風云三號(D)氣象衛星微波濕溫度計系統建模和仿真
doi: 10.11999/JEIT190507 cstr: 32379.14.JEIT190507
-
1.
中國科學院國家空間科學中心 微波遙感重點實驗室 北京 100190
-
2.
中國科學院大學 北京 100190
基金項目: 國家重點研發計劃(2018YFB0504900)
Modeling and Simulating of Microwave Humidity and Temperature Sounder Onboard the FY-3(D) Satellite
-
1.
Key Laboratory of Microwave Remote Sensing, National Space Science Center, Chinese Academy of Sciences, Beijing 100190, China
-
2.
University of Chinese Academy of Sciences, Beijing 100190, China
Funds: The National Key R&D Program of China (2018YFB0504900)
-
摘要:
針對風云三號衛星微波濕溫度計，該文建立了全功率式微波輻射計系統的仿真模型，重點對熱輻射噪聲源、混頻器、低噪放、濾波器與檢波器等關鍵性器件進行了參數化建模。從信號處理的角度對全功率式微波輻射計的工作過程進行了模擬，并對仿真系統的輸出功率、靈敏度和線性度進行評估與分析。通過與實際儀器的測試結果對比，驗證了所提仿真模型的正確性。
-
關鍵詞:
- 風云三號(D)氣象衛星 /
- 微波濕溫度計 /
- 全功率式微波輻射計 /
- 毫米波系統建模 /
- 計算機仿真
Abstract:A simulation model of total power microwave radiometer is developed for the microwave humidity and temperature sounder onboard the FY-3 satellite. The key components such as mixer, low noise amplifier, local oscillator, filter and detector are parametrically modeled. The model is studied from the aspect of signal processing, and dynamic range, sensitivity and linearity of the simulation system are evaluated and analyzed. The correctness of the simulation model is verified by comparing them with the test results of the actual system.
-
表 2 各級功率輸出與檢波電壓輸出結果
仿真功率(dBm) 實際功率(dBm) 3 K 340 K 3 K 340 K 濾波器 –10.75 –9.34 –10.69 –9.27 仿真檢波電壓(mV) 實際檢波電壓(mV) 檢波器 20.21 27.92 20.04 27.56
下載: 導出CSV
表 3 系統線性度仿真結果
$\Delta G/G$(%) ${T_{\rm in} }(\rm K)$ ${V_{\rm C} }(\rm mV)$ ${V_{\rm H} }(\rm mV)$ ${V_{\rm out} }(\rm mV)$ $a$ $b$ ${T_{\rm out} }(\rm K)$ $\Delta T(\rm K)$ 0.024 3 20.63 27.59 17.75 30.17 –532.46 3.10 –0.10 0.057 80 20.65 27.64 20.32 30.04 –530.39 80.09 –0.09 0.055 160 20.67 27.64 22.99 30.13 –532.77 159.90 0.10 0.042 240 20.63 27.59 25.60 30.17 –532.46 239.96 0.04 0.039 320 20.74 27.74 28.41 30.00 –532.20 320.10 –0.10
下載: 導出CSV
-
谷松巖, 郭楊, 王振占, 等. 風云三號A星微波濕度計探測通道定標分析[J]. 氣象科技進展, 2013, 3(4): 43–49. doi: 10.3969/j.issn.2095-1973.2013.04.005GU Songyan, GUO Yang, WANG Zhenzhan, et al. Calibration analyses for sounding channels of MWHS onboard FY-3A[J]. Advances in Meteorological Science and Technology, 2013, 3(4): 43–49. doi: 10.3969/j.issn.2095-1973.2013.04.005 陸其峰. 風云三號A星大氣探測資料數據在歐洲中期天氣預報中心的初步評價與同化研究[J]. 中國科學: 地球科學, 2011, 54(10): 1453–1894. doi: 10.1007/s11430-011-4243-9LU Qifeng. Initial evaluation and assimilation of FY-3A atmospheric sounding data in the ECMWF System[J]. Science China Earth Sciences, 2011, 54(10): 1453–1894. doi: 10.1007/s11430-011-4243-9 牛立杰, 劉浩, 吳季. 高靈敏度、高穩定度微波輻射計技術研究與實驗驗證[J]. 電子與信息學報, 2017, 39(8): 2028–2032. doi: 10.11999/JEIT161112NIU Lijie, LIU Hao, and WU Ji. Research and experimental verification on high sensitivity and high stability microwave radiometer[J]. Journal of Electronics &Information Technology, 2017, 39(8): 2028–2032. doi: 10.11999/JEIT161112 BURRAGE D M, GOODBERLET M A, and HERON M L. Simulating passive microwave radiometer designs using Simulink[J]. Simulation, 2002, 78(1): 36–55. doi: 10.1177/0037549702078001201 盧紅麗. L波段全極化微波輻射計鏈路仿真與分析[D]. 中國科學院研究生院(空間科學與應用研究中心), 2011.LU Hongli. Link simulation and analysis of L-band microwave radiometer[D]. Graduate School of Chinese Academy of Sciences (Center for Space Science and Applied Research), 2011. 高飛, 張俊榮. 數字增益自動補償微波輻射計的計算機仿真[J]. 電子學報, 1999, 27(9): 22–24. doi: 10.3321/j.issn:0372-2112.1999.09.007GAO Fei and ZHANG Junrong. Computer simulation of digital auto gain compensative microwave radiometer[J]. Acta Electronica Sinica, 1999, 27(9): 22–24. doi: 10.3321/j.issn:0372-2112.1999.09.007 高飛, 張俊榮. 星載微波成像儀接收通道的仿真研究[J]. 遙感技術與應用, 1998, 13(3): 24–29. doi: 10.3969/j.issn.1004-0323.1998.03.005GAO Fei and ZHANG Junrong. Simulative study of received channel about space-borne microwave imaging instrument[J]. Remote Sensing Technology and Application, 1998, 13(3): 24–29. doi: 10.3969/j.issn.1004-0323.1998.03.005 張升偉, 王振占, 孫茂華, 等. 風云三號衛星先進微波大氣探測儀系統設計與研制[J]. 中國工程科學, 2013, 15(7): 81–87. doi: 10.3969/j.issn.1009-1742.2013.07.012ZHANG Shengwei, WANG Zhenzhan, SUN Maohua, et al. The design and development of advanced microwave atmospheric counder onboard FY-3 satellite[J]. Engineering Science in China, 2013, 15(7): 81–87. doi: 10.3969/j.issn.1009-1742.2013.07.012 TIURI M. Radio astronomy receivers[J]. IEEE Transactions on Antennas and Propagation, 1964, 12(7): 930–938. doi: 10.1109/TAP.1964.1138345 PENG Jinzheng. Polarimetric microwave radiometer calibration[D]. [Ph.D. dissertation], University of Michigan, 2008. PENG Jinzheng and RUF C S. Covariance statistics of fully Polarimetric brightness temperature measurements[J]. IEEE Geoscience and Remote Sensing Letters, 2010, 7(3): 460–463. doi: 10.1109/LGRS.2009.2039115 SKOU N. Microwave Radiometer Systems: Design and Analysis[M]. Norwood, MA: Artech House, 1989. SEIFFERT M, MENNELLA A, BURIGANA C, et al. 1/f noise and other systematic effects in the Planck-LFI radiometers[J]. Astronomy & Astrophysics, 2002, 391(3): 1185–1197. doi: 10.1051/0004-6361:20020880 王振占. 海面風場全極化微波輻射測量——原理、系統設計與模擬研究[D]. [博士論文], 中國科學院研究生院(空間科學與應用研究中心), 2005.WANG Zhenzhan. Sea surface wind vector measured by polarimetric microwave radiometer-Principle, system design and simulation study[D]. [Ph.D. dissertation], Graduate School of Chinese Academy of Sciences (Center for Space Science and Applied Research), 2005. 何杰穎. 微波/毫米波大氣溫濕度探測定標與反演的理論和方法研究[D]. [博士論文], 中國科學院研究生院(空間科學與應用研究中心), 2012.HE Jieying. Research on theory and method of microwave and millimeter wave atmospheric temperature and humidity detection calibration and retrieval[D]. [Ph.D. dissertation], Graduate School of Chinese Academy of Sciences (Center for Space Science and Applied Research), 2012. -
