一種基于短合成孔徑的雙星干涉精確定位方法

孫光才; 王裕旗; 高昭昭; 江帆; 邢孟道; 保錚

doi:10.11999/JEIT180940

一種基于短合成孔徑的雙星干涉精確定位方法

doi: 10.11999/JEIT180940 cstr: 32379.14.JEIT180940

1.
西安電子科技大學雷達信號處理國家重點實驗室西安 710071
2.
電子信息控制重點實驗室成都 610036

基金項目: 電子信息控制重點實驗室基金(20170105)

詳細信息

作者簡介:
孫光才：男，1984年生，博士，副教授，研究方向為合成孔徑雷達成像和動目標檢測

王裕旗：男，1994年生，博士生，研究方向為合成孔徑雷達成像

高昭昭：男，1982年生，博士，高級工程師，研究方向為雷達信號處理和毫米波無源成像探測

江帆：女，1988年生，博士，高級工程師，研究方向為陣列信號處理與微波光子

邢孟道：男，1975年生，博士，教授，研究方向為雷達成像和目標檢測與識別

保錚：男，1927年生，中國科學院院士，研究方向為雷達系統與雷達信號處理、動目標檢測、陣列信號處理、空時自適應信號處理等

通訊作者:
孫光才　rsandsgc@126.com

中圖分類號: TN958
計量
- 文章訪問數: 2910
- HTML全文瀏覽量: 945
- PDF下載量: 101
- 被引次數: 0
出版歷程
- 收稿日期: 2018-10-09
- 修回日期: 2019-07-18
- 網絡出版日期: 2019-09-17
- 刊出日期: 2020-02-19

A Dual Satellite Interferometric Precise Localization Method Based on Short Synthetic Aperture

1.
National Laboratary of Radar Signal Processing, Xidian University, Xi’an 710071, China
2.
Science and Technology on Electronic Information Control Laboratory, Chengdu 610036, China

Funds: The Foundation of Science and Technology on Electronic Information Control Laboratory (20170105)

摘要

摘要:
雙星TDOA/FDOA聯合定位通過時差曲面和頻差曲面進行定位，定位的精度受時差/頻差測量精度的影響。針對精確測量時差/頻差的需求，該文提出一種基于短合成孔徑的雙星干涉測量時差/頻差的方法，利用一定長度的合成孔徑提高測量精度。對于窄帶信號，該方法有估計單星多普勒頻率的能力，通過兩顆衛星單獨估計的結果得到頻差；對于寬帶信號，通過雙星數據干涉可以獲得頻差的高精度估計。對于短期穩定的雷達信號，STK仿真數據的處理結果證實了該方法在大范圍內可以實現1 km的定位精度。
- 雙星定位 /
- 短合成孔徑 /
- 雙星干涉 /
- 到達時差 /
- 到達頻差
Abstract:
Dual satellite TDOA/FDOA localization is achieved by the TDOA hyperboloid and FDOA hyperboloid. The accuracy of localization is affected by TDOA/FDOA accuracy. In order to measure accurately the TDOA/FDOA, a method of TDOA/FDOA measurement based on short synthetic aperture is presented. This method improves the measurement accuracy by using a certain length of synthetic aperture. For narrowband signals, the method has the ability to estimate a single satellite Doppler frequency, and the frequency difference can be obtained from the results estimated by the two satellites. For wideband signals, high-precision estimates of frequency differences can be obtained by dual satellite data interference. For short-term stable radar signals, the processing results of STK simulation data confirm the effectiveness of the proposed method.
- Dual-satellite localization /
- Short synthetic aperture /
- Dual-satellite interferometry /
- TDOA /
- FDOA

HTML全文

圖 1 雙星信號模型

下載: 全尺寸圖片幻燈片

圖 2 頻差測量算法流程

下載: 全尺寸圖片幻燈片

圖 3 雙星定位模型

下載: 全尺寸圖片幻燈片

圖 4 有噪聲的情況下干涉的相位圖

下載: 全尺寸圖片幻燈片

圖 5 某個脈沖距離向剖面圖

下載: 全尺寸圖片幻燈片

圖 6 LFM信號頻差均方誤差值隨信噪比變化

下載: 全尺寸圖片幻燈片

圖 7 單頻信號頻差均方誤差值隨信噪比變化

下載: 全尺寸圖片幻燈片

圖 8 時差均值隨信噪比的變化

下載: 全尺寸圖片幻燈片

圖 9 雙星時差頻差定位的GDOP (km)

下載: 全尺寸圖片幻燈片

表 1 STK仿真數據處理結果

載頻(GHz)	脈寬(μs)	脈沖重復周期(μs)	帶寬(MHz)	基頻測量結果(Hz)	基頻測量誤差(Hz)	相對誤差(Hz)
1.59	10	100	10	–4781.5	33.9742	2.16
1.59	10	100	10	1710.5	31.8189	2.16
1.78	10	100	10	–1120.3	40.6852	4.20
1.78	10	100	10	2486.2	36.4891	4.20

下載: 導出CSV

表 2 時差頻差定位結果

載頻(GHz)	脈寬(μs)	脈沖重復周期(μs)	帶寬(MHz)	目標真實位置	目標測量位置	相對誤差
1.59	10	100	10	(6303534, –92215, 968286)	(6303532, –92876, 968234)	662
1.59	10	100	10	(6348796, –27959, 610439)	(6348797, –27448, 610446)	510
1.78	10	100	10	(6339522, –16218, 700588)	(6339520, –16829, 700590)	611
1.78	10	100	10	(6374947, 30978, 199294)	(6374945, 30530, 199409)	462

下載: 導出CSV

表 3 常規方法定位結果

目標真實位置	目標測量位置	相對誤差
(6303534, –92215, 968286)	(6303808, –91936, 970069)	1825
(6348796, –27959, 610439)	(6348976, –28173, 612353)	1935
(6339522, –16218, 700588)	(6339615, –16496, 701470)	930
(6374947, 30978, 199294)	(6374905, 30788, 198028)	1280

下載: 導出CSV

參考文獻(23)

陳濤, 王夢馨, 黃湘松. 基于樽海鞘群算法的無源時差定位[J]. 電子與信息學報, 2018, 40(7): 1591–1597. doi: 10.11999/JEIT170979

CHEN Tao, WANG Mengxin, and HUANG Xiangsong. Time difference of arrival passive location based on salp swarm algorithm[J]. Journal of Electronics &Information Technology, 2018, 40(7): 1591–1597. doi: 10.11999/JEIT170979

BAMLER R and JUST D. Phase statistics and decorrelation in SAR interferograms[C]. The IGARSS '93- IEEE International Geoscience and Remote Sensing Symposium, Tokyo, Japan, 1993: 980–984. doi: 10.1109/IGARSS.1993.322637.

KIM Y H, KIM D G, HAN J W, et al. Analysis of sensor-emitter geometry for emitter localisation using TDOA and FDOA measurements[J]. IET Radar, Sonar & Navigation, 2017, 11(2): 341–349. doi: 10.1049/iet-rsn.2016.0314

張磊, 陳艷玲, 陳俊平. SAR回波信號及InSAR干涉相位的統計特性研究[J]. 天文學進展, 2007, 25(2): 169–176. doi: 10.3969/j.issn.1000-8349.2007.02.006

ZHANG Lei, CHEN Yanling, and CHEN Junping. The statistic characteristics of SAR signals and interferometric phases[J]. Progress in Astronomy, 2007, 25(2): 169–176. doi: 10.3969/j.issn.1000-8349.2007.02.006

CAO H, CHAN Y T, and SO H C. Maximum likelihood TDOA estimation from compressed sensing samples without reconstruction[J]. IEEE Signal Processing Letters, 2017, 24(5): 564–568. doi: 10.1109/LSP.2017.2684185

PEPE A and MASTRO P. On the use of directional statistics for the adaptive spatial multi-looking of sequences of differential SAR interferograms[C]. 2017 IEEE International Geoscience and Remote Sensing Symposium, Fort Worth, USA, 2017: 3791–3794. doi: 10.1109/IGARSS.2017.8127825.

XU Huaping, CHEN Wei, LIU Wei, et al. Phase statistics for strong scatterers in SAR interferograms[J]. IEEE Geoscience and Remote Sensing Letters, 2014, 11(11): 1966–1970. doi: 10.1109/LGRS.2014.2315611

NOROOZI A, OVEIS A H, HOSSEINI S M R, et al. Improved algebraic solution for source localization from TDOA and FDOA measurements[J]. IEEE Wireless Communications Letters, 2018, 7(3): 352–355. doi: 10.1109/LWC.2017.2777995

QU Xiaomei, XIE Lihua, and TAN Wenrong. Iterative constrained weighted least squares source localization using TDOA and FDOA measurements[J]. IEEE Transactions on Signal Processing, 2017, 65(15): 3990–4003. doi: 10.1109/TSP.2017.2703667

馮明月, 何明浩, 徐璟, 等. 低信噪比條件下寬帶欠定信號高精度DOA估計[J]. 電子與信息學報, 2017, 39(6): 1340–1347. doi: 10.11999/JEIT160921

FENG Mingyue, HE Minghao, XU Jing, et al. High accuracy DOA estimation under low SNR condition for wideband underdetermined signals[J]. Journal of Electronics &Information Technology, 2017, 39(6): 1340–1347. doi: 10.11999/JEIT160921

劉倩, 夏斌, 彭榮群, 等. 基于包絡提取的TOA估計算法[J]. 山東大學學報: 工學版, 2012, 42(5): 24–29. doi: 10.6040/j.issn.1672-3961.2012.05.005

LIU Qian, XIA Bin, PENG Rongqun, et al. A TOA estimation algorithm based on envelope extraction[J]. Journal of Shandong University:Engineering Science, 2012, 42(5): 24–29. doi: 10.6040/j.issn.1672-3961.2012.05.005

王方秋, 張小飛, 汪飛. IR-UWB系統中基于root-MUSIC算法的TOA和DOA聯合估計[J]. 通信學報, 2014, 35(2): 137–145. doi: 10.3969/j.issn.1000-436x.2014.02.018

WANG Fangqiu, ZHANG Xiaofei, and WANG Fei. Root-MUSIC-based joint TOA and DOA estimation in IR-UWB[J]. Journal on Communications, 2014, 35(2): 137–145. doi: 10.3969/j.issn.1000-436x.2014.02.018

劉德樹. 空間譜估計及其應用[M]. 合肥: 中國科學技術大學出版社, 1997.

孫超, 王世練, 朱江. 基于自相關算法的TOA估計方法研究[J]. 微處理機, 2014, 35(4): 39–43. doi: 10.3969/j.issn.1002-2279.2014.04.013

SUN Chao, WANG Shilian, and ZHU Jiang. Research of TOA estimation based on auto -correlation algorithm[J]. Microprocessors, 2014, 35(4): 39–43. doi: 10.3969/j.issn.1002-2279.2014.04.013

楊小鳳, 陳鐵軍, 劉峰. 基于TOA-DOA聯合估計的無線定位新方法[J]. 數據采集與處理, 2014, 29(6): 1036–1040. doi: 10.16337/j.1004-9037.2014.06.024

YANG Xiaofeng, CHEN Tiejun, and LIU Feng. Novel wireless positioning method based on joint TOA-DOA estimation[J]. Journal of Data Acquisition and Processing, 2014, 29(6): 1036–1040. doi: 10.16337/j.1004-9037.2014.06.024

YEREDOR A and ANGEL E. Joint TDOA and FDOA estimation: A conditional bound and its use for optimally weighted localization[J]. IEEE Transactions on Signal Processing, 2011, 59(4): 1612–1623. doi: 10.1109/TSP.2010.2103069

張桀, 沈重. 聯合TDOA改進算法和卡爾曼濾波的UWB室內定位研究[J]. 現代電子技術, 2016, 39(13): 1–5. doi: 10.16652/j.issn.1004-373x.2016.13.001

ZHANG Jie and SHEN Chong. Research on UWB indoor positioning in combination with TDOA improved algorithm and Kalman filtering[J]. Modern Electronics Technique, 2016, 39(13): 1–5. doi: 10.16652/j.issn.1004-373x.2016.13.001

林雪原, 何友, 史佩. 利用二星TDOA和FDOA測量及輔助高度信息對地面目標的定位算法及精度分析[J]. 空間科學學報, 2006, 26(4): 277–281. doi: 10.3969/j.issn.0254-6124.2006.04.006

LIN Xueyuan, HE You, and SHI Pei. Location algorithm and error analysis for earth object using TDOA, FDOA by dual-satellite and aided height information[J]. Chinese Journal of Space Science, 2006, 26(4): 277–281. doi: 10.3969/j.issn.0254-6124.2006.04.006

盧鑫. 無源定位多普勒頻差測量方法研究[C]. 江蘇省電子學會2010年學術年會論文集, 南京, 2010: 96-99.

LU Xin. Research on accurate FDOA measurement of radar coherent pulses in passive location[C]. 2010 Annual Conference of Jiangsu Institute of Electronics, Nanjing, China, 2010: 96-99.

STEIN S. Algorithms for ambiguity function processing[J]. IEEE Transactions on Acoustics, Speech, and Signal Processing, 1981, 29(3): 588–599. doi: 10.1109/TASSP.1981.1163621

呂宏春, 盧曉春, 武建鋒. 星間鏈路體制下的星地雙向時間同步方法[J]. 宇航學報, 2017, 38(7): 728–734. doi: 10.3873/j.issn.1000-1328.2017.07.008

LV Hongchun, LU Xiaochun, WU Jianfeng. A method of two-way satellite-ground time synchronization under inter-satellite links system[J]. Journal of Astronautics, 2017, 38(7): 728–734. doi: 10.3873/j.issn.1000-1328.2017.07.008

郭福成, 樊昀. 雙星時差頻差聯合定位方法及其誤差分析[J]. 宇航學報, 2008, 29(4): 1381–1386. doi: 10.3873/j.issn.1000-1328.2008.04.053

GUO Fucheng and FAN Yun. A method of dual-satellites geolocation using TDOA and FDOA and its precision analysis[J]. Journal of Astronautics, 2008, 29(4): 1381–1386. doi: 10.3873/j.issn.1000-1328.2008.04.053

馬淑歌. 脈沖信號TOA估計方法研究[D]. [碩士論文], 哈爾濱工業大學, 2017.

MA Shuge. Research on pulse signal TOA estimation method[D]. [Master dissertation], Harbin Institute of Technology, 2017.
