基于軟件定義網絡的服務器集群負載均衡技術研究

于天放; 芮蘭蘭; 邱雪松

doi:10.11999/JEIT180207

基于軟件定義網絡的服務器集群負載均衡技術研究

doi: 10.11999/JEIT180207 cstr: 32379.14.JEIT180207

北京郵電大學 網絡與交換技術國家重點實驗室 ??北京 ??100876

基金項目: 國家自然科學基金(61702048, 61302078)

詳細信息

作者簡介:
于天放：男，1980年生，博士生，研究方向?yàn)檐浖x網絡

芮蘭蘭：女，1979年生，博士，副教授，研究方向?yàn)榫W(wǎng)絡和業務質量管理、泛在網絡、大數據等

邱雪松：男，1973年生，博士，教授，研究方向?yàn)榫W(wǎng)絡管理與通信軟件

通訊作者:
于天放　 m2015010@foxmail.com

中圖分類號: TP393
計量
- 文章訪問數: 1847
- HTML全文瀏覽量: 778
- PDF下載量: 56
- 被引次數: 0
出版歷程
- 收稿日期: 2018-02-28
- 修回日期: 2018-08-13
- 網絡出版日期: 2018-08-22
- 刊出日期: 2018-12-01

Research on SDN-based Load Balancing Technology of Server Cluster

State Key Laboratory of Networking and Switching Technology, Beijing University of Posts and Telecommunications, Beijing 100876, China

Funds: The National Natural Science Foundation of China (61702048, 61302078)

摘要

摘要: 在當前的網絡體系結構下，采用硬件系統實現服務器集群負載均衡存在著獲取負載節點狀態困難、流量導向方式復雜等制約因素，不利于提升服務器集群的伸縮性和服務性能。針對此問題，該文提出一種基于軟件定義網絡(SDN)的負載均衡機制(SDNLB)。該機制借助SDN具有的集中式控制和流量靈活調度優勢，利用SNMP協議和OpenFlow協議對服務器的運行狀態和全局網絡負載信息進行實時監測，并通過權值計算的方式選擇出權重最高的服務器作為流處理的目標服務器，在此基礎上，采用最優轉發路徑算法進行流量調度，從而達到提高服務器集群的利用率與處理性能的目的。搭建了實驗平臺對SDNLB的性能進行仿真測試，實驗結果表明：在相同的網絡負載條件下，SDNLB與其他負載均衡算法相比，能夠有效地降低服務器集群的負載，并能夠顯著提高網絡吞吐量和帶寬利用率，縮短流的完成時間和平均時延。
- 軟件定義網絡 /
- OpenFlow /
- 服務器集群 /
- 負載均衡 /
- 流量工程
Abstract: Under the present network architecture, it is disadvantageous for scalability and service performance of server cluster to adopt hardware systems to realize load balancing of server cluster, because there are some restriction factors in such a method, including the difficulty of acquiring load nodes status and the complexity of redirecting traffic, etc. To solve the problem, a Load Balancing mechanism based on Software-Defined Networking (SDNLB) is proposed. With superiorities of SDN such as centralized control and flexible traffic scheduling, SDNLB monitors run states of servers and overall network load information by means of SNMP protocol and OpenFlow protocol in real time, and chooses the highest weight server as target server aiming for processing coming flows through the way of weight value calculation. On this basis, SDNLB takes full advantage of the optimal forwarding path algorithm to carry on traffic scheduling, and achieves the goal that raises utilization rate and processing performance of server cluster. An experiment platform is built to carry out simulation tests for overall performance of SDNLB, and the experiment results show that under the same network load conditions, SDNLB lowers effectively loads of server cluster, noticeably raises network throughput and bandwidth utilization, and reduces finish time and average latency of flows, compared with other load balancing algorithms.
- Software-Defined Networking (SDN) /
- OpenFlow /
- Server cluster /
- Load balancing /
- Traffic engineering

HTML全文

圖 1 服務器性能監測的主要過程

下載: 全尺寸圖片幻燈片

圖 2 不同算法的網絡性能指標對比

下載: 全尺寸圖片幻燈片

圖 3 不同算法的流完成時間、平均時延對比

下載: 全尺寸圖片幻燈片

表 1 服務器主要性能指標

指標類型	指標值	狀態
CPU利用率	非空閑任務占用比小于70%	良好
	70%~85%	過高
	90%以上	很差
內存訪問	沒有頁交換	良好
	每個CPU每秒10個頁交換	過高
	更多的頁交換	很差
磁盤I/O	活動時間百分比小于30%	良好
	30%~45%	過高
	50%以上	很差

下載: 導出CSV

表 2 流轉發過程

　算法1　SDNLB最優轉發路徑算法

　輸入：Topology_View　/*當前網絡拓?fù)湟晥D*/

　　　　Link_Load　/*網絡鏈路負載信息*/

　　　　Target-Server　/*目標服務器*/

　　　　Flow　/*新到達的流*/

　輸出：R /*最優轉發路徑*/

　(1) implement logical loopless processing

　(2) destination=target-server

　(3) create a graph that meets bandwidth demand of flow

　(4) A=[ ]

　(5) A[0]= Dijkstra(graph, source, destination)

　(6) B=[ ]

　(7) for i: 1 to K do

　(8)　for j: 0 to size(A[i –1])–1 do

　(9)　 spur=A[i –1].node( j)

　(10)　　root=A[i –1].nodes(0, j)

　(11)　　for path in A do

　(12)　　　if root==path.nodes(0, j) do

　(13)　　　　remove path.nodes(j, j+1)

　(14)　　　end if

　(15)　　end for

　(16)　　spurpath=Dijkstra(graph, spur, destination)

　(17)　　entirepath=root+spurpath

　(18)　　if entirepath not in B do

　(19)　　　 B.add(entirepath)

　(20)　　end if

　(21) recover those removed edges

　(22)　end for

　(23)　if B.length==0 do

　(24)　　break

　(25)　else do

　(26)　　 B.sort()

　(27)　　 A[i]=B[0]

　(28)　　 B.delete(B[0])

　(29)　end if

　(30) end for

　(31) if A.length==1 do

　(32)　 R=A[0]

　(33) else do

　(34) determine R by choosing a path from list A.Bandwidth utilization of the path should be minimum

　(35)　end if

　(36)　return R

下載: 導出CSV

表 4 服務器平均負載

服務器編號	2	4	6	8	10	12	14	16
SDNLB	0.71	0.71	0.70	0.71	0.68	0.69	0.73	0.72
E-Dijkstra	0.75	0.74	0.75	0.76	0.74	0.74	0.76	0.77
GFF	0.74	0.75	0.78	0.78	0.77	0.74	0.77	0.78
ECMP	0.86	0.86	0.87	0.89	0.87	0.87	0.85	0.87

下載: 導出CSV

表 3 CPU平均利用率(%)

服務器編號	2	4	6	8	10	12	14	16
SDNLB	22.65	22.53	22.43	22.31	22.20	22.58	22.48	22.11
E-Dijkstra	23.39	23.34	23.32	23.29	23.26	23.50	23.36	23.29
GFF	23.40	23.46	23.45	23.48	23.46	23.37	23.34	23.54
ECMP	23.79	23.70	23.66	23.60	23.59	23.75	23.68	23.56

下載: 導出CSV

參考文獻(17)

GHOMI E, RAHMANI A, and QADER N. Load-balancing algorithms in cloud computing: A survey[J]. Journal of Network and Computer Applications, 2017, 88(12): 50–71 doi: 10.1016/j.jnca.2017.04.007

SHARMA G and BUSCH C. A load balanced directory for distributed shared memory objects[J]. Journal of Parallel and Distributed Computing, 2015, 78(4): 6–24 doi: 10.1016/j.jpdc.2015.02.002

ILCHOL P, QIAO Baiyou, SHEN Muchuan, et al. An efficient load balancing approach for N-hierarchical web server cluster[J]. Wuhan University Journal of Natural Sciences, 2015, 20(6): 537–542 doi: 10.1007/s11859-015-1130-9

YANG Juipin. Elastic load balancing using self-adaptive replication management[J]. IEEE Access, 2017, 5(99): 7495–7504 doi: 10.1109/ACCESS.2016.2631490

SHEIKHI S and BABAMIR S. A predictive framework for load balancing clustered web servers[J]. The Journal of Supercomputing, 2016, 72(2): 588–611 doi: 10.1007/s11227-015-1584-8

MAO Qilin and SHEN Weikang. A load balancing method based on SDN[C]. The 7th International Conference on Measuring Technology and Mechatronics Automation, Nanchang, China, 2015: 18–21.

TRESTIAN R, KATRINIS K, and MUNTEAN G. OFLoad: An OpenFlow-based dynamic load balancing strategy for datacenter networks[J]. IEEE Transactions on Network and Service Management, 2017, 14(4): 792–803 doi: 10.1109/TNSM.2017.2758402

李龍, 付斌章, 陳明宇, 等. Nimble: 一種適用于OpenFlow網絡的快速流調度策略[J]. 計算機學報, 2015, 38(5): 1056–1068 doi: 10.3724/SP.J.1016.2015.01056

LI Long, FU Binzhang, CHEN Mingyu, et al. Nimble: A fast flow scheduling strategy for OpenFlow networks[J]. Chinese Journal of Computers, 2015, 38(5): 1056–1068 doi: 10.3724/SP.J.1016.2015.01056

AL-FARES M, RADHAKRISHNAN S, RAGHAVAN B, et al. Hedera: Dynamic flow scheduling for data center networks[C]. NSDI’10 Proceedings of the 7th USENIX conference on networked systems design and implementation, San Jose, USA, 2010: 281–296.

蔡岳平, 王昌平. 軟件定義數據中心網絡混合路由機制[J]. 通信學報, 2016, 37(4): 44–52 doi: 10.11959/j.issn.1000-436x.2016071

CAI Yueping and WANG Changping. Software defined data center network with hybrid routing[J]. Journal on Communications, 2016, 37(4): 44–52 doi: 10.11959/j.issn.1000-436x.2016071

覃匡宇, 黃傳河, 劉柯威, 等. 基于多路廣播樹的SDN多路徑路由算法[J]. 計算機科學, 2018, 45(1): 211–215 doi: 10.11896/j.issn.1002-137X.2018.01.037

TAN Kuangyu, HUANG Chuanhe, LIU Kewei, et al. Multipath routing algorithm in software defined networking based on multipath broadcast tree[J]. Computer Science, 2018, 45(1): 211–215 doi: 10.11896/j.issn.1002-137X.2018.01.037

LIAO Lingxia and LEUNG VC. LLDP based link latency monitoring in software defined networks[C]. The 12th International Conference on Network and Service Management, Montreal, Canada, 2016: 330–335.

RUBIN I and ZHANG Runhe. Max-min utility fair flow management for networks with route diversity[J]. International Journal of Network Management, 2010, 20(6): 361–381 doi: 10.1002/nem.740

YEN J Y. Finding the K shortest loopless paths in a network[J]. Management Science, 1971, 17(11): 712–716 doi: 10.1287/mnsc.17.11.712

JIANG J R, HUANG H W, LIAO J H, et al. Extending Dijkstra’s shortest path algorithm for software defined networking[C]. The 16th Asia-Pacific Network Operations and Management Symposium, Hsinchu, China, 2014: 1–4.

ZHANG Zhe, BOCKELMAN B, CARDER D, et al. Lark: An effective approach for software-defined networking in high throughput computing clusters[J]. Future Generation Computer Systems, 2017, 72(7): 105–117 doi: 10.1016/j.future.2016.03.010

CHEN Yingying, JAIN S, ADHIKARI V, et al. A first look at inter-data center traffic characteristics via Yahoo! datasets[C]. IEEE INFOCOM, Shanghai, China, 2011: 1620–1628.
