一種車載服務的快速深度Q學習網絡邊云遷移策略
doi: 10.11999/JEIT190612 cstr: 32379.14.JEIT190612
-
1.
中南大學計算機學院 長沙 410083
-
2.
中南大學自動化學院 長沙 410083
基金項目: 國家自然科學基金(61873353, 61672539)
A Fast Deep Q-learning Network Edge Cloud Migration Strategy for Vehicular Service
-
1.
School of Computer Science and Engineering, Central South University, Changsha 410083, China
-
2.
School of Automation, Central South University, Changsha 410083, China
Funds: The National Natural Science Foundation of China(61873353, 61672539)
-
摘要: 智能網聯交通系統中車載用戶的高速移動，不可避免地造成了數據在邊緣服務器之間頻繁遷移，產生了額外的通信回傳時延，對邊緣服務器的實時計算服務帶來了巨大的挑戰。為此，該文提出一種基于車輛運動軌跡的快速深度Q學習網絡(DQN-TP)邊云遷移策略，實現數據遷移的離線評估和在線決策。車載決策神經網絡實時獲取接入的邊緣服務器網絡狀態和通信回傳時延，根據車輛的運動軌跡進行虛擬機或任務遷移的決策，同時將實時的決策信息和獲取的邊緣服務器網絡狀態信息發送到云端的經驗回放池中；評估神經網絡在云端讀取經驗回放池中的相關信息進行網絡參數的優化訓練，定時更新車載決策神經網絡的權值，實現在線決策的優化。最后仿真驗證了所提算法與虛擬機遷移算法和任務遷移算法相比能有效地降低時延。Abstract: The high-speed movement of vehicles inevitably leads to frequent data migration between edge servers and increases communication delay, which brings great challenges to the real-time computing service of edge servers. To solve this problem, a real-time reinforcement learning method based on Deep Q-learning Networks according to vehicle motion Trajectory Process (DQN-TP) is proposed. The proposed algorithm separates the decision-making process from the training process by using two neural networks. The decision neural network obtains the network state in real time according to the vehicle’s movement track and chooses the migration method in the virtual machine migration and task migration. At the same time, the decision neural network uploads the decision records to the memory replay pool in the cloud. The evaluation neural network in the cloud trains with the records in the memory replay pool and periodically updates the parameters to the on-board decision neural network. In this way, training and decision-making can be carried out simultaneously. At last, a large number of simulation experiments show that the proposed algorithm can effectively reduce the latency compared with the existing methods of task migration and virtual machine migration.
-
表 1 變量表
變量名 變量符號 決策周期長度 $\sigma $ 決策周期 $t$ 邊緣服務器數量 $i$ 車載用戶位置 ${\nu _t}$ 邊緣服務器位置 ${\mu _m}$ 路徑損失參數 $\delta $ 路旁單元覆蓋半徑 $r$ 任務大小 ${q_{\rm s}}$ 任務最大容忍時延 ${q_{\rm d}}$ 傳輸功率 ${P_{\rm s}}$ 時延 $T$ 虛擬機所在位置 ${ D}$
下載: 導出CSV
表 2 DQN-TP算法
算法1: DQN-TP算法 (1) Repeat: (2) 車載用戶上傳車載決策神經網絡的經驗$({X_t},{a_t},{U_t},{X_{t + 1}})$到經驗回放池； (3) While $t \ne $最后一個周期do (4) 從經驗回放池中隨機抽取$n$個經驗作為一個mini-batch； (5) 將${X_t},{a_t}$作為評估神經網絡的輸入獲得${Q_{\pi} }({X_t},{a_t};\theta )$，將${X_{t + 1}}$作為決策神經網絡的輸入獲得${Q_{\pi } }({X_{t + 1} },{a_{t + 1} };{\theta ^-})$； (6) 根據式(13)、式(14)訓練神經網絡； (7) End While (8) 每訓練$c$次將云端的神經網絡參數更新給車載神經網絡$\theta \to {\theta ^{^\_}}$； (9) 車載用戶使用$\varepsilon {\rm{ - }}$貪婪算法選擇動作-狀態值函數最高的動作作為車載用戶動作執行； (10) End
下載: 導出CSV
表 3 仿真參數設定
參數名 參數符號 參數值 決策周期 $\sigma $ 10–3 s 邊緣服務器數量 $i$ 10 路徑損失參數 $\delta $ 1.5 帶寬 $W$ 4 MHz 路旁單元覆蓋半徑 $r$ 500 m 效用函數參數 $k$ 1.3 效用函數參數 $b$ 0.1 記憶回放池最大存儲數 $o$ 3000 Mini-batch大小 $n$ 500 參數更新間隔步長 $c$ 80 神經網絡層數 無 4 神經元總數 無 100
下載: 導出CSV
-
ZHU Li, YU F R, WANG Yige, et al. Big data analytics in intelligent transportation systems: A survey[J]. IEEE Transactions on Intelligent Transportation Systems, 2019, 20(1): 383–398. doi: 10.1109/TITS.2018.2815678 D’OREY P M and FERREIRA M. ITS for sustainable mobility: A survey on applications and impact assessment tools[J]. IEEE Transactions on Intelligent Transportation Systems, 2014, 15(2): 477–493. doi: 10.1109/TITS.2013.2287257 彭軍, 馬東, 劉凱陽, 等. 基于LTE D2D技術的車聯網通信架構與數據分發策略研究[J]. 通信學報, 2016, 37(7): 62–70. doi: 10.11959/j.issn.1000-436x.2016134PENG Jun, MA Dong, LIU Kaiyang, et al. LTE D2D based vehicle networking communication architecture and data distributing strategy[J]. Journal on Communications, 2016, 37(7): 62–70. doi: 10.11959/j.issn.1000-436x.2016134 GAO Kai, HAN Farong, DONG Pingping, et al. Connected vehicle as a mobile sensor for real time queue length at signalized intersections[J]. Sensors, 2019, 19(9): 2059. doi: 10.3390/s19092059 KONG Yue, ZHANG Yikun, WANG Yichuan, et al. Energy saving strategy for task migration based on genetic algorithm[C]. 2018 International Conference on Networking and Network Applications, Xi’an, China, 2018: 330–336. CHEN Xianfu, ZHANG Honggang, WU C, et al. Optimized computation offloading performance in virtual edge computing systems via deep reinforcement learning[J]. IEEE Internet of Things Journal, 2019, 6(3): 4005–4018. doi: 10.1109/JIOT.2018.2876279 SAHA S and HASAN M S. Effective task migration to reduce execution time in mobile cloud computing[C]. The 23rd International Conference on Automation and Computing, Huddersfield, UK, 2017: 1–5. GON?ALVES D, VELASQUEZ K, CURADO M, et al. Proactive virtual machine migration in fog environments[C]. 2018 IEEE Symposium on Computers and Communications, Natal, Brazil, 2018: 742–745. KIKUCHI J, WU C, JI Yusheng, et al. Mobile edge computing based VM migration for QoS improvement[C]. The 6th IEEE Global Conference on Consumer Electronics, Nagoya, Japan, 2017: 1–5. CHOWDHURY M, STEINBACH E, KELLERER W, et al. Context-Aware task migration for HART-Centric collaboration over FiWi based tactile internet infrastructures[J]. IEEE Transactions on Parallel and Distributed Systems, 2018, 29(6): 1231–1246. doi: 10.1109/TPDS.2018.2791406 LU Wei, MENG Xianyu, and GUO Guanfei. Fast service migration method based on virtual machine technology for MEC[J]. IEEE Internet of Things Journal, 2019, 6(3): 4344–4354. doi: 10.1109/JIOT.2018.2884519 WANG Yanting, SHENG Min, WANG Xijun, et al. Mobile-edge computing: Partial computation offloading using dynamic voltage scaling[J]. IEEE Transactions on Communications, 2016, 64(10): 4268–4282. doi: 10.1109/TCOMM.2016.2599530 SUTTON R S and BARTO A G. Reinforcement Learning: An Introduction[M]. Cambridge: MIT Press, 1998: 25–42. SNIA trace data[EB/OL]. http://iotta.snia.org/traces, 2018. -
