基于卷積神經網絡的印刷電路板色環電阻檢測與定位方法

劉小燕; 李照明; 段嘉旭; 項天遠

doi:10.11999/JEIT190608

基于卷積神經網絡的印刷電路板色環電阻檢測與定位方法

doi: 10.11999/JEIT190608 cstr: 32379.14.JEIT190608

劉小燕^{1, 2, ,},
李照明¹,
段嘉旭¹,
項天遠³

1.
湖南大學電氣與信息工程學院長沙 410082
2.
電子制造業智能機器人技術湖南省重點實驗室長沙 410082
3.
中國科學院空天信息創新研究院北京 100094

基金項目: 國家自然科學基金(61973108, U1913202)，電子制造業智能機器人技術湖南省重點實驗室開放基金(IRT2018001)

詳細信息

作者簡介:
劉小燕：女，1973年生，教授，博士生導師，研究方向為圖像處理技術及其應用、智能建模與控制

李照明：男，1996年生，碩士生，研究方向為圖像處理技術

段嘉旭：男，1989年生，博士生，研究方向為深度學習與圖像處理技術

項天遠：男，1985年生，博士生，研究方向為機器人控制與信息系統

通訊作者:
劉小燕　xiaoyan.liu@hnu.edu.cn

中圖分類號: TN911.73; TP391.41
計量
- 文章訪問數: 2671
- HTML全文瀏覽量: 1656
- PDF下載量: 103
- 被引次數: 0
出版歷程
- 收稿日期: 2019-08-09
- 修回日期: 2020-05-26
- 網絡出版日期: 2020-06-23
- 刊出日期: 2020-09-27

Method for Color-ring Resistor Detection and Localization in Printed Circuit Board Based on Convolutional Neural Network

1.
College of Electrical and Information Engineering, Hunan University, Changsha 410082, China
2.
Hunan Key Laboratory of Intelligent Robot Technology in Electronic Manufacturing, Changsha 410082, China
3.
Areospace Information Research Institute, Chinese Academy of Sciences, Beijing 100094, China

Funds: The National Natural Fundation of China (61973108, U1913202), The Open fund for Hunan Key Laboratory of Intelligent Robot Technology in Electronic Manufacturing Industry (IRT2018001)

摘要

摘要: 色環電阻是印刷電路板(PCB)中最常用的電子元器件之一，主要依靠色環的排列順序和顏色等視覺信息進行區分，易發生裝配錯誤。但是色環電阻裝配質量的人工檢測方法效率低、誤檢率高，而傳統的基于圖像處理技術的自動檢測方法魯棒性較差，難以解決不同拍攝角度、物距及光照條件下的PCB板色環電阻檢測問題。針對這一問題，該文提出一種基于卷積神經網絡(CNN)的PCB板色環電阻自動檢測與定位方法，首先采用編碼器-解碼器結構的卷積神經網絡模型及帶有權重的交叉熵損失函數的網絡訓練方法，較好地解決了復雜光照及場景下PCB板色環電阻的圖像分割問題；然后采用最小面積外接矩形方法定位單個色環電阻，并通過仿射變換對色環電阻位置進行垂直校正；最后通過高斯模板匹配方法實現了色環電阻的色環定位。采用1270幅PCB圖像對該文方法進行了實驗和驗證，并與傳統的基于形態學和基于模板匹配的色環電阻檢測方法進行了對比，結果表明，該文方法在召回率、準確率及重疊度等性能指標上具有明顯優勢，處理速度快，能滿足實際應用要求。
- 圖像分割 /
- 色環電阻 /
- 卷積神經網絡 /
- 印刷電路板
Abstract: The color-ring resistor is one of the most commonly used electronic components in Printed Circuit Board (PCB). It is featured by sequential color rings, which often brings assembling errors, however. Manual detection of color-ring resistors has low efficiency and high false detection rate. Traditional image-based automatic detection methods have difficulties in dealing with PCB images under various illuminations, imaging distance and views. To solve this problem, an automatic detection and localization method for PCB color-ring resistor is proposed based on Convolution Neural Network (CNN). Firstly, the encoder-decoder CNN model is established and trained using weighted cross-entropy loss function. With CNN, color-ring resistors are segmented from PCB images with complex illumination and scenes. Secondly, each color-ring resistor is localized using minimum area bounding rectangle, and its position is adjusted to the vertical direction by affine transformation. Finally, the localization of color rings on the resistor is achieved by Gaussian template matching. The proposed method is tested and verified by 1270 PCB images, and the result is compared with that of the traditional method (method based on geometric contour, and method based on template matching). It is shown that the proposed method has obvious advantages in performance indices, including recall rate, precision, and intersection of unions, which can meet the requirements of practical applications.
- Image segmentation /
- Color-ring resistor /
- Convolutional Neural Network(CNN) /
- Printed Circuit Board (PCB)

HTML全文

圖 1 PCB圖像數據集示例

下載: 全尺寸圖片幻燈片

圖 2 本文算法的總體流程圖

下載: 全尺寸圖片幻燈片

圖 3 編碼器-解碼器結構的卷積神經網絡模型

下載: 全尺寸圖片幻燈片

圖 4 Max pooling與Upsamping計算過程

下載: 全尺寸圖片幻燈片

圖 5 色環電阻及色環的定位方法流程圖以及中間過程示意圖

下載: 全尺寸圖片幻燈片

圖 6 色環電阻最小外接矩形的確定

下載: 全尺寸圖片幻燈片

圖 7 本文方法與傳統方法的色環電阻分割與檢測結果對比

下載: 全尺寸圖片幻燈片

圖 8 本文方法與Ostu方法^[9]的色環分割結果對比

下載: 全尺寸圖片幻燈片

圖 9 PCB板上色環電阻的色環定位結果

下載: 全尺寸圖片幻燈片

圖 10 網絡層數不同時的卷積神經網絡模型示意圖(W=3, W=5)

下載: 全尺寸圖片幻燈片

圖 11 訓練過程中誤差及準確率隨迭代次數的變化曲線

下載: 全尺寸圖片幻燈片

表 1 不同檢測方法對圖像1-圖像4中色環電阻的分割與檢測結果

方法	圖像分割性能指標					PCB板中色環電阻實際個數	檢測出的色環電阻個數
方法	Acc	Recall	Precision	IoU	F₁	PCB板中色環電阻實際個數	檢測出的色環電阻個數
基于形態學的方法^[5]	0.796	0.575	0.174	0.154	0.260	31	13
基于模板匹配的方法^[8]	–	–	–	–	–	31	4
本文方法	0.966	0.991	0.666	0.660	0.785	31	31

下載: 導出CSV

表 2 不同網絡層數時色環電阻的分割性能指標對比

	平均Acc	平均Recall	平均Precision	平均IoU	平均F₁
W=3	0.985	0.970	0.887	0.870	0.925
W=4	0.991	0.959	0.953	0.924	0.995
W=5	0.985	0.883	0.965	0.865	0.921
W=6	0.979	0.837	0.936	0.805	0.881

下載: 導出CSV

表 3 CNN在測試集與驗證集上的性能指標對比

	平均Acc	平均Recall	平均Precision	平均IoU	平均F₁
驗證集	0.991	0.959	0.953	0.924	0.995
測試集	0.982	0.979	0.851	0.834	0.899

下載: 導出CSV

參考文獻(21)

熊光潔, 馬樹元, 聶學俊, 等. 基于機器視覺的高密度電路板缺陷檢測系統[J]. 計算機測量與控制, 2011, 19(8): 1824–1826.

XIONG Guangjie, MA Shuyuan, NIE Xuejun, et al. Defects inspection system of HID PCB based on machine vision[J]. Computer Measurement &Control, 2011, 19(8): 1824–1826.

吳福培, 張憲民. 印刷電路板無鉛焊點假焊的檢測[J]. 光學精密工程, 2011, 19(3): 697–702. doi: 10.3788/OPE.20111903.0697

WU Fupei and ZHANG Xianmin. Inspection of pseudo solders for lead-free solder joints in PCBs[J]. Optics and Precision Engineering, 2011, 19(3): 697–702. doi: 10.3788/OPE.20111903.0697

CHEN Y S and WANG J Y. Reading resistor based on image processing[C]. 2015 IEEE International Conference on Machine Learning and Cybernetics, Guangzhou, China, 2015: 566–571. doi: 10.1109/ICMLC.2015.7340616.

GAIDHANE V H, HOTE Y V, and SINGH V. An efficient similarity measure approach for PCB surface defect detection[J]. Pattern Analysis and Applications, 2018, 21(1): 277–289. doi: 10.1007/s10044-017-0640-9

倪堯, 鮑宇. 基于目標輪廓幾何特征的電容元件定位方法[J]. 計算機工程與科學, 2017, 39(8): 1476–1482. doi: 10.3969/j.issn.1007-130X.2017.08.014

NI Yao and BAO Yu. A capacitor element localization method based on geometrical features of target contour[J]. Computer Engineering and Science, 2017, 39(8): 1476–1482. doi: 10.3969/j.issn.1007-130X.2017.08.014

DONG Na, WU C H, IP W H, et al. Chaotic species based particle swarm optimization algorithms and its application in PCB components detection[J]. Expert Systems with Applications, 2012, 39(16): 12501–12511. doi: 10.1016/j.eswa.2012.04.063

王耀南, 劉良江, 周博文, 等. 一種基于混沌優化算法的PCB板元件檢測方法[J]. 儀器儀表學報, 2010, 31(2): 410–415. doi: 10.19650/j.cnki.cjsi.2010.02.028

WANG Yaonan, LIU Liangjiang, ZHOU Bowen, et al. Detection method of printed circuit board components based on chaotic optimization algorithm[J]. Chinese Journal of Scientific Instrument, 2010, 31(2): 410–415. doi: 10.19650/j.cnki.cjsi.2010.02.028

姜建國, 王國林, 孟宏偉, 等. 一種電子元器件組裝結果檢測方法[J]. 西安電子科技大學學報: 自然科學版, 2014, 41(3): 110–115, 173. doi: 10.3969/j.issn.1001-2400.2014.03.016

JIANG Jianguo, WANG Guolin, MENG Hongwei, et al. Detection method for assembling results of electronic components[J]. Journal of Xidian University, 2014, 41(3): 110–115, 173. doi: 10.3969/j.issn.1001-2400.2014.03.016

毛林威. 軸向色環電阻質量自動檢測系統的設計[D]. [碩士論文], 北京理工大學, 2015.

MAO Linwei. The design of color-ring resistor quality automatic detection system[D]. [Master dissertation], Beijing Institute of Technology, 2015.

CHEN Y S and WANG J Y. Computer vision on color-band resistor and its cost-effective diffuse light source design[J]. Journal of Electronic Imaging, 2016, 25(6): 061409. doi: 10.1117/1.JEI.25.6.061409

BADRINARAYANAN V, KENDALL A, and CIPOLLA R. SegNet: A deep convolutional encoder-decoder architecture for image segmentation[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2017, 39(12): 2481–2495. doi: 10.1109/TPAMI.2016.2644615

王海, 蔡英鳳, 賈允毅, 等. 基于深度卷積神經網絡的場景自適應道路分割算法[J]. 電子與信息學報, 2017, 39(2): 263–269. doi: 10.11999/JEIT160329

WANG Hai, CAI Yingfeng, JIA Yunyi, et al. Scene adaptive road segmentation algorithm based on deep convolutional neural network[J]. Journal of Electronics &Information Technology, 2017, 39(2): 263–269. doi: 10.11999/JEIT160329

DUAN Jiaxu, LIU Xiaoyan, WU Xin, et al. Detection and segmentation of iron ore green pellets in images using lightweight U-net deep learning network[J]. Neural Computing and Applications, 2020, 32(10): 5775–5790. doi: 10.1007/s00521-019-04045-8

YE Ruifang, PAN C S, CHANG Ming, et al. Intelligent defect classification system based on deep learning[J]. Advances in Mechanical Engineering, 2018, 10(3): 1–7. doi: 10.1177/1687814018766682

ZHANG Shifeng, WEN Longyin, BIAN Xiao, et al. Single-shot refinement neural network for object detection[C]. 2018 IEEE/CVF Conference on Computer Vision and Pattern Recognition, Salt Lake City, USA, 2018: 18–23. doi: 10.1109/CVPR.2018.00442.

REN Shaoqing, HE Kaiming, GIRSHICK R, et al. Faster RCNN: Towards real-time object detection with region proposal networks[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2017, 39(6): 1137–1149. doi: 10.1109/TPAMI.2016.2577031

張燁, 許艇, 馮定忠, 等. 基于難分樣本挖掘的快速區域卷積神經網絡目標檢測研究[J]. 電子與信息學報, 2019, 41(6): 1496–1502. doi: 10.11999/JEIT180702

ZHANG Ye, XU Ting, FENG Dingzhong, et al. Research on faster RCNN object detection based on hard example mining[J]. Journal of Electronics &Information Technology, 2019, 41(6): 1496–1502. doi: 10.11999/JEIT180702

IOFFE S and SZEGEDY C. Batch normalization: Accelerating deep network training by reducing internal covariate shift[C]. The 32nd International Conference on Machine Learning, Lille, France, 2015: 448–456.

KINGMA D P and BA J. Adam: A method for stochastic optimization[C]. The 3rd International Conference on Learning Representations (ICLR), San Diego, USA, 2015: 1–13.

邸男, 李桂菊, 陳春寧, 等. 結合歸一化差分高斯特征的圖像匹配技術研究[J]. 電子測量與儀器學報, 2014, 28(6): 585–590. doi: 10.13382/j.jemi.2014.06.002

DI Nan, LI Guiju, CHEN Chunning, et al. Image matching technology research based on normalized DOG features[J]. Journal of Electronic Measurement and Instrumentation, 2014, 28(6): 585–590. doi: 10.13382/j.jemi.2014.06.002

盧倩雯, 陶青川, 趙婭琳, 等. 基于生成對抗網絡的漫畫草稿圖簡化[J]. 自動化學報, 2018, 44(5): 75–89. doi: 10.16383/j.aas.2018.c170486

LU Qianwen, TAO Qingchuan, ZHAO Yalin, et al. Sketch simplification using generative adversarial networks[J]. Acta Automatica Sinica, 2018, 44(5): 75–89. doi: 10.16383/j.aas.2018.c170486
