云無線接入網絡高能效功率分配和波束成形聯合優化算法
doi: 10.11999/JEIT180218 cstr: 32379.14.JEIT180218
-
1.
南京郵電大學物聯網學院 ??南京 ??210023
-
2.
南京郵電大學通信與信息工程學院 ??南京 ??210023
基金項目: 江蘇省博士后基金(SBH17024)，江蘇省高校自然科學基金(15KJB510026)，江蘇省自然科學基金(BK20150866)，南京郵電大學引進人才基金(NY215046, NY217056)，國家自然科學基金(61801237, 61701255)
Energy Efficient Joint Power Allocation and Beamforming for Cloud Radio Access Network
-
1.
College of Internet of Things, Nanjing University of Posts and Telecommunications, Nanjing 210023, China
-
2.
College of Telecommunications & Information Engineering, Nanjing University of Posts and Telecommunications, Nanjing 210023, China
Funds: The Postdoctoral Fund of Jiangsu Province (SBH17024), The Jiangsu University of Natural Science Foundation (15KJB510026), The Natural Science Foundation of Jiangsu Province (BK20150866), The Introduction of Talent Fund of Nanjing University of Posts and Telecommunications (NY215046, NY217056), The National Natural Science Fundation of China (61801237, 61701255)
-
摘要: 針對云無線接入網絡(C-RAN)的資源分配問題，該文采用max-min公平準則作為優化準則，以C-RAN用戶的能量效率作為優化目標函數，在滿足最大發射功率和最小傳輸速率約束條件下，通過最大化最差鏈路的能量效率來實現用戶發射功率和無線遠端射頻單元(RRHs)波束成形向量的聯合優化。上述優化問題屬于非線性、分式規劃問題，為了方便求解，首先將原優化問題轉化為差分形式的優化問題，然后通過引入變量將差分形式的、非平滑優化問題轉化為平滑優化問題。最終，提出一種雙層迭代功率分配和波束成形算法。在仿真實驗中，將該文算法與傳統的非能效資源分配算法和能量效率最大化算法進行了比較，實驗結果證明該文算法在改進C-RAN能量效率和提高資源分配公平性方面的有效性。
-
關鍵詞:
- 云無線接入網絡 /
- 能量效率 /
- 功率分配 /
- 波束成形
Abstract: The resource allocation for Cloud Radio Access Network (C-RAN) is investigated. The max-min fairness criterion is used as the optimization criterion and the Energy Efficiency (EE) of C-RAN users is taken as the optimization objective function, by maximizing the EE of the worst link under the constraints of maximum transmit power and minimum transmit rate, the user transmit power and Remote Radio Heads (RRHs) beamforming vectors are jointly optimized. The above optimization problem belongs to the nonlinear and fractional programming problem. First, the original nonconvex optimization problem is transformed into an equivalent optimization problem in subtractive form. Then, by introducing a new variable, non-smooth equivalent optimization problem is transformed into a smooth optimization problem. Finally, a two-layer iterative power allocation and beamforming algorithm is proposed. The proposed algorithm is compared with traditional non-EE resource allocation algorithm and EE maximization algorithm. The experimental results show that the proposed algorithm is effective in improving the EE and the fairness of resource allocation.-
Key words:
- Cloud Radio Access Network (C-RAN) /
- Energy efficiency /
- Power allocation /
- Beamforming
-
表 1 Dinkelbach算法求解優化問題式(6)
外循環： (1)根據式(9)和式(10)計算 $P_{\rm lb}^{\rm{total}}$and $P_{\rm ub}^{\rm{total}}$，令 $t = 1$, ${\mathbb{I}^1} =( - \infty, $
$+\infty)$，選取 ${\lambda ^1} \in {\mathbb{I}^1}$，并設置迭代終止精度閾值 $\varepsilon > 0$(2)對于 ${\lambda ^t}$，通過求解優化問題式(6)得到 ${p_{n,t}}$和 ${{w}_{n,t}}$,n=1,2,···,N (3)計算 $F\left( {{\lambda ^t}} \right) = \mathop {\min }\limits_n \left\{ {{R_n}\left( {{p_{n,t}},{{w}_{n,t}}} \right) - \lambda P_n^{\rm{total}}\left( {{p_{n,t}}} \right)} \right\}$ (4)根據式 (11) 和式 (12)更新區間 $\left[ {\alpha _{\min }^t,\alpha _{\max }^t} \right]$ (5)更新 ${\mathbb{I}^{t + 1}} = {\mathbb{I}^t} \cap \left[ {\alpha _{\min }^t,\alpha _{\max }^t} \right]$，并選取 ${\lambda ^t} \in {\mathbb{I}^{t + 1}}$ (6)如果 $\left| {F\left( {{\lambda ^t}} \right)} \right| \ge \varepsilon $，令 $t = t + 1$ (7)重復步驟2～步驟6，直到 $\left| {F\left( {{\lambda ^t}} \right)} \right| < \varepsilon $
下載: 導出CSV
表 2 求解優化問題式(13)的步驟
內循環： (1)初始化 ${\alpha _n},{\beta _n},{\chi _n}$, ${{w}_{n}}$ (2)repeat (3)根據式(19)更新 ${p_n}$ 由式(21)、式(23)計算 ${\varGamma _n}$和 ${\phi _n}$，根據式(22)計算 ${{w}_{n}}$ (4) $\tau = \tau + 1$, 根據公式(26)，式(27)，式(28)更新 ${\alpha _n}\left( \tau \right)$, ${\beta _n}\left( \tau \right)$,
${\chi _n}\left( \tau \right)$(5)until ${\alpha _n}\left( {\tau + 1} \right)$, ${\beta _n}\left( {\tau + 1} \right)$, ${\chi _n}\left( {\tau + 1} \right)$收斂
下載: 導出CSV
-
ZHANG Deyu, CHEN Zhigang, CAI Lin, et al. Resource allocation for green cloud radio access networks with hybrid energy supplies[J]. IEEE Transactions on Vehicular Technology, 2018, 67(2): 1684–1697 doi: 10.1109/TVT.2017.2754273 DARIO P, ABOLFAZI H, and TUYEN X. Elastic resource utilization framework for high capacity and energy efficiency in cloud RAN[J]. IEEE Communications Magazine, 2016, 54(1): 26–32 doi: 10.1109/MCOM.2016.7378422 SAXENA N, ROY A, and KIM H. Traffic-aware cloud RAN: A key for green 5G networks[J]. IEEE Journal of Selected Areas in Communications, 2016, 34(4): 1010–1021 doi: 10.1109/JSAC.2016.2549438 YOON C and CHO D H. Energy efficient beamforming and power allocation in dynamic TDD based C-RAN system[J]. IEEE Communications Letters, 2015, 19(10): 1806–1809 doi: 10.1109/LCOMM.2015.2469294 LI Peirong and RENG Kaiten. Channel-aware resource allocation for energy-efficient cloud radio access networks under outage specifications[J]. IEEE Transactions on Wireless Communications, 2017, 16(11): 7389–7403 doi: 10.1109/TWC.2017.2748104 ZHAO Zhongyuan, PENG Mugen, DING Zhiguo, et al. Cluster content caching: an energy-efficient approach to improve quality of service in cloud[J]. IEEE Journal of Selected Areas in Communications, 2016, 34(5): 1207–1221 doi: 10.1109/JSAC.2016.2545384 PENG Mugen, WANG Yayun, DANG Tian, et al. Cost-efficient resource allocation in cloud radio access networks with heterogeneous fronthaul expenditures[J]. IEEE Transactions on Wireless Communications, 2017, 16(7): 4626–4638 doi: 10.1109/TWC.2017.2700841 DAI Binbin and YU Wei. Energy efficiency of downlink transmission strategies for cloud radio access networks[J]. IEEE Journal of Selected Areas in Communications, 2016, 34(4): 1037–1050 doi: 10.1109/JSAC.2016.2544459 YANG Jiaxin, CHAMPAGNE B, ZOU Yulong, et al. Centralized energy-efficient multiuser multiantenna relaying in next-generation radio access networks[J]. IEEE Transactions on Vehicular Technology, 2017, 66(9): 7913–7924 doi: 10.1109/TVT.2017.2677880 WANG Yong, MA Lin, XU Yubin, et al. Computationally efficient energy optimization for cloud radio access networks with CSI uncertainty[J]. IEEE Transactions on Communications, 2017, 65(12): 1–15 doi: 10.1109/TCOMM.2017.2737014 LI Yuzhou, SHENG Min, TAN W C, et al. Energy-efficient subcarrier assignment and power allocation in OFDM system with max-min fairness guarantees[J]. IEEE Transactions on Communications, 2015, 63(9): 3183–3195 doi: 10.1109/TCOMM.2015.2450724 NGUYEN T D and HAN Y. A proportional fairness algorithm with QoS Provision in downlink OFDM system[J]. IEEE Communications Letters, 2006, 10(11): 760–762 doi: 10.1109/LCOMM.2006.060750 CROUZEIX J P, FERLAND J A, and SCHAIBLE S. Algorithm for generalized fractional programs[J]. Journal of Optimization Theory and Applications, 1985, 47(1): 35–49 doi: 10.1007/BF00941314 CHEN H J, SCHAIBLE S, and SHEN R L. Generic algorithm for generalized fractional programming[J]. Journal of Optimization Theory and Applications, 2009, 141(1): 93–105 doi: 10.1007/s10957-008-9499-7 BOYD S and VANDENBERGHE L. Convex Optimization[M]. Cambridge, England: Cambridge University Press, 2004: 215–223. VENTURINO L, PRASSAD N, and WANG Xiaodong. Coordinated liner beamforming in downlink muti-cell wireless networks[J]. IEEE Transactions on Wierless Communicaitons, 2010, 9(4): 1451–1461 doi: 10.1109/TWC.2010.04.090553 BOYD S, XIAO Lin, and MUTAPCIC A. Subgradient Methods[OL]. http://101.96.10.63/web.mit.edu/6.976/www/notes/subgrad_method.pdf, 2003. PENG Mugen, XIANG Hongyu, Chen Yangyuan, et al. Inter-tier interfernce suppression in heterogeneous cloud radio access networks[J]. IEEE Access, 2015, 3: 2441–2455 doi: 10.1109/ACCESS.2015.2497268 -
