多約束稀布矩形平面陣列天線的方向圖綜合

戴定成; 姚敏立; 賈維敏; 金偉; 張峰干

doi:10.11999/JEIT180262

多約束稀布矩形平面陣列天線的方向圖綜合

doi: 10.11999/JEIT180262 cstr: 32379.14.JEIT180262

1.
火箭軍工程大學作戰保障學院 ??西安 ??710025
2.
火箭軍工程大學核工程學院 ??西安 ??710025

基金項目: 國家自然科學基金(61179004, 61179005)

詳細信息

作者簡介:
戴定成：男，1991年生，博士生，研究方向為陣列天線的優化設計、陣列信號處理

姚敏立：男，1966年生，教授，博士生導師，主要研究方向為寬帶移動衛星通信、陣列信號處理

賈維敏：女，1971年生，教授，博士生導師，主要研究方向為陣列信號處理、寬帶移動衛星通信等

金偉：男，1984年生，博士，講師，主要研究方向為陣列信號處理、雷達數據處理

張峰干：男，1985年生，博士，講師，主要研究方向為陣列信號處理、陣列天線優化

通訊作者:
戴定成　ddc264@163.com

中圖分類號: TN821
計量
- 文章訪問數: 1871
- HTML全文瀏覽量: 695
- PDF下載量: 76
- 被引次數: 0
出版歷程
- 收稿日期: 2018-03-21
- 修回日期: 2018-09-14
- 網絡出版日期: 2018-10-08
- 刊出日期: 2019-01-01

Synthesis of Multi-constrained Sparse Rectangular Arrays

1.
School of Military Operation Support, Rocket Force University of Engineering, Xi’an 710025, China
2.
School of Nuclear Engineering, Rocket Force University of Engineering, Xi’an 710025, China

Funds: The National Natural Science Foundation of China (61179004, 61179005)

摘要

摘要:
針對多約束稀布矩形陣列天線的優化設計問題，該文提出一種新的矩陣映射(NMM)方法。首先，綜合考慮陣元的可分布范圍與可分布數量，重新定義陣元坐標矩陣的維數以提高陣元分布的自由度。其次，當坐標矩陣定義的陣元數量大于實際陣元數量時，建立選擇矩陣以確定各陣元的取舍。再次，針對現有矩陣映射方法無法完全避免不可行解的問題，構建了一種NMM方法，通過兩種不同的矩陣映射函數將多約束優化問題轉換為無約束優化問題。最后進行仿真對比實驗，實驗結果證明了算法的有效性。
- 陣列天線 /
- 稀布平面陣列 /
- 約束優化 /
- 旁瓣電平
Abstract:
A Novel Matrix Mapping (NMM) method is proposed for the synthesis of sparse rectangular arrays with multiple constraints. Firstly, the sizes of element coordinate matrices are resized to improve the Degree Of Freedom (DOF) of elements by taking account of both placeable number and distributable range of elements. Then, a selection matrix is established to determine which elements should be turned off when the coordinate matrices should be thinned. By establishing two different mapping functions, a NMM method is presented to overcome the drawbacks of existing methods in terms of flexibility and effectiveness. Finally, comparison experiments are conducted to verify the effectiveness of the proposed method. The numerical validation points out that the proposed method outperforms the existing methods in the design of sparse rectangular arrays.
- Antenna arrays /
- Sparse planar arrays /
- Constrained optimization /
- Sidelobe level

HTML全文

圖 1 稀布矩形平面陣列天線結構圖

下載: 全尺寸圖片幻燈片

圖 2 矩陣映射法坐標矩陣維數示意圖

下載: 全尺寸圖片幻燈片

圖 3 矩陣映射法陣元位置示意圖

下載: 全尺寸圖片幻燈片

圖 4 矩陣映射法陣元位置示意圖

下載: 全尺寸圖片幻燈片

圖 5 T₂映射原理

下載: 全尺寸圖片幻燈片

圖 6 實驗1中A類仿真結果

下載: 全尺寸圖片幻燈片

圖 7 實驗1 B類仿真結果

下載: 全尺寸圖片幻燈片

圖 8 實驗1 A類實驗蒙特卡洛仿真迭代曲線對比

下載: 全尺寸圖片幻燈片

圖 9 實驗1 B類實驗蒙特卡洛仿真迭代曲線對比

下載: 全尺寸圖片幻燈片

圖 10 實驗2仿真結果

下載: 全尺寸圖片幻燈片

表 1 實驗1仿真結果對比(dB)

實驗類型	方法	最優值	最差值	均值	方差
A	NMM	–61.2178	–52.3630	–57.8363	4.0813
A	MMM	–53.5222	–50.4478	–51.9317	0.4940
B	NMM	–22.7591	–20.4355	–21.4060	0.1993
B	MMM	–19.1338	–17.9751	–18.5972	0.0875

下載: 導出CSV

表 2 算法運算效率對比

實驗1	方法	平均運行時間	平均內存峰值使用量(kB)	平均適應值(dB)	可行解占比(%)
A	MMM算法	247.614	620	–51.9317	44
A	本文方法	283.704	620	–57.8363	100
B	MMM算法	20472.744	904	–18.5972	60
B	本文方法	25823.421	984	–21.4060	100

下載: 導出CSV

表 3 實驗2仿真結果對比(dB)

實驗類型	方法	最優值	最差值	均值	方差
A	NMM	–60.2701	–50.6686	–56.0144	4.7592
B	NMM	–22.0422	–20.1613	–20.9181	0.2303

下載: 導出CSV

參考文獻(18)

DARVISH A and EBRAHIMZADEH A. Improved fruit-fly optimization algorithm and its applications in antenna arrays synthesis[J]. IEEE Transactions on Antennas & Propagation, 2018, 66(4): 1756–1766. doi: 10.1109/TAP.2018.2800695

ZHANG Xuejing, HE Zishu, LIAO Bin, et al. Pattern synthesis for arbitrary arrays via weight vector orthogonal decomposition[J]. IEEE Transactions on Signal Processing, 2018, 66(5): 1286–1299. doi: 10.1109/TSP.2017.2787143

ZHANG Xuejing, HE Zishu, LIAO Bin, et al. Pattern synthesis with multi-point accurate array response control[J]. IEEE Transactions on Antennas & Propagation, 2017, 65(8): 4075–4088. doi: 10.1109/TAP.2017.2718582

LI Xun, DUAN Baoyan, ZHOU Jinzhu, et al. Planar array synthesis for optimal microwave power transmission with multiple constraints[J]. IEEE Antennas & Wireless Propagation Letters, 2017, 16: 70–73. doi: 10.1109/LAWP.2016.2555980

LEEPER D. Isophoric arrays—Massively thinned phased arrays with well-controlled sidelobes[J]. IEEE Transactions on Antennas & Propagation, 1999, 47(12): 1825–1835. doi: 10.1109/8.817659

KEIZER W. Synthesis of thinned planar circular and square arrays using density tapering[J]. IEEE Transactions on Antennas & Propagation, 2014, 62(4): 1555–1563. doi: 10.1109/TAP.2013.2267194

李龍軍, 王布宏, 夏春和. 基于改進迭代FFT算法的均勻線陣交錯稀疏布陣方法[J]. 電子與信息學報, 2016, 38(4): 970–977. doi: 10.11999/JEIT150749

LI Longjun, WANG Buhong, and XIA Chunhe. Interleaved thinned linear arrays based on modified iterative FFT technique[J]. Journal of Electronics &Information Technology, 2016, 38(4): 970–977. doi: 10.11999/JEIT150749

ZHANG Li, JIAO Yongchang, WENG Zibin, et al. Design of planar thinned arrays using a Boolean differential evolution algorithm[J]. IET Microwaves, Antennas & Propagation, 2010, 4(12): 2172–2178. doi: 10.1049/iet-map.2009.0630

DONELLI M, MARTINI A, and MASSA A. A hybrid approach based on PSO and Hadamard difference sets for the synthesis of square thinned arrays[J]. IEEE Transactions on Antennas & Propagation, 2009, 57(8): 2491–2495. doi: 10.1109/TAP.2009.2024570

YAN Fei, YANG Peng, YANG Feng, et al. Synthesis of planar sparse arrays by perturbed compressive sampling framework[J]. IET Microwaves Antennas & Propagation, 2016, 10(11): 1146–1153. doi: 10.1049/iet-map.2015.0775

VIANI F, OLIVERI G, and MASSA A. Compressive sensing pattern matching techniques for synthesizing planar sparse arrays[J]. IEEE Transactions on Antennas & Propagation, 2013, 61(9): 4577–4587. doi: 10.1109/TAP.2013.2267195

于波, 陳客松, 朱盼, 等. 稀布圓陣的降維優化方法[J]. 電子與信息學報, 2014, 36(2): 476–481. doi: 10.3724/SP.J.1146.2013.00526

YU Bo, CHEN Kesong, Zhu Pan, et al. An optimum method of sparse concentric rings array based on dimensionality reduction[J]. Journal of Electronics &Information Technology, 2014, 36(2): 476–481. doi: 10.3724/SP.J.1146.2013.00526

CHEN Kesong, YUN Xiaohua, HE Zishu, et al. Synthesis of sparse planar arrays using modified real genetic algorithm[J]. IEEE Transactions on Antennas & Propagation, 2007, 55(4): 1067–1073. doi: 10.1109/TAP.2007.893375

LIU Heng, ZHAO Hongwei, LI Weimei, et al. Synthesis of sparse planar arrays using matrix mapping and differential evolution[J]. IEEE Antennas & Wireless Propagation Letters, 2016, 15: 1905–1908. doi: 10.1109/LAWP.2016.2542882

LIN Zhiqiang, JIA Weimin, YAO Minli, et al. Synthesis of sparse linear arrays using vector mapping and simultaneous perturbation stochastic approximation[J]. IEEE Antennas & Wireless Propagation Letters, 2012, 11: 220–223. doi: 10.1109/LAWP.2012.2188266

賈維敏, 林志強, 姚敏立, 等. 一種多約束稀布線陣的天線綜合方法[J]. 電子學報, 2013, 41(5): 926–930. doi: 10.3969/j.issn.0372-2112.2013.05.015

JIA Weimin, LIN Zhiqiang, YAO Minli, et al. A synthesis technique for linear sparse arrays with multiple constraints[J]. Acta Electronica Sinica, 2013, 41(5): 926–930. doi: 10.3969/j.issn.0372-2112.2013.05.015

DAI Dingcheng, YAO Minli, MA Hongguang, et al. An effective approach for the synthesis of uniformly excited large linear sparse array[J]. IEEE Antennas & Wireless Propagation Letters, 2018, 17(3): 377–380. doi: 10.1109/LAWP.2018.2790907

ZHANG Fenggan, JIA Weimin, and YAO Minli. Linear aperiodic array synthesis using differential evolution algorithm[J]. IEEE Antennas & Wireless Propagation Letters, 2013, 12(9): 797–800. doi: 10.1109/LAWP.2013.2270930
