短參考多用戶差分混沌移位鍵控通信系統性能分析

賀利芳; 陳俊; 張?zhí)祢U

doi:10.11999/JEIT190117

短參考多用戶差分混沌移位鍵控通信系統性能分析

doi: 10.11999/JEIT190117 cstr: 32379.14.JEIT190117

重慶郵電大學通信與信息工程學院重慶 400065

基金項目: 國家自然科學基金(61771085, 61371164)，信號與信息處理重慶市市級重點實驗室建設項目(CSTC2009CA2003)，重慶市教育委員會科研項目(KJ1600429)

詳細信息

作者簡介:
賀利芳：女，1979年生，碩士，副教授，研究方向?yàn)榛煦绫Ｃ芡ㄐ?，微弱信?hào)檢測

陳俊：男，1993年生，碩士生，研究方向?yàn)榛煦绫Ｃ芡ㄐ?/p>
張?zhí)祢U：男，1971年生，博士后，教授，研究方向?yàn)閿U(kuò)頻信號的盲處理、語音信號處理、神經網絡實現以及信號的同步處理

通訊作者:
陳俊　945916163@qq.com

中圖分類號: TN911.3
計量
- 文章訪問數: 1961
- HTML全文瀏覽量: 800
- PDF下載量: 76
- 被引次數: 0
出版歷程
- 收稿日期: 2019-02-27
- 修回日期: 2020-01-08
- 網絡出版日期: 2020-07-02
- 刊出日期: 2020-08-18

Performance Analysis of Short Reference Multi-User Differential Chaos Shift Keying Communication System

School of Communication and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China

Funds: The National Natural Science Foundation of China (61771085, 61371164), The Project of Key Laboratory of Signal and Information Processing of Chongqing (CSTC2009CA2003), The Research Project of Chongqing Educational Commission (KJ1600429)

摘要

摘要:
短參考差分混沌移位鍵控(SR-DCSK)系統主要的缺陷是數據傳輸速率較低。為此，該文提出一種短參考多用戶差分混沌移位鍵控(SR-MUDCSK) 通信方案。利用Walsh碼的正交性傳輸多個用戶的信息，有效提高了數據傳輸速率。在AWGN和多徑Rayleigh衰落信道環境下，對其誤碼性能進行了理論分析，并進行了實驗仿真。結果表明：該系統在傳輸速率方面有較大提升，且能量效率也得到了顯著改善，因此其具有重要應用價值。
- 短參考多用戶差分混沌移位鍵控通信系統 /
- 短參考差分混沌移位鍵控 /
- Walsh碼 /
- 傳輸速率 /
- 誤碼率
Abstract:
The major drawback of Short Reference Differential Chaos Shift Keying (SR-DCSK) system is the low data transmission rate. To solve the problem, a Short Reference Multi-User Differential Chaos Shift Keying (SR-MUDCSK) communication scheme is proposed. The orthogonality of Walsh code is used to transmit the information of multiple users, which effectively improves the data transmission rate. The theoretical Bit Error Rate (BER) performance is analyzed, and experimental simulation is carried out under AWGN and multipath Rayleigh fading channel environment, respectively. The results show that the system has a significant improvement in transmission rate, and the energy efficiency is also significantly improved. Therefore, it is of great value in application.

HTML全文

圖 1 SR-DCSK系統框圖

下載: 全尺寸圖片幻燈片

圖 2 SR-MUDCSK系統框圖

下載: 全尺寸圖片幻燈片

圖 3 兩徑Rayleigh衰落信道模型

下載: 全尺寸圖片幻燈片

圖 4 $R$取值不同時，系統誤碼率的實驗值和理論值隨信噪比變化的曲線

下載: 全尺寸圖片幻燈片

圖 5 用戶數$N$不同時，系統誤碼率隨信噪比變化的曲線

下載: 全尺寸圖片幻燈片

圖 6 信噪比${{{E_{\rm b}}} / {{N_0}}}$不同時，系統誤碼率隨用戶數$N$變化的曲線

下載: 全尺寸圖片幻燈片

圖 7 用戶數$N$為2, 4時，SR-MUDCSK系統與SRMR-DCSK系統誤碼率的對比曲線

下載: 全尺寸圖片幻燈片

圖 8 SR-MUDCSK系統在兩種情況下誤碼率的實驗值和理論值能隨E_b/N₀變化的曲線

下載: 全尺寸圖片幻燈片

圖 9 SR-MUDCSK系統與SRMR-DCSK系統在兩種情況下誤碼率的對比曲線

下載: 全尺寸圖片幻燈片

表 1 幾種系統的能量效率和數據傳輸速率

系統名稱	能量效率(${E_\eta }$)	傳輸速率(${R_{\rm{B}}}$)
DCSK	${1 / 2}$	${1 / {2\beta }}$
SR-DCSK	${P / {(1 + P)}}$	${1 / {(R + PR)}}$
SR-MUDCSK	${{PN} / {(1 + PN)}}$	${N / {(R + PR)}}$

下載: 導出CSV
