基于FPGA的快速差頻測量系統設計

王粉花,  謝斌,  王華濤

王粉花, 謝斌, 王華濤. 基于FPGA的快速差頻測量系統設計[J]. 電子與信息學報, 2019, 41(1): 187-194. doi: 10.11999/JEIT180243
引用本文: 王粉花, 謝斌, 王華濤. 基于FPGA的快速差頻測量系統設計[J]. 電子與信息學報, 2019, 41(1): 187-194. doi: 10.11999/JEIT180243
Fenhua WANG, Bin XIE, Huatao WANG. Design of Fast Differential Frequency Measurement System Based on FPGA[J]. Journal of Electronics & Information Technology, 2019, 41(1): 187-194. doi: 10.11999/JEIT180243
Citation: Fenhua WANG, Bin XIE, Huatao WANG. Design of Fast Differential Frequency Measurement System Based on FPGA[J]. Journal of Electronics & Information Technology, 2019, 41(1): 187-194. doi: 10.11999/JEIT180243

基于FPGA的快速差頻測量系統設計

doi: 10.11999/JEIT180243 cstr: 32379.14.JEIT180243

  • 北京科技大學自動化學院 ??北京 ??100083

基金項目: 國家自然科學基金(61672094)
詳細信息
    作者簡介:

    王粉花：女，1971年生，副教授，研究方向為智能信息處理、模式識別及嵌入式技術

    謝斌：男，1995年生，碩士生，研究方向為智能檢測技術與設備

    王華濤：男，1993年生，碩士生，研究方向為智能檢測技術與設備

    通訊作者:

    王粉花　wangfenhua@ustb.edu.cn

  • 中圖分類號: TP274; TH89

Design of Fast Differential Frequency Measurement System Based on FPGA

  • School of Automation, University of Science and Technology Beijing, Beijing 100083, China

Funds: The National Natural Science Foundation of China (61672094)
  • 摘要:

    針對電子測量中如何對基頻較高而頻率變化值較小的動態信號進行高精度頻率測量的問題，引入了差頻測量的方法。該文提出一種新型的動態可調的多級差頻電路結構，設計了基于FPGA的快速差頻測量系統，通過在FPGA上設計快速傅里葉變換(FFT)算法來實現系統的數據處理功能。仿真結果表明，在滿足差頻條件的基礎上，合理設計多級差頻電路的結構能夠實現高精度頻率測量，在進行信號頻譜分析時能得到較為準確的結果。實驗驗證了該測量系統能夠實現快速FFT運算，相比于MATLAB軟件平臺，在數據處理效率上有明顯的優勢；同時在性能指標滿足數據采集要求的前提下，系統可動態調整FFT模型的結構來適應不同規模點數FFT運算的需求。

    Abstract:

    For the problem of high precision frequency measurement of dynamic signals with high fundamental frequency and small frequency change value in electronic measurement, a method of differential frequency measurement is introduced. A novel dynamic adjustable multi-stage frequency-difference circuit structure is proposed. The fast differential frequency measurement system based on FPGA is used to design the Fast Fourier Transform (FFT) algorithm on the FPGA to realize the data processing function of the system. The simulation and experimental results show that the structure of the multi-stage differential frequency circuit can be designed with high precision frequency, and the result can be obtained when the spectrum analysis is carried out. The system can realize the fast FFT operation. Compared with the MATLAB software platform, the system has obvious advantages in the efficiency of data processing. The structure of the FFT model can be dynamically adjusted to meet the requirements of FFT operation of different scale points, and the system performance index can meet the requirements of data acquisition system.

    • HTML全文

  • 圖  1  多級差頻電路結構

    圖  2  4級差頻電路仿真

    圖  3  4級差頻電路仿真結果

    圖  4  快速差頻測量系統原理框圖

    圖  5  乒乓傳輸數據控制流程圖

    圖  6  蝶形運算單元

    圖  7  并行FFT模塊框圖

    圖  8  FPGA上FFT運算頻譜圖

    圖  9  MATLAB上FFT運算頻譜圖

    表  1  差頻電路實驗測量數據

    fin=35.00005 kHz理論頻差(kHz)實測頻差(kHz)絕對誤差(Hz)相對誤差(%)
    fck/finfck (kHz)
    0.660011 23.100414 11.899636 11.200800 698.836 5.872751
    0.663334 23.216715 11.783335 11.433400 349.935 2.969745
    0.666668 23.333414 11.666636 11.666700 0.064 0.000549
    0.670002 23.450113 11.549937 11.549900 0.037 0.000320
    0.673337 23.566816 11.433234 11.433200 0.034 0.000297
    0.733337 25.666827 9.333223 9.333200 0.023 0.000246
    0.800003 28.000136 6.999914 6.999600 0.314 0.004486
    0.866672 30.333548 4.666502 4.666500 0.002 0.000043
    0.933337 32.666858 2.333192 2.333200 0.008 0.000343
    0.980003 34.300166 0.699884 0.699890 0.006 0.000857
    0.990003 34.650168 0.349882 0.349894 0.012 0.003430
    1.000003 35.000172 0.000122 0.000132 0.010 8.196721
    1.020004 35.700174 0.700124 0.700109 0.015 0.002142
    1.200004 42.000206 7.000156 7.000034 0.122 0.001743
    1.400005 49.000243 14.000193 14.000069 0.124 0.000886
    1.600006 56.000277 21.000227 21.000000 0.227 0.001081
    1.800007 63.000318 28.000268 28.000140 0.128 0.000457
    1.980007 69.300355 34.300305 34.300280 0.025 0.000073
    1.990099 69.653570 34.653520 34.530000 123.520 0.356443
    2.000010 70.000463 35.000413 34.640000 360.410 1.029739
    2.010011 70.350470 35.350420 34.880000 470.420 1.330734
    2.020011 70.700478 35.700428 35.000000 700.428 1.961960
    下載: 導出CSV

    表  2  差頻測量系統和MATLAB數據處理效率

    點數采樣頻率/待測頻率分辨率(Hz)相對誤差(%)時間消耗
    差頻測量系統t1×10–6 (s)MATALB t2 (s)t2/t1
    641.58.4465.121.79110.072840645.41
    2.514.062.771.79110.072940701.25
    3.519.694.591.79120.072940698.97
    1281.54.2271.113.18210.082425894.85
    2.57.031.443.18230.082525924.65
    3.59.842.513.19210.082425813.73
    2561.52.1168.875.46610.092716959.08
    2.53.521.245.46540.092816979.54
    3.54.921.355.46570.092816978.61
    5121.51.0571.1210.93510.10849913.03
    2.51.761.0210.93320.10839905.61
    3.52.461.1210.94110.10849907.60
    下載: 導出CSV

    表  3  量化位數對FFT的影響

    量化位數信噪比(dB)
    1627.10
    3267.83
    6498.43
    下載: 導出CSV

    表  4  差頻測量系統測量誤差及分辨率

    ft (kHz)閘門個數計數器計數值fck–fin (Hz)fin (Hz)相對誤差(×10–6)分辨率(×10–6)
    170.00039200079993712000.26227170000.77772.28085.81575
    170.20039180079991651800.28240170200.75762.15985.81619
    170.40039160079997471600.13460170400.90543.02465.81629
    170.60038140079981351400.39997170600.64181.53455.81673
    170.80039120079989311200.22338170800.81662.49785.81521
    171.00039100079876471001.59909170999.44095.55025.81764
    下載: 導出CSV
  • 李存龍, 陳偉民, 章鵬, 等. 采用差頻技術的正弦調制型微波測距系統研究[J]. 電子測量與儀器學報, 2014, 28(1): 17–21. doi: 10.13382/j.jemi.2014.01.003

    LI Cunlong, CHEN Weimin, Zhang Peng, et al. Research on sinusoidal modulation microwave ranging system based on heterodyne technique[J]. Journal of Electronic Measurement and Instrument, 2014, 28(1): 17–21. doi: 10.13382/j.jemi.2014.01.003
    馮冠平. 諧振傳感理論及器件[M]. 北京: 清華大學出版社, 2008: 35–40.

    FENG Guanping. Resonant Sensor Theory and Device[M]. Beijing: Tsinghua University Press, 2008: 35–40.
    樊養余, 李利品, 黨瑞榮. 基于隨機共振的任意大頻率微弱信號檢測方法研究[J]. 儀器儀表學報, 2013, 34(3): 566–572. doi: 10.3969/j.issn.0254-3087.2013.03.013

    FAN Yangyu, LI Lipin, and Dang Ruirong. Study on high frequency weak signal detection method based on stochastic resonance[J]. Chinese Journal of Scientific Instrument, 2013, 34(3): 566–572. doi: 10.3969/j.issn.0254-3087.2013.03.013
    王盟盟, 董瑞芳, 項曉, 等. 基于外差檢測原理的絕對測距性能理論研究[J]. 儀器儀表學報, 2016, 37(8): 1861–1868. doi: 10.3969/j.issn.0254-3087.2016.08.018

    WANG Mengmeng, DONG Ruifang, XIANG Xiao, et al. Theoretical research for absolute distance measurement based on heterodyne detection principle[J]. Chinese Journal of Scientific Instrument, 2016, 37(8): 1861–1868. doi: 10.3969/j.issn.0254-3087.2016.08.018
    劉婉茹, 葉建芳, 孫一萍. 基于Multisim乘法器混頻電路的仿真研究[J]. 微型電腦應用, 2016, 32(10): 48–50. doi: 10.3969/j.issn.1007-757X.2016.10.014

    LIU Wanru, YE Jianfang, and SUN Yiping. Simulation and study of multiplier mixer circuit based on multism[J]. Microcomputer Applications, 2016, 32(10): 48–50. doi: 10.3969/j.issn.1007-757X.2016.10.014
    LIN Ningning, MENG Xiaofeng, and NIE Jing. Dew point calibration system using a quartz crystal sensor with a differential frequency method[J]. Sensors, 2016, 16(11): 1944–1948. doi: 10.3390/s16111944
    程坤, 黃慶安, 秦明, 等. 一種簡單實用的差頻方法原理研究及應用[J]. 電子器件, 2006, 29(2): 473–475. doi: 10.3969/j.issn.1005-9490.2006.02.046

    CHENG Kun, HUANG Qingan, QIN Ming, et al. Simple method of improving the differential frequency using D flip-flop[J]. Chinese Journal of Electron Devices, 2006, 29(2): 473–475. doi: 10.3969/j.issn.1005-9490.2006.02.046
    徐洋洋. 基于FPGA的多通道大容量FIFO設計[J]. 電子測量技術, 2017, 40(8): 193–197. doi: 10.19651/j.cnki.emt.2017.08.043

    XU Yangyang. Design of multi-channel FIFO with mass storage facility based on FPGA[J]. Electronic Measurement Technology, 2017, 40(8): 193–197. doi: 10.19651/j.cnki.emt.2017.08.043
    梁晨, 趙邦信. 基于FPGA和DDR3 SDRAM的大規模查找表設計與實現[J]. 電子器件, 2017, 40(4): 849–855. doi: 10.3969/j.issn.1005-9490.2017.04.014

    LIANG Chen and ZHAO Bangxin. Design of large-scale look-up table based on FPGA and DDR3 SDRAM[J]. Chinese Journal of Electron Devices, 2017, 40(4): 849–855. doi: 10.3969/j.issn.1005-9490.2017.04.014
    梁華國, 孫紅云, 孫駿, 等. 一種基于FPGA的微處理器軟錯誤敏感性分析方法[J]. 電子與信息學報, 2017, 39(1): 245–249. doi: 10.11999/JEIT.160225

    LIANG Huaguo, SUN Hongyun, SUN Jun, et al. FPGA-based soft error sensitivity analysis method for microprocessor[J]. Journal of Electronics &Information Technology, 2017, 39(1): 245–249. doi: 10.11999/JEIT.160225
    WANG Jiawei, YU Le, and YANG Haigang. FPGA based multi-channel variable-length FFT implementation[J]. Journal of Terahertz Science and Electronic Information Technology, 2017, 15(3): 469–474. doi: 10.11805/TKYDA201703.0469
    陳杰男, 費超, 袁建生, 等. 超高速全并行快速傅里葉變換器[J]. 電子與信息學報, 2016, 38(9): 2410–2414. doi: 10.11999/JEIT160036

    CHEN Jienan, FEI Chao, YUAN Jiansheng, et al. An ultra-high-speed fully-parallel fast fourier transform design[J]. Journal of Electronics &Information Technology, 2016, 38(9): 2410–2414. doi: 10.11999/JEIT160036
    CHEN Jiyang, YUAN Wulei, YUAN Xipeng, et al. Configurable floating-point FFT accelerator on FPGA based multiple-rotation CORDIC[J]. Chinese Journal of Electronics, 2016, 25(6): 1063–1070. doi: 10.1049/cje.2016.08.002
    黃志洪, 李威, 楊立群, 等. 一種基于與非錐簇架構 FPGA 輸入交叉互連設計優化方法[J]. 電子與信息學報, 2016, 38(9): 2397–2404. doi: 10.11999/JEIT151216

    HUANG Zhihong, LI Wei, YANG Liqun, et al. An input crossbar optimization method for and-inveter cone based FPGA[J]. Journal of Electronics &Information Technology, 2016, 38(9): 2397–2404. doi: 10.11999/JEIT151216
    蘇斌, 劉暢, 潘志剛. 基于FPGA的高速浮點FFT/IFFT處理器設計與實現[J]. 中國科學院大學學報, 2015, 32(2): 259–263. doi: 10.7523/j.issn.2095-6134.2015.02.016

    SU Bin, LIU Chang, and PAN Zhigang. Design and implementation on high-speed floating points FFT processor based on FPGA[J]. Journal of University of Chinese Academy of Sciences, 2015, 32(2): 259–263. doi: 10.7523/j.issn.2095-6134.2015.02.016
    施佺, 韓賽飛, 黃新明, 等. 面向全同態加密的有限域FFT算法FPGA設計[J]. 電子與信息學報, 2018, 40(1): 57–62. doi: 10.11999/JEIT170312

    SHI Quan, HAN Saifei, HUANG Xinming, et al. Design of finite field FFT for fully homomorphic encryption based on FPGA[J]. Journal of Electronics &Information Technology, 2018, 40(1): 57–62. doi: 10.11999/JEIT170312
