基于隨機平均梯度下降和對比源反演的非線性逆散射算法研究

周輝林; 歐陽韜; 劉健

doi:10.11999/JEIT190566

基于隨機平均梯度下降和對比源反演的非線性逆散射算法研究

doi: 10.11999/JEIT190566 cstr: 32379.14.JEIT190566

南昌大學信息工程學院南昌 330031

基金項目: 國家自然科學基金(61561034, 61261010, 41505015)

詳細信息

作者簡介:
周輝林：男，1979年生，教授，研究方向?yàn)槌瑢拵Ю走_(dá)成像、雷達信號處理

歐陽韜：男，1996年生，碩士生，研究方向?yàn)槌瑢拵降乩走_(dá)成像，逆散射成像方法研究

劉?。耗?，1995年生，碩士生，研究方向?yàn)槌瑢拵Т走_(dá)成像，逆散射成像方法研究

通訊作者:
周輝林　zhouhuilin@ncu.edu.cn

中圖分類號: O451
計量
- 文章訪問數: 3125
- HTML全文瀏覽量: 1352
- PDF下載量: 84
- 被引次數: 0
出版歷程
- 收稿日期: 2019-07-26
- 修回日期: 2020-02-22
- 網絡出版日期: 2020-03-23
- 刊出日期: 2020-08-18

Stochastic Average Gradient Descent Contrast Source Inversion Based Nonlinear Inverse Scattering Method for Complex Objects Reconstruction

Institute of Information engineering, Nanchang University, Nanchang 330031, China

Funds: The National Natural Science Foundation of China (61561034, 61261010, 41505015)

摘要

摘要:
采用非線性對比源反演(CSI)算法求解電磁逆散射問題時，在每次迭代過程中都涉及到求解散射場數據關于對比源和總場的微分，即Jacobi矩陣，該矩陣求解導致算法存在計算代價大和收斂速度慢等問題。該文在CSI框架下，采用一種基于隨機平均梯度下降的對比源反演算法(SAG-CSI)代替原來的全梯度交替共軛梯度算法來重構介質目標介電常數的空間分布信息。該方法在每次迭代中只需計算隨機抽取的部分測量數據在目標函數中的梯度信息，同時目標函數對未抽中的測量數據的梯度信息保持不變，用以上兩部分梯度信息共同求解出目標函數的最優值。由模擬數據結果表明，該方法與傳統CSI方法在成像精度相比擬的情況下，降低了計算代價并提高算法收斂速度。
- 非線性電磁場逆散射 /
- 對比源反演 /
- 隨機平均梯度
Abstract:
When using the nonlinear Contrast Source Inversion (CSI) algorithm to solve the electromagnetic inverse scattering problem, each iteration involves finding the differential of the dissolution radiation field data about the contrast source and the total field, i.e., the Jacobi matrix. the solution of the matrix leads to the problem of large computational cost and slow convergence speed of the algorithm. in this paper, a Contrast Source Inversion algorithm based on Stochastic Average Gradient descent (SAG-CSI) is used instead of the original full gradient alternating Conjugate Gradient algorithm to reconstruct the spatial distribution information of the dielectric constant of the dielectric target under the CSI framework. the method only needs to calculate the gradient information of the randomly selected part of the measurement data in the objective function in each iteration, while the objective function keeps the gradient information of the unscented measurement data, and the optimal value of the objective function is solved together with the above two parts of the gradient information. The simulation results show that the proposed method reduces the computational cost and improves the convergence speed of the algorithm when compared with the traditional CSI method.
- Inverse scattering /
- Contrast Source Inversion (CSI) /
- Stochastic Average Gradient (SAG)

HTML全文

圖 1 2維電磁逆散射模型

下載: 全尺寸圖片幻燈片

圖 2 Austria散射體

下載: 全尺寸圖片幻燈片

圖 3 SNR為10 dB 時SAG-CSI的成像結果

下載: 全尺寸圖片幻燈片

圖 5 SNR為10 dB 時CSI的成像結果

下載: 全尺寸圖片幻燈片

圖 4 不同信噪比下兩種方法的目標函數

下載: 全尺寸圖片幻燈片

圖 6 SAG-CSI中不同散射場數據量的目標函數

下載: 全尺寸圖片幻燈片

表 1 SAG-CSI算法

　輸入：對比源初值：${{{w}}_0}$，

　　　　散射場數據：${{{E}}_{{\rm{sca}}}}$，

　　　　測量數據的索引：$i \in \left( {1,2, ··· ,N} \right)$，

　　　　隨機抽取數據的索引：${i_k} \in \left( {1,2, ··· ,N} \right)$。

　輸出：當目標函數${{{F}}_n}$達到設定誤差值$\delta $或最大迭代次數${{{N}}_{{\rm{iter}}}}$時，輸出對比度函數：${{{\chi}} _n}$

　(1) 計算格林函數${{{G}}_{\rm{D}}}$, ${{{G}}_{\rm{R}}}$

　(2) 對比度函數初值${{{\chi}} _0} = 0$，

　(3) 由前向模型計算得到對比源初值
　　　　　　　　　　　　　　　　　　　　　　　${ {{w} }_0} = \dfrac{ {\parallel { {{G} }^H_{\rm R} }{ {{E} }_{\rm sca} }{\parallel ^2} } }{ {\parallel { {{G} }_{\rm R} }{ {{G} }^H{\rm R} }{ {{E} }_{\rm sca} }{\parallel ^2} } }{ {{G} }^H_R}{ {{E} }_{\rm sca} }$ (*為共軛轉置) (16)

　(4) $n \leftarrow 0$(n為迭代次數)

　(5) while ${{{F}}_n}\left( {{w_n}} \right) < {{\delta}} $或${{n}} < {N_{{\rm{iter}}}}$ do

　　　步驟 1 ?每次迭代隨機抽取測量數據的索引：${i_k} = {\rm{randperm}}\left( i \right)$

　　　步驟 2 將步驟1抽取的測量數據按照進行梯度更新計算(其中$\rho _{n - 1}^{{i_k}}$, $\gamma _{n - 1}^{{i_k}}$和${\chi _{n - 1}}$分別表示隨機抽取散射場數據的數據方程誤差和場誤差以及上次迭代保存的對比度函數)
　　　　　　　　　　　　　　　　　　　　${{g} }_n^{ {i_k} } = - \frac{ { { {\left( { {{G} }_{\rm{R} }^{ {i_k} } } \right)}^H}\rho _{n - 1}^{ {i_k} } } }{ {\displaystyle\sum\limits_k {\parallel {{E} }_{ {\rm{sca} } }^{ {i_k} }{\parallel ^2} } } } - \frac{ {\gamma _{n - 1}^{ {i_k} } - {{G} }^H_{\rm{D} } { { {{{\chi} } }^* _{n - 1} } } \gamma _{n - 1}^{ {i_k} })} }{ {\displaystyle\sum\limits_k {\parallel { {{\chi} } _{n - 1} }{{E} }_{ {\rm{inc} } }^{ {i_k} }{\parallel ^2} } } }$(*為復共軛) (17)

　　　步驟 3 ?對抽取的散射場數據在目標函數中的梯度值進行更新，其余散射場數據對應的梯度不變(其中${\nabla _{{w_n}}}{{F}}_n^i$表示隨機抽取散射場數據在目標函數中關于對比源的更新梯度值，${{g}}_{n - 1}^{{i_k}}$表示上次迭代該散射場數據對應的梯度值，${\overline { { {{g} }_{n - 1} } } }$表示所有散射場數據在目標函數中的梯度矩陣)

　　　　　　　　　　　　　　　　　　　　　　　　　　${ { { {{\overline{{g} } } }_n} } } ={ { { { {\overline{{g} } } }_{n - 1} } } } - {{g} }_{n - 1}^{ {i_k} } + { {\text{?} } _{ {w_n} } }{{F} }_n^i$ (18)

　將所有測量數據構成的梯度矩陣$\overline{\overline {{{{g}}_n}}} $求和取平均得出當前迭代的梯度${{{g}}_n}$,即搜索方向的反方向。

　　　步驟 4 ?由步驟3所得的搜索方向和式(15)所求得的搜索步長可計算更新的對比源(上次迭代保存的對比源${{{w}}_{n - 1}}$)：${{{w}}_n} \!=\! {{{w}}_{n - 1}} \!-\! {{{\alpha}} _n}{{{g}}_n}$

　　　步驟 5 ?更新總場的值：${{E}}_{{\rm{tot}}}^n = E_{{\rm{tot}}}^{n - 1} - {{{\alpha }}_n}{{{G}}_{\rm{D}}}{{{g}}_n}$

　　　步驟 6 ?由對比源作為輔助變量公式可知
　　　　　　　　　　　　　　　　　　　${ {{\chi} } _n} = \frac{ {\displaystyle\sum\limits_K { { {{w} }_n} ({ { {{{E} } } }_{ {\rm{tot} } }^n})^* } } }{ {\displaystyle\sum\limits_K { {{E} }_{ {\rm{tot} } }^n ({ {{{E} } }_{ {\rm{tot} } }^n})^* } } }$ (*為復共軛,K為抽取樣本的總個數) (19)

　　　步驟 7 ?${{n}} = {{n}} + 1$

　(6) end

　(7) ${{\chi}} = {{{\chi}} _n}$

下載: 導出CSV

參考文獻(16)

LI Lianlin, WANG Longgang, DING Jun, et al. A probabilistic model for the nonlinear electromagnetic inverse scattering: TM case[J]. IEEE Transactions on Antennas and Propagation, 2017, 65(11): 5984–5991. doi: 10.1109/TAP.2017.2751654

KIM S B, VAN ZYL J J, JOHNSON J T, et al. Surface soil moisture retrieval using the l-band synthetic aperture radar onboard the Soil Moisture Active-Passive satellite and evaluation at core validation sites[J]. IEEE Transactions on Geoscience and Remote Sensing, 2017, 55(4): 1897–1914. doi: 10.1109/TGRS.2016.2631126

WANG Longgang, Li Lianlin, DING Jun, et al. A fast patches-based imaging algorithm for 3-D multistatic imaging[J]. IEEE Geoscience and Remote Sensing Letters, 2017, 14(6): 941–945. doi: 10.1109/LGRS.2017.2688461

VAN DEN BERG P M and KLEINMAN R E. A contrast source inversion method[J]. Inverse Problems, 1997, 13(6): 1607. doi: 10.1088/0266-5611/13/6/013

POLI L, OLIVERI G, and MASSA A. Microwave imaging within the first-order Born approximation by means of the contrast-field Bayesian compressive sensing[J]. IEEE Transactions on Antennas and Propagation, 2012, 60(6): 2865–2879. doi: 10.1109/TAP.2012.2194676

SHEA J D, VAN VEEN B D, and HAGNESS S C. A TSVD analysis of microwave inverse scattering for breast imaging[J]. IEEE Transactions on Biomedical Engineering, 2012, 59(4): 936–945. doi: 10.1109/TBME.2011.2176727

OLIVERI G, ANSELMI N, and MASSA A. Compressive sensing imaging of non-sparse 2D scatterers by a total-variation approach within the Born approximation[J]. IEEE Transactions on Antennas and Propagation, 2014, 62(10): 5157–5170. doi: 10.1109/TAP.2014.2344673

BEVACQUA M T, CROCCO L, DI DONATO L, et al. Non-linear inverse scattering via sparsity regularized contrast source inversion[J]. IEEE Transactions on Computational Imaging, 2017, 3(2): 296–304. doi: 10.1109/TCI.2017.2675708

CHEN Xudong. Subspace-based optimization method for solving inverse-scattering problems[J]. IEEE Transactions on Geoscience and Remote Sensing, 2010, 48(1): 42–49. doi: 10.1109/TGRS.2009.2025122

周輝林, 鄭靈輝, 莫仲念, 等. 基于直接采樣法和子空間優化法的多介質目標混合逆散射成像方法[J]. 電子與信息學報, 2017, 39(3): 758–762. doi: 10.11999/JEIT160534

ZHOU Huilin, ZHENG Linghui, MO Zhongnian, et al. DSM-SOM based hybrid inverse scattering method for multiple dielectric objects reconstruction[J]. Journal of Electronics &Information Technology, 2017, 39(3): 758–762. doi: 10.11999/JEIT160534

SONG Xiaoqian, LI Maokun, YANG Fan, et al. Feasibility study of acoustic imaging for human thorax using an acoustic contrast source inversion algorithm[J]. The Journal of the Acoustical Society of America, 2018, 144(5): 2782–2792. doi: 10.1121/1.5078590

GUO Lei and ABBOSH A M. Microwave imaging of nonsparse domains using Born iterative method with wavelet transform and block sparse Bayesian learning[J]. IEEE Transactions on Antennas and Propagation, 2015, 63(11): 4877–4888. doi: 10.1109/TAP.2015.2473000

YE Xiuzhu and CHEN Xudong. Subspace-based distorted-Born iterative method for solving inverse scattering problems[J]. IEEE Transactions on Antennas and Propagation, 2017, 65(12): 7224–7232. doi: 10.1109/TAP.2017.2766658

ABUBAKAR A, VAN DEN BERG P M, and KOOIJ B J. A conjugate gradient contrast source technique for 3D profile inversion[J]. IEICE Transactions on Electronics, 2000, E83-C(12): 1864–1874.

SCHMIDT M, LE ROUX N, and BACH F. Minimizing finite sums with the stochastic average gradient[J]. Mathematical Programming, 2017, 162(1/2): 83–112. doi: 10.1007/s10107-016-1030-6

DOGNIN P and GOEL V. Combining stochastic average gradient and hessian-free optimization for sequence training of deep neural networks[C]. 2013 IEEE Workshop on Automatic Speech Recognition and Understanding. Olomouc: IEEE, 2013: 321–325.
