基于深度學習的絕緣子定向識別算法

李彩林,  張青華,  陳文賀,  江曉斌,  袁斌,  楊長磊

李彩林, 張青華, 陳文賀, 江曉斌, 袁斌, 楊長磊. 基于深度學習的絕緣子定向識別算法[J]. 電子與信息學報, 2020, 42(4): 1033-1040. doi: 10.11999/JEIT190350
引用本文: 李彩林, 張青華, 陳文賀, 江曉斌, 袁斌, 楊長磊. 基于深度學習的絕緣子定向識別算法[J]. 電子與信息學報, 2020, 42(4): 1033-1040. doi: 10.11999/JEIT190350
Cailin LI, Qinghua ZHANG, Wenhe CHEN, Xiaobin JIANG, Bin YUAN, Changlei YANG. Insulator Orientation Detection Based on Deep Learning[J]. Journal of Electronics & Information Technology, 2020, 42(4): 1033-1040. doi: 10.11999/JEIT190350
Citation: Cailin LI, Qinghua ZHANG, Wenhe CHEN, Xiaobin JIANG, Bin YUAN, Changlei YANG. Insulator Orientation Detection Based on Deep Learning[J]. Journal of Electronics & Information Technology, 2020, 42(4): 1033-1040. doi: 10.11999/JEIT190350

基于深度學習的絕緣子定向識別算法

doi: 10.11999/JEIT190350 cstr: 32379.14.JEIT190350

  • 山東理工大學建筑工程學院 淄博 255000

基金項目: 國家自然科學基金(41601496, 41701525)，山東省重點研發計劃(2018GGX106002)，山東省自然科學基金(ZR2017LD002)，山東理工大學齊文化研究專項(2017QWH032)
詳細信息
    作者簡介:

    李彩林：男，1985年生，副教授，研究方向為數字攝影測量與計算機視覺

    張青華：男，1992年生，碩士，研究方向為深度學習目標檢測、計算機視覺

    陳文賀：男，1992年生，碩士，研究方向為深度學習目標識別

    江曉斌：男，1994年生，碩士，研究方向為點云3維重建

    袁斌：女，1995年生，碩士，研究方向為傾斜攝影測量

    楊長磊：男，1995年生，碩士，研究方向為深度學習在農業遙感中的應用

    通訊作者:

    張青華　zhangqinghuamail@163.com

  • 中圖分類號: TP391.4

Insulator Orientation Detection Based on Deep Learning

  • Shandong University of Technology, Zibo 255000, China

Funds: The National Naturals Science Foundation of China (41601496, 41701525), The Shandong Key R&D Program (2018GGX106002), The Shandong Natural Science Foundation (ZR2017LD002), The Qi Culture Research Project of Shandong University of Technology (2017QWH032)
  • 摘要:

    為了解決絕緣子目標檢測中無法精確定位的問題，該文基于深度學習提出一種絕緣子定向識別算法，通過在軸對齊檢測框中加入角度信息，可有效解決常規深度學習算法無法精確定位目標的問題。該算法首先將角度旋轉參數引入軸對齊矩形檢測框中構成定向檢測框，然后將該參數偏移量作為第5參數加入到損失函數中進行迭代回歸，同時為提高檢測精度在訓練過程中使用Adam算法替代隨機梯度下降(SGD)算法進行損失函數優化，最終可獲得絕緣子定向檢測模型。實驗分析表明，加入旋轉角度的定向檢測框可有效對絕緣子目標進行精確定位。

    Abstract:

    In order to solve the problem of inaccurate location in insulator target detection, this paper proposes an insulator orientation recognition algorithm based on deep learning. By adding angle information to the axis alignment detection frame, it can effectively solve the problem that conventional deep learning algorithm can not accurately locate the target. First, the angular rotation parameters are introduced into the axially aligned rectangular detection frame to form a directional detection frame. Then the parameter offset is added as the fifth parameter to the loss function for iterative regression. At the same time, in order to improve the detection accuracy, Adam algorithm is used to replace Stochastic Gradient Descent (SGD) to optimize the loss function. Finally, the insulator directional detection model can be obtained. The experimental results show that the orientation detection frame with rotation angle can effectively locate the insulator target accurately.
