虛擬化云無線接入網絡下基于在線學習的網絡切片虛擬資源分配算法

唐倫; 魏延南; 馬潤琳; 賀小雨; 陳前斌

doi:10.11999/JEIT180771

虛擬化云無線接入網絡下基于在線學習的網絡切片虛擬資源分配算法

doi: 10.11999/JEIT180771 cstr: 32379.14.JEIT180771

1.
重慶郵電大學通信與信息工程學院? ?重慶? ?400065
2.
重慶郵電大學移動通信技術重點實驗室? ?重慶? ?400065

基金項目: 國家自然科學基金(61571073)，重慶市教委科學技術研究項目(KJZD-M201800601)

詳細信息

作者簡介:
唐倫：男，1973年生，教授，主要研究方向為下一代無線通信網絡、異構蜂窩網絡、軟件定義無線網絡等

魏延南：男，1995年生，碩士生，研究方向為5G網絡切片、虛擬資源分配、隨機優化理論

馬潤琳：女，1993年生，碩士生，研究方向為5G網絡切片、網絡功能虛擬化、無線資源分配

賀小雨：女，1995年生，碩士生，研究方向為5G網絡切片、無線網絡虛擬化、智能優化理論

陳前斌：男，1967年生，教授，博士生導師，主要研究方向為個人通信、多媒體信息處理與傳輸、異構蜂窩網絡等

通訊作者:
魏延南　weiyannan_cqupt@163.com

中圖分類號: TN929.5
計量
- 文章訪問數: 3035
- HTML全文瀏覽量: 1223
- PDF下載量: 145
- 被引次數: 0
出版歷程
- 收稿日期: 2018-08-03
- 修回日期: 2019-02-20
- 網絡出版日期: 2019-03-19
- 刊出日期: 2019-07-01

Online Learning-based Virtual Resource Allocation for Network Slicing in Virtualized Cloud Radio Access Network

1.
School of Communication and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China
2.
Key Laboratory of Mobile Communication Technology, Chongqing University of Posts and Telecommunications, Chongqing 400065, China

Funds: The National Natural Science Foundation of China (61571073), The Science and Technology Research Program of Chongqing Municipal Education Commission (KJZD-M201800601)

摘要

摘要: 針對現有研究中缺乏云無線接入網絡(C-RAN)場景下對網絡切片高效的動態資源分配方案的問題，該文提出一種虛擬化C-RAN網絡下的網絡切片虛擬資源分配算法。首先基于受限馬爾可夫決策過程(CMDP)理論建立了一個虛擬化C-RAN場景下的隨機優化模型，該模型以最大化平均切片和速率為目標，同時受限于各切片平均時延約束以及網絡平均回傳鏈路帶寬消耗約束。其次，為了克服CMDP優化問題中難以準確掌握系統狀態轉移概率的問題，引入決策后狀態(PDS)的概念，將其作為一種“中間狀態”描述系統在已知動態發生后，但在未知動態發生前所處的狀態，其包含了所有與系統狀態轉移有關的已知信息。最后，提出一種基于在線學習的網絡切片虛擬資源分配算法，其在每個離散的資源調度時隙內會根據當前系統狀態為每個網絡切片分配合適的資源塊數量以及緩存資源。仿真結果表明，該算法能有效地滿足各切片的服務質量(QoS)需求，降低網絡回傳鏈路帶寬消耗的壓力并同時提升系統吞吐量。
- 5G網絡切片 /
- 云無線接入網絡 /
- 資源分配 /
- 馬爾可夫決策過程
Abstract: To solve the problem of lacking efficient and dynamic resource allocation schemes for 5G Network Slicing (NS) in Cloud Radio Access Network (C-RAN) scenario in the existing researches, a virtual resource allocation algorithm for NS in virtualized C-RAN is proposed. Firstly, a stochastic optimization model in virtualized C-RAN network is established based on the Constrained Markov Decision Process (CMDP) theory, which maximizes the average sum rates of all slices as its objective, and is subject to the average delay constraint for each slice as well as the average network backhaul link bandwidth consumption constraint in the meantime. Secondly, in order to overcome the issue of having difficulties in acquiring the accurate transition probabilities of the system states in the proposed CMDP optimization problem, the concept of Post-Decision State (PDS) as an " intermediate state” is introduced, which is used to describe the state of the system after the known dynamics, but before the unknown dynamics occur, and it incorporates all of the known information about the system state transition. Finally, an online learning based virtual resource allocation algorithm is presented for NS in virtualized C-RAN, where in each discrete resource scheduling slot, it will allocate appropriate Resource Blocks (RBs) and caching resource for each network slice according to the observed current system state. The simulation results reveal that the proposed algorithm can effectively satisfy the Quality of Service (QoS) demand of each individual network slice, reduce the pressure of backhaul link on bandwidth consumption and improve the system throughput.
- 5G Network Slicing (NS) /
- Cloud Radio Access Network (C-RAN) /
- Resource allocation /
- Markov Decision Process (MDP)

HTML全文

圖 1 虛擬化C-RAN網絡系統場景

下載: 全尺寸圖片幻燈片

圖 2 不同平均時延約束下的平均切片和速率

下載: 全尺寸圖片幻燈片

圖 3 不同平均時延約束下的平均切片總時延

下載: 全尺寸圖片幻燈片

圖 4 不同數據包到達率${\lambda _1}$下的平均切片和速率

下載: 全尺寸圖片幻燈片

圖 5 不同數據包到達率${\lambda _1}$下的平均切片總時延

下載: 全尺寸圖片幻燈片

表 1 虛擬化C-RAN網絡下基于在線學習的網絡切片虛擬資源分配算法

　輸入　系統狀態空間$C$，動作空間$A$，拉格朗日回報函數
$g({c_t}, {\text{π}} ({c_t}))$，有限信道狀態集合${\text{H}}$。

　初始化：初始化決策后狀態的狀態值函數${\tilde V_0}(\tilde c) \in R, \forall \tilde c \in C\,$，令
$t \leftarrow 0$, ${c_t} \leftarrow c \in C\,$。

　學習階段：
　　(1) 求解
${a_t} = \mathop {\arg \min }\limits_{a \in A} \left\{ {g({c_t}, a) + \gamma {{\tilde V}_t}({S^{M, a}}({c_t}, a))} \right\}$； (27)

　　(2) 觀察PDS狀態${\tilde c_t}$和下一時隙狀態${c_{t + 1}}$：${\tilde c_t} = {S^{M, a}}({c_t}, {a_t})$,
${c_{t + 1}} = {S^{M, W}}({\tilde c_t}, {{\text{A}}_t}, {{\text{H}}_{t + 1}})$；

　　(3) 計算${c_{t + 1}}$的狀態值函數：
　　　${V_t}({c_{t + 1}}) = \mathop {\min }\limits_{a \in A} \left\{ {g({c_{t + 1}}, a) + \gamma {{\tilde V}_t}({S^{M, a}}({c_{t + 1}}, a))} \right\}$； (28)

　　(4) 更新${\tilde V_{t + 1}}({\tilde c_t})$：

　　　${\tilde V_{t + 1}}({\tilde c_t}) = (1 - {\alpha _t}){\tilde V_t}({\tilde c_t}) + {\alpha _t}{V_t}({c_{t + 1}})$；　　　　 (29)

　　(5) 利用隨機次梯度法更新拉格朗日乘子${\text{β}} :{\beta _i} \ge 0$。

　輸出　最優策略${\text{π}} _{{\rm{PDS}}}^ * $。

下載: 導出CSV

表 2 仿真參數

仿真參數	值
遠端射頻頭(RRH)最大發射功率	20 dBm
各切片最大隊列長度${Q_{s, \max }}$	20 packets
噪聲功率譜密度	–174 dBm/Hz
數據包大小$L$	4 kbit/packet
路徑損耗模型	104.5+20lg(d) (d[km])
時隙長度$\tau $	1 ms

下載: 導出CSV

參考文獻(11)

HOSSAIN E and HASAN M. 5G cellular: Key enabling technologies and research challenges[J]. IEEE Instrumentation & Measurement Magazine, 2015, 18(3): 11–21. doi: 10.1109/MIM.2015.7108393

CHECKO A, CHRISTIANSEN H L, YAN Ying, et al. Cloud RAN for mobile networks-A technology overview[J]. IEEE Communications Surveys & Tutorials, 2015, 17(1): 405–426. doi: 10.1109/COMST.2014.2355255

NIU Binglai, ZHOU Yong, SHAH-MANSOURI H, et al. A dynamic resource sharing mechanism for cloud radio access networks[J]. IEEE Transactions on Wireless Communications, 2016, 15(12): 8325–8338. doi: 10.1109/TWC.2016.2613896

KALIL M, Al-DWEIK A, SHARKH M F A, et al. A framework for joint wireless network virtualization and cloud radio access networks for next generation wireless networks[J]. IEEE Access, 2017, 5: 20814–20827. doi: 10.1109/ACCESS.2017.2746666

BERTSEKAS D and GALLAGER R. Data Networks[M]. Englewood Cliffs: Prentice-Hall, 1991, 152–162.

YANG Jian, ZHANG Shuben, WU Xiaomin, et al. Online learning-based server provisioning for electricity cost reduction in data center[J]. IEEE Transactions on Control Systems Technology, 2017, 25(3): 1044–1051. doi: 10.1109/TCST.2016.2575801

KALIL M, SHAMI A, and YE Yinghua. Wireless resources virtualization in LTE systems[C]. Proceedings of 2014 IEEE Conference on Computer Communications Workshops, Toronto, Canada, 2014: 363–368. doi: 10.1109/INFCOMW.2014.6849259.

POWELL W B. Approximate Dynamic Programming: Solving the Curses of Dimensionality[M]. Hoboken, USA: Wiley, 2011, 289–388.

LAKSHMINARAYANAN C and BHATNAGAR S. Approximate dynamic programming with (min, +) linear function approximation for Markov decision processes[J]. arXiv preprint arXiv: 1403.4179, 2014.

LI Rongpeng, ZHAO Zhifeng, CHEN Xianfu, et al. TACT: A transfer actor-critic learning framework for energy saving in cellular radio access networks[J]. IEEE Transactions on Wireless Communications, 2014, 13(4): 2000–2011. doi: 10.1109/TWC.2014.022014.130840

HE Xiaoming, WANG Kun, HUANG Huawei, et al. Green resource allocation based on deep reinforcement learning in content-centric IoT[J]. IEEE Transactions on Emerging Topics in Computing, 2019. doi: 10.1109/TETC.2018.2805718
