一種自適應的太赫茲無線個域網高效定向MAC協議

任智; 呂昱輝; 徐兆坤; 鄒明芮; 田潔麗

doi:10.11999/JEIT180306

一種自適應的太赫茲無線個域網高效定向MAC協議

doi: 10.11999/JEIT180306 cstr: 32379.14.JEIT180306

1.
重慶郵電大學移動通信技術重慶市重點實驗室 ??重慶　400065
2.
中國工程物理研究院激光聚變研究中心 ??成都　610000

基金項目: 國家自然科學基金(61379159)，重慶市基礎與前沿研究計劃項目(cstc2015jcyjBX0085)

詳細信息

作者簡介:
任智：男，1971年生，教授，博士生導師，研究方向?yàn)樘掌潫o線個域網和機會網絡

呂昱輝：男，1993年生，碩士生，研究方向?yàn)樘掌潫o線個域網定向MAC協議

徐兆坤：男，1993年生，碩士生，研究方向?yàn)樘掌潫o線個域網定向并行MAC協議

鄒明芮：女，1986年生，助理研究員，博士，研究方向?yàn)樘掌潫o線網絡MAC層協議

田潔麗：女，1992年生，碩士生，研究方向?yàn)樘掌潫o線個域網跨PAN數據傳輸

通訊作者:
呂昱輝　lvyuhui_cqupt@126.com

中圖分類號: TP393.04
計量
- 文章訪問數: 1568
- HTML全文瀏覽量: 665
- PDF下載量: 79
- 被引次數: 0
出版歷程
- 收稿日期: 2018-04-02
- 修回日期: 2018-08-16
- 網絡出版日期: 2018-09-12
- 刊出日期: 2019-01-01

An Adaptive Directional MAC Protocol for Terahertz Wireless Personal Networks

1.
Chongqing Key Laboratory of Mobile Communication Technology, Chongqing University of Post & Telecommunications, Chongqing 400065, China
2.
Research Center of Laser Fusion, Chinese Academy of Engineering Physics, Chengdu 610000, China

Funds: The National Natural Science Foundation of China (61379159), The Chongqing Basic and Frontier Research Project (cstc2015jcyjBX0085)

摘要

摘要:
針對現有太赫茲無線個域網定向MAC協議存在的波束訓練開銷和入網時延偏大以及Beacon, S-CAP時段時隙利用不足問題，該文提出一種自適應的定向MAC協議——AD-MAC，自適應地在靜態場景下采用全網協同波束訓練，在動態場景下節點基于歷史信息快速回復波束訓練幀，同時使用反向監聽策略減小同扇區節點的幀碰撞概率，并且通過時隙復用在Beacon和S-CAP時段并行發送控制幀和數據幀。理論分析表明了AD-MAC協議的有效性，仿真結果顯示：相較于ENLBT-MAC等典型協議，AD-MAC在靜態場景下的波束訓練開銷和節點平均入網時延分別降低了約21.84%和22.70%，在動態場景下上述二指標則分別減小了約18.7%和13.07%。
- 無線個域網 /
- 太赫茲 /
- MAC協議 /
- 定向
Abstract:
To reduce the beamforming training cost and network delay, make the best of Beacon and S-CAP sub-period in the existing Terahertz Wireless Personal Access Network (TWPAN) directional MAC protocols, an Adaptive Directional MAC (AD-MAC) protocol for TWPAN is proposed. AD-MAC adaptively uses the entire network cooperative beam training in a static scenario, and makes network nodes quickly respond to beam training frames based on historical information in a dynamic scenario. The reverse listening strategy is used to reduce the collision probability of same sector nodes. The control frame and data frame are transmitted simultaneously in the Beacon and S-CAP slot using time-slot reuse. Theoretical analysis verifies the effectiveness of AD-MAC. Also, simulation results show that, comparing with ENLBT-MAC, AD-MAC reduces about 21.84% of beamforming training cost and 22.70% of the average network delay in static scene, and reduces about 18.7% of beamforming training cost and 13.07% of the average network delay in dynamic scene.
- Wireless personal access networks /
- Terahertz /
- MAC protocols /
- Orientation

HTML全文

圖 1 波束訓練開銷比較

下載: 全尺寸圖片幻燈片

圖 2 平均入網時延比較

下載: 全尺寸圖片幻燈片

圖 3 MAC層吞吐量比較

下載: 全尺寸圖片幻燈片

圖 4 平均數據幀延遲比較

下載: 全尺寸圖片幻燈片

表 1 公共仿真參數

參數(單位)	數值
節點數目(個)	4,7,10,13,16
波束寬度(°)	5
傳輸速率(Gbps)	10
收發端距離	10
仿真時間	10
超幀周期	10
節點緩存(Mb)	10
發包間隔	0.08
數據幀長(bit)	64000

下載: 導出CSV

參考文獻(15)

GE Xiaohu, TU Song, MAO Guoqiang, et al. 5G ultra-dense cellular networks[J]. IEEE Wireless Communications, 2016, 23(1): 72–79. doi: 10.1109/MWC.2016.7422408

張健, 鄧賢進, 王成, 等. 太赫茲高速無線通信: 體制, 技術與驗證系統[J]. 太赫茲科學與電子信息學報, 2014, 12(1): 1–13. doi: 10.11805/TKYDA201401.0013

ZHANG Jian, DENG Xianjin, WANG Cheng, et al. Terahertz high speed wireless communications: Systems, techniques and demonstrations[J]. Journal of Terahertz Science and Electronic Information Technology, 2014, 12(1): 1–13. doi: 10.11805/TKYDA201401.0013

WANG Pu, JORNET J M, MALIK M G A, et al. Energy and spectrum-aware MAC protocol for perpetual wireless nanosensor networks in the terahertz band[J]. Ad Hoc Networks, 2013, 11(8): 2541–2555. doi: 10.1016/j.adhoc.2013.07.002

MUMTAZ S, JORNET J M, AULIN J, et al. Terahertz communication for vehicular networks[J]. IEEE Transactions on Vehicular Technology, 2017, 66(7): 5617–5625. doi: 10.1109/TVT.2017.2712878

YAO Xinwei and JORNET J M. TAB-MAC: Assisted beamforming MAC protocol for terahertz communication networks[J]. Nano Communication Networks, 2016, 9: 36–42. doi: 10.1016/j.nancom.2016.07.003

任智, 游磊, 呂昱輝, 等. 高時隙利用率太赫茲無線個域網公平接入?yún)f(xié)議[J]. 系統工程與電子技術, 2017, 39(10): 2339–2345. doi: 10.3969/j.issn.1001-506X.2017.10.27

REN Zhi, YOU Lei, Lü Yuhui, et al. High-slot-utilization and fair access protocol for terahertz wireless personal area networks[J]. Systems Engineering and Electronics, 2017, 39(10): 2339–2345. doi: 10.3969/j.issn.1001-506X.2017.10.27

CAO Jianling, WANG Min, CHEN Cong, et al. High-throughput low-delay MAC protocol for terahertz ultra-high data-rate wireless networks[J]. The Journal of China Universities of Posts and Telecommunications, 2016, 23(4): 17–24. doi: 10.1016/S1005-8885(16)60041-9

SHAHRAM M, MICHELE C W, and SAJAL K D. DRIH-MAC: A distributed receiver-initiated harvesting-aware MAC for nanonetworks[J]. IEEE Transactions on Molecular, Biological, and Multi-Scale Communications, 2015, 1(1): 97–110. doi: 10.1109/TMBMC.2015.2465519

KEN H, TORU T, MAKOTO Y, et al. Modifications to the draft TG3d ARD after the July 2014 meeting[OL]. https:mentor.ieee.org/802.15/dcn/14/15-14-0528-00-003d-modification-of-tg3d-ard-after-july-meeting.docx. 2014.

BILE P, SEBASTIAN P, and THOMAS K. Fast beam searching concept for indoor terahertz communications[C]. The 8th European Conference on Antennas and Propagation, Hague, Netherlands, 2014: 639–643. doi: 10.1109/EuCAP.2014.6901840.

WANG Junyi, ZHOU Lan, PYO C W, et al. Beam codebook based beamforming protocol for multi-Gbps millimeter-wave WPAN systems[J]. IEEE Journal on Selected Areas in Communications, 2009, 27(8): 1390–1399. doi: 10.1109/JSAC.2009.091009

IEEE Standard802.15.3c-2009. Part 15.3: Wireless Medium Access Control (MAC) and Physical Layer (PHY) specifications for high rate Wireless Personal Area Networks (WPANs) amendment 2: Millimeter-wave-based alternative physical layer extension[S]. IEEE Computer Society, 2009.

IEEE 802.11ad-2012. Part 11: Wireless LAN Medium Access Control (MAC) and Physical Layer (PHY) specifications amendment 3: enhancements for very high throughput in the 60 GHz band[S]. IEEE Computer Society, 2012.

AKHTAR A and ERGEN S C. Efficient network level beamforming training for IEEE 802.11 ad WLANs[C]. International Symposium Performance Evaluation of Computer and Telecommunication Systems, Chicago, USA, 2015: 1–6, doi: 10.1109/SPECTS.2015.7285289.

CHONG Han, TONG Wenqian, and WU Xinyi. A memory-assisted MAC protocol with angular-division-multiplexing in terahertz networks[C]. IEEE International Conference on Computer Communications and Networks, Paris, France, 2017: 1–6.
