IEEE International Conference on Computer Science and Information Technology, Beijing, China, 2009: 491–494. doi: 10.1109/ICCSIT.2009.5234650.

王勇, 鄒輝, 饒勤菲, 等. 結合空域噪聲信息的小波脊提取算法[J]. 電子科技大學學報, 2018, 47(4): 613–620. doi: 10.3969/j.issn.1001-0548.2018.04.022

WANG Yong, ZOU Hui, RAO Qinfei, et al. A wavelet ridge extraction algorithm combined with spatial noise information[J]. Journal of University of Electronic Science and Technology of China, 2018, 47(4): 613–620. doi: 10.3969/j.issn.1001-0548.2018.04.022

唐智靈. 通信輻射源非線性個體識別方法研究[D]. [博士論文], 西安電子科技大學, 2013.

TANG Zhiling. A study of nonlinear method for specific communications emitter identification[D]. [Ph. D. dissertation], Xidian University, 2013.

WU Longwen, ZHAO Yaqin, WANG Zhao, et al. Specific emitter identification using fractal features based on box-counting dimension and variance dimension[C]. 2017 IEEE International Symposium on Signal Processing and Information Technology, Bilbao, Spain, 2017: 226–231. doi: 10.1109/ISSPIT.2017.8388646.

BIHL T J, BAUER K W, and TEMPLE M A. Feature selection for RF fingerprinting with multiple discriminant analysis and using ZigBee device emissions[J]. IEEE Transactions on Information Forensics and Security, 2016, 11(8): 1862–1874. doi: 10.1109/TIFS.2016.2561902

WU Longwen, ZHAO Yaqin, FENG Mengfei, et al. Specific emitter identification using IMF-DNA with a joint feature selection algorithm[J]. Electronics, 2019, 8(9): 934. doi: 10.3390/electronics8090934

CHEN Taowei, JIN Weidong, and LI Jie. Feature extraction using surrounding-line integral bispectrum for radar emitter signal[C]. 2008 IEEE International Joint Conference on Neural Networks, Hong Kong, China, 2008: 294–298. doi: 10.1109/IJCNN.2008.4633806.
