基于災難預測多區域故障的虛擬光網絡生存性映射

劉煥淋; 杜理想; 陳勇; 王展鵬

doi:10.11999/JEIT190561

基于災難預測多區域故障的虛擬光網絡生存性映射

doi: 10.11999/JEIT190561 cstr: 32379.14.JEIT190561

1.
重慶郵電大學通信與信息工程學院重慶 400065
2.
重慶郵電大學工業物聯網與網絡化控制教育部重點實驗室重慶 400065

基金項目: 國家自然科學基金(51977021)；重慶市自然科學基金面上項目(2019jcyj-msxmX0613)

詳細信息

作者簡介:
劉煥淋：女，1970年生，教授，研究方向為光通信技術與未來網絡

杜理想：男，1995年生，碩士，研究方向為光網絡生存性路由算法

陳勇：男，1963年生，教授，研究方向為光通信技術、傳感檢測與自動化技術

王展鵬：男，1996年生，碩士，研究方向為光網絡生存性調度算法

通訊作者:
劉煥淋　liuhl2@sina.com

中圖分類號: TN929.11
計量
- 文章訪問數: 2543
- HTML全文瀏覽量: 812
- PDF下載量: 51
- 被引次數: 0
出版歷程
- 收稿日期: 2019-07-25
- 修回日期: 2020-02-19
- 網絡出版日期: 2020-03-12
- 刊出日期: 2020-07-23

Disaster Prediction-based Survivable Virtual Optical Network Mapping for Multi-Area Faults

1.
School of Communication and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China
2.
Key Laboratory of Industrial Internet of Things and Networked Control, Ministry of Education, Chongqing University of Posts and Telecommunications, Chongqing 400065, China

Funds: The National Natural Science Foundation of China (51977021), The Natural Science Foundation Project of Chongqing Science and Technology Commission (2019 jcyj-msxmX0613)

摘要

摘要:
生存性虛擬光網絡映射是提高光網絡應對災難故障的重要技術保障措施。為解決災難性多區域故障導致彈性光網絡的帶寬容量損失問題，該文提出基于災難預測故障模型的蟻群優化虛擬光網絡映射 (DFM-ACO-VNM)算法。在該算法中，設計基于光節點資源和相鄰鏈路的全局潛在故障概率的光節點排序映射準則，并設計啟發式信息公式實現多區域故障下最小帶寬容量損失的虛擬節點和虛擬鏈路協同映射。仿真結果表明，該文所提算法在多區域故障時能降低帶寬容量損失，減少帶寬阻塞率和提高頻譜利用率。
- 彈性光網絡 /
- 多區域故障 /
- 生存性映射 /
- 蟻群優化 /
- 帶寬容量損失
Abstract:
Survivable virtual optical network mapping is an important technology to improve the optical network response to disaster failures. In order to solve the problem of bandwidth capacity loss caused by multi-area faults resulted from disasters in Elastic Optical Networks (EONs), a multi-area disaster fault model of survivable virtual network based on risk assessment is established, and a Disaster Fault Model based Ant Colony Optimization for Virtual Network Mapping (DFM-ACO-VNM) algorithm is proposed in the paper. An optical node ranking mapping criterion based on node resources and global potential failure probability of adjacent links in EONs is designed. Then, a heuristic information formula is designed to realize cooperative mapping of virtual nodes and virtual links with minimum bandwidth capacity loss under multi-area faults. The simulation results show that the proposed algorithm can decrease the bandwidth capacity loss, reduce the bandwidth blocking probability and improve the spectrum utilization in multi-area faults.
- Elastic Optical Network (EONs) /
- Multi-area fault /
- Survivability mapping /
- Ant Colony Optimization (ACO) /
- Bandwidth capacity loss

HTML全文

圖 1 虛擬網絡映射到災難彈性光網絡示意圖

下載: 全尺寸圖片幻燈片

圖 2 仿真網絡多區域災難故障拓撲

下載: 全尺寸圖片幻燈片

圖 3 不同負載下帶寬阻塞率的對比

下載: 全尺寸圖片幻燈片

圖 4 不同負載下帶寬容量損失的對比

下載: 全尺寸圖片幻燈片

圖 5 不同負載下頻譜利用率的對比

下載: 全尺寸圖片幻燈片

表 1 DFM-ACO-VNM算法

　輸入：輸入底層網絡${{{G}}_{\rm{s}}}({{{N}}_{\rm{s}}},{{{{\rm E}}}_{\rm{s}}})$和災難事件F，虛擬網絡請求${{{G}}_{\rm{v}}}({{{N}}_{\rm{v}}},{{{E}}_{\rm{v}}})$。

　輸出：Ant_best，即虛擬網絡的虛擬節點映射，虛擬鏈路映射和頻譜資源分配結果。

　(1) 　初始化信息素濃度矩陣τ[n][m]，啟發式信息矩陣η[n][m]，轉移概率矩陣P[n][m]，初始化${A_{{\rm{best}}}} = 1000000$, n為N_v集合的虛擬節點
　　　數，m為N_s集合的光節點數，設置蟻群算法最大迭代次數G_max，迭代變量j=0; A_j為虛擬網絡蟻群映射第j輪結果；

　(2) 　根據災難集合F，計算EONs區域A災難概率${p_A}\left( {{f_i}} \right)\;$，根據式(7)計算各光纖鏈路e_s的災難評估$M({e_{\rm{s}}})$值；

　(3) 　根據式(5)，對虛擬網絡中的虛擬節點降序排列在集合${R_{{n_{\rm{v}}}}}$中；

　(4) 　For(j =0, j+1, j <G_max)

　(5) 　　For 從排序第1個虛擬節點到第n個虛擬節點

　(6) 　　　執行EBCL-VNM映射算法(表2)，構造虛擬網絡映射解A_j；

　(7) 　　End for

　(8) 　　　If ${{\rm{E}}_{{\rm{BCL}}}}({A_{{\rm{best}}}})$ > ${{{E}}_{{\rm{BCL}}}}({A_j})$

　(9) 　　　　令${{{E}}_{{\rm{BCL}}}}({A_{{\rm{best}}}})$ = ${{{E}}_{{\rm{BCL}}}}({A_j})$

　(10) 　　　End if

　(11) 　　　根據式(10)，更新信息素濃度矩陣

　(12) 　　　if converge

　(13) 　　　　Break；

　(14) 　　　end if

　(15) 　end for

　(16) 　Return ${{\rm{E}}_{{\rm{BCL}}}}({A_{{\rm{best}}}})$ and ${A_{{\rm{best}}}}$

下載: 導出CSV

表 2 EBCL-VNM 算法

　(1) 　初始化虛擬網絡請求的虛擬節點、鏈路映射結果集合和資源分配結合，即A₀ = Φ；

　(2) 　根據式(6)，排序EONs中光節點在集合${R_{{n_{\rm{s}}}}}$中；

　(3) 　選擇順序列表${R_{{n_{\rm{v}}}}}$中的第1個虛擬節點$n_{\rm{v}}^0$；

　(4)　選擇順序列表${R_{{n_{\rm{s}}}}}$中的第1個光節點$n_{\rm{s}}^0$；

　(5) 　將滿足資源約束的$n_{\rm{v}}^0$映射到$n_{\rm{s}}^0$，記錄已映射節點信息，并從集合${R_{{n_{\rm{v}}}}}$中刪除$n_{\rm{v}}^0$；

　(6) 　For 依次映射集合${R_{{n_{\rm{v}}}}}$的剩余虛擬節點

　(7) 　當前擬映射虛擬節點$n_v^i$加入已映射虛擬節點和虛擬鏈路集合時，根據式(8)結果確定需要新映射的虛擬鏈路；

　(8) 　找出滿足虛擬節點資源約束條件的候選光節點集合$n_{\rm{s}}^{i{\rm{ - C}}}$；

　(9) 　　For 對所有候選光節點集合$n_{\rm{s}}^{i{\rm{ - C}}}$依次執行

　(10) 　　　運行多商品流算法映射各虛擬鏈路的K條候選光路路由和資源光路帶寬分配；

　(11) 　　　根據式(8)計算啟發式信息矩陣η[$n_{\rm{v}}^i$][$n_{\rm{s}}^j$]；

　(12) 　　　根據式(9)計算轉移概率矩陣P[$n_{\rm{v}}^i$][$n_{\rm{s}}^j$]；

　(13) 　　　將虛擬節點i按式(9)計算值，概率地選擇映射到光節點j；

　(14) 　　End for

　(15) 　　更新虛擬節點和虛擬鏈路映射集合；

　(16) 　End for

　(17) 　Return 虛擬節點映射、虛擬鏈路映射和資源分配結果。

下載: 導出CSV

參考文獻(21)

鮑寧海, 蘇國慶, 陳靜波. 恢復時間敏感的光網絡混合通路保護算法[J]. 重慶郵電大學學報: 自然科學版, 2017, 29(3): 313–319. doi: 10.3979/j.issn.1673-825X.2017.03.005

BAO Ninghai, SU Guoqing, and CHEN Jingbo. Recovery-time aware hybrid path protection algorithm in optical networks[J]. Journal of Chongqing University of Posts and Telecommunications:Natural Science Edition, 2017, 29(3): 313–319. doi: 10.3979/j.issn.1673-825X.2017.03.005

LIU Huanlin, DU Jundan, CHEN Yong, et al. A coordinated virtual optical network embedding algorithm based on resources availability-aware over elastic optical networks[J]. Optical Fiber Technology, 2018, 45: 391–398. doi: 10.1016/j.yofte.2018.08.021

ELMIRGHANI J M H, KLEIN T, HINTON K, et al. GreenTouch greenMeter core network energy-efficiency improvement measures and optimization[J]. Journal of Optical Communications and Networking, 2018, 10(2): A250–A269. doi: 10.1364/JOCN.10.00A250

PAOLUCCI F, CUGINI F, FRESI F, et al. Superfilter technique in SDN-controlled elastic optical networks[Invited][J]. Journal of Optical Communications and Networking, 2015, 7(2): A285–A292. doi: 10.1364/JOCN.7.00A285

LU Shuaibing, WU Jie, ZHENG Huanyang, et al. On maximum elastic scheduling in cloud-based data center networks for virtual machines with the hose model[J]. Journal of Computer Science and Technology, 2019, 34(1): 185–206. doi: 10.1007/s11390-019-1890-3

LIN Rongping, LUO Shan, ZHOU Jingwei, et al. Column generation algorithms for virtual network embedding in flexi-grid optical networks[J]. Optics Express, 2018, 26(8): 10898–10913. doi: 10.1364/OE.26.010898

DUBOIS D J and CASALE G. Autonomic provisioning and application mapping on spot cloud resources[C]. 2015 International Conference on Cloud and Autonomic Computing, Boston, USA, 2015: 57–68. doi: 10.1109/ICCAC.2015.21.

XIE Weisheng, JUE J P, ZHANG Qiong, et al. Survivable virtual optical network mapping in flexible-grid optical networks[C]. 2014 International Conference on Computing, Networking and Communications, Honolulu, USA, 2014: 221–225. doi: 10.1109/ICCNC.2014.6785335.

ZHANG Huibin, WANG Wei, ZHAO Yongli, et al. Shared protection based virtual network mapping in space division multiplexing optical networks[J]. Optical Fiber Technology, 2018, 42: 63–68. doi: 10.1016/j.yofte.2017.12.004

XUAN Hejun, WANG Yuping, XU Zhanqi, et al. Virtual optical network mapping and core allocation in elastic optical networks using multi-core fibers[J]. Optics Communications, 2017, 402: 26–35. doi: 10.1016/j.optcom.2017.05.065

GALDAMEZ C and YE Zilong. Resilient virtual network mapping against large-scale regional failures[C]. 2017 IEEE Conference of Wireless and Optical Communication, Newark, USA, 2017: 1–4. doi: 10.1109/WOCC.2017.7928978.

FERDOUSI S, DIKBIYIK F, FARHAN HABIB M, et al. Disaster-aware datacenter placement and dynamic content management in cloud networks[J]. IEEE OSA Journal of Optical Communications and Networking, 2015, 7(7): 681–694. doi: 10.1364/JOCN.7.000681

GOUR R, KONG Jian, ISHIGAKI G, et al. Survivable routing in multi-domain optical networks with geographically correlated failures[C]. 2017 IEEE Global Communications Conference, Singapore, 2017: 1–6. doi: 10.1109/GLOCOM.2017.8254775.

劉煥淋, 易鵬飛, 陳勇, 等. 一種最小故障風險損失的彈性光網絡多鏈路故障概率保護策略[J]. 電子與信息學報, 2017, 39(8): 1819–1825. doi: 10.11999/JEIT161159

LIU Huanlin, YI Pengfei, CHEN Yong, et al. Multi-link failure probability protection strategy based on minimum fault risk loss in elastic optical networks[J]. Journal of Electronics &Information Technology, 2017, 39(8): 1819–1825. doi: 10.11999/JEIT161159

劉煥淋, 林振宇, 王欣, 等. 彈性光網絡中基于安全性感知的差異化虛擬光網絡的映射策略[J]. 電子與信息學報, 2019, 41(2): 424–432. doi: 10.11999/JEIT180335

LIU Huanlin, LIN Zhengyu, WANG Xin, et al. A diverse virtual optical network mapping strategy based on security awareness in elastic optical networks[J]. Journal of Electronics &Information Technology, 2019, 41(2): 424–432. doi: 10.11999/JEIT180335

POURVALI M, BAI Hao, CRICHIGNO J, et al. Multicast virtual network services embedding for improved disaster recovery support[J]. IEEE Communications Letters, 2018, 22(7): 1362–1365. doi: 10.1109/LCOMM.2018.2822739

WANG Ying, LIU Xiao, QIU Xuesong, et al. Prediction-based survivable virtual network mapping against disaster failures[J]. International Journal of Network Management, 2016, 26(5): 336–354. doi: 10.1002/nem.1939

朱顥東, 孫振, 吳迪, 等. 基于改進蟻群算法的移動機器人路徑規劃[J]. 重慶郵電大學學報: 自然科學版, 2016, 28(6): 849–855. doi: 10.3979/j.issn.1673-825X.2016.06.017

ZHU Haodong, SUN Zhen, WU Di, et al. Path planning for mobile robot based on improved ant colony algorithm[J]. Journal of Chongqing University of Posts and Telecommunications:Natural Science Edition, 2016, 28(6): 849–855. doi: 10.3979/j.issn.1673-825X.2016.06.017

ZHENG Hongkun, LI Jingjing, GONG Yuejiao, et al. Link mapping-oriented ant colony system for virtual network embedding[C]. 2017 IEEE Congress on Evolutionary Computation, San Sebastian, Spain, 2017: 1223–1230. doi: 10.1109/CEC.2017.7969445.

謝暉. 抗毀SDN光網絡資源優化調度研究[J]. 激光雜志, 2019, 40(4): 97–101. doi: 10.14016/j.cnki.jgzz.2019.04.097

XIE Hui. Research on optimal scheduling of SDN optical network resources[J]. Laser Journal, 2019, 40(4): 97–101. doi: 10.14016/j.cnki.jgzz.2019.04.097

DU Xiaowu and MA Lisheng. Backup path provisioning for service protection against disaster failures in telecom networks[C]. 2017 International Conference on Networking and Network Applications, Kathmandu, Nepal, 2017: 220–224. doi: 10.1109/NaNA.2017.40.
