一種新型衛星導航信號波形畸變特性評估新方法

賀成艷; 盧曉春; 郭際

doi:10.11999/JEIT180656

一種新型衛星導航信號波形畸變特性評估新方法

doi: 10.11999/JEIT180656 cstr: 32379.14.JEIT180656

賀成艷^{1, 2, ,},
盧曉春^{2, 3},
郭際^{1, 2, 3}

1.
地理信息工程國家重點實驗室 ??西安 ??710054
2.
中國科學院國家授時中心 ??西安 ??710600
3.
中國科學院大學天文與空間科學學院 ??北京 ??101408

基金項目: 國家自然科學基金青年基金(61501430)，地理信息工程國家重點實驗室開放基金(SKLGIE2017-M-2-2)

詳細信息

作者簡介:
賀成艷：女，1986年生，副研究員，碩士生導師，研究方向為衛星導航信號接收處理、信號質量評估等

盧曉春：女，1970年生，研究員，研究方向為衛星導航定位系統設計和建設

郭際：男，1955年生，研究員，研究方向為天文測時、數據誤差分析、導航系統建設等

通訊作者:
賀成艷　hechengyan@ntsc.ac.cn

中圖分類號: TN911.6
計量
- 文章訪問數: 2719
- HTML全文瀏覽量: 1162
- PDF下載量: 113
- 被引次數: 0
出版歷程
- 收稿日期: 2018-07-04
- 修回日期: 2019-01-10
- 網絡出版日期: 2019-01-22
- 刊出日期: 2019-05-01

Evil Waveform Evaluating Method for New GNSS Signals

Chengyan HE^{1, 2
, ,},
Xiaochun LU^{2, 3},
Ji GUO^{1, 2, 3}

1.
State Key Laboratory of Geo-information Engineering, Xi’an 710054, China
2.
National Time Service Center, Chinese Academy of Sciences, Xi’an 710600, China
3.
School of Astronomy and Space Science, University of Chinese Academy of Sciences, Beijing 101408, China

Funds: The National Nature Science Foundation of China (61501430), The State Key Laboratory of Geo-information Engineering Open Foundation (SKLGIE2017-M-2-2)

摘要

摘要:
全球衛星導航系統(GNSS)導航信號的波形特性將會影響導航信號質量，而信號質量優劣則直接決定了整個GNSS的服務性能極限。傳統的波形畸變評估方法主要針對傳統相移鍵控(PSK)調制信號的波形幅度和寬度開展研究，而忽視了波形不對稱對跟蹤誤差和測距誤差帶來的影響。該文在國際民航組織(ICAO)所采用的傳統測距碼波形分析模型TMA/TMB/TMC基礎上，給出了適用于各種新型二進制偏置載波(BOC)調制的波形畸變分析擴展模型。接著提出能夠精細分析波形上升下降沿對稱特性(WRaFES)分析模型，并從時域波形、相關函數、S曲線過零點偏差3個方面，深入仿真分析了WRaFES模型的性能特點。最后，以北斗試驗衛星M1-S B1Cd信號為例，給出了基于WRaFES模型及相關曲線特性的實測分析結果。研究表明：該方法能夠精確分析導航信號波形不對稱性及對用戶帶來的影響，研究成果可為新型衛星導航信號評估提供一種新方法和新思路，同時還可為GNSS用戶接收機相關器間隔參數的合理選取提供建議和技術支撐。
- 全球衛星導航系統 /
- 衛星導航信號 /
- 波形畸變 /
- 波形不對稱性
Abstract:
The waveform characteristics of the navigation signals of Global Navigation Satellite Systems (GNSSs) will be of vital importance for signal quality, which plays an imperative and direct role in achieving high performance of GNSS services. These traditional methods for evaluating evil waveforms mainly deal with the amplitude and width of simple modulated signals such as Phase Shift Keying (PSK) signals. However, no research is done on the influences of waveform asymmetry on tracking errors and ranging errors. Based on the traditional thread models, such as Thread Model A (TMA), Thread Model B (TMB) and Thread Model C (TMC), adopted by International Civil Aviation Organization (ICAO), this paper provides a new extended general thread model suitable for new Binary Offset Carrier (BOC) modulated signals. Then a new evil waveform analysis method, Waveform Rising and Falling Edge Symmetry (WRaFES) Method, is proposed. The effects of WRaFES model are analyzed in detail in terms of time domain, correlation peak and S curve bias. Finally, by taking the B1Cd signal of the first modernized BeiDou navigation satellite System (BDS) experimental satellite named M1-S as an example, tested results of WRaFES model and correlation curves are shown in detail. Results show that the proposed methods could be able to analyze the asymmetry of signal deformation and its impact on ranging performance with high accuracy. The research brings about a new reference for new satellite navigation signal evaluation and signal system optimized design. In addition, it can provide valuable suggestions and technical supports for GNSS users to choose reasonable receivers’ correlator spacing.
- Global Navigation Satellite System /
- Satellite navigation signal /
- Evil waveform /
- Waveform asymmetry

HTML全文

圖 1 WRaFES波形不對稱分析

下載: 全尺寸圖片幻燈片

圖 2 BOC(1, 1)數字畸變功率譜：$\varDelta = 0.06{T_c}$

下載: 全尺寸圖片幻燈片

圖 3 WRaFES波形不對稱分析

下載: 全尺寸圖片幻燈片

圖 4 BOC (1, 1) SQM相關器輸出

下載: 全尺寸圖片幻燈片

圖 5 碼片上升下降沿不對稱帶來的SCB影響分析

下載: 全尺寸圖片幻燈片

圖 6 分離后的BDS M1-S B1Cd基帶信號波形

下載: 全尺寸圖片幻燈片

表 1 WRaFES參數列表

$\Delta \Delta $測試參數	對稱性面積比參數：
$M1 = \frac{{({W_{ - 0.50}} - {W_{0.50}}) - ({W_{ - 0.47}} - {W_{0.47}})}}{{{W_0}}}$$M2 = \frac{{({W_{ - 0.53}} - {W_{0.53}}) - ({W_{ - 0.50}} - {W_{0.50}})}}{{{W_0}}}$	$M24 = 20 \times \lg \left[ {\displaystyle\frac{{\displaystyle\int_{t = - 0.60{T_{\rm c}}}^{t = - 0.40{T_{\rm c}}} {s(t){\rm dt}} }}{{\displaystyle\int_{t = 0.40{T_{\rm c}}}^{t = 0.60{T_{\rm c}}} {s(t){\rm dt}} }}} \right]$
對稱性評價參數：	非對稱性評價參數：
$M3 = \displaystyle\frac{{({W_{ - 0.40}} - {W_{0.40}})}}{{{W_0}}}$ $M4 = \displaystyle\frac{{({W_{ - 0.43}} - {W_{0.43}})}}{{{W_0}}}$ $M5 = \displaystyle\frac{{({W_{ - 0.47}} - {W_{0.47}})}}{{{W_0}}}$ $M6 = \displaystyle\frac{{({W_{ - 0.50}} - {W_{0.50}})}}{{{W_0}}}$ $M7 = \displaystyle\frac{{({W_{ - 0.53}} - {W_{0.53}})}}{{{W_0}}}$ $M8 = \displaystyle\frac{{({W_{ - 0.57}} - {W_{0.57}})}}{{{W_0}}}$ $M9 = \displaystyle\frac{{({W_{ - 0.60}} - {W_{0.60}})}}{{{W_0}}}$	$M10 = \displaystyle\frac{{{W_{ - 0.40}}}}{{{W_0}}}$ $M11 = \displaystyle\frac{{{W_{0.40}}}}{{{W_0}}}$ $M12 = \displaystyle\frac{{{W_{ - 0.43}}}}{{{W_0}}}$ $M13 = \displaystyle\frac{{{W_{0.43}}}}{{{W_0}}}$ $M14 = \displaystyle\frac{{{W_{ - 0.47}}}}{{{W_0}}}$ $M15 = \displaystyle\frac{{{W_{0.47}}}}{{{W_0}}}$ $M16 = \displaystyle\frac{{{W_{-0.50}}}}{{{W_0}}}$ $M17 = \displaystyle\frac{{{W_{0.50}}}}{{{W_0}}}$ $M18 = \displaystyle\frac{{{W_{-0.53}}}}{{{W_0}}}$ $M19 = \displaystyle\frac{{{W_{0.53}}}}{{{W_0}}}$ $M20 = \displaystyle\frac{{{W_{-0.57}}}}{{{W_0}}}$ $M21 = \displaystyle\frac{{{W_{0.57}}}}{{{W_0}}}$ $M22 = \displaystyle\frac{{{W_{-0.60}}}}{{{W_0}}}$ $M23 = \displaystyle\frac{{{W_{0.60}}}}{{{W_0}}}$

下載: 導出CSV

表 2 相關特性參數均值和方差

參數	${P_1}$	${P_2}$	${P_3}$	${P_4}$	${P_5}$	${P_6}$	${P_7}$
均值	0	0	0	0	0	0	0.85
方差	$\frac{{0.6}}{{2T\,(C/{N_0})}}$	$\frac{{2.4}}{{2T\,(C/{N_0})}}$	$\frac{{0.6}}{{2T\,(C/{N_0})}}$	$\frac{{1.2}}{{2T\,(C/{N_0})}}$	$\frac{{2.0}}{{2T\,(C/{N_0})}}$	$\frac{{2.0}}{{2T\,(C/{N_0})}}$	$\frac{{2.775}}{{2T\,(C/{N_0})}}$

參數	${P_8}$	${P_9}$	${P_{10}}$	${P_{11}}$	${P_{12}}$	${P_{13}}$	${P_{14}}$
均值	0.85	0.70	0.70	–0.50	–0.50	0	0
方差	$\frac{{2.775}}{{2T\,(C/{N_0})}}$	$\frac{{0.51}}{{2T\,(C/{N_0})}}$	$\frac{{0.51}}{{2T\,(C/{N_0})}}$	$\frac{{0.75}}{{2T\,(C/{N_0})}}$	$\frac{{0.75}}{{2T\,(C/{N_0})}}$	$\frac{{1.0}}{{2T\,(C/{N_0})}}$	$\frac{{1.0}}{{2T\,(C/{N_0})}}$

下載: 導出CSV

表 3 BDS M1-S B1CdWRaFES 參數統計結果

參數	M1	M2	M5	M6	M7	M24	M14	M15	M16	M17	M18	M19
均值	0.0132	0.0149	0.0118	0.0014	0.0162	0.0091	0.5775	0.5893	0.0010	0.0003	0.5766	0.5928
標準差	0.1233	0.1396	0.1568	0.1292	0.1708	1.6188	0.0942	0.1359	0.0896	0.0942	0.1223	0.1571

參數	M3	M4	M8	M9	M10	M11	M12	M13	M20	M21	M22	M23
均值	0.0008	0.0110	0.0339	0.0247	1.0391	1.0383	0.9369	0.9481	0.9321	0.9659	1.0425	1.0673
標準差	0.2455	0.1999	0.2571	0.3510	0.1557	0.2294	0.1089	0.1809	0.1941	0.2557	0.2759	0.3286

下載: 導出CSV

表 4 BDS M1-S B1Cd實測相關特性參數統計結果

參數	P₁	P₂	P₃	P₄	P₅	P₆	P₇
均值	0.0148	–0.0002	–0.0022	0.0114	0.0099	–0.0048	0.8663
標準差	0.0352	0.0488	0.0369	0.0369	0.0526	0.0745	0.0076

參數	P₈	P₉	P₁₀	P₁₁	P₁₂	P₁₃	P₁₄
均值	0.8698	0.7160	0.7060	–0.5013	–0.5099	0.0151	0.0211
標準差	0.0079	0.0121	0.0136	0.0593	0.0636	0.0576	0.0728

下載: 導出CSV

參考文獻(8)

陳昌川, 周楊, 張?zhí)祢U. TDDM-BOC信號組合碼序列及信息序列盲估計[J]. 電子與信息學報, 2016, 38(11): 2760–2766. doi: 10.11999/JEIT160042

CHEN Changchuan, ZHOU Yang, and ZHANG Tianqi. Blind estimation of the combination code sequence and information sequence for TDDM-BOC signal[J]. Journal of Electronics &Information Technology, 2016, 38(11): 2760–2766. doi: 10.11999/JEIT160042

EDGAR C, CZOPEK F, and BARKER L B. A cooperative anomaly resolution on PRN-19[C]. Proceedings of 1999 Institute of Navigation GPS, Nashville, Tennessee, USA, 1999: 2269–2271.

賀成艷, 郭際, 盧曉春, 等. GNSS導航信號常見畸變產生機理及對測距性能影響分析[J]. 系統工程與電子技術, 2015, 37(7): 1611–1620. doi: 10.3969/j.issn.1001-506X.2015.07.22

HE Chengyan, GUO Ji, LU Xiaochun, et al. Generation mechanisms of GNSS navigation signal distortions and influence on ranging performance[J]. Systems Engineering and Electronics, 2015, 37(7): 1611–1620. doi: 10.3969/j.issn.1001-506X.2015.07.22

PHELTS R E. Multicorrelator techniques for robust mitigation of threats to GPS signal quality[D]. [Ph.D. dissertation], Stanford University, 2001: 1–345.

FONTANELLA D, PAONNI M, and EISSFELLER B. A novel evil waveforms threat model for new generation GNSS signals: theoretical analysis and performance[C]. Proceedings of the 20105th ESA Workshop on Satellite Navigation Technologies and European Workshop on GNSS Signals and Signal Processing, Noordwijk, Netherlands, 2010: 1–8. doi: 10.1109/NAVITEC.2010.5708037.

MISRA P and ENGE P. Global Positioning System: Signals, Measurements, and Performance[M]. 2nd ed. Lincoln, MA, Ganga-Jamuna Press, 2006: 1125–1134.

JAHROMI A J, BROUMANDAN A, DANESHMAND S, et al. Galileo signal authenticity verification using signal quality monitoring methods[C]. Proceedings of 2016 International Conference on Localization and GNSS, Barcelona, Spain, 2016: 1–8. doi: 10.1109/ICL-GNSS.2016.7533684.

賀成艷. GNSS空間信號質量評估方法研究及測距性能影響分析[D]. [博士論文], 中國科學院大學, 2013: 1–205.

HE Chengyan. Research on evaluation methods of GNSS signal quality and the influence of GNSS signal on ranging performance[D]. [Ph.D. dissertation], University of Chinese Academy of Sciences, 2013: 1–205.
