利用信號重構的全球?qū)Ш叫l(wèi)星系統欺騙干擾抑制方法

盧丹,  白天霖

盧丹, 白天霖. 利用信號重構的全球?qū)Ш叫l(wèi)星系統欺騙干擾抑制方法[J]. 電子與信息學報, 2020, 42(5): 1268-1273. doi: 10.11999/JEIT190321
引用本文: 盧丹, 白天霖. 利用信號重構的全球?qū)Ш叫l(wèi)星系統欺騙干擾抑制方法[J]. 電子與信息學報, 2020, 42(5): 1268-1273. doi: 10.11999/JEIT190321
Dan LU, Tianlin BAI. Global Navigation Satellite System Spoofing Mitigation Method by Utilizing Signal Reconstruction[J]. Journal of Electronics & Information Technology, 2020, 42(5): 1268-1273. doi: 10.11999/JEIT190321
Citation: Dan LU, Tianlin BAI. Global Navigation Satellite System Spoofing Mitigation Method by Utilizing Signal Reconstruction[J]. Journal of Electronics & Information Technology, 2020, 42(5): 1268-1273. doi: 10.11999/JEIT190321

利用信號重構的全球?qū)Ш叫l(wèi)星系統欺騙干擾抑制方法

doi: 10.11999/JEIT190321 cstr: 32379.14.JEIT190321

  • 中國民航大學天津市智能信號與圖像處理重點實驗室 天津 300300

詳細信息
    作者簡介:

    盧丹：女，1978年生，副教授，主要研究方向?yàn)樾l(wèi)星導航抗干擾、陣列信號處理

    白天霖：男，1993年生，碩士生，研究方向?yàn)樾l(wèi)星導航抗干擾

    通訊作者:

    盧丹　dlu@cauc.edu.cn

  • 中圖分類號: TN967.1

Global Navigation Satellite System Spoofing Mitigation Method by Utilizing Signal Reconstruction

  • Tianjin Key Laboratory for Advanced Signal Processing, Civil Aviation University of China, Tianjin 300300, China

  • 摘要:

    欺騙式干擾通過發射與真實衛星信號相似的信號誤導接收機產生錯誤的定位結果，具有極大的危害。該文針對轉發式欺騙干擾，提出一種基于信號重構的單天線欺騙干擾抑制方法。該方法首先通過參數估計方法估計出欺騙信號載波頻率和碼相位，然后構建欺騙信號子空間正交投影矩陣以抑制干擾。仿真實驗結果表明該方法對欺騙干擾具有良好的抑制效果，能夠保障接收機在干擾環境中實現有效定位，并具有較低的運算復雜度。

    Abstract:

    Spoofing misleads the receiver to generate the wrong position information by trans-mitting signals similar to authentic satellite signals, which has great harm. In this paper, a single-antenna spoofing mitigation algorithm based on signal reconstruction is proposed for meaconing. Firstly, the carrier frequency and code phase of spoofing signal are obtained by parameter estimation method, and then the orthogonal projection matrix of spoofing signal subspace is constructed to suppress spoofing. The simulation results show that the algorithm has a good suppression effect on spoofing and ensure the receiver can locate effectively in the interference environment, and the algorithm also has lower computational complexity.

    • HTML全文

  • 圖  1  欺騙干擾抑制算法流程圖

    圖  2  $\mu ,\Delta f$以及度$L$的關系曲線圖

    圖  3  PRN1的捕獲結果

    圖  4  真實衛星信號定位結果

    圖  5  欺騙干擾抑制前后定位結果

    表  1  仿真參數

    星號中頻(MHz)采樣率(MHz)信噪比(dB)干噪比
    1 2 3 6 14 20 22 251.4055.714–20–15
    下載: 導出CSV

    表  2  兩種算法計算量比較

    乘法次數加法次數FFT計算次數時間復雜度
    文獻算法7QP+4Q2QP+3Q2QPO(QP)
    本文算法6QM+4M3QM+7MQ(M+1)+1O(QM)
    下載: 導出CSV

    表  3  算法計算時間隨衛星個數變化表

    衛星數量456789101112
    文獻算法2.5072.5442.5672.5972.6412.6422.6892.6982.733
    本文算法0.2350.2680.2930.3130.3360.3550.3800.4020.421
    下載: 導出CSV
  • 吳仁彪, 王文益, 盧丹, 等. 衛星導航自適應抗干擾技術[M]. 北京: 科學出版社, 2015: 1–22.

    WU Renbiao, WANG Wenyi, LU Dan, et al. Adaptive Interference Mitigation in GNSS[M]. Beijing: Science Press, 2015: 1–22.
    JAFARNIA JAHROMI A. GNSS signal authenticity verification in the presence of structural interference[D]. [Ph.D. dissertation], University of Calgary, 2013: 18-51.
    WESSON K D, GROSS J N, HUMPHREYS T E, et al. GNSS signal authentication via power and distortion monitoring[J]. IEEE Transactions on Aerospace and Electronic Systems, 2018, 54(2): 739–754. doi: 10.1109/TAES.2017.2765258
    PSIAKI M L, O’HANLON B W, POWELL S P, et al. GNSS spoofing detection using two-antenna differential carrier phase[C]. The 27th International Technical Meeting of the Satellite Division of the Institute of Navigation, Tampa, USA, 2014: 2776–2800.
    BROUMANDAN A, JAFARNIA-JAHROMI A, DANESHMAND S, et al. Overview of spatial processing approaches for GNSS structural interference detection and mitigation[J]. Proceedings of the IEEE, 2016, 104(6): 1246–1257. doi: 10.1109/JPROC.2016.2529600
    HU Yanfeng, BIAN Shaofeng, CAO Kejin, et al. GNSS spoofing detection based on new signal quality assessment model[J]. GPS Solutions, 2018, 22(1): No. 28. doi: 10.1007/s10291-017-0693-7
    SUN Chao, CHEONG J W, DEMPSTER A G, et al. Moving variance-based signal quality monitoring method for spoofing detection[J]. GPS Solutions, 2018, 22(3): No. 83. doi: 10.1007/s10291-018-0745-7
    WESSON K D, SHEPARD D P, BHATTI J A, et al. An evaluation of the vestigial signal defense for civil GPS anti-spoofing[C]. The 24th International Technical Meeting of the Satellite Division of The Institute of Navigation, Portland, USA, 2011: 2646–2656.
    HUMPHREYS T E, LEDVINA B M, PSIAKI M L, et al. Assessing the spoofing threat: Development of a portable GPS civilian spoofer[C]. The 21st International Technical Meeting of the Satellite Division of The Institute of Navigation, Savanna, Georgia, 2008: 2314-2325.
    PSIAKI M L and HUMPHREYS T E. GNSS spoofing and detection[J]. Proceedings of the IEEE, 2016, 104(6): 1258–1270. doi: 10.1109/JPROC.2016.2526658
    MAGIERA J and KATULSKI R. Applicability of null-steering for spoofing mitigation in civilian GPS[C]. 2014 The 79th IEEE Vehicular Technology Conference, Seoul, South Korea, 2014: 1-5. doi: 10.1109/VTCSpring.2014.7022835.
    DANESHMAND S, JAFARNIA-JAHROMI A, BROUMANDAN A, et al. A low-complexity GPS anti-spoofing method using a multi-antenna array[C]. The 25th International Technical Meeting of the Satellite Division of the Institute of Navigation, Nashville, USA, 2012: 1233–1243.
    PSIAKI M L, HUMPHREYS T E, and STAUFFER B. Attackers can spoof navigation signals without our knowledge. Here’s how to fight back GPS lies[J]. IEEE Spectrum, 2016, 53(8): 26–53. doi: 10.1109/MSPEC.2016.7524168
    HAN Shuai, CHEN Lei, MENG Weixiao, et al. Improve the security of GNSS receivers through spoofing mitigation[J]. IEEE Access, 2017, 5: 21057–21069. doi: 10.1109/access.2017.2754414
    SCHARF L L and FRIEDLANDER B. Matched subspace detectors[J]. IEEE Transactions on Signal Processing, 1994, 42(8): 2146–2157. doi: 10.1109/78.301849
    崔建華, 程乃平, 倪淑燕. 陣列天線抑制欺騙式導航干擾信號方法研究[J]. 電子學報, 2018, 46(2): 365–371. doi: 10.3969/j.issn.0372-2112.2018.02.015

    CUI Jianhua, CHENG Naiping, and NI Shuyan. Research on spoofing suppressing method using antenna array for navigation signal[J]. Acta Electronica Sinica, 2018, 46(2): 365–371. doi: 10.3969/j.issn.0372-2112.2018.02.015
    LI Jian and WU Renbiao. An efficient algorithm for time delay estimation[J]. IEEE Transactions on Signal Processing, 1998, 46(8): 2231–2235. doi: 10.1109/78.705444
    LI Jie, WU Renbiao, WANG Wenyi, et al. A novel GPS signal acquisition algorithm[J]. Advances in Information Sciences & Service Sciences, 2012, 4(17): 597–604.
