車聯網中一種基于軟件定義網絡與移動邊緣計算的卸載策略
doi: 10.11999/JEIT190304 cstr: 32379.14.JEIT190304
-
1.
重慶郵電大學通信與信息工程學院 重慶 400065
-
2.
武漢大學電子信息學院 武漢 430000
An Offloading Mechanism Based on Software Defined Network and Mobile Edge Computing in Vehicular Networks
-
1.
School of Communication and Information Engineering, Chongqing University of Posts andTelecommunications, Chongqing 400065, China
-
2.
School of Electronic Information, Wuhan University, Wuhan 430000, China
-
摘要:
在新興的車聯網絡中，汽車終端請求卸載的任務對網絡帶寬、卸載時延等有著更加嚴苛的需求，而新型通信網絡研究中移動邊緣計算(MEC)的提出更好地解決了這一挑戰。該文著重解決的是汽車終端進行任務卸載時卸載對象的匹配問題。文中引入了軟件定義車載網絡(SDN-V)對全局變量統一調度，實現了資源控制管理、設備信息采集以及任務信息分析?；谟脩羧蝿?wù)的差異化性質，定義了重要度的模型，在此基礎上，通過設計任務卸載優先級機制算法，實現任務優先級劃分。針對多目標優化模型，采用乘子法對非凸優化模型進行求解。仿真結果表明，與其他卸載策略相比，該文所提卸載機制對時延和能耗優化效果明顯，能夠最大程度地保證用戶的效益。
-
關鍵詞:
- 車聯網 /
- 軟件定義網絡 /
- 移動邊緣計算 /
- 卸載機制
Abstract:In the emerging vehicular networks, the task of the car terminal requesting offloading has more stringent requirements for network bandwidth and offload delay, and the proposed Mobile Edge Computing (MEC) in the new communication network research solves better this challenge. This paper focuses on matching the offloaded objects when the car terminal performs the task offloading. By introducing the Software-Defined in-Vehicle Network (SDN-V) to schedule uniformly global variables, which realizes resource control management, device information collection and task information analysis. Based on the differentiated nature of user tasks, a model of importance is defined. On this basis, task priority is divided by designing the task to offload the priority mechanism. For the multi-objective optimization model, the non-convex optimization model is solved by the multiplier method. The simulation results show that compared with other offloading strategies, the proposed offloading mechanism has obvious effects on delay and energy consumption optimization, which can guarantee the benefit of users to the greatest extent.
-
表 1 任務卸載優先級機制
(1) 輸入：車輛$i$的請求信息為$\{ {C_i},{S_i},t_{{Q_i}}^{\max }\} $，定義$\zeta $的取值，$i \in \{ 1\; 2\; ··· \; n\} $, ${\rm{Im}}{{\rm{p}}_{\rm{i}}}{\rm{ = \{ im}}{{\rm{p}}_{\rm{1}}}{\kern 1pt} {\kern 1pt} {\rm{im}}{{\rm{p}}_{\rm{2}}}\; ···\; {\rm{im}}{{\rm{p}}_{{n}}}\; {\rm{\} }}$ (2) 輸出：降序排列的重要度${\rm{im}}{{\rm{p}}_i}$ (3) for $i = 1;i < n;i + + $ (4) 將${C_i},t_{{Q_i}}^{\max }$代入式(9)求出${\rm{im}}{{\rm{p}}_i}$ (5) ${\rm{Im}}{{\rm{p}}_{\rm{i}}}={\rm{\{ im}}{{\rm{p}}_{\rm{1}}}{\kern 1pt} {\kern 1pt} {\rm{im}}{{\rm{p}}_{\rm{2}}}{\kern 1pt} {\kern 1pt} ···\; {\rm{im}}{{\rm{p}}_{{i}}}{\rm{\} }}$ (6) for $i = 1:n$ do (7) if ${{{\rm Imp}(i) < {\rm Imp}(i + 1)}}$; ${{\rm temp} = {\rm Imp}(i + 1)}$; ${{{\rm Imp}(i + 1) = {\rm Imp}(i)}}{\kern 1pt} {\kern 1pt} {\kern 1pt} ;{{{\rm Imp}(i) = {\rm temp}}}$ (8) end
下載: 導出CSV
表 2 基于Q-學習的任務卸載策略機制
(1) 輸入：車輛$i$的請求信息$\{ {Q_i},{T_i}\} $, ${\tau _{\rm{1}}},{\tau _2},({\rm{0 < }}{\tau _{\rm{1}}} < {\tau _{\rm{2}}})$, $i \in \{ 1\; 2\; ··· \; n\} $, ${\rm{Im}}{{\rm{p}}_{{i}}}{\rm{ = \{ im}}{{\rm{p}}_{\rm{1}}}{\kern 1pt} {\kern 1pt} {\rm{im}}{{\rm{p}}_{\rm{2}}}\; ···\; {\rm{im}}{{\rm{p}}_{{i}}}{\rm{\} }}$ (2) 輸出：${x_i}$, ${\psi _i}$ (3) if ${\rm{im}}{{\rm{p}}_i} < {\tau _{\rm{1}}}$：${x_i}=0$；${\kern 1pt} {\kern 1pt} {\rm{im}}{{\rm{p}}_i} > {\tau _2}$：${x_i}{\rm{ = 1}}$ (4) elif ${\tau _{\rm{1}}} < {\rm{im}}{{\rm{p}}_i} < {\tau _{\rm{2}}}$：初始化$g$, ${x_{ij}} = 1$, $\varsigma $, $p$, $\hat Q\left( {{a_i}} \right) = 0,\; {\kern 1pt} t = 0$最大收斂時間${t_{c - \max }}$ (5) while ${\kern 1pt} t < {t_{c - \max }} + 1$：按照時延約束對車輛用戶排序 (6) for $i = 1:N\; {\kern 1pt} {\kern 1pt} $ do (7) 根據貪婪方法選擇行為${a_i}$、根據式(15)求出用戶獎勵 (8) 更新$\hat { Q}$數值矩陣通過${\hat Q_{t + 1}}\left( {s,a} \right) \leftarrow \left( {1 - \varsigma } \right){\hat Q_t}\left( {s,a} \right) + \varsigma \left( {g + \eta \mathop {\max }\limits_{a'} {{\hat Q}_t}\left( {s',a'} \right)} \right)$, $p \leftarrow \left( {p/\sqrt t } \right)$ (9) end for；$t = t + 1$；end while (10) 利用${\psi _i}$更新目標優化式(7) (11) end
下載: 導出CSV
表 3 模擬參數表
參數 數值 計算任務${Q_i}$ 1～50 MB 傳輸帶寬$W$ 100 MHz 汽車用戶發射功率${p_i}$ 0.2 W 任務所需CPU周期數${C_i}$ 0.1～1 GHz MEC服務器CPU周期頻率${f_{\rm b}}$ 6 GHz 車輛用戶的CPU周期頻率${f_v}$ 0.5～1 GHz 高斯噪聲${\sigma ^2}$ –100 dBm 信道傳輸距離${d_{mn}}$ 5～500 m 汽車CPU能耗功率系數${p_{{v} } }$ 80 W/GHz 電池最大容量 20 kWh
下載: 導出CSV
-
程剛, 郭達. 車聯網現狀與發展研究[J]. 移動通信, 2011, 35(17): 23–26. doi: 10.3969/j.issn.1006-1010.2011.17.004CHENG Gang, and GUO Da. Research on the status and development of internet of vehicles[J]. Mobile Communications, 2011, 35(17): 23–26. doi: 10.3969/j.issn.1006-1010.2011.17.004 齊彥麗, 周一青, 劉玲, 等. 融合移動邊緣計算的未來5G移動通信網絡[J]. 計算機研究與發展, 2018, 55(3): 478–486. doi: 10.7544/issn1000-1239.2018.20170801QI Yanli, ZHOU Yiqing, LIU Ling, et al. MEC coordinated future 5G mobile wireless networks[J]. Journal of Computer Research and Development, 2018, 55(3): 478–486. doi: 10.7544/issn1000-1239.2018.20170801 LI Yong, JIN Depeng, HUI Pan, et al. Optimal base station scheduling for device-to-device communication underlaying cellular networks[J]. IEEE Journal on Selected Areas in Communications, 2015, 34(1): 27–40. doi: 10.1109/JSAC.2015.2452415 AMEMIYA K, AKIYAMA Y, KOBAYASHI K, et al. On-site evaluation of a software cellular based MEC system with downlink slicing technology[C]. The 7th IEEE International Conference on Cloud Networking, Tokyo, Japan, 2018: 1–7. doi: 10.1109/CloudNet.2018.8549380. WANG Hansong, LI Xi, JI Hong, et al. Dynamic offloading scheduling scheme for MEC-enabled vehicular networks[C]. 2018 IEEE/CIC International Conference on Communications in China, Beijing, China, 2018: 206–210. doi: 10.1109/ICCChinaW.2018.8674508. YU Rong, DING Jiefei, HUANG Xumin, et al. Optimal resource sharing in 5G-enabled vehicular networks: A matrix game approach[J]. IEEE Transactions on Vehicular Technology, 2016, 65(10): 7844–7856. doi: 10.1109/tvt.2016.2536441 鮑楠, 左加闊, 胡晗, 等. 基于SDN的網絡資源選擇多目標優化算法[J]. 通信學報, 2019, 40(2): 51–59. doi: 10.11959/j.issn.1000?436x.2019031BAO Nan, ZUO Jiakuo, HU Han, et al. SDN based network resource selection multi-objective optimization algorithm[J]. Journal on Communications, 2019, 40(2): 51–59. doi: 10.11959/j.issn.1000?436x.2019031 CHEN Min and HAO Yixue. Task offloading for mobile edge computing in software defined ultra-dense network[J]. IEEE Journal on Selected Areas in Communications, 2018, 36(3): 587–597. doi: 10.1109/JSAC.2018.2815360 ZHANG Ke, MAO Yuming, LENG Supeng, et al. Optimal delay constrained offloading for vehicular edge computing networks[C]. 2017 IEEE International Conference on Communications, Paris, France, 2017: 1–6. doi: 10.1109/ICC.2017.7997360. HU Bo, CHEN Jianye, and LI fengcun. Dynamic service allocation algorithm in mobile edge computing[C]. 2017 International Conference on Information and Communication Technology Convergence, Jeju, South Korea, 2017: 104–109. doi: 10.1109/ICTC.2017.8190951. LI Baozhu, ZHAO Xuhui, HAN Shiyuan, et al. New SDN-based architecture for integrated vehicular cloud computing networking[C]. 2018 International Conference on Selected Topics in Mobile and Wireless Networking, Tangier, Morocco, 2018: 1–4. doi: 10.1109/MoWNet.2018.8428935. HUANG Xumin, YU Rong, KANG Jiawen, et al. Distributed reputation management for secure and efficient vehicular edge computing and networks[J]. IEEE Access, 2017, 5: 25408–25420. doi: 10.1109/ACCESS.2017.2769878 TRAN T X and POMPILI D. Joint task offloading and resource allocation for multi-server mobile-edge computing networks[J]. IEEE Transactions on Vehicular Technology, 2019, 68(1): 856–868. doi: 10.1109/TVT.2018.2881191 JAIN R and PAUL S. Network virtualization and software defined networking for cloud computing: A survey[J]. IEEE Communications Magazine, 2013, 51(11): 24–31. doi: 10.1109/MCOM.2013.6658648 WILHELMI F, BELLALTA B, CANO C, et al. Implications of decentralized Q-learning resource allocation in wireless networks[C]. The 28th IEEE Annual International Symposium on Personal, Indoor, and Mobile Radio Communications, Montreal, Canada, 2017: 1–5. doi: 10.1109/PIMRC.2017.8292321. -
