Crosstalk-aware Spectrum Converters Sparse Configuration and Resource Allocation for Space Division Multiplexing Elastic Optical Networks

1.
School of Communication and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China
2.
Key Laboratory of Industrial Internet of Things and Networked Control, Ministry of Education, Chongqing University of Posts and Telecommunications, Chongqing 400065, China

Funds: The National Natural Science Foundation of China(51977021), The Science Foundation Project of Chongqing Science and Technology Commission (2019 jcyj-msxmX0613)

摘要

摘要:
針對大容量多芯光纖空分復用彈性光網絡(SDM-EON)中芯間串?dāng)_導致業務傳輸質量下降和阻塞率上升的問題，該文提出了節點稀疏配置頻譜轉換器降低芯間串?dāng)_的路由纖芯頻譜分配方法。該方法根據網絡中節點中介中心性稀疏配置頻譜轉換器。在業務路由階段，設計綜合考慮光路負載和節點頻譜轉換能力的光路選擇的權重方法；為了降低串?dāng)_，在纖芯頻譜分配階段，設計纖芯分組和頻譜分區分配方法；最后，針對串?dāng)_較大的業務，采用頻譜轉換以降低業務串?dāng)_和改善帶寬阻塞率。仿真結果表明，所提算法能有效地提高頻譜利用率，降低因芯間串?dāng)_導致的帶寬阻塞率。
- 空分復用彈性光網絡 /
- 芯間串?dāng)_ /
- 頻譜轉換器 /
- 纖芯路由頻譜分配 /
- 帶寬阻塞率
Abstract:
In order to solve the problem of inter-core crosstalk in Space Division Multiplexing Elastic Optical Network (SDM-EON), which leads to the decline of service transmission quality and the increase of blocking probability, a routing, fiber core and spectrum allocation method for reducing inter-core crosstalk through sparse configuration spectrum converter at nodes is proposed in the paper. This method configures the spectrum converter according to the node’s centrality sparseness in SDM-EON. During service routing, a weighting method for optical path selection considering both optical path load and node spectrum conversion capability is designed.to reduce crosstalk. In the core spectrum allocation stage, a method of fiber core grouping and spectrum partition allocation is utilized. Finally, spectrum conversion is used to reduce traffic crosstalk and improve bandwidth blocking probability for services with high crosstalk. The simulation results show that the proposed algorithm can effectively improve the spectrum utilization and reduce the bandwidth blocking probability caused by fibers inter-core crosstalk.
- Space Division Multiplexing Elastic Optical Network (SDM-EON) /
- Inter-core crosstalk /
- Spectrum converter /
- Fiber core and routing spectrum allocation /
- Bandwidth blocking probability

HTML全文

圖 1 節點稀疏配置頻譜轉換器的路由示意圖

下載: 全尺寸圖片幻燈片

圖 2 仿真網絡拓?fù)?/p>

下載: 全尺寸圖片幻燈片

圖 3 不同網絡負載下4種算法的帶寬阻塞率

下載: 全尺寸圖片幻燈片

圖 4 不同網絡負載下4種算法的頻譜利用率

下載: 全尺寸圖片幻燈片

圖 5 與KSP-FF算法對比的各算法的XT改善率

下載: 全尺寸圖片幻燈片

表 1 NSCC-XT-RSCA算法

(1) 預處理階段，根據式(2)計算網絡拓?fù)渌泄?jié)點的中介中心性，根據給定的比例選取節點作為SC⁺節點配置頻譜轉換器；根據2.4節所述　　將纖芯頻譜進行分組和分區；
(2) 業務請求到達后，確定業務調制格式，并計算業務在該調制格式所需頻隙數；
(3) 根據光路權重公式(3)，計算源、目的節點間K條候選最短長度光路權重，根據權值對候選光路進行降序排序，設變量k=1；
(4) 判斷第k條光路上是否存在滿足業務傳輸?shù)目捎妙l譜塊，如有，轉步驟(7)，否則，轉步驟(5)；
(5) 判斷光路上是否有SC⁺節點，如有，則轉步驟(6)，否則，轉步驟(8)；
(6) 判斷光路是否有經過SC⁺節點轉換的可用頻譜塊，若有，轉步驟(7)，否則，轉步驟(8)；
(7) 根據式(4)～式(6)計算光路上的纖芯頻譜分配成本C^P，確定頻譜塊，轉步驟(9)；
(8) 若k>K，則業務被阻塞；否則，令k加1，轉步驟(4)；
(9) 判斷$\left\lceil { {C^p} } \right\rceil \ge {H_p}$?若是，則業務在光路p上受串?dāng)_影響較大，p=1, 2, ···, k，轉步驟(10)，否則轉步驟(16)；
(10) 根據式(1)計算業務所受串?dāng)_，若該串?dāng)_小于串?dāng)_閾值條件，則轉步驟(16)，否則，轉步驟(11)；
(11) 判斷光路上是否有SC⁺節點，若有，轉步驟(12)，否則，阻塞業務；
(12) 判斷光路是否存在能降低XT值的頻譜塊，若有，轉步驟(14)，否則，轉步驟(13)；
(13) 判斷光路信號是否為最低調制格式，如是，則阻塞業務，否則，降低調制格式，減少業務需求的頻譜塊數目，轉步驟(2)；
(14) 判斷是否存在2個及以上節點為SC⁺節點，如有，轉步驟(15)，否則，轉步驟(10)；
(15) 根據式(7)計算各SC⁺節點的使用排名，選取排名高的節點使用SC⁺功能，轉步驟(10)；
(16) 業務成功傳輸，輸出業務所選擇的光路p、纖芯編號、頻譜資源以及SC⁺節點頻譜轉換要求。

下載: 導出CSV
