異構云無線接入網架構下面向混合能源供應的動態資源分配及能源管理算法

陳前斌; 譚頎; 魏延南; 賀蘭欽; 唐倫

doi:10.11999/JEIT190499

異構云無線接入網架構下面向混合能源供應的動態資源分配及能源管理算法

doi: 10.11999/JEIT190499 cstr: 32379.14.JEIT190499

1.
重慶郵電大學通信與信息工程學院重慶 400065
2.
重慶郵電大學移動通信技術重點實驗室重慶 400065

基金項目: 國家自然科學基金(6157073)，重慶市教委科學技術研究項目(KJZD-M201800601)

詳細信息

作者簡介:
陳前斌：男，1967年生，教授，博士生導師，研究方向?yàn)閭€(gè)人通信、多媒體信息處理與傳輸、異構蜂窩網絡等

譚頎：女，1995年生，碩士生，研究方向?yàn)?G網絡切片、資源分配、隨機優化理論

魏延南：男，1995年生，碩士生，研究方向?yàn)?G網絡切片、虛擬資源分配、隨機優化理論

賀蘭欽：男，1995年生，碩士生，研究方向?yàn)?G網絡切片，機器學習算法

唐倫：男，1973年生，教授，博士，研究方向?yàn)橄乱淮鸁o(wú)線通信網絡、異構蜂窩網絡、軟件定義無線網絡等

通訊作者:
陳前斌　cqb@cqupt.edu.cn

中圖分類號: TN929.5
計量
- 文章訪問數: 2262
- HTML全文瀏覽量: 890
- PDF下載量: 83
- 被引次數: 0
出版歷程
- 收稿日期: 2019-07-04
- 修回日期: 2020-01-29
- 網絡出版日期: 2020-02-20
- 刊出日期: 2020-06-22

Dynamic Resource Allocation and Energy Management Algorithm for Hybrid Energy Supply in Heterogeneous Cloud Radio Access Networks

1.
School of Communication and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China
2.
Key Laboratory of Mobile Communications Technology, Chongqing University of Posts and Telecommunications, Chongqing 400065, China

Funds: The National Natural Science Foundation of China (61571073), The Science and Technology Research Program of Chongqing Municipal Education Commission (KJZD-M201800601)

摘要

摘要:
針對面向混合能源供應的 5G 異構云無線接入網(H-CRANs)網絡架構下的動態資源分配和能源管理問題，該文提出一種基于深度強化學習的動態網絡資源分配及能源管理算法。首先，由于可再生能源到達的波動性及用戶數據業務到達的隨機性，同時考慮到系統的穩定性、能源的可持續性以及用戶的服務質量(QoS)需求，將H-CRANs網絡下的資源分配以及能源管理問題建立為一個以最大化服務提供商平均凈收益為目標的受限無窮時間馬爾科夫決策過程(CMDP)。然后，使用拉格朗日乘子法將所提CMDP問題轉換為一個非受限的馬爾科夫決策過程(MDP)問題。最后，因?yàn)樾袨榭臻g與狀態空間都是連續值集合，因此該文利用深度強化學習解決上述MDP問題。仿真結果表明，該文所提算法可有效保證用戶QoS及能量可持續性的同時，提升了服務提供商的平均凈收益，降低了能耗。
- 異構云無線接入網 /
- 混合能源 /
- 資源分配 /
- 能源管理 /
- 深度強化學習
Abstract:
Considering the dynamic resource allocation and energy management problem in the 5G Heterogeneous Cloud Radio Access Networks(H-CRANs) architecture for hybrid energy supply, a dynamic network resource allocation and energy management algorithm based on deep reinforcement learning is proposed. Firstly, due to the volatility of renewable energy and the randomness of user data service arrival, taking into account the stability of the system, the sustainability of energy and the Quality of Service(QoS) requirements of users, the resource allocation and energy management issues in the H-CRANs network as a Constrained infinite time Markov Decision Process (CMDP) are modeled with the goal of maximizing the average net profit of service providers. Then, the Lagrange multiplier method is used to transform the proposed CMDP problem into an unconstrained Markov Decision Process (MDP) problem. Finally, because the action space and the state space are both continuous value sets, the deep reinforcement learning is used to solve the above MDP problem. The simulation results show that the proposed algorithm can effectively guarantee the QoS and energy sustainability of the system, while improving the average net income of the service provider and reducing energy consumption.
- Heterogeneous Cloud Radio Access Networks (H-CRANs) /
- Hybrid energy /
- Resource allocation /
- Energy management /
- Deep reinforcement learning

HTML全文

圖 1 混合能源供能的RRHs和電能供能的MBS下行傳輸場景

下載: 全尺寸圖片幻燈片

圖 2 不同評判家學習速率下的平均凈收益

下載: 全尺寸圖片幻燈片

圖 3 每30 min更新1次價格得到的系統凈收益

下載: 全尺寸圖片幻燈片

圖 4 不同量化級數下的平均網絡凈收益對比

下載: 全尺寸圖片幻燈片

圖 5 不同算法下的平均凈收益對比

下載: 全尺寸圖片幻燈片

圖 6 不同用戶數下的系統和速率

下載: 全尺寸圖片幻燈片

圖 7 不同用戶數下系統購買的電能

下載: 全尺寸圖片幻燈片

圖 8 一天內的平均能效與可再生能源到達

下載: 全尺寸圖片幻燈片

表 1 算法流程表

算法1：基于DDPG算法的資源分配與能源管理算法
(1)初始化
隨機初始化參數${\theta ^Q}$和${\theta ^\mu }$；初始化目標網絡參數：${\theta ^{Q'}} \leftarrow {\theta ^Q}$，${\theta ^{\mu '}} \leftarrow {\theta ^\mu }$；初始化拉格朗日乘子${\xi _u} \ge 0,\forall u \in { {{U} }_{\rm{RRH} } },{\upsilon _u} \ge 0,$ 　　　$\forall u \in { {{U} }_{\rm{MBS} } } $；初始化經驗回放池D
(2)學習階段
For episode=1 to M do
初始化一個隨機過程作為行為噪聲${{N}}$，并觀察初始狀態${x_0}$
For t=1 to T do
根據${a_t} = \mu ({x_t}\|\theta _t^\mu ) + {{N}}$選擇一個行為
if 約束C3-C13滿足：
執行行動${a_t}$，并得到回報值${r_{{t}}}$與下一狀態${x_{t + 1}}$
將狀態轉換組$ < {x_t},{a_t},{r_t},{x_{t + 1}} > $存入經驗回放池D
從經驗回放池D中隨機采樣${N_{\rm{D}}}$個樣本，每個樣本用i表示
(a) 更新評判家網絡
從行動者目標網絡得到$\mu '({x_{i + 1}}\|{\theta ^{\mu '}})$
從評判家目標網絡中得到$Q({s_{i + 1}},\mu '({x_{i + 1}}\|{\theta ^{\mu '}})\|{\theta ^{Q'}})$
根據式(20)得到${y_i}$，從評判家網絡得到$Q({x_i},{a_i}\|{\theta ^Q})$
根據式(21)計算損失函數，并根據式(19)更新評判家網絡參數${\theta ^Q}$
(b) 更新行動者網絡
從評判家網絡得到$Q({x_i},{a_i}\|{\theta ^Q})$，并根據式(22)計算策略梯度
根據策略梯度更新行動者網絡參數${\theta ^\mu }$
(c) 更新行動者目標網絡和評判家目標網絡
根據式(23)更新行動者目標網絡和評判家網絡參數
(d)基于標準次梯度法^[15]更新拉格朗日乘子
${\xi _{u,t + 1} } \leftarrow {\left[ { {\xi _{u,t} } - {\alpha _\xi }({Q_{ {\max} } } - { {\bar Q}_u})} \right]^ + },\forall u \in { {{U} }_{ {\rm{RRH} } } }\;\;\;\;\;\;\;\;\;\;(24)$
${\nu _{u,t + 1} } \leftarrow {\left[ { {\nu _{u,t} } - {\alpha _\nu }({Q_{ {\max} } } - { {\bar Q}_u})} \right]^ + },\forall u \in { {{U} }_{ {\rm{MBS} } } }\;\;\;\;\;\;\;\;\;\;(25)$
End for
End for

下載: 導出CSV

表 2 仿真參數

仿真參數	值	仿真參數	值
RRH最大發射功率	3 W	數據包大小$L$	4 kbit/packet
MBS最大發射功率	10 W	MUEs路徑損耗模型	31.5+35lg(d) (d[km])
熱噪聲功率譜密度	–102 dBm/Hz	RUEs路徑損耗模型	31.5+40lg(d) (d[km])
子載波個數$N$	12	折扣因子$\gamma $	0.99
單個資源塊帶寬	180 kHz	${r_{{{{\varGamma}} _1}}}$	4 Mbps
軟更新因子$\varsigma $	0.01	${r_{{{{\varGamma}} _2}}}$	4.5 Mbps
時隙長度$\tau $	10 ms	${r_{{\rm{MBS}}}}$	512 kbps

下載: 導出CSV

參考文獻(17)

彭木根, 艾元. 異構云無線接入網絡: 原理、架構、技術和挑戰[J]. 電信科學, 2015, 31(5): 41–45.

PENG Mugen and AI Yuan. Heterogeneous cloud radio access networks: Principle, architecture, techniques and challenges[J]. Telecommunications Science, 2015, 31(5): 41–45.

ALNOMAN A, CARVALHO G H S, ANPALAGAN A, et al. Energy efficiency on fully cloudified mobile networks: Survey, challenges, and open issues[J]. IEEE Communications Surveys & Tutorials, 2018, 20(2): 1271–1291. doi: 10.1109/COMST.2017.2780238

AKTAR M R, JAHID A, AL-HASAN M, et al. User association for efficient utilization of green energy in cloud radio access network[C]. 2019 International Conference on Electrical, Computer and Communication Engineering, Cox’sBazar, Bangladesh, 2019: 1–5. doi: 10.1109/ECACE.2019.8679128.

ALQERM I and SHIHADA B. Sophisticated online learning scheme for green resource allocation in 5G heterogeneous cloud radio access networks[J]. IEEE Transactions on Mobile Computing, 2018, 17(10): 2423–2437. doi: 10.1109/TMC.2018.2797166

LIU Qiang, HAN Tao, ANSARI N, et al. On designing energy-efficient heterogeneous cloud radio access networks[J]. IEEE Transactions on Green Communications and Networking, 2018, 2(3): 721–734. doi: 10.1109/TGCN.2018.2835451

吳曉民. 能量捕獲驅動的異構網絡資源調度與優化研究[D]. [博士論文], 中國科學技術大學, 2016.

WU Xiaomin. Resources optimization and control in the energy harvesting heterogeneous network[D]. [Ph.D. dissertation], University of Science and Technology of China, 2016.

ZHANG Deyu, CHEN Zhigang, CAI L X, et al. Resource allocation for green cloud radio access networks with hybrid energy supplies[J]. IEEE Transactions on Vehicular Technology, 2018, 67(2): 1684–1697. doi: 10.1109/TVT.2017.2754273

孔巧. 混合能源供能的異構蜂窩網絡中能源成本最小化問題的研究[D]. [碩士論文], 華中科技大學, 2016.

KONG Qiao. Research on energy cost minimization problem in heterogeneous cellular networks with hybrid energy supplies[D]. [Master dissertation], Huazhong University of Science and Technology, 2016.

YANG Jian, YANG Qinghai, SHEN Zhong, et al. Suboptimal online resource allocation in hybrid energy supplied OFDMA cellular networks[J]. IEEE Communications Letters, 2016, 20(8): 1639–1642. doi: 10.1109/LCOMM.2016.2575834

WEI Yifei, YU F R, SONG Mei, et al. User scheduling and resource allocation in HetNets with hybrid energy supply: An actor-critic reinforcement learning approach[J]. IEEE Transactions on Wireless Communications, 2018, 17(1): 680–692. doi: 10.1109/TWC.2017.2769644

PENG Mugen, ZHANG Kecheng, JIANG Jiamo, et al. Energy-efficient resource assignment and power allocation in heterogeneous cloud radio access networks[J]. IEEE Transactions on Vehicular Technology, 2015, 64(11): 5275–5287. doi: 10.1109/TVT.2014.2379922

陳前斌, 楊友超, 周鈺, 等. 基于隨機學習的接入網服務功能鏈部署算法[J]. 電子與信息學報, 2019, 41(2): 417–423. doi: 10.11999/JEIT180310

CHEN Qianbin, YANG Youchao, ZHOU Yu, et al. Deployment algorithm of service function chain of access network based on stochastic learning[J]. Journal of Electronics &Information Technology, 2019, 41(2): 417–423. doi: 10.11999/JEIT180310

深度強化學習-DDPG算法原理和實現[EB/OL]. https://www.jianshu.com/p/6fe18d0d8822, 2018.

齊岳, 黃碩華. 基于深度強化學習DDPG算法的投資組合管理[J]. 計算機與現代化, 2018(5): 93–99. doi: 10.3969/j.issn.1006-2475.2018.05.019

QI Yue and HUANG Shuohua. Portfolio management based on DDPG algorithm of deep reinforcement learning[J]. Computer and Modernization, 2018(5): 93–99. doi: 10.3969/j.issn.1006-2475.2018.05.019

California ISO[EB/OL]. http://www.caiso.com, 2019.

WANG Xin, ZHANG Yu, CHEN Tianyi, et al. Dynamic energy management for smart-grid-powered coordinated multipoint systems[J]. IEEE Journal on Selected Areas in Communications, 2016, 34(5): 1348–1359. doi: 10.1109/JSAC.2016.2520220

LI Jian, PENG Mugen, YU Yuling, et al. Energy-efficient joint congestion control and resource optimization in heterogeneous cloud radio access networks[J]. IEEE Transactions on Vehicular Technology, 2016, 65(12): 9873–9887. doi: 10.1109/TVT.2016.2531184
